Date: Jan 13 2024

Job: Eye level tutor center

Equipment list for project: Eye level tutor center - Dated: Jan 13 2024

Units

Tag No Model No Qty Description

RA13NZ: 13NZ SEER2 split condenser matched with air
handler
RA13NZ36AJ1NA
CU - 1 1 AH Model: RH1T3621HTANJA
RH1T3621HTANJA
Voltage: 208-230V - 1PH - 60Hz
Factory Options: None

Accessories

Tag No Field Model Description

Notes
 Jan 13 2024

Performance Summary

Tag: CU - 1 Model No: RA13NZ36AJ1NA / RH1T3621HTANJA

Project: Eye level tutor center City: AUSTIN/MUELLER MUNI State: TX AHRI Ref: 211903041
Altitude: 495 Air Discharge: Upflow/Downflow/Horizontal

Cooling Performance

AHRI Rating - Capacity: 34,200 EER2: 13 SEER2: 16

Ambient Air (F) - Dry Bulb: 98.2 Wet Bulb: 74.7
Airflow (CFM) - CFM: 1,200 SCFM: 1,045 OA CFM: 265
System Entering Air (F) - Dry Bulb: 79.1 Wet Bulb: 68.6 % RH: 59.3
System Leaving Air (F) - Dry Bulb: 57.7 Wet Bulb: 57.2
Air Enthalpy (btu/lb) - Entering: 32.8 Leaving: 24.5
Design Net Cooling Capacity (btuh) - Total: 38,700 Sensible: 24,100 Latent: 14,600
Design Gross Capacity (btuh) - Capacity: 39,600 Sensible: 25,000
Total Power - Watts: 2,965.3 KW: 3

Heating Performance

Electric Heat Input - KW: 10.8

Heating Airflow (CFM) - CFM: 1,045
Air Dry Bulb (F) - Outdoor: 29.8 Entering Air: 62.7 Leaving Air: 96
Air Temperature Rise (F) - Rise: 33.4
Capacity (btuh) - Total: 37,660
Total Heating Power - Watts: 11,038 KW: 11

Air Moving System Characteristics

External Static Pressure (inches WG) - ESP: 0.5

Blower Speed or Speed Tap - Tap: High Drive: Direct
Motor Characteristic (watts & BHP) - Power: 237.5

Electrical Supply

Ampacity & Overcurrent Protection @ 208 Volts

Outdoor Unit Power Supply (Volt/Hz/Ph) - 208-230/60/1
Outdoor Unit Min Ampacity (amps) - 21
Max Overcurrent Protection (amps) - Fuse: 35 HACR Breaker: 35
Field Installed Electric Heater Kit - RXBH-1724A15C
Power Supply (Voltage/Hz/Ph) - 208/60/3 (Single circuit power supply for air handlers & heaters)
Minimum Ampacity (amps) - 43
Max Overcurrent Protection (amps) - Fuse: 45
Dimensions, Weight & Clearances

Dimensions - Length: 33.75 Width: 33.75 Height: 25

Outdoor Unit Weight (lb) - Weight: 186
Air Handler Dimensions (inches) - Length: 21.6875 Width: 21 Height: 57
Air Handler Weight (lb) - Weight: 137
Outdoor Unit Clearances (inches) - Sides: 24 Top: 36

Product Submittal #: c1152398-2037-4fae-ab2d-dab9b0abc80c

Submittal Printed on: 1/13/2024 4:07:55 PM
For Model: RA13NZ36AJ1NA
In keeping with its policy of continous progress and product improvement, reserves the right to make changes without notice.
Gross capacity does not include the effect of motor heat. AHRI rating is net capacity and includes the effect of fan motor heat. All net capacities also accounts for the effect of motor
heat.
ASHRAE Weather Data © 2009 American Society of Heating, Refrigerating and Air-Conditioning Engineers, Inc., Atlanta, GA, USA. www.ashrae.org All rights reserved. Used by
permission in this program.
 Model: RA13NZ36AJ1NA

Endeavor™ Line Classic® Series

iM Air Conditioners

RA13NZ
Cooling Efficiency: 15.2 SEER2/12 EER2
Nominal Sizes: 1.5 to 5 Ton [5.3 to 17.6 kW]
Cooling Capacities: 17.1 to 55.5 kBTU [5.0 to 16.3 kW]
 Model: RA13NZ36AJ1NA

