CHAPTER
24
ELECTRICAL POWER
CESSNA AIRCRAFT COMPANY
MAINTENANCE MANUAL
RECORD OF TEMPORARY REVISIONS

Temporary Revision
Page Number Issue Date By Date Removed By
Number
CESSNA®
MODEL 172 (SERIES 1996 AND ON)
ILLUSTRATED PARTS CATALOG
CHAPTER/ NUMBER
SECTION/ START PAGE OF
SUBJECT OR FIGURE PAGES DATE
24 - TITLE 1
24 - LIST OF EFFECTIVE PAGES Page 1 1 Jul 7, 2022
24 - TABLE OF CONTENTS Page 1 1 Jul 7, 2022
24-20-00 Figure 01 4 Jul 7, 2022
24-34-00 Figure 01 4 Jul 7, 2022
24-34-00 Figure 02 3 Jul 7, 2022
24-60-00 Figure 01 5 Jul 7, 2022
24-60-01 Figure 01 3 Jul 7, 2022
24-61-00 Figure 01 7 Jul 7, 2022
24-61-00 Figure 01A 4 Jul 7, 2022
24-61-00 Figure 01B 8 Jul 7, 2022
24-61-00 Figure 02 5 Jul 7, 2022
24-61-00 Figure 03 3 Jul 7, 2022
24-61-00 Figure 03A 5 Jul 7, 2022
24-61-00 Figure 04 5 Jul 7, 2022
24-61-00 Figure 05 5 Jul 7, 2022
24-61-00 Figure 06 5 Jul 7, 2022
24-61-00 Figure 07 3 Jul 7, 2022
24-61-00 Figure 08 3 Jul 7, 2022
24-61-00 Figure 09 3 Jul 7, 2022
24-61-00 Figure 10 3 Jul 7, 2022
24-61-00 Figure 11 3 Jul 7, 2022
24-61-00 Figure 12 3 Jul 7, 2022
24-61-00 Figure 13 3 Jul 7, 2022
24-61-00 Figure 14 3 Jul 7, 2022
24-61-00 Figure 15 3 Jul 7, 2022
Page 1
24 - LIST OF EFFECTIVE PAGES Jul 7, 2022
©TEXTRON AVIATION INC.
CESSNA®
CHAPTER/
SECTION/ EFFECTIVITY
SUBJECT SUBJECT FIGURE START END
ALTERNATOR INSTALLATION 24-20-00 01 (172) 80001 & ON
(172S) 08001 & ON
BATTERY INSTALLATION 24-34-00 01 (172) 80001 & ON
(172S) 08001 & ON
STANDBY BATTERY INSTALLATION-NAV III 24-34-00 02 (172) 81241 & ON
(172S) 09810 & ON
POWER JUNCTION BOX INSTALLATION 24-60-00 01 (172) 80001 & ON
(172S) 08001 & ON
POWER CONVERTER INSTALLATION 24-60-01 01 (172) 80001 & ON
(172S) 08001 & ON
CIRCUIT BREAKER PANEL ASSEMBLY 24-61-00 01 (172) 80001 & ON
(172S) 08001 & ON
CIRCUIT BREAKER PANEL ASSEMBLY 24-61-00 01A (172) 80984 & ON
(172S) 08704 & ON
CIRCUIT BREAKER PANEL ASSEMBLY-NAV III 24-61-00 01B (172) 81241 & ON
(172S) 09810 & ON
AVIONICS CIRCUIT BREAKER PANEL-STANDARD 24-61-00 02 (172) 80001 & ON
(172S) 08001 & ON
AVIONICS CIRCUIT BREAKER PANEL-NAV 1 24-61-00 03 (172) 80001 & ON
(172S) 08001 & ON
AVIONICS CIRCUIT BREAKER PANEL-NAV 1 WITH 24-61-00 03A (172) 80001 & ON
ADF (172S) 08001 & ON
AVIONICS CIRCUIT BREAKER PANEL-NAV 2 WITH 24-61-00 04 (172) 80001 & ON
IFR (172S) 08001 & ON
HSI (172S) 08001 & ON
AVIONICS CIRCUIT BREAKER 24-61-00 06 (172) 80001 & ON
(172S) 08001 & ON
HSI/ADF (172S) 08001 & ON
MFD (172S) 08001 & ON
ADF/MFD (172S) 08001 & ON
HSI/ADF/MFD (172S) 08001 & ON
HSI/MFD (172S) 08001 & ON
AVIONICS CIRCUIT BREAKER PANEL-NAV II WITH 24-61-00 12 (172) 80001 & ON
HSI/MFD/FIS (172S) 08001 & ON
AVIONICS CIRCUIT BREAKER-NAV II WITH HSI/MFD/ 24-61-00 13 (172) 80001 & ON
FIS/ADF (172S) 08001 & ON
AVIONICS CIRCUIT BREAKER-NAV II WITH MFD/FIS 24-61-00 14 (172) 80001 & ON
(172S) 08001 & ON
AVIONICS CIRCUIT BREAKER-NAV II WITH MFD/FIS/ 24-61-00 15 (172) 80001 & ON
ADF (172S) 08001 & ON
Page 1
24 - CONTENTS Jul 7, 2022
CESSNA®
24-20-00
ALTERNATOR INSTALLATION
AIRPLANES (172R) 80001 & ON AND AIRPLANES (172S) 08001 & ON
Figure 01
Page 1
24-20-00 Jul 7, 2022
CESSNA®
B122
2
18
15 5
16
7
1
B
4
17
DETAIL B
3
6
DETAIL A
0510T1007
A0550T1001
B0550T1001
Figure 01. (Sheet 1)
Figure 01
Page 2
24-20-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
ITEM PART NUMBER 1 2 3 4 5 6 7 EFFECTIVITY ASSY
1 9910591-5 . ALTERNATOR ASSEMBLY (172) 80001 - 80325 NP

FOR SPARES ORDER (MUST REPLACE WITH):
9910591-11
- 1A 9910591-11 . ALTERNATOR ASSEMBLY 00779 (172) 80326 & ON 01
SPARES REPLACEMENT FOR:
9910591-5
- 1B 9910591-11 . ALTERNATOR ASSEMBLY 00779 (172S) 08001 & ON 01
ATTACHING PARTS
2 0750220-1 . BOLT (172) 80001 & ON 01
(172S) 08001 & ON
3 AN7-43A . BOLT (172) 80001 & ON 01
(172S) 08001 & ON
4 MS21045L7 . NUT (172) 80001 & ON 01
(172S) 08001 & ON
5 S1450-6-14-080 . WASHER (172) 80001 & ON 01
(172S) 08001 & ON
--*--
6 0552155-1 . BRACKET ASSEMBLY (172) 80001 & ON 01
(172S) 08001 & ON
7 378K4 . BELT - ALTERNATOR (172) 80001 & ON 01
(172S) 08001 & ON
-8 . WIRE BUNDLE - REFER TO WIRING DIAGRAM MANUAL RF
-9 MS21919WDG16 . CLAMP (172) 80001 & ON 01
ALTERNATE SPARE (INTERCHANGEABLE WITH): (172S) 08001 & ON
AS21919WDG16
- 9A AS21919WDG16 . CLAMP (172) 80001 & ON 01
MS21919WDG16
- 10 MS21919WDG12 . CLAMP (172) 80001 & ON 01
AS21919WDG12
- 10A AS21919WDG12 . CLAMP (172) 80001 & ON 01
MS21919WDG12
- 11 MS21919WDG7 . CLAMP (172) 80001 & ON 01
(172S) 08001 & ON
- 12 MS35207-262 . SCREW 80205 (172) 80001 & ON 03
(172S) 08001 & ON
- 13 NAS1149F0332P . WASHER (172) 80001 & ON 06
(172S) 08001 & ON
- 14 MS21042-3 . NUT (172) 80001 & ON 03
(172S) 08001 & ON
15 S1915-1 . CAPACITOR (172) 80001 - 80690 NP
ALTERNATE SPARE (INTERCHANGEABLE WITH):
S1915-3
- 15A S1915-1 . CAPACITOR (172S) 08001 - 08049 NP
S1915-3
16 S1915-3 . CAPACITOR (172) 80691 & ON 01
S1915-1
- ITEM NOT ILLUSTRATED
Figure 01
Page 3
24-20-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
- 16A S1915-3 . CAPACITOR (172S) 08050 & ON 01

S1915-1
17 MS21919WDG6 . CLAMP 84971 (172) 80001 & ON 01
AS21919WDG06
- 17A AS21919WDG06 . CLAMP (172) 80001 & ON 01
MS21919WDG6
18 S1399-1-18.00 . SLEEVE (172) 80001 & ON 01
(172S) 08001 & ON
- 19 . ENGINE COMPONENTS RF
REFER TO 71-00-01 FIGURE 01.
Figure 01
Page 4
24-20-00 Jul 7, 2022
CESSNA®
24-34-00
BATTERY INSTALLATION
Figure 01
Page 1
24-34-00 Jul 7, 2022
CESSNA®
B123
5
2
11
3 10
1 4
18 14
A
8
15
17
12
16 13
18
5 DETAIL A
AIRPLANES −80001 THRU −80003
2
11 6 7
10
9 6
3
8
1B
4
18
15 14
12
8
16 13
17 18 DETAIL A
MAIN BATTERY INSTALLATION
AIRPLANES −80004 AND ON AND 0510T1007
AIRPLANES −08001 AND ON A0518T1023
A0518T1023
Figure 01
Page 2
24-34-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
1 C614002-0101 . BATTERY ASSEMBLY - MANIFOLD STANDARD REF G-241 UN002 (172) 80001 & ON 01
- 1A C614002-0101 . BATTERY ASSEMBLY - MANIFOLD STANDARD REF G-241 UN002 (172S) 08001 & ON 01
1B RG24-15M . BATTERY ASSEMBLY - MANIFOLD SEALED UN002 63017 (172) 81623 & ON 01
- 1C RG24-15M . BATTERY ASSEMBLY - MANIFOLD SEALED UN002 63017 (172S) 11436 & ON 01
- 1D C614002-0102 . BATTERY ASSEMBLY - HEAVY DUTY REF G-243 UN035 (172) 80001 & ON 01
(172S) 08001 & ON
ATTACHING PARTS
2 S2480-1 . BOLT (172) 80001 & ON 02
(172S) 08001 & ON
3 NAS1149F0463P . WASHER 99321 (172) 80001 & ON 02
(172S) 08001 & ON
--*--
4 0412007-15 . STRAP - BATTERY GROUND (172) 80001 & ON 01
(172S) 08001 & ON
5 0770741-1 . COVER - TERMINAL (172) 80001 & ON 01
(172S) 08001 & ON
6 MS3367-1-9 . TIE STRAP (172) 80001 & ON 02
(172S) 08001 & ON
7 S2421-10P . ELBOW (172) 80001 & ON 01
(172S) 08001 & ON
8 S1775-7 . TUBE - BATTERY DRAIN BULK ITEM (172) 80001 & ON 01
(172S) 08001 & ON
- 8A S1775-7 . TUBE - BATTERY DRAIN BULK ITEM (172) 80001 & ON 02
(172S) 08001 & ON
ATTACHING PARTS
9 NAS397-14 . CLAMP (172) 80001 & ON 01
(172S) 08001 & ON
10 MS3367-1-9 . TIE STRAP (172) 80001 & ON 01
(172S) 08001 & ON
--*--
11 0570512-2 . CABLE ASSEMBLY - BATTERY (172) 80001 & ON 01
(172S) 08001 & ON
12 MS21919WDG12 . CLAMP (172) 80001 & ON 01
AS21919WDG12
- 12A AS21919WDG12 . CLAMP (172) 80001 & ON 01
MS21919WDG12
13 0553028-1 . SHIELD ASSEMBLY (172) 80001 & ON 01
(172S) 08001 & ON
14 NAS463W416 . . SPACER (172) 80001 & ON 01
(172S) 08001 & ON
15 0553028-3 . . RETAINER (172) 80001 & ON 01
(172S) 08001 & ON
16 0553028-4 . . TUBE (172) 80001 & ON 01
(172S) 08001 & ON
17 S1053E8T . DUCT - 24.0 INCH LONG BULK ITEM (172) 80001 & ON AR
S1053K8T
Figure 01
Page 3
24-34-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
- 17A S1053K8T . DUCT (172) 80001 & ON AR

S1053E8T
ATTACHING PARTS
18 S1891-12 . CLAMP (172) 80001 & ON 02
S1891-12H
- 18A S1891-12H . CLAMP (172) 80001 & ON 02
S1891-12
--*--
Figure 01
Page 4
24-34-00 Jul 7, 2022
CESSNA®
24-34-00
STANDBY BATTERY INSTALLATION-NAV III

Figure 02
Page 1
24-34-00 Jul 7, 2022
CESSNA®
B4047
4 7
8
1
DETAIL A
0510T1007
A0518T1113

Figure 02
Page 2
24-34-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
1 AVT-200413 . BATTERY PACK UC005 0MBZ4 (172) 81241 - 81563 01

S4236-7
- 1A AVT-200413 . BATTERY PACK UC005 0MBZ4 (172S) 09810 - 11032 01
S4236-7
- 1B S4236-7 . BATTERY PACK ASSEMBLY UC007 (172) 81564 & ON 01
AVT-200413
- 1C S4236-7 . BATTERY PACK ASSEMBLY UC007 (172S) 11033 & ON 01
AVT-200413
-2 S4236-10 . . WIRE BUNDLE ASSEMBLY (172) 81241 & ON 01
(172S) 09810 & ON
-3 ATM-25 . . . FUSE 71400 (172) 81241 & ON 01
(172S) 09810 & ON
4 3930378-24 . BATTERY ANGLE (172) 81241 & ON 01
(172S) 09810 & ON
NOTE: IF REQUIRED, SHIM GAP BETWEEN BATTERY ANGLE AND
BRACKET AS REQUIRED, USING STANDARD WASHERS, NAS1149
SERIES OR EQUIVALENT.
5 3930378-6 . BRACKET ASSEMBLY (172) 81241 & ON 01
(172S) 09810 & ON
-6 MS21059L3 . . NUTPLATE (172) 81241 & ON 01
(172S) 09810 & ON
7 AN3-4A . BOLT 80205 (172) 81241 & ON 03
(172S) 09810 & ON
8 NAS1149F0332P . WASHER (172) 81241 & ON 03
(172S) 09810 & ON
9 . AVIONICS SUPPORT STRUCTURE - FORWARD RF
Figure 02
Page 3
24-34-00 Jul 7, 2022
CESSNA®
24-60-00
POWER JUNCTION BOX INSTALLATION

Figure 01
Page 1
24-60-00 Jul 7, 2022
CESSNA®
B131
1
17 3
2
21
A B 15
18
A
13 24
23
A 16
22
DETAIL A
19
DETAIL C
INCOPORATING
SB00−24−01
20
14 VIEW A−A
5 4 12
10
C
DETAIL C 6
INCOPORATING
SB05−24−01
9
8
DETAIL B 0510T1007
A0558T1001
AA0558T1001

Figure 01
Page 2
24-60-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
1 MC01-1 . MASTER CONTROL UNIT 3RCD2 (172) 80001 - 80003 01

- 1A MC01-2 . MASTER CONTROL UNIT 3RCD2 (172) 80004 - 80690 NP
ALTERNATE SPARE (PERMISSIBLE TO ALSO USE):
S3100-606
- 1B MC01-2 . MASTER CONTROL UNIT 3RCD2 (172S) 08001 - 08049 NP
S3100-606
- 1C MC01-2A . MASTER CONTROL UNIT 3RCD2 (172) 80691 - 80846 NP
S3100-606
- 1D MC01-2A . MASTER CONTROL UNIT 3RCD2 (172S) 08050 - 08365 NP
S3100-606
- 1E S3100-137 . MASTER CONTROL UNIT - REF MC01-2A(MOD IC7) (172) 80847 - 80983 NP
S3100-606
- 1F S3100-137 . MASTER CONTROL UNIT - REF MC01-2A(MOD IC7) (172S) 08366 - 08703 NP
S3100-606
- 1G S3100-138 . MASTER CONTROL UNIT - REF MC01-3A (MOD IC7 AND IC8) 65702 (172) 80984 - 81185 NP
S3100-594
- 1H S3100-138 . MASTER CONTROL UNIT - REF MC01-3A (MOD IC7 AND IC8) 65702 (172S) 08704 - 09475 NP
S3100-594
- 1J S3100-297 . MASTER CONTROL UNIT - REF MC01-3A (MOD IC9) (172) 81186 - 81230 NP
S3100-594
- 1K S3100-297 . MASTER CONTROL UNIT - REF MC01-3A (MOD IC9) (172S) 09476 - 09740 NP
S3100-594
- 1L S3100-344 . MASTER CONTROL UNIT - REF MC01-3A (MOD IC10) (172) 81231 - 81449 NP
S3100-594
- 1M S3100-344 . MASTER CONTROL UNIT - REF MC01-3A (MOD IC10) (172S) 09741 - 10608 NP
S3100-594
- 1N S3100-366 . MASTER CONTROL UNIT - REF MC01-3A (MOD IC11) (172) 81450 - 81592 NP
S3100-594
NOTE: IF THE S3100-549 (OR LATER) IS ORDERED FOR AIRPLANES
17280984 THRU 17281592 AND AIRPLANES 172S80704 THRU
172S11126, THE P52-0036 CONNECTOR COVER KIT WILL NEED TO
BE INSTALLED ON THE UNUSED J-5 CONNECTOR.
- 1P S3100-366 . MASTER CONTROL UNIT - REF MC01-3A (MOD IC11) (172S) 10609 - 11126 NP
S3100-594
NOTE: IF THE S3100-549 (OR LATER) IS ORDERED FOR AIRPLANES
17280984 THRU 17281592 AND AIRPLANES 172S80704 THRU
172S11126, THE P52-0036 CONNECTOR COVER KIT WILL NEED TO
BE INSTALLED ON THE UNUSED J-5 CONNECTOR.
Figure 01
Page 3
24-60-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
- 1Q S3100-549 . MASTER CONTROL UNIT - REF MC01-3A (MOD IC12 AND IC13) (172) 81593 - 81622 NP
S3100-594
- 1R S3100-549 . MASTER CONTROL UNIT - REF MC01-3A (MOD IC12 AND IC13) (172S) 11127 - 11320 NP
S3100-594
- 1S S3100-587 . MASTER CONTROL UNIT - REF MC01-3A (MOD IC14 ONLY) (172S) 11321 - 11475 NP
S3100-594
- 1T S3100-594 . MASTER CONTROL UNIT - REF MC01-3A (MOD IC14 ONLY) (172) 81623 & ON 01
S3100-138
- 1U S3100-594 . MASTER CONTROL UNIT - REF MC01-3A (MOD IC14 ONLY) (172S) 11476 & ON 01
S3100-138
- 1V S3100-606 . MASTER CONTROL UNIT - REF MC01-2A (MOD IC8 AND ON) (172) 80001 & ON 01
- 1W S3100-606 . MASTER CONTROL UNIT - REF MC01-2A (MOD IC8 AND ON) (172S) 08001 & ON 01
ATTACHING PARTS
2 AN3CH5A . BOLT (172) 80001 & ON 04
(172S) 08001 & ON
3 NAS1149C0332R . WASHER (172) 80001 & ON 04
(172S) 08001 & ON
--*--
4 X61-0007 . . CONTACTOR - ALTERNATOR 3RCD2 (172) 80001 & ON 01
ALTERNATE SPARE (PERMISSIBLE TO ALSO USE): (172S) 08001 & ON
X61-0029
- 4A X61-0029 . CONTACTOR - ALTERNATOR (172) 80001 & ON 01
(172S) 08001 & ON
5 AC2101 . . ALTERNATOR CONTROL UNIT - WAS AC2100 3RCD2 (172) 80001 & ON 01
(172S) 08001 & ON
- 5A AC2100 . ALTERNATOR CONTROL UNIT (172) 80001 & ON
(172S) 08001 & ON
6 CS3100 . . TRANSDUCER - AMMETER 3RCD2 (172) 80001 - 81233 NP
CS3200
- 6A CS3100 . . TRANSDUCER - AMMETER 3RCD2 (172S) 08001 - 09740 NP
CS3200
- 6B CS3200 . . CURRENT SENSOR KIT - AMMETER 3RCD2 (172) 80001 - 81233 01
- 6C CS3200 . . CURRENT SENSOR KIT - AMMETER 3RCD2 (172S) 08001 - 09740 01
- 6D CS3200-1 . . CURRENT SENSOR 3RCD2 (172) 81234 & ON 01
- 6E CS3200-1 . . CURRENT SENSOR 3RCD2 (172S) 09741 & ON 01
7 X61-0012 . . CONTACTOR - STARTER 3RCD2 (172) 80001 & ON 01
X61-0027
X61-0031
- 7A X61-0027 . . CONTACTOR - STARTER 3RCD2 (172) 80001 & ON 01
X61-0031
- 7B X61-0031 . . CONTACTOR - STARTER (172) 80001 & ON 01
(172S) 08001 & ON
Figure 01
Page 4
24-60-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
8 X61-0007 . . CONTACTOR - BATTERY 3RCD2 (172) 80001 & ON 01

X61-0029
- 8A X61-0029 . . CONTACTOR - BATTERY (172) 80001 & ON 01
(172S) 08001 & ON
9 X61-0007 . . CONTACTOR - EXTERNAL POWER 3RCD2 (172) 80001 & ON 01
X61-0029
- 9A X61-0029 . . CONTACTOR - EXTERNAL POWER (172) 80001 & ON 01
(172S) 08001 & ON
10 F52-0002 . . FUSE HOLDER - CAP ASSEMBLY-J BOX 3RCD2 (172) 80001 & ON 01
(172S) 08001 & ON
- 11 F51-0003 . . FUSE - CLOCK 3RCD2 (172) 80001 & ON 02
(172S) 08001 & ON
12 F51-0002 . . FUSE - 30 AMP 3RCD2 (172) 80001 & ON 03
(172S) 08001 & ON
13 F53-0003 . . CIRCUIT BREAKER - 30 AMP 3RCD2 (172) 80001 - 80983 02
* AIRPLANES (172R) 80001 THRU 80839 INCORPORATING (172) *80001 - 80839
SB00-24-01 (172S) 08001 - 08703
* AIRPLANES (172S) 08001 THRU 08358 INCORPORATING (172S) *08001 - 08358
SB00-24-01
14 F53-0006 . . CIRCUIT BREAKER - 40 AMP 3RCD2 (172) 80984 & ON 02
* AIRPLANES (172R) 81186 THRU 81232 INCORPORATING (172) *81186 - 81232
SB05-24-01 (172S) 08704 & ON
* AIRPLANES (172S) 09476 THRU 09689 AND 09691 THRU 09770 (172S) *09476 - 09689
INCORPORATING SB05-24-01 (172S) *09691 - 09770
15 0412007-18 . GROUND STRAP (172) 80001 & ON 01
(172S) 08001 & ON
16 0412007-15 . GROUND STRAP (172) 80001 & ON 01
(172S) 08001 & ON
17 N52-0007 . COVER (172) 80001 & ON 01
(172S) 08001 & ON
18 S2562-2 . TUBING (172) 80001 & ON 01
(172S) 08001 & ON
19 0553032-1 . SEAL ASSEMBLY - FIREWALL (172) 80001 - 81535 01
- 19A 0553032-1 . SEAL ASSEMBLY - FIREWALL (172S) 08001 - 10770 01
- 19B 0553032-3 . SEAL ASSEMBLY - FIREWALL (172) 80984 - 81535 01
- 19C 0553032-3 . SEAL ASSEMBLY - FIREWALL (172S) 08704 - 10770 01
- 19D 0553047-2 . SEAL ASSEMBLY - FIREWALL (172) 81536 & ON 01
- 19E 0553047-2 . SEAL ASSEMBLY - FIREWALL (172S) 10771 & ON 01
20 MS35206-244 . SCREW (172) 80001 & ON 01
(172S) 08001 & ON
21 AN5-4A . BOLT (172) 80001 & ON 01
(172S) 08001 & ON
22 NAS1149C0632R . WASHER (172) 80001 & ON 01
(172S) 08001 & ON
23 MS21043-5 . NUT (172) 80001 & ON 01
(172S) 08001 & ON
24 . BATTERY - WIRE BUNDLE ASSEMBLY RF
Figure 01
Page 5
24-60-00 Jul 7, 2022
CESSNA®
24-60-01
POWER CONVERTER INSTALLATION