Unit Dimensions
OPERATING SHIPPING
Model
H (Height) L (Length) W (Width) H (Height) L (Length) W (Width)
No.
INCHES mm INCHES mm INCHES mm INCHES mm INCHES mm INCHES mm
RA13NZ18 25.00 635 29.75 756 29.75 756 26.50 673 32.38 822 32.38 822
RA13NZ24 25.00 635 33.75 857 33.75 857 26.50 673 36.38 924 36.38 924
RA13NZ30 25.00 635 33.75 857 33.75 857 26.50 673 36.38 924 36.38 924
RA13NZ36 25.00 635 33.75 857 33.75 857 26.50 673 36.38 924 36.38 924
RA13NZ42 27.00 686 33.75 857 33.75 857 28.50 724 36.38 924 36.38 924
RA13NZ48 39.00 991 35.75 908 35.75 908 40.50 1029 38.38 975 38.38 975
RA13NZ60 45.00 1143 35.75 908 35.75 908 46.50 1181 38.38 975 38.38 975

Unit
MODEL OPERATING SHIPPING
NO. H (Height) L (Length) W (Width) H (Height) L (Length)
INCHES mm INCHES mm INCHES mm INCHES mm INCHES
RA13NZ18 25 635 29.75 756 29.75 756 26.5 673 32.38
RA13NZ24 25 635 33.75 857 33.75 857 26.5 673 36.38
RA13NZ30 25 635 33.75 857 33.75 857 26.5 673 36.38
RA13NZ35 25 635 33.75 857 33.75 857 26.5 673 36.38
RA13NZ36 35 889 33.75 857 33.75 857 36.5 927 36.38
RA13NZ42 27 686 33.75 857 33.75 857 28.5 724 36.38
RA13NZ48 39 991 35.75 908 35.75 908 40.5 1029 38.38
RA13NZ60 45 1143 35.75 908 35.75 908 46.5 1181 38.38

[   ] Designates Metric Conversions ST-A1226-02-00

 Model: RH1T3621HTANJA

Unit Dimensions
ELECTRICAL CONNECTIONS SUPPLY AIR
NOTE: 24 CLEARANCE REQUIRED IN FRONT OF
MAY EXIT TOP OR EITHER SIDE
UNIT FOR FILTER AND COIL MAINTENANCE.
HIGH VOLTAGE CONNECTION 7/8 [22.2 mm],
13/32 [27.8 mm], 131/32 [50 mm] DIA. KNOCKOUTS. 105/16
[262 mm]
W

A
LOW VOLTAGE CONNECTION
5/8 [15.9 mm] AND 7/8 [22.2 mm] KNOCKOUT
Return Air Opening Dimensions
Return Air Return Air Opening
Model
Opening Width Depth/Length
Cabinet Size
(Inches) (Inches)
17 157/8 193/4
21 193/8 193/4
24 227/8 193/4

AUXILIARY DRAIN CONNECTION

3/4 [19.1 mm] FEMALE PIPE THREAD (NPT)
HORIZONTAL APPLICATION ONLY

PRIMARY DRAIN CONNECTION

3/4
[19.1 mm] FEMALE PIPE THREAD (NPT)

AUXILIARY DRAIN CONNECTION

3/4 [19.1 mm] FEMALE PIPE THREAD (NPT)
191/2 [495 mm]
UPFLOW/DOWNFLOW APPLICATION ONLY
RETURN AIR
OPENING 2111/16
[551 mm]
LIQUID LINE CONNECTION
COPPER (SWEAT)

VAPOR LINE CONNECTION

COPPER (SWEAT)
UPFLOW UNIT SHOWN:
UNIT MAY BE INSTALLED UPFLOW, DOWNFLOW,
HORIZONTAL RIGHT OR LEFT AIR SUPPLY.

515/16
[151 mm] 41/8
[105 mm] 3 /16
1
[76 mm] 13/16 [48 mm] 11/8 [29 mm]
HORIZONTAL ADAPTER KIT
11/16
[27 mm]
13/8
[35 mm]
213/16
[71 mm] 51/4
[133 mm]
53/8
VAPOR LINE [136 mm]
CONNECTION

AUXILIARY HORIZONTAL UPFLOW UNIT SHOWN:

DRAIN CONNECTION UNIT MAY BE INSTALLED UPFLOW,
DOWNFLOW, HORIZONTAL RIGHT
OR LEFT AIR SUPPLY.