Figure 01
Page 1
24-60-01 Jul 7, 2022
CESSNA®
B2243
6
2
B A 4
1B
5
DETAIL A
7
8
3
6 7B 1D
3
DETAIL B
AIRPLANES 17281241 THRU
17281496 AND
AIRPLANES 172S09810 THRU 8
172S10655
WITH NAV III
DETAIL A
AIRPLANES 17281497 AND ON AND 0510T1007
AIRPLANES 172S10656 AND ON A0518T1068
A0518T1156
WITH NAV III B0518T1121

Figure 01
Page 2
24-60-01 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
1 0518021-1 . POWER CONVERTER ASSEMBLY (172) 80984 & ON 01

- 1A 0518021-1 . POWER CONVERTER ASSEMBLY (172S) 08704 & ON 01
1B 0518021-1 . POWER CONVERTER ASSEMBLY - NAV III (172) 81241 - 81496 01
- 1C 0518021-1 . POWER CONVERTER ASSEMBLY - NAV III (172S) 09810 - 10655 01
1D 0518021-1 . POWER CONVERTER ASSEMBLY - NAV III (172) 81497 & ON 01
- 1E 0518021-1 . POWER CONVERTER ASSEMBLY - NAV III (172S) 10656 & ON 01
ATTACHING PARTS
2 MS27039-0809 . SCREW (172) 80001 & ON 04
(172S) 08001 & ON
3 MS35206-245 . SCREW - NAV III 0TRC3 (172) 80001 & ON 04
(172S) 08001 & ON
4 NAS1149FN816P . WASHER (172) 80001 & ON 04
(172S) 08001 & ON
5 MS21069L08 . NUTPLATE 71785 (172) 80001 & ON 04
(172S) 08001 & ON
--*--
6 0570518-1 . . CABLE ASSEMBLY - POWER CONVERTER (172) 80001 & ON 01
(172S) 08001 & ON
7 0718021-2 . BRACKET ASSEMBLY - NAV III (172) 81241 - 81496 02
- 7A 0718021-2 . BRACKET ASSEMBLY - NAV III (172S) 09810 - 10655 02
7B 0518032-4 . BRACKET ASSEMBLY - NAV III (172) 81497 & ON 02
- 7C 0518032-4 . BRACKET ASSEMBLY - NAV III (172S) 10656 & ON 02
8 MS21069L08 . . NUTPLATE - NAV III 71785 (172) 80001 & ON 02
(172S) 08001 & ON
Figure 01
Page 3
24-60-01 Jul 7, 2022
CESSNA®
24-61-00
CIRCUIT BREAKER PANEL ASSEMBLY

Figure 01
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B124
BA
38
39 36
40 37
B
A
3
2 DETAIL A
14 15 16 17 18 19 20 21
22 22 22 22 22 22 22 22
41
4 7 8 9 10 11 12 13 5
6 22 22 22 22 22 22 22 6
VIEW A−A
34 30 31
34
24 27 23 28 32 35 33 29 35
25 25 0510T1007
26 26 VIEW B−B
A0518T1015
AA0585T1040
BB0518T1016

Figure 01
Page 2
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
-1 0518003-1 . CIRCUIT PANEL ASSEMBLY - CIRCUIT BREAKER (172) 80001 - 80003 01

0518003-4
- 1A 0518003-2 . CIRCUIT PANEL ASSEMBLY - CIRCUIT BREAKER (172) 80004 - 80798 01
0518003-4
- 1B 0518003-2 . CIRCUIT PANEL ASSEMBLY - CIRCUIT BREAKER (172S) 08001 - 08297 01
0518003-4
- 1C 0518003-4 . PANEL ASSEMBLY - CIRCUIT BREAKER (172) 80799 - 80849 01
0518003-1
0518003-2
- 1D 0518003-4 . PANEL ASSEMBLY - CIRCUIT BREAKER (172S) 08298 - 08376 01
0518003-2
- 1E 0518003-3 . PANEL ASSEMBLY - CIRCUIT BREAKER SPLIT AVIONICS SWITCH (172) 80718 - 80849 01
OPTION
- 1F 0518003-3 . PANEL ASSEMBLY - CIRCUIT BREAKER SPLIT AVIONICS MASTER (172S) 08118 - 08376 01
SWITCH OPTION
- 1G 0518003-6 . PANEL ASSEMBLY - CIRCUIT BREAKER (172) 80850 - 80983 01
- 1H 0518003-6 . PANEL ASSEMBLY - CIRCUIT BREAKER (172S) 08377 - 08703 01
- 1I 0518003-5 . PANEL ASSEMBLY - CIRCUIT BREAKER SPLIT AVIONICS MASTER (172) 80850 - 80983 01
SWITCH OPTION
- 1J 0518003-5 . PANEL ASSEMBLY - CIRCUIT BREAKER SPLIT AVIONICS MASTER (172S) 08377 - 08703 01
SWITCH OPTION
ATTACHING PARTS
2 CM3558-10-8B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
3 0518011-4 . . PANEL ASSEMBLY - 172 (172) 80001 - 80849 01
- 3A 0518011-4 . . PANEL ASSEMBLY - 172S (172S) 08001 - 08376 01
- 3B 0518011-7 . . PANEL ASSEMBLY 172 - 172 (172) 80850 & ON 01
- 3C 0518011-7 . . PANEL ASSEMBLY 172 - 172S (172S) 08377 & ON 01
4 S3272-1-1 . . SWITCH - MASTER ALTERNATE BATTERY SI009 (172) 80001 & ON 01
(172S) 08001 & ON
- 4A 0570512-1 . . BATTERY SYSTEM WIRE BUNDLE ASSEMBLY/FUSELAGE - (172) 80001 & ON 01
REFER TO WIRING DIAGRAM MANUAL (172S) 08001 & ON
- 4B 0570513-2 . . BUS BAR WIRE BUNDLE ASSEMBLY/FUSELAGE - REFER TO (172) 80001 & ON 01
WIRING DIAGRAM MANUAL (172S) 08001 & ON
5 S3271-1-1 . . SWITCH - AVIONICS MASTER SI001 (172) 80001 - 80798 01
FOR SPARES ORDER (MUST REPLACE WITH): (172S) 08001 - 08297
S3377-1-1
- 5A S3377-1-1 . . SWITCH - AVIONICS MASTER REPLACES S3271-1-1 SI001 (172) 80799 - 80983 01
SPARES REPLACEMENT FOR: (172S) 08298 - 08703
S3271-1-1
- 5B S3443-1-1 . . SWITCH - SPLIT MASTER SWITCH OPTION (172) 80984 & ON 01
(172S) 08704 & ON
6 S1843-1 . . BEZEL - SWITCH (172) 80001 & ON 02
(172S) 08001 & ON
Figure 01
Page 3
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
7 CM3589-5 . . CIRCUIT BREAKER - FUEL PUMP HI012 (172) 80001 & ON 01

(172S) 08001 & ON
- 7A 0570530-1 . . FUEL PUMP WIRE BUNDLE ASSEMBLY/FUSELAGE (172) 80001 & ON 01
(172S) 08001 & ON
8 CM3589-5 . . CIRCUIT BREAKER - BCN LIGHT HI004 (172) 80001 & ON 01
(172S) 08001 & ON
9 CM3589-10 . . CIRCUIT BREAKER - LAND LIGHT HI001 (172) 80001 & ON 01
(172S) 08001 & ON
10 CM3589-10 . . CIRCUIT BREAKER - TAXI LIGHT HI013 (172) 80001 & ON 01
(172S) 08001 & ON
11 CM3589-5 . . CIRCUIT BREAKER - NAV LIGHT HI002 (172) 80001 & ON 01
(172S) 08001 & ON
12 CM3589-5 . . CIRCUIT BREAKER - STROBE LIGHT HI005 (172) 80001 & ON 01
(172S) 08001 & ON
13 CM3589-5 . . CIRCUIT BREAKER - PITOT HEAT HI006 (172) 80001 & ON 01
(172S) 08001 & ON
14 S1360-10L . . CIRCUIT BREAKER - FLAP HI007 (172) 80001 & ON 01
(172S) 08001 & ON
15 S1360-5L . . CIRCUIT BREAKER - INST HI009 (172) 80001 & ON 01
(172S) 08001 & ON
16 S1360-15L . . CIRCUIT BREAKER - AVN BUS 1 HI023 (172) 80001 & ON 01
(172S) 08001 & ON
(172S) 08001 & ON
18 S1360-5L . . CIRCUIT BREAKER - TURN COORD HI008 (172) 80001 & ON 01
(172S) 08001 & ON
19 S1360-5L . . CIRCUIT BREAKER - INST LTS HI003 (172) 80001 & ON 01
(172S) 08001 & ON
20 S1360-5L . . CIRCUIT BREAKER - ALT FLD HI010 (172) 80001 & ON 01
(172S) 08001 & ON
21 S1360-5L . . CIRCUIT BREAKER - WARN HI022 (172) 80001 & ON 01
(172S) 08001 & ON
22 S2122-1 . . NUT - KNURLED (172) 80001 & ON 15
(172S) 08001 & ON
23 1N6391 . . DIODE DI001 (172) 80001 & ON 01
(172S) 08001 & ON
24 1N6391 . . DIODE DI002 (172) 80001 & ON 01
(172S) 08001 & ON
ATTACHING PARTS
25 MS35333-39 . . LOCK WASHER (172) 80001 & ON 01
(172S) 08001 & ON
26 MS35650-305T . . NUT 80205 (172) 80001 & ON 01
(172S) 08001 & ON
--*--
27 0518013-4 . . BUS BAR - DIODE MOUNT HI021 (172) 80001 & ON 01
(172S) 08001 & ON
28 6238373-42 . . BUS BAR HI014 (172) 80001 & ON 01
(172S) 08001 & ON
29 6238373-30 . . BUS BAR HI016 (172) 80001 & ON 01
(172S) 08001 & ON
Figure 01
Page 4
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
30 6238373-3 . . BUS BAR HI014 (172) 80001 & ON 01

(172S) 08001 & ON
31 6238373-3 . . BUS BAR HI016 (172) 80001 & ON 01
(172S) 08001 & ON
32 0518013-2 . . BUS BAR - JUMPER HI014 (172) 80001 & ON 01
(172S) 08001 & ON
(172S) 08001 & ON
34 MS35206-226 . . SCREW 80205 (172) 80001 & ON 02
(172S) 08001 & ON
35 MS35206-241 . . SCREW 72914 (172) 80001 & ON 02
(172S) 08001 & ON
Figure 01
Page 5
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
36 0518022-1 . COVER - CIRCUIT BREAKER BACK (172) 80069 - 80073 01

* AIRPLANES (172R) 80001 THRU 80068, 80074 THRU 80138, 80140 (172) 80159 - 80159
THRU 80155, 80157 THRU 80158, 80160 THRU 80233, 80235 THRU (172) 80234 - 80234
80241, 80243 THRU 80244, 80246 THRU 80250, 80252, 80254 THRU (172) 80242 - 80242
80256, 80258 THRU 80261, 80263 THRU 80280, 80283 THRU 80284, (172) 80245 - 80245
80286 THRU 80291, 80293 THRU 80296, 80298 THRU 80300, 80302 (172) 80251 - 80251
THRU 80436, 80438, 80440 THRU 80453, 80455, 80457 THRU 80458, (172) 80253 - 80253
80460 THRU 80605, 80611 THRU 80612, 80615, 80617 THRU 80620, (172) 80257 - 80257
80625 THRU 80630, 80635 THRU 80637, 80641 THRU 80645, 80649 (172) 80262 - 80262
THRU 80651, 80654, 80656 THRU 80658, 80663, 80665 THRU 80666, (172) 80281 - 80282
80671 AND 80676 THRU 80849 INCORPORATING MK172-24-02 (172) 80285 - 80285
(172) 80292 - 80292
(172) 80297 - 80297
(172) 80301 - 80301
(172) 80305 - 80305
(172) 80437 - 80437
(172) 80439 - 80439
(172) 80454 - 80454
(172) 80456 - 80456
(172) 80459 - 80459
(172) 80606 - 80610
(172) 80613 - 80614
(172) 80616 - 80616
(172) 80621 - 80624
(172) 80631 - 80634
(172) 80638 - 80640
(172) 80646 - 80648
(172) 80652 - 80653
(172) 80655 - 80655
(172) 80659 - 80662
(172) 80664 - 80664
(172) 80672 - 80675
(172) 80850 & ON
(172) *80001 - 80068
(172) *80074 - 80138
(172) *80140 - 80155
(172) *80157 - 80158
(172) *80160 - 80233
(172) *80235 - 80241
(172) *80243 - 80244
(172) *80246 - 80250
(172) *80252 - 80252
(172) *80254 - 80256
(172) *80258 - 80261
(172) *80263 - 80280
(172) *80283 - 80284
(172) *80286 - 80291
(172) *80293 - 80296
(172) *80298 - 80300
(172) *80302 - 80436
(172) *80438 - 80438
(172) *80440 - 80453
(172) *80455 - 80455
(172) *80457 - 80458
(172) *80460 - 80605
Figure 01
Page 6
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
(172) *80611 - 80612

(172) *80615 - 80615
(172) *80617 - 80620
(172) *80625 - 80630
(172) *80635 - 80637
(172) *80641 - 80645
(172) *80649 - 80651
(172) *80654 - 80654
(172) *80656 - 80658
(172) *80663 - 80663
(172) *80665 - 80666
(172) *80671 - 80671
(172) *80676 - 80849
37 0518022-1 . COVER - CIRCUIT BREAKER BACK (172S) 08002 - 08005 01
* AIRPLANES (172S) 08001, 08006 THRU 08007, 08010 THRU 08011 (172S) 08008 - 08009
AND 08014 THRU 08393 INCORPORATING MK172-24-02 (172S) 08012 - 08013
(172S) 08377 & ON
(172S) *08001 - 08001
(172S) *08006 - 08007
(172S) *08010 - 08011
(172S) *08014 - 08393
38 NAS1149FN816P . . WASHER (172) 80001 & ON 01
(172S) 08001 & ON
39 S1741-5 . . ANCHOR (172) 80001 & ON 01
(172S) 08001 & ON
40 AN525-832R7 . . SCREW (172) 80001 & ON 01
(172S) 08001 & ON
41 . IGNITION SWITCH RF
ATTACHING PARTS
- 42 AN525-832R7 . SCREW (172) 80001 & ON 04
(172S) 08001 & ON
--*--
- 43 0570511-1 . MAGNETO WIRE BUNDLE ASSEMBLY - REFER TO WIRING (172) 80001 & ON 01
DIAGRAM MANUAL (172S) 08001 & ON
- 44 0570513-3 . BUS BAR SWITCH PANEL WIRE BUNDLE ASSEMBLY - REFER TO (172) 80001 & ON 01
WIRING DIAGRAM MANUAL (172S) 08001 & ON
- 45 0570514-1 . WIRE BUNDLE ASSEMBLY - BUS BAR SWITCH PANEL/SPLIT (172) 80001 & ON 01
AVIONICS MASTER SWITCH (172S) 08001 & ON
Figure 01
Page 7
24-61-00 Jul 7, 2022
CESSNA®
24-61-00

Figure 01A
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B1447
A
B
A
B
2 DETAIL A
C C
22 22 22 22 22 22 22 22 22
33
38 13 14 15 16 17 18 19 20 21
37
36
35 36 34 31 3 5 6 7 8 9 10 11 12 5 4
32 22 22 22 22 22 22 22
FWD C C
VIEW A−A
VIEW C−C 34 28 23A 2
34 27
33 30 33 29 26 23
0510T1007
VIEW B−B 25 24 A0518T1015
AA0518T1090
BB0518T1089
CC0518T1091

Figure 01A. (Sheet 1)
Figure 01A
Page 2
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
-1 0518003-7 . CIRCUIT PANEL ASSEMBLY (172) 80984 & ON 01

(172S) 08704 & ON
2 0518011-10 . . PANEL ASSEMBLY (172) 80984 & ON 01
(172S) 08704 & ON
3 S3272-1-1 . . SWITCH - MASTER ALT BAT SI009 (172) 80984 & ON 01
(172S) 08704 & ON
4 S3443-1-1 . . SWITCH - AVIONICS MASTER SI010 (172) 80984 & ON 01
(172S) 08704 & ON
5 S1843-1 . . MOUNTING BEZEL - SWITCH (172) 80984 & ON 02
(172S) 08704 & ON
6 CM3589-5 . . CIRCUIT BREAKER - FUEL PUMP SWITCH HI012 (172) 80984 & ON 01
(172S) 08704 & ON
7 CM3589-5 . . CIRCUIT BREAKER - BEACON LIGHT SWITCH HI004 (172) 80984 & ON 01
(172S) 08704 & ON
8 CM3589-10 . . CIRCUIT BREAKER - LAND LIGHT SWITCH HI001 (172) 80984 & ON 01
(172S) 08704 & ON
9 CM3589-10 . . CIRCUIT BREAKER - TAXI LIGHT SWITCH HI013 (172) 80984 & ON 01
(172S) 08704 & ON
10 CM3589-5 . . CIRCUIT BREAKER - CI-NAV LIGHT SWITCH HI002 (172) 80984 & ON 01
(172S) 08704 & ON
11 CM3589-5 . . CIRCUIT BREAKER - STROBE LIGHT SWITCH HI005 (172) 80984 & ON 01
(172S) 08704 & ON
12 CM3589-5 . . CIRCUIT BREAKER - PITOT HEAT SWITCH HI006 (172) 80984 & ON 01
(172S) 08704 & ON
13 S1360-5L . . CIRCUIT BREAKER - CABIN LIGHTS/POWER HI015 (172) 80984 & ON 01
(172S) 08704 & ON
14 S1360-10L . . CIRCUIT BREAKER - FLAP HI007 (172) 80984 & ON 01
(172S) 08704 & ON
15 S1360-5L . . CIRCUIT BREAKER - INST HI009 (172) 80984 & ON 01
(172S) 08704 & ON
(172S) 08704 & ON
(172S) 08704 & ON
18 S1360-5L . . CIRCUIT BREAKER - TURN COORD HI008 (172) 80984 & ON 01
(172S) 08704 & ON
19 S1360-5L . . CIRCUIT BREAKER - C-INST LIGHTS HI003 (172) 80984 & ON 01
(172S) 08704 & ON
20 S1360-5L . . CIRCUIT BREAKER - ALT FLD HI010 (172) 80984 & ON 01
(172S) 08704 & ON
21 S1360-5L . . CIRCUIT BREAKER - C-WARN HI022 (172) 80984 & ON 01
(172S) 08704 & ON
22 S2122-1 . . NUT - KNURLED (172) 80984 & ON 16
(172S) 08704 & ON
23 1N6391 . . DIODE DI002 (172) 80984 & ON 02
(172S) 08704 & ON
23A 1N6391 . . DIODE DI001 (172) 80984 & ON 02
(172S) 08704 & ON
ATTACHING PARTS
24 MS35333-39 . . LOCK WASHER (172) 80984 & ON 01
(172S) 08704 & ON
Figure 01A
Page 3
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
25 MS35650-305T . . NUT 80205 (172) 80984 & ON 01

(172S) 08704 & ON
--*--
26 0518013-4 . . BUS BAR - DIODE MOUNT HI021 (172) 80984 & ON 01
(172S) 08704 & ON
27 6238373-42 . . BUS BAR HI014 (172) 80984 & ON 01
(172S) 08704 & ON
28 6238373-30 . . BUS BAR HI016 (172) 80984 & ON 01
(172S) 08704 & ON
29 6238373-3 . . BUS BAR HI014 (172) 80984 & ON 01
(172S) 08704 & ON
30 6238373-4 . . BUS BAR HI016 (172) 80984 & ON 01
(172S) 08704 & ON
(172S) 08704 & ON
(172S) 08704 & ON
ATTACHING PARTS
33 MS35206-226 . . SCREW 80205 (172) 80984 & ON 01
(172S) 08704 & ON
34 MS35206-241 . . SCREW 72914 (172) 80984 & ON 01
(172S) 08704 & ON
35 MS35207-261 . . SCREW 07187 (172) 80984 & ON 01
(172S) 08704 & ON
36 NAS1149F0332P . . FLAT WASHER (172) 80984 & ON 02
(172S) 08704 & ON
37 MS35333-39 . . LOCK WASHER (172) 80984 & ON 01
(172S) 08704 & ON
38 MS35650-305T . . NUT 80205 (172) 80984 & ON 01
(172S) 08704 & ON
--*--
- 39 . WIRE BUNDLE ASSEMBLY BUS BAR - REFER TO WIRING RF
DIAGRAM MANUAL
- 40 . WIRE BUNDLE ASSEMBLY BATTERY SYSTEM - REFER TO WIRING RF
DIAGRAM MANUAL
Figure 01A
Page 4
24-61-00 Jul 7, 2022
CESSNA®
24-61-00
CIRCUIT BREAKER PANEL ASSEMBLY-NAV III

Figure 01B
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B4042
B DETAIL A
36 37 41
C 32 33 34 35 38 39 40
AL T AD C NAV I STDB Y STDB Y

FIEL D WAR N PF D AHR S EN G COMM 1 IND LT S BAT T
X−FEE D ES S
BU S BU S
MAGNETO S
R L BOT H
FUE L BC N LAN D CABI N AV N AD C NAV I
O S PUM P LT LT LTS/PW R FLAP S 1 PF D AHR S EN G FI S AD F
F T ELE C AV N
F A BU S BU S
R 1 1
T
PITO T NA V TAX I STROB E PANE L AV N AUT O
HEA T LT S LT LT S LT S 2 MF D XPND R NAV 2 COMM 2 AUDI O PILO T
ELE C AV N
BU S BU S
2 2
2 1 21 22 23 24 25 26 27 28 29 30 31
20
9
19 DETAIL B
E 3
5
15 8 4
7
14 17
18
4
3 6
5
DETAIL D
TYPICAL
12
D 11
DETAIL E 0510T1007
A0518T1135
TYPICAL B0518T1135
DETAIL C C0518T1137
D1218T1080
E0718T1055