[ ] Designates Metric Conversions

( ) Designates Unit with Double Coil Cabinet
PRIMARY DRAIN
CONNECTION LIQUID LINE VERTICAL DRAIN PAN
CONNECTION

AUXILIARY UPFLOW/DOWNFLOW
DRAIN CONNECTION
 Model: RH1T3621HTANJA

Unit Dimensions & Weights

Refrigerant Connections [ ] Air Flow
Designates Unit Weight/Shipping Weight
Metric Conversions
Model Sweat (In.) [mm] ID Unit Unit Supply CFM (Nom.) [L/s] (Lbs.) [kg]
Size Width Height Duct ( ) Designates Unit with Double Coil Cabinet
RH1T “W” In. [mm] “H” In. [mm] “A” In. [mm] Unit With
Liquid
Unit Dimensions & Weights Vapor Lo Hi
Coil (Max. KW)
2417ST 3/8 [9.53] 3/4 [19.05] 171/2 [445] 421/2 [1080] 161/2 [406] 600 [283] 800 [378] 92/106 [42/48]
3617ST 3/8 [9.53] 3/4 [19.05] 171/2 [445] 421/2 [1080] 161/2 [406] 1000 [472] 1200 [566] 96/110 [44/50]
3621HT 3/8 [9.53] 7/8 [22.23] 211/2 [533] 571/2 [1448] 191/2 [495] 1000 [472] 1200 [566] 137/149 [62/68]
3621MT 3/8 [9.53] 7/8 [22.23] 211/2 [533] 501/2 [1282] 191/2 [495] 1000 [472] 1200 [566] 126/142 [57/64]
4821MT 3/8 [9.53] 7/8 [22.23] 211/2 [533] 571/2 [1448] 191/2 [495] 1400 [661] 1600 [755] 139/151 [63/68]
4821ST 3/8 [9.53] 7/8 [22.23] 211/2 [533] 501/2 [1282] 191/2 [495] 1400 [661] 1600 [755] 128/144 [56/65]
4824ST 3/8 [9.53] 7/8 [22.23] 241/2 [622] 501/2 [1282] 231/2 [585] 1600 [755] — 142/160 [64/72]
6021ST 3/8 [9.53] 7/8 [22.23] 211/2 [533] 571/2 [1448] 191/2 [495] 1600 [755] 1725 [814] 139/151 [63/68]
6024ST 3/8 [9.53] 7/8 [22.23] 241/2 [622] 551/2 [1410] 231/2 [585] — 1800 [850] 159/176 [72/80]
*Maximum dehumidification airflow.

Unit Dimensions & Weights

Refrigerant Connections Air Flow Unit Weight/Shipping Weight
Model Sweat (In.) [mm] ID Unit Unit Supply CFM (Nom.) [L/s] (Lbs.) [kg]
Size Width Height Duct
RH2T “W” In. [mm] “H” In. [mm] “A” In. [mm] Unit With
Liquid Vapor Lo Hi
Coil (Max. KW)
2421MT 3/8 [9.53] 3/4 [19.05] 211/2 [533] 421/2 [1080] 191/2 [495] 525 [248] 700 [330] 111/126 [50/57]
3621MT 3/8 [9.53] 7/8 [22.23] 211/2 [533] 501/2 [1282] 191/2 [495] 800 [377] 1050 [495] 129/145 [59/66]
4824MT 3/8 [9.53] 7/8 [22.23] 241/2 [622] 551/2 [1410] 231/2 [584] 1050 [495] 1400 [660] 128/146 [58/66]
6024ST 3/8 [9.53] 7/8 [22.23] 241/2 [622] 551/2 [1410] 231/2 [584] 1200 [566] 1600 [755] 161/178 [73/81]

[ ] Designates Metric Conversions

 Model: RH1T3621HTANJA

RH1T/RH2T- Series
Constant Torque Motor (ECM)
Efficiencies up to 16 SEER

• RH1T/RH2T feature a Constant Torque motor (ECM) which
provides enhanced SEER performance with most Rheem out-
door units.
• Versatile 4-way convertible design for upflow, downflow,
horizontal left and horizontal right applications.
• Factory-installed indoor coil.
• Sturdy cabinet construction with 1.0 inch [25.4 mm] of
foil faced insulation for excellent sound and insulating
characteristics.
• Field-installed auxiliary electric heater kits provide exact heat
for indoor comfort. Kits include circuit breakers which meet
U.L. and cUL requirements for service disconnect.
• 11/2 ton [5.3 kW] through 5 ton [17.6 kW] models are between
421/2 to 57 inches [1080 to 1448 mm] tall and 22 inches
[559 mm] deep.
• All models meet or exceed 330 to 400 CFM [156 to 189 L/s]
per ton at .3 inches [.7 kPa] of external static pressure.
• Enhanced airflow up to .7" external static pressure.
• Evaporator is constructed of aluminum fins bonded to inter-
nally grooved aluminum tubing.
• Suitable for application in mobile homes.