Figure 01B. (Sheet 1)
Figure 01B
Page 2
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
1 0518024-1 . CIRCUIT BREAKER PANEL ASSEMBLY - NAV III (172) 81241 - 81578 01
- 1A 0518024-1 . CIRCUIT BREAKER PANEL ASSEMBLY - NAV III (172S) 09810 - 11085 01
- 1B 0518024-10 . CIRCUIT BREAKER PANEL ASSEMBLY - NAV III (172) 81579 - 81616 01
- 1C 0518024-10 . CIRCUIT BREAKER PANEL ASSEMBLY - NAV III (172S) 11086 - 11190 01
- 1D 0518024-11 . CIRCUIT BREAKER PANEL ASSEMBLY - NAV III (172) 81617 & ON 01
- 1E 0518024-11 . CIRCUIT BREAKER PANEL ASSEMBLY - NAV III (172S) 11191 - 11758 01
- 1F 0518024-13 . CIRCUIT BREAKER PANEL ASSEMBLY - NAV III (172S) 11759 - 12700 01
- 1G 0518024-14 . CIRCUIT BREAKER PANEL ASSEMBLY - NAV III (172S) 12701 & ON 01
ATTACHING PARTS
2 CM3658-7 . SCREW (172) 81241 & ON 06
(172S) 09810 & ON
--*--
3 MS35650-305T . . NUT 80205 (172) 81241 & ON 12
- 3A MS35650-305T . . NUT 80205 (172S) 09810 - 11758 12
- 3B MS35650-305T . . NUT 80205 (172S) 11759 & ON 13
4 NAS1149F0332P . . WASHER (172) 81241 & ON 16
- 4A NAS1149F0332P . . WASHER (172S) 09810 - 11758 16
- 4B NAS1149F0332P . . WASHER (172S) 11759 & ON 18
5 MS35333-39 . . WASHER - LOCK FLAT (172) 81241 & ON 12
- 5A MS35333-39 . . WASHER - LOCK FLAT (172S) 09810 - 11758 12
- 5B MS35333-39 . . WASHER - LOCK FLAT (172S) 11759 & ON 13
6 MS35207-261 . . SCREW 07187 (172) 81241 & ON 08
- 6A MS35207-261 . . SCREW 07187 (172S) 09810 - 11758 08
- 6B MS35207-261 . . SCREW 07187 (172S) 11759 & ON 09
(172S) 09810 & ON
8 MS21071L04 . . . NUTPLATE (172) 81241 & ON 05
(172S) 09810 & ON
9 MS21076L04 . . . NUTPLATE (172) 81241 & ON 01
(172S) 09810 & ON
- 10 0518024-4 . . BUS BAR HI021 (172) 81241 & ON 01
(172S) 09810 & ON
11 0718018-5 . . BUS BAR - ELECTRICAL HI014 (172) 81241 & ON 01
(172S) 09810 & ON
12 0718018-5 . . BUS BAR - ELECTRICAL HI016 (172) 81241 & ON 01
(172S) 09810 & ON
- 13 0718018-5 . . BUS BAR - AVIONICS HI019 (172) 81241 & ON 01
(172S) 09810 & ON
14 0718018-5 . . BUS BAR - AVIONICS HI018 (172) 81241 & ON 01
(172S) 09810 & ON
15 0718018-5 . . BUS BAR - ESSENTIAL HI020 (172) 81241 & ON 01
(172S) 09810 & ON
- 16 S3478-1 . . CIRCUIT BREAKER BLOCK ASSEMBLY 2X920 (172) 81241 & ON 01
(172S) 09810 & ON
17 1N6391 . . DIODE DI001 (172) 81241 & ON 01
(172S) 09810 & ON
18 1N6391 . . DIODE DI002 (172) 81241 & ON 01
(172S) 09810 & ON
19 1N6391 . . DIODE DI006 (172) 81241 & ON 01
(172S) 09810 & ON
Figure 01B
Page 3
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
20 1N6391 . . DIODE DI007 (172) 81241 & ON 01

(172S) 09810 & ON
21 S2899L5.0 . . CIRCUIT BREAKER - PITOT HEAT HI032 82647 (172) 81241 & ON 01
(172S) 09810 & ON
22 S2899L5.0 . . CIRCUIT BREAKER - NAV LIGHTS HI029 82647 (172) 81241 & ON 01
(172S) 09810 & ON
23 S2899L10.0 . . CIRCUIT BREAKER - TAXI LIGHT HI028 82647 (172) 81241 & ON 01
(172S) 09810 & ON
24 S2899L5.0 . . CIRCUIT BREAKER - STROBE LIGHTS HI031 82647 (172) 81241 & ON 01
(172S) 09810 & ON
25 S2899L5.0 . . CIRCUIT BREAKER - PANEL LIGHTS HI053 82647 (172) 81241 & ON 01
(172S) 09810 & ON
26 S2899L15.0 . . CIRCUIT BREAKER - AVIONICS 2 HI059 82647 (172) 81241 & ON 01
(172S) 09810 & ON
27 S2899L5.0 . . CIRCUIT BREAKER - MFD HI052 82647 (172) 81241 & ON 01
(172S) 09810 & ON
28 S2899L5.0 . . CIRCUIT BREAKER - TRANSPONDER HI048 82647 (172) 81241 & ON 01
(172S) 09810 & ON
29 S2899L5.0 . . CIRCUIT BREAKER - NAV 2 HI051 82647 (172) 81241 & ON 01
(172S) 09810 & ON
30 S2899L5.0 . . CIRCUIT BREAKER - COMM 2 HI050 82647 (172) 81241 & ON 01
(172S) 09810 & ON
31 S2899L5.0 . . CIRCUIT BREAKER - AUDIO HI049 82647 (172) 81241 & ON 01
(172S) 09810 & ON
32 S2899L5.0 . . CIRCUIT BREAKER - FUEL PUMP HI025 82647 (172) 81241 & ON 01
(172S) 09810 & ON
33 S2899L5.0 . . CIRCUIT BREAKER - BEACON LIGHT HI026 82647 (172) 81241 & ON 01
(172S) 09810 & ON
34 S2899L10.0 . . CIRCUIT BREAKER - LANDING LIGHT HI027 82647 (172) 81241 & ON 01
(172S) 09810 & ON
35 S2899L5.0 . . CIRCUIT BREAKER - CABIN LIGHTS/POWER HI056 82647 (172) 81241 & ON 01
(172S) 09810 & ON
36 S2899L10.0 . . CIRCUIT BREAKER - FLAPS HI054 82647 (172) 81241 & ON 01
(172S) 09810 & ON
37 S2899L15.0 . . CIRCUIT BREAKER - AVIONICS 1 HI058 82647 (172) 81241 & ON 01
(172S) 09810 & ON
38 S2899L5.0 . . CIRCUIT BREAKER - PFD HI042 82647 (172) 81241 & ON 01
(172S) 09810 & ON
39 S2899L10.0 . . CIRCUIT BREAKER - AIR DATA COMPUTER/AHRS HI041 82647 (172) 81241 & ON 01
(172S) 09810 & ON
40 S2899L15.0 . . CIRCUIT BREAKER - NAV 1/ENGINE MONITOR HI040 82647 (172) 81241 & ON 01
(172S) 09810 & ON
41 S2899L5.0 . . CIRCUIT BREAKER - PFD HI036 82647 (172) 81241 & ON 01
(172S) 09810 & ON
Figure 01B
Page 4
24-61-00 Jul 7, 2022
CESSNA®
B17661
B
DETAIL A
81 80 91 75 76 79 78 77
ALT ADC NAV I STDBY STDBY

FIELD WARN PFD AHRS ENG COMM 1 IND LTS BATT
91
X−FEED
ESS
BUS
MAGNETOS BUS
R L BOTH
O S FUEL BCN LAND CABIN AVN ADC NAV I
F T PUMP LT LT LTS/PWR FLAPS 1 PFD AHRS ENG FIS ADF
F A ELEC AVN
R BUS BUS
T 1 1
PITOT NAV TAXI STROBE PANEL AVN AUTO

HEAT LTS LT LTS LTS 2 MFD XPNDR NAV 2 COMM 2 AUDIO PILOT
ELEC
BUS
AVN
BUS
90
91
2 2
89 88 86
92
91 91 87
DETAIL B 91
0510T1007
A0518T1135
B0518T1135

Figure 01B. (Sheet 2)
Figure 01B
Page 6
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
75 S2899L10.0 . . CIRCUIT BREAKER - AIR DATA COMPUTER/AHRS HI037 82647 (172) 81241 - 81578 01
- 75A S2899L10.0 . . CIRCUIT BREAKER - AIR DATA COMPUTER/AHRS HI037 82647 (172S) 09810 - 11085 01
- 75B S2899L5.0 . . CIRCUIT BREAKER - AIR DATA COMPUTER/AHRS HI036 82647 (172) 81579 & ON 01
- 75C S2899L5.0 . . CIRCUIT BREAKER - AIR DATA COMPUTER/AHRS HI036 82647 (172S) 11086 & ON 01
76 S2899L15.0 . . CIRCUIT BREAKER - NAV 1/ENGINE MONITOR HI038 82647 (172) 81241 & ON 01
(172S) 09810 & ON
77 S2899L20.0 . . CIRCUIT BREAKER - STANDBY BATTERY HI034 (172) 81241 & ON 01
(172S) 09810 & ON
78 S2899L5.0 . . CIRCUIT BREAKER - STANDBY INDICATOR LIGHTS HI035 82647 (172) 81241 & ON 01
(172S) 09810 & ON
79 S2899L5.0 . . CIRCUIT BREAKER - COMM 1 HI039 82647 (172) 81241 & ON 01
(172S) 09810 & ON
80 S2899L5.0 . . CIRCUIT BREAKER - WARNING HI057 82647 (172) 81241 & ON 01
(172S) 09810 & ON
81 S2899L5.0 . . CIRCUIT BREAKER - ALTERNATOR FIELD HI055 82647 (172) 81241 & ON 01
(172S) 09810 & ON
- 82 0570519-1 . . CIRCUIT BREAKER PANEL WBA (172) 81241 - 81578 01
- 82A 0570519-1 . . CIRCUIT BREAKER PANEL WBA (172S) 09810 - 11085 01
- 82B 0570519-2 . . CIRCUIT BREAKER PANEL WBA (172) 81579 - 81616 01
- 82C 0570519-2 . . CIRCUIT BREAKER PANEL WBA (172S) 11086 - 11190 01
- 82D 0570519-3 . . CIRCUIT BREAKER PANEL WBA (172) 81617 & ON 01
- 82E 0570519-3 . . CIRCUIT BREAKER PANEL WBA (172S) 11191 - 11758 01
- 82F 0570519-4 . . CIRCUIT BREAKER PANEL WBA (172S) 11759 - 12700 01
- 82G 0570519-5 . CIRCUIT BREAKER PANEL WBA (172S) 12701 & ON 01
- 83 0518024-5 . . CIRCUIT BREAKER PANEL COVER - INBOARD (172) 81241 & ON 01
(172S) 09810 & ON
- 84 0518024-6 . . CIRCUIT BREAKER PANEL COVER - OUTBOARD (172) 81241 & ON 01
(172S) 09810 & ON
ATTACHING PARTS
- 85 MS3367-2-9 . . STRAP (172) 81241 & ON 02
(172S) 09810 & ON
--*--
86 S2899L5.0 . CIRCUIT BREAKER - AUTOPILOT HI047 82647 (172) 81241 & ON 01
(172S) 09810 & ON
87 10164-3 . EXTENSION CAP 26835 (172) 81241 & ON 01
(172S) 09810 & ON
88 S2899L5.0 . CIRCUIT BREAKER - DME/ADF HI046 82647 (172) 81241 & ON 01
(172S) 09810 & ON
89 S2899L5.0 . CIRCUIT BREAKER - FIS HI045 82647 (172S) *09810 - 09811 01
* AIRPLANES (172S) 09810 THRU 09811, 09813 THRU 09847, 09849, (172S) *09813 - 09847
09851 THRU 09857, 09859 THRU 09860, 09862 THRU 09887, 09889 (172S) *09849 - 09849
THRU 09902, 09904, 09906 THRU 09920 AND 09922 THRU 09932 (172S) *09851 - 09857
INCORPORATING SB05-34-09 (172S) *09859 - 09860
(172S) *09862 - 09887
(172S) *09889 - 09902
(172S) *09904 - 09904
(172S) *09906 - 09920
(172S) *09922 - 09932
90 S2899L5.0 . CIRCUIT BREAKER - TAS HI044 82647 (172) 81617 & ON 01
- 90A S2899L5.0 . CIRCUIT BREAKER - TAS HI044 82647 (172S) 11191 & ON 01
Figure 01B
Page 7
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
91 CM2692-16P2S . PLUG BUTTON (172) 81241 & ON NP

CM2692-16Z2S
- 91A CM2692-16Z2S . PLUG BUTTON (172) 81241 & ON AR
CM2692-16P2S
92 . LED PANEL ATTACH RF
Figure 01B
Page 8
24-61-00 Jul 7, 2022
CESSNA®
24-61-00
AVIONICS CIRCUIT BREAKER PANEL-STANDARD

Figure 02
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B125
B
A
A
A
DETAIL A
1 2
AVN NAV
FAN COM1 XPNDR
7 8 9
10 10 10
VIEW A−A
6 5 12
11
VIEW B−B
AIRPLANES 17280001 THRU 17280983 AND 0510T1007
AIRPLANES 172S8001 THRU 172S8703 A0518T1019
AA0518T1099
BB0518T1099

Figure 02
Page 2
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
1 3930306-3 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL (172S) 08001 - 08703 01

- 1A 3930306-3 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL (172) 80001 - 80983 01
ATTACHING PARTS
2 CM3558-6-16B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
-3 3930418-2 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER STANDARD (172) 80001 - 80983 01
- 3A 3930418-2 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER STANDARD (172S) 08001 - 08703 01
(172S) 08001 & ON
5 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
6 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
7 1610-128-050A7 . . CIRCUIT BREAKER - AVIONICS FAN HI906 76374 (172) 80001 & ON 01
(172S) 08001 & ON
8 1610-128-080A7 . . CIRCUIT BREAKER - NAV COM 1 HI900 76374 (172) 80001 & ON 01
(172S) 08001 & ON
9 1610-128-050A7 . . CIRCUIT BREAKER - TRANSPONDER HI904 76374 (172) 80001 & ON 01
(172S) 08001 & ON
10 S2878-8 . . NUT (172) 80001 & ON 03
(172S) 08001 & ON
11 6238373-3 . . BUS BAR HI909 (172) 80001 & ON 01
(172S) 08001 & ON
12 MS35206-226 . . SCREW 80205 (172) 80001 & ON 01
(172S) 08001 & ON
Figure 02
Page 3
24-61-00 Jul 7, 2022
CESSNA®
B2089
B
A
A
A
DETAIL A
75
AVN NAV
FAN COM1 XPNDR
81 82 83 76
84 84 84
VIEW A−A
87 79 78
80
86 85
VIEW B−B

AA0518T1093
BB0518T1093

Figure 02
Page 4
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
75 3930348-1 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL (172) 80984 & ON 01

- 75A 3930348-1 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL (172S) 08704 & ON 01
ATTACHING PARTS
76 CM3558-6-16B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
- 77 3930342-1 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER STANDARD (172) 80984 & ON 01
- 77A 3930342-1 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER STANDARD (172S) 08704 & ON 01
(172S) 08001 & ON
79 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
80 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
84 S2878-8 . . NUT (172) 80001 & ON 03
(172S) 08001 & ON
85 6238373-2 . . BUS BAR HI909 (172) 80001 & ON 01
(172S) 08001 & ON
86 MS35206-226 . . SCREW 80205 (172) 80001 & ON 01
(172S) 08001 & ON
87 . C/A AVIONICS POWER - REFER TO WIRING DIAGRAM MANUAL RF
Figure 02
Page 5
24-61-00 Jul 7, 2022
CESSNA®
24-61-00
AVIONICS CIRCUIT BREAKER PANEL-NAV 1

Figure 03
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B2077
B
A
A
A
DETAIL A
1
2
AVN NAV NAV
FAN GPS COM1 COM 2 XPNDR
7 8 9 10 11
12 12 12 12 12
VIEW A−A
4
6
16
5
14 15 13
VIEW B−B
A0518T1019
AIRPLANES 172S8704 AND ON AA0518T1095
BB0518T1095

Figure 03
Page 2
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER

ATTACHING PARTS
2 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
-3 3930343-1 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER (172) 80984 & ON 01
- 3A 3930343-1 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER (172S) 08704 & ON 01
(172S) 08001 & ON
5 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
6 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
8 1610-128-050A7 . . CIRCUIT BREAKER - GPS HI902 76374 (172) 80001 & ON 01
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
11 1610-128-050A7 . . CIRCUIT BREAKER - TRANSPONDER 76374 (172) 80001 & ON 01
(172S) 08001 & ON
12 S2878-8 . . NUT (172) 80001 & ON 05
(172S) 08001 & ON
13 6238373-3 . . BUS BAR HI908 (172) 80001 & ON 01
(172S) 08001 & ON
14 6238373-4 . . BUS BAR HI907 (172) 80001 & ON 01
(172S) 08001 & ON
15 MS35206-226 . . SCREW 80205 (172) 80001 & ON 02
(172S) 08001 & ON
16 . AVIONICS POWER - REFER TO WIRING DIAGRAM MANUAL RF
Figure 03
Page 3
24-61-00 Jul 7, 2022
CESSNA®
24-61-00
AVIONICS CIRCUIT BREAKER PANEL-NAV 1 WITH ADF

Figure 03A
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B126
B
A
A
A
DETAIL A
1 2
AVN NAV NAV

FAN GPS COM 1 COM 2 ADF XPNDR
7 8 9 10 11 12
13 13 13 13 13 13
VIEW A−A
4
17
6 16 14 15 16
VIEW B−B
AA0518T1053
BB0518T1053

Figure 03A
Page 2
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
1 3930307-3 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL (172) 80001 - 80983 01

- 1A 3930307-3 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL (172S) 08001 - 08703 01
ATTACHING PARTS
2 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
-3 3930420-1 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER (172) 80001 - 80983 01
- 3A 3930420-1 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER (172S) 08001 - 08703 01
(172S) 08001 & ON
-5 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
6 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
11 1610-128-050A7 . . CIRCUIT BREAKER - ADF 76374 (172) 80001 & ON 01
(172S) 08001 & ON
(172S) 08001 & ON
13 S2878-8 . . NUT (172) 80001 & ON 06
(172S) 08001 & ON
14 6238373-3 . . BUS BAR HI908 (172) 80001 & ON 01
(172S) 08001 & ON
15 6238373-4 . . BUS BAR HI907 (172) 80001 & ON 01
(172S) 08001 & ON
16 MS35206-226 . . SCREW 80205 (172) 80001 & ON 02
(172S) 08001 & ON
Figure 03A
Page 3
24-61-00 Jul 7, 2022
CESSNA®
B2076
B
A
A
A
DETAIL A
75
76
AVN NAV NAV
FAN GPS COM1 COM 2 XPNDR ADF
81 82 83 84 85 86
87 87 87 87 87 87
VIEW A−A
78
80
91
79
89 90 88
VIEW B−B

A0518T1019
BB0518T1096

Figure 03A
Page 4
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
75 3930348-5 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL-NAV 1 WITH ADF (172) 80984 - 81496 01
- 75A 3930348-5 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL-NAV 1 WITH ADF (172S) 08704 - 10655 01
ATTACHING PARTS
76 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
- 77 3930343-2 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER NAV 2 (172) 80984 - 81496 01
- 77A 3930343-2 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER NAV 2 (172S) 08704 - 10655 01
(172S) 08001 & ON
79 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
80 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
86 1610-128-050A7 . . CIRCUIT BREAKER - ADF H1904 76374 (172) 80001 & ON 01
(172S) 08001 & ON
87 S2878-8 . . NUT (172) 80001 & ON 06
(172S) 08001 & ON
88 6238373-3 . . BUS BAR HI908 (172) 80001 & ON 01
(172S) 08001 & ON
89 6238373-4 . . BUS BAR HI907 (172) 80001 & ON 01
(172S) 08001 & ON
90 MS35206-226 . . SCREW 80205 (172) 80001 & ON 02
(172S) 08001 & ON
Figure 03A
Page 5
24-61-00 Jul 7, 2022
CESSNA®
24-61-00
AVIONICS CIRCUIT BREAKER PANEL-NAV 2 WITH IFR

Figure 04
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B127
B
A
A
DETAIL A
1
2
AVN AUTO NAV NAV
FAN PILOT GPS COM 1 COM 2 ADF XPNDR
7 8 9 10 11 12 13
14 14 14 14 14 14 14
VIEW A−A
4
6
17 15
16 17
VIEW B−B
AA0518T1097
BB0518T1097

Figure 04
Page 2
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
1 3930305-1 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL (172) 80001 - 80983 01

- 1A 3930305-1 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL (172S) 08001 - 08703 01
ATTACHING PARTS
2 CM3558-6-16B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
-3 3930421-1 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER NAV 2 (172) 80001 - 80983 01
- 3A 3930421-1 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER NAV 2 (172S) 08001 - 08703 01
(172S) 08001 & ON
-5 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
6 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
8 1610-128-050A7 . . CIRCUIT BREAKER - AUTOPILOT HI905 76374 (172) 80001 & ON 01
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
12 1610-128-050A7 . . CIRCUIT BREAKER - ADF HI903 76374 (172) 80001 & ON 01
(172S) 08001 & ON
(172S) 08001 & ON
14 S2878-8 . . NUT (172) 80001 & ON 07
(172S) 08001 & ON
15 6238373-3 . . BUS BAR HI908 (172) 80001 & ON 01
(172S) 08001 & ON
16 6238373-4 . . BUS BAR HI907 (172) 80001 & ON 01
(172S) 08001 & ON
17 MS35206-226 . . SCREW 80205 (172) 80001 & ON 02
(172S) 08001 & ON
Figure 04
Page 3
24-61-00 Jul 7, 2022
CESSNA®
B2075
B
A
A
A
DETAIL A
75
76
AVN NAV NAV AUTO

FAN GPS COM 1 COM 2 XPNDR PILOT
81 83 84 85 86 82
87 87 87 87 87
VIEW A−A
78
80 79 89
90 88
90
VIEW B−B
AA0518T1098
BB0518T1098

Figure 04
Page 4
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER

ATTACHING PARTS
76 CM3558-6-16B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
- 77 3930344-1 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER NAV 2 (172) 80984 & ON 01
- 77A 3930344-1 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER NAV 2 (172S) 08704 & ON 01
(172S) 08001 & ON
79 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
80 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
82 1610-128-050A7 . . CIRCUIT BREAKER - AUTO PILOT HI905 76374 (172) 80001 & ON 01
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
87 S2878-8 . . NUT (172) 80001 & ON 05
(172S) 08001 & ON
88 6238373-2 . . BUS BAR HI908 (172) 80001 & ON 01
(172S) 08001 & ON
89 6238373-3 . . BUS BAR HI907 (172) 80001 & ON 01
(172S) 08001 & ON
90 MS35206-226 . . SCREW 80205 (172) 80001 & ON 02
(172S) 08001 & ON
Figure 04
Page 5
24-61-00 Jul 7, 2022
CESSNA®
24-61-00
AVIONICS CIRCUIT BREAKER PANEL-NAV 2 WITH HSI

Figure 05
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B129
B
A
A
A
DETAIL A
1 2
AVN NAV NAV AUTO

FAN GPS COM1 ADF COM 2 XPNDR PILOT GYRO
7 8 9 10 11 12 13 13A
14 14 14 14 14 14 14
VIEW A−A
18 4
6
17 15 16 17
VIEW B−B
AA0518T1054
BB0518T1054

Figure 05
Page 2
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
1 3940369-1 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL/HSI (172) 80694 - 80983 01

- 1A 3940369-1 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL/HSI (172S) 08113 - 08703 01
ATTACHING PARTS
2 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
-3 3940368-1 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER (172) 80694 - 80983 01
4 3930312-1 . . MOUNTING PLATE ASSEMBLY (172) 80001 & ON 01
(172S) 08001 & ON
-5 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
6 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
13 MS26574-5 . . CIRCUIT BREAKER - AUTOPILOT HI905 76374 (172) 80001 & ON 01
(172S) 08001 & ON
13A 1610-128-050A7 . . CIRCUIT BREAKER - GYRO HI911 76374 (172) 80001 & ON 01
(172S) 08001 & ON
14 S2878-8 . . NUT (172) 80001 & ON 07
(172S) 08001 & ON
15 6238373-2 . . BUS BAR HI909 (172) 80001 & ON 01
(172S) 08001 & ON
16 6238373-4 . . BUS BAR HI907 (172) 80001 & ON 01
(172S) 08001 & ON
17 MS35206-226 . . SCREW 80205 (172) 80001 & ON 02
(172S) 08001 & ON
18 . C/A POWER - REFER TO WIRING DIAGRAM MANUAL RF
Figure 05
Page 3
24-61-00 Jul 7, 2022
CESSNA®
B2074
B
A
A
A
DETAIL A
75
76
AVN NAV NAV AUTO

FAN GPS GYRO COM 1 COM 2 XPNDR PILOT
81 82 83 84 85 86 87
88 88 88 88 88 88 88
VIEW A−A
78
92
80
79 91 89 91 90
VIEW B−B
AA0518T1094
BB0518T1094

Figure 05
Page 4
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
75 3930348-11 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL NAV 2 W/HSI (172) 80984 & ON 01
- 75A 3930348-11 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL NAV 2 W/HSI (172S) 08704 & ON 01
ATTACHING PARTS
76 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
- 77 3930344-1 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER (172) 80694 - 80983 01
(172S) 08001 & ON
79 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
80 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
83 1610-128-050A7 . . CIRCUIT BREAKER - GYRO HI911 76374 (172) 80001 & ON 01
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
88 S2878-8 . . NUT (172) 80001 & ON 06
(172S) 08001 & ON
89 6238373-2 . . BUS BAR HI918 (172) 80001 & ON 01
(172S) 08001 & ON
90 6238373-4 . . BUS BAR HI920 (172) 80001 & ON 01
(172S) 08001 & ON
91 MS35206-226 . . SCREW 80205 (172) 80001 & ON 03
(172S) 08001 & ON
Figure 05
Page 5
24-61-00 Jul 7, 2022
CESSNA®
24-61-00
AVIONICS CIRCUIT BREAKER

Figure 06
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B130
B
A
A
A
DETAIL A
1
2
AVN NAV NAV AUTO
FAN GPS COM 1 COM 2 ADF XPOND PILOT
7 8 9 11 10 12 13
14 14 14 14 14 14
VIEW A−A
5
4 17 15 16 17
6
VIEW B−B
0510T1007
AA0518T1067
BB0518T1067

Figure 06
Page 2
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER

(172S) 08001 & ON
ATTACHING PARTS
2 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
(172S) 08001 & ON
(172S) 08001 & ON
5 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
6 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
14 S2878-8 . . NUT (172) 80001 & ON 06
(172S) 08001 & ON
15 6238373-3 . . BUS BAR HI908 (172) 80001 & ON 01
(172S) 08001 & ON
16 6238373-3 . . BUS BAR HI907 (172) 80001 & ON 01
(172S) 08001 & ON
17 MS35206-226 . . SCREW 80205 (172) 80001 & ON 03
(172S) 08001 & ON
Figure 06
Page 3
24-61-00 Jul 7, 2022
CESSNA®
B2072
B
A
A
A
DETAIL A
76
AVN NAV NAV AUTO

FAN GPS COM 1 COM 2 XPNDR ADF PILOT
75 81 82 83 85 86 84 87
88 88 88 88 88 88
VIEW A−A
78 80 79 91 89 91 90
VIEW B−B
0510T1007
AIRPLANES 17280984 AND ON AND A0518T1019
BB0518T1102

Figure 06
Page 4
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
75 3930348-9 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL NAV 2 WITH ADF (172S) 08348 - 08703 01
ATTACHING PARTS
76 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
- 77 3930344-2 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER (172) 80001 & ON 01
(172S) 08001 & ON
(172S) 08001 & ON
79 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
80 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
88 S2878-8 . . NUT (172) 80001 & ON 06
(172S) 08001 & ON
89 6238373-3 . . BUS BAR HI908 (172) 80001 & ON 01
(172S) 08001 & ON
90 6238373-3 . . BUS BAR HI907 (172) 80001 & ON 01
(172S) 08001 & ON
91 MS35206-226 . . SCREW 80205 (172) 80001 & ON 03
(172S) 08001 & ON
Figure 06
Page 5
24-61-00 Jul 7, 2022
CESSNA®
24-61-00
AVIONICS CIRCUIT BREAKER PANEL-NAV 2 WITH HSI/

ADF
Figure 07
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B2073
B
A
A
A
DETAIL A
2
AVN NAV NAV AUTO
FAN GPS GYRO COM 1 COM 2 XPNDR PILOT ADF
7 8 13A 9 11 12 13 10
14 14 14 14 14 14 14
VIEW A−A
4 5
18
6 17 15 17 16
VIEW B−B
AIRPLANES 17280984 AND ON AND
0510T1007
AA0518T1101
BB0518T1101
AVIONICS CIRCUIT BREAKER PANEL-NAV 2 WITH HSI/ADF

Figure 07
Page 2
24-61-00 Jul 7, 2022
CESSNA®
AVIONICS CIRCUIT BREAKER PANEL-NAV 2 WITH HSI/ADF
UNITS
NOMENCLATURE
PER
1 3930348-13 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL W/HSI/ADF (172) 80984 & ON 01
- 1A 3930348-13 . BEZEL - AVIONICS CIRCUIT BREAKER PANEL W/HSI/ADF (172S) 08704 & ON 01
ATTACHING PARTS
2 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
- 3A 3940368-1 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER (172S) 08704 & ON 01
(172S) 08001 & ON
5 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
6 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
13A 1610-128-050A7 . . CIRCUIT BREAKER - GYRO HI911 76374 (172) 80001 & ON 01
(172S) 08001 & ON
14 S2878-8 . . NUT (172) 80001 & ON 07
(172S) 08001 & ON
15 6238373-2 . . BUS BAR HI909 (172) 80001 & ON 01
(172S) 08001 & ON
16 6238373-4 . . BUS BAR HI907 (172) 80001 & ON 01
(172S) 08001 & ON
17 MS35206-226 . . SCREW 80205 (172) 80001 & ON 03
(172S) 08001 & ON
Figure 07
Page 3
24-61-00 Jul 7, 2022
CESSNA®
24-61-00
AVIONICS CIRCUIT BREAKER PANEL-NAV 2 WITH MFD

Figure 08
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B3415
B
A
B
A
DETAIL A
2 2
AVN NAV NAV AUTO
FAN GPS COM 1 COM 2 XPONDER MFD PILOT
2
7 8 9 10 11 12 13
14 14 14 14 14 14
VIEW A−A
4 6
16 15A 16 15
5 6
VIEW B−B
AA0518T1077
BB0518T1076

Figure 08
Page 2
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
1 3930348-21 . BEZEL - NAV 2 W/MFD (172) 81098 & ON 01

- 1A 3930348-21 . BEZEL - NAV 2 W/MFD (172S) 09063 & ON 01
ATTACHING PARTS
2 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
-3 3930344-5 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER NAV 2 W/MFD (172) 80001 & ON 01
(172S) 08001 & ON
(172S) 08001 & ON
5 MS21071-06-4 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
6 MS21069-06-4 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
11 1610-128-050A7 . . CIRCUIT BREAKER - XPNDR HI904 76374 (172) 80001 & ON 01
(172S) 08001 & ON
12 1610-128-050A7 . . CIRCUIT BREAKER - MFD HI921 76374 (172) 80001 & ON 01
(172S) 08001 & ON
(172S) 08001 & ON
14 S2878-8 . . NUT (172) 80001 & ON 06
(172S) 08001 & ON
15 6238373-3 . . BUS BAR HI919 (172) 80001 & ON 01
(172S) 08001 & ON
15A 6238373-3 . . BUS BAR HI908 (172) 80001 & ON 01
(172S) 08001 & ON
16 MS35206-226 . . SCREW 80205 (172) 80001 & ON 03
(172S) 08001 & ON
Figure 08
Page 3
24-61-00 Jul 7, 2022
CESSNA®
24-61-00
AVIONICS CIRCUIT BREAKER PANEL-NAV 2 WITH ADF/

MFD
Figure 09
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B3416
B
A
B
A
A
DETAIL A
2 2
AVN NAV NAV AUTO
FAN GPS COM 1 COM 2 XPNDR ADF PILOT MFD
2
7 8 9 10 11 12 13 14
15 15 15 15 15 15 15
VIEW A−A
4 6 6
5
5
5
6 17 16A 17 6 17 16
VIEW B−B
AIRPLANES17281098 AND ON AND 0510T1007
AIRPLANES172S9063 AND ON A0518T1019
AA0518T1079
BB0518T1078
AVIONICS CIRCUIT BREAKER PANEL-NAV 2 WITH ADF/MFD

Figure 09
Page 2
24-61-00 Jul 7, 2022
CESSNA®
AVIONICS CIRCUIT BREAKER PANEL-NAV 2 WITH ADF/MFD
UNITS
NOMENCLATURE
PER
1 3930348-23 . BEZEL - NAV 2 W/ADF/MFD (172) 81098 & ON 01

- 1A 3930348-23 . BEZEL - NAV 2 W/ADF/MFD (172S) 09063 & ON 01
ATTACHING PARTS
2 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
-3 3930344-6 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER NAV 2 W/ADF/ (172) 80001 & ON 01
MFD (172S) 08001 & ON
(172S) 08001 & ON
5 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
6 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
15 S2878-8 . . NUT (172) 80001 & ON 07
(172S) 08001 & ON
16 6238373-3 . . BUS BAR HI919 (172) 80001 & ON 01
(172S) 08001 & ON
16A 6238373-3 . . BUS BAR HI908 (172) 80001 & ON 01
(172S) 08001 & ON
17 MS35206-226 . . SCREW 80205 (172) 80001 & ON 03
(172S) 08001 & ON
Figure 09
Page 3
24-61-00 Jul 7, 2022
CESSNA®
24-61-00

ADF/MFD
Figure 10
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B3417
B
A
B
A
A
DETAIL A
2 2
AVN NAV NAV AUTO
FAN GPS GYRO COM 1 COM 2 XPNDR PILOT ADF MDF
7 8 9 10 11 12 13 14 15 2
16 16 16 16 16 16 16 16
VIEW A−A
6
4 6
5
18 17A 18 6 17
VIEW B−B
AA0518T1082
BB0518T1082
AVIONICS CIRCUIT BREAKER PANEL-NAV 2 WITH HSI/ADF/MFD

Figure 10
Page 2
24-61-00 Jul 7, 2022
CESSNA®
AVIONICS CIRCUIT BREAKER PANEL-NAV 2 WITH HSI/ADF/MFD
UNITS
NOMENCLATURE
PER
1 3930348-27 . BEZEL - NAV 2 W/HSI/ADF/MFD (172) 81098 & ON 01

- 1A 3930348-27 . BEZEL - NAV 2 W/HSI/ADF/MFD (172S) 09063 & ON 01
ATTACHING PARTS
2 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
-3 3930344-7 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER NAV 2 W/HSI/ (172) 80001 & ON 01
ADF/MFD (172S) 08001 & ON
(172S) 08001 & ON
5 MS21071-06-4 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
6 MS21069-06-4 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
16 S2878-8 . . NUT (172) 80001 & ON 08
(172S) 08001 & ON
17 6238373-4 . . BUS BAR HI919 (172) 80001 & ON 01
(172S) 08001 & ON
17A 6238373-2 . . BUS BAR HI908 (172) 80001 & ON 01
(172S) 08001 & ON
18 MS35206-226 . . SCREW 80205 (172) 80001 & ON 03
(172S) 08001 & ON
Figure 10
Page 3
24-61-00 Jul 7, 2022
CESSNA®
24-61-00

MFD
Figure 11
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B3418
B
A
B
A
A
DETAIL A
2 2
AVN NAV NAV AUTO
FAN GPS GYRO COM 1 COM 2 XPNDR PILOT MFD
2
7 8 9 10 11 12 13 14
15 15 15 15 15 15 15
VIEW A−A
4 6 6
5
5
17 17 6 16
16A
VIEW B−B
A0518T1019
BB0518T1075
AVIONICS CIRCUIT BREAKER PANEL-NAV 2 WITH HSI/MFD

Figure 11
Page 2
24-61-00 Jul 7, 2022
CESSNA®
AVIONICS CIRCUIT BREAKER PANEL-NAV 2 WITH HSI/MFD
UNITS
NOMENCLATURE
PER
1 3930348-25 . BEZEL - NAV 2 W/HSI/MFD (172) 81098 & ON 01

- 1A 3930348-25 . BEZEL - NAV 2 W/HSI/MFD (172S) 09063 & ON 01
ATTACHING PARTS
2 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
-3 3930344-8 . PANEL ASSEMBLY - AVIONICS CIRCUIT BREAKER NAV 2 W/HSI/ (172) 80001 & ON 01
MFD (172S) 08001 & ON
(172S) 08001 & ON
5 MS21071-06-4 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
6 MS21069-06-4 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
15 S2878-8 . . NUT (172) 80001 & ON 07
(172S) 08001 & ON
16 6238373-4 . . BUS BAR HI919 (172) 80001 & ON 01
(172S) 08001 & ON
16A 6238373-2 . . BUS BAR HI908 (172) 80001 & ON 01
(172S) 08001 & ON
17 MS35206-226 . . SCREW 80205 (172) 80001 & ON 03
(172S) 08001 & ON
Figure 11
Page 3
24-61-00 Jul 7, 2022
CESSNA®
24-61-00
AVIONICS CIRCUIT BREAKER PANEL-NAV II WITH HSI/

MFD/FIS
Figure 12
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B4174
B
A
A
A
1
DETAIL A
2
AVN NAV NAV AUTO

FAN GPS GYRO COM 1 COM 2 XPNDR PILOT MFD IHAS
7 9 10 13 14 8 16 11 12
VIEW A−A
20 5 4 17 19 18
DETAIL B−B 0510T1007

A0518T1019
AA0518T1147
BB0518T1148
AVIONICS CIRCUIT BREAKER PANEL-NAV II WITH HSI/MFD/FIS

Figure 12
Page 2
24-61-00 Jul 7, 2022
CESSNA®
AVIONICS CIRCUIT BREAKER PANEL-NAV II WITH HSI/MFD/FIS
UNITS
NOMENCLATURE
PER
1 3930348-29 . BEZEL - NAV II W/IHAS (172) 80001 & ON 01

(172S) 08001 & ON
ATTACHING PARTS
2 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
-3 3930347-3 . CIRCUIT BREAKER PANEL ASSEMBLY - AVIONICS (172) 80001 & ON 01
(172S) 08001 & ON
(172S) 08001 & ON
5 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
6 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
7 1610-128-050A7 . . CIRCUIT BREAKER HI906 76374 (172) 80001 & ON 01
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
- 15 S2878-8 . . NUT (172) 80001 & ON 08
(172S) 08001 & ON
16 MS26574-5 . . CIRCUIT BREAKER HI916 76374 (172) 80001 & ON 01
(172S) 08001 & ON
17 6238373-2 . . BUS BAR (172) 80001 & ON 01
(172S) 08001 & ON
18 6238373-4 . . BUS BAR (172) 80001 & ON 01
(172S) 08001 & ON
19 MS35206-226 . . SCREW 80205 (172) 80001 & ON 03
(172S) 08001 & ON
20 3929133-1 . . AVIONICS POWER CABLE ASSEMBLY (172) 80001 & ON 01
(172S) 08001 & ON
Figure 12
Page 3
24-61-00 Jul 7, 2022
CESSNA®
24-61-00
AVIONICS CIRCUIT BREAKER-NAV II WITH HSI/MFD/FIS/

ADF
Figure 13
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B4177
B
A
A
A
1
DETAIL A
2
AVN NAV NAV AUTO

FAN GPS GYRO COM 1 COM 2 XPNDR PILOT ADF MFD IHAS
7 9 10 14 15 8 21 11 12 13
VIEW A−A
20 17 20 19
22 5 4 18
0510T1007
A0518T1019
DETAIL B−B AA0518T1145
BB0518T1146
AVIONICS CIRCUIT BREAKER-NAV II WITH HSI/MFD/FIS/ADF

Figure 13
Page 2
24-61-00 Jul 7, 2022
CESSNA®
AVIONICS CIRCUIT BREAKER-NAV II WITH HSI/MFD/FIS/ADF
UNITS
NOMENCLATURE
PER
1 3930348-30 . BEZEL (172) 80001 & ON 01

(172S) 08001 & ON
ATTACHING PARTS
2 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
-3 3930347-4 . AVIONICS CIRCUIT BREAKER PANEL ASSEMBLY (172) 80001 & ON 01
(172S) 08001 & ON
(172S) 08001 & ON
5 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
6 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
- 16 S2878-8 . . NUT (172) 80001 & ON 09
(172S) 08001 & ON
17 6238373-2 . . BUS BAR HI918 (172) 80001 & ON 01
(172S) 08001 & ON
18 6238373-3 . . BUS BAR HI918 (172) 80001 & ON 01
(172S) 08001 & ON
19 6238373-4 . . BUS BAR HI920 (172) 80001 & ON 01
(172S) 08001 & ON
20 MS35206-226 . . SCREW 80205 (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
Figure 13
Page 3
24-61-00 Jul 7, 2022
CESSNA®
24-61-00
AVIONICS CIRCUIT BREAKER-NAV II WITH MFD/FIS

Figure 14
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B4175
B
A
A
A
DETAIL A
1
2
AVN NAV NAV AUTO

FAN GPS COM 1 COM 2 XPNDR MFD PILOT IHAS
8 9 13 14 10 11 7 12
VIEW A−A
19
17 5 4 6 15 16
0510T1007
A0518T1019
BB0518T1144

Figure 14
Page 2
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
1 3930348-34 . BEZEL (172) 80001 & ON 01

(172S) 08001 & ON
ATTACHING PARTS
2 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
(172S) 08001 & ON
(172S) 08001 & ON
5 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
6 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
15 6238373-3 . . BUS BAR HI919 (172) 80001 & ON 01
(172S) 08001 & ON
16 6238373-3 . . BUS BAR HI908 (172) 80001 & ON 01
(172S) 08001 & ON
(172S) 08001 & ON
- 18 S2878-8 . . NUT (172) 80001 & ON 08
(172S) 08001 & ON
19 MS35206-226 . . SCREW 80205 (172) 80001 & ON 04
(172S) 08001 & ON
Figure 14
Page 3
24-61-00 Jul 7, 2022
CESSNA®
24-61-00
AVIONICS CIRCUIT BREAKER-NAV II WITH MFD/FIS/ADF

Figure 15
Page 1
24-61-00 Jul 7, 2022
CESSNA®
B4176
B
A
A
A
1 DETAIL A
2
AVN NAV NAV AUTO STRM

FAN GPS GYRO COM 1 COM 2 XPNDR PILOT SCOPE ADF
AVIONICS
9 10 15 16 11 14 7 12 13
VIEW A−A
19
5 4 6 17 18
0510T1007
A0518T1019
BB0518T1142

Figure 15
Page 2
24-61-00 Jul 7, 2022
CESSNA®
UNITS
NOMENCLATURE
PER
1 3930348-36 . BEZEL (172) 80001 & ON 01

(172S) 08001 & ON
ATTACHING PARTS
2 CM3558-6-6B . SCREW (172) 80001 & ON 08
(172S) 08001 & ON
--*--
(172S) 08001 & ON
(172S) 08001 & ON
5 MS21071-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
6 MS21069-06 . . . NUTPLATE (172) 80001 & ON 04
(172S) 08001 & ON
(172S) 08001 & ON
-8 S2878-8 . . NUT (172) 80001 & ON 07
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
(172S) 08001 & ON
17 6238373-3 . . BUS BAR HI919 (172) 80001 & ON 01
(172S) 08001 & ON
18 6238373-3 . . BUS BAR HI908 (172) 80001 & ON 01
(172S) 08001 & ON
19 MS35206-226 . . SCREW 80205 (172) 80001 & ON 04
(172S) 08001 & ON
Figure 15
Page 3
24-61-00 Jul 7, 2022

Electrical Power

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Electrical Power

Uploaded by

Copyright:

Available Formats

CHAPTER

RECORD OF TEMPORARY REVISIONS

AIRPLANES (172R) 80001 & ON AND AIRPLANES (172S) 08001 & ON

1 9910591-5 . ALTERNATOR ASSEMBLY (172) 80001 - 80325 NP

AIRPLANES (172R) 80001 & ON AND AIRPLANES (172S) 08001 & ON

- 16A S1915-3 . CAPACITOR (172S) 08050 & ON 01

AIRPLANES (172R) 80001 & ON AND AIRPLANES (172S) 08001 & ON

AIRPLANES (172R) 80001 & ON AND AIRPLANES (172S) 08001 & ON

- 17A S1053K8T . DUCT (172) 80001 & ON AR

STANDBY BATTERY INSTALLATION-NAV III

STANDBY BATTERY INSTALLATION-NAV III

STANDBY BATTERY INSTALLATION-NAV III

AIRPLANES (172R) 81241 & ON AND AIRPLANES (172S) 09810 & ON

1 AVT-200413 . BATTERY PACK UC005 0MBZ4 (172) 81241 - 81563 01

POWER JUNCTION BOX INSTALLATION

POWER JUNCTION BOX INSTALLATION

POWER JUNCTION BOX INSTALLATION

AIRPLANES (172R) 80001 & ON AND AIRPLANES (172S) 08001 & ON

1 MC01-1 . MASTER CONTROL UNIT 3RCD2 (172) 80001 - 80003 01

AIRPLANES (172R) 80001 & ON AND AIRPLANES (172S) 08001 & ON

AIRPLANES (172R) 80001 & ON AND AIRPLANES (172S) 08001 & ON

8 X61-0007 . . CONTACTOR - BATTERY 3RCD2 (172) 80001 & ON 01

POWER CONVERTER INSTALLATION

POWER CONVERTER INSTALLATION

POWER CONVERTER INSTALLATION

AIRPLANES (172R) 80001 & ON AND AIRPLANES (172S) 08001 & ON

1 0518021-1 . POWER CONVERTER ASSEMBLY (172) 80984 & ON 01

CIRCUIT BREAKER PANEL ASSEMBLY

CIRCUIT BREAKER PANEL ASSEMBLY

CIRCUIT BREAKER PANEL ASSEMBLY

AIRPLANES (172R) 80001 & ON AND AIRPLANES (172S) 08001 & ON

-1 0518003-1 . CIRCUIT PANEL ASSEMBLY - CIRCUIT BREAKER (172) 80001 - 80003 01

AIRPLANES (172R) 80001 & ON AND AIRPLANES (172S) 08001 & ON

7 CM3589-5 . . CIRCUIT BREAKER - FUEL PUMP HI012 (172) 80001 & ON 01

AIRPLANES (172R) 80001 & ON AND AIRPLANES (172S) 08001 & ON

30 6238373-3 . . BUS BAR HI014 (172) 80001 & ON 01

AIRPLANES (172R) 80001 & ON AND AIRPLANES (172S) 08001 & ON

36 0518022-1 . COVER - CIRCUIT BREAKER BACK (172) 80069 - 80073 01

AIRPLANES (172R) 80001 & ON AND AIRPLANES (172S) 08001 & ON

(172) *80611 - 80612

CIRCUIT BREAKER PANEL ASSEMBLY

CIRCUIT BREAKER PANEL ASSEMBLY

CIRCUIT BREAKER PANEL ASSEMBLY

AIRPLANES (172R) 80984 & ON AND AIRPLANES (172S) 08704 & ON

-1 0518003-7 . CIRCUIT PANEL ASSEMBLY (172) 80984 & ON 01

AIRPLANES (172R) 80984 & ON AND AIRPLANES (172S) 08704 & ON

25 MS35650-305T . . NUT 80205 (172) 80984 & ON 01

CIRCUIT BREAKER PANEL ASSEMBLY-NAV III

AL T AD C NAV I STDB Y STDB Y

CIRCUIT BREAKER PANEL ASSEMBLY-NAV III

CIRCUIT BREAKER PANEL ASSEMBLY-NAV III

AIRPLANES (172R) 81241 & ON AND AIRPLANES (172S) 09810 & ON

AIRPLANES (172R) 81241 & ON AND AIRPLANES (172S) 09810 & ON

20 1N6391 . . DIODE DI007 (172) 81241 & ON 01

ALT ADC NAV I STDBY STDBY

PITOT NAV TAXI STROBE PANEL AVN AUTO

CIRCUIT BREAKER PANEL ASSEMBLY-NAV III

CIRCUIT BREAKER PANEL ASSEMBLY-NAV III

AIRPLANES (172R) 81241 & ON AND AIRPLANES (172S) 09810 & ON

AIRPLANES (172R) 81241 & ON AND AIRPLANES (172S) 09810 & ON

91 CM2692-16P2S . PLUG BUTTON (172) 81241 & ON NP

AVIONICS CIRCUIT BREAKER PANEL-STANDARD

AVIONICS CIRCUIT BREAKER PANEL-STANDARD
