Digital Unit Description

DESCRIPTION

21/1551-LZA 701 6001-V1 Uen AL

Copyright

© Ericsson AB 2009–2014. All rights reserved. No part of this document may be

reproduced in any form without the written permission of the copyright owner.

Disclaimer

The contents of this document are subject to revision without notice due to
continued progress in methodology, design and manufacturing. Ericsson shall
have no liability for any error or damage of any kind resulting from the use
of this document.

Trademark List

All trademarks mentioned herein are the property of their respective owners.
These are shown in the document Trademark Information.

21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27

 Contents

Contents

1 Product Overview 1
1.1 Purpose 1
1.2 Variants 1
1.3 Overview 2
1.4 Warranty Seal 3

2 Function Description 5
2.1 Maintenance Button 5

3 Technical Data 9

4 DU Interfaces 11

21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27

Digital Unit Description

21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27

 Product Overview

1 Product Overview

This document describes the Digital Unit (DU) for RBS 6000 systems used
for the LTE standard.

1.1 Purpose
The DU provides switching, traffic management, timing, baseband processing,
and radio interfacing.

1.2 Variants
The DU variants are the following:

• DUL 20 01

0 DUL 20 01 supports the feature autointegration with laptop.

• DUS 31 01

0 R1B, R1C only to be installed in RBS 6601

0 R2A can also be installed in RBS 6101, 6102, 6201, 6202 and 6301.

0 R3A possible to install DUS as secondary DU. Dual DUS are not
supported in L12B software.

0 DUS 31 01 supports the feature autointegration with laptop.

• DUS 41 01

0 R3C, R3D only to be installed in RBS 6601.

0 R4A can also be installed in RBS 6101, 6102, 6201, 6202, 6301.

0 R5A possible to install DUS as secondary DU. Dual DUS is not

supported in L12B software.

0 DUS 41 01 supports the feature autointegration with laptop.

• DUS 31 02, and DUS 41 02

0 Supports the feature autointegration with or without laptop.

The R-State R1B, R1C and so on is the last part of the DU product number.

21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27 1

 Digital Unit Description

1.3 Overview
This section provides an overview of the DU, as shown in Figure 1, and Figure 2.

DUL 20 DUL 20

PWR

PWR
GPS

GPS
EC

EC
AUX

AUX
LMT A

LMT A
LMT B

LMT B
TN A

TN A

I
O
F
IDL

IDL
TN B

TN B
RI A

A
RI B

B
RI C

C
RI D

D
RI E

E
RI F

Ge3498A

Figure 1 Overview DUL 20 01

Figure 1 shows DUL 20 01 with product number KDU 137 533/3 on the
left-hand side, and DUL 20 01 with product number KDU 137 533/4 on the
right-hand side.

DUS
–48V
GPS
EC
LMT
TN A
TN B
TN C
COMP
IDL
A
B
C
D
E
F

Ge2841A

Figure 2 Overview DUS 31 01, DUS 31 02, DUS 41 01, and DUS 41 02

2 21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27

 Product Overview

Information about DU placement can be found in RBS Description.

1.4 Warranty Seal

The unit is equipped with a warranty seal sticker.

Note: Seals that have been implemented by Ericsson are not be broken or
removed, as it otherwise voids warranty.

21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27 3

 Digital Unit Description

4 21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27

 Function Description

2 Function Description

The DU has the following functions:

• Timing function

• Loadable software

• Downlink baseband processing

• Uplink baseband processing

• IP traffic management

• Radio interface

• Transmission handling

• Controlling power and climate of the RBS

More information can be found in RBS Configurations.

For the block diagram of the DU, see Figure 3.

DU

Processing

Transmission Radio
Baseband interface

Timing

Ge0376A

Figure 3 DU Block Diagram

2.1 Maintenance Button

The maintenance button is used to activate one of four different modes or
to do a hardware reset. Table 1 lists the available functions activated by the
maintenance button.

21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27 5

 Digital Unit Description

Note: For DUs in LTE the HW Reset is the only function that can be activated
with the maintenance button.

Table 1 Available Functions for Maintenance Button

Function Description
Technician Present Not applicable for LTE
Mode
Full Maintenance Mode Not applicable for LTE
HW Reset The unit is restarted when HW Reset is activated.
No Maintenance Mode Not applicable for LTE
Alarm Suppressed Not applicable for LTE
Mode

Figure 4 shows how to use the maintenance button to activate the different
functions, and what flashing pattern corresponds to what function. While
pressing the maintenance button the unit enters temporary states before
activating a mode, this is represented with dotted lines. When the button is
released the mode will be activated, this is represented with solid lines. The
hardware reset function is activated after pressing the maintenance button
more than 7 seconds.

OFF Button pressed, less than 7 seconds, a second time

HW Reset
No Maintenance
Mode HW Reset

Indicator
Button Pressed Test
Technician Present Activated

Button Released (RU)

Flickering
Flickering Button Released (DU)
Suppressing
Alarms

Indicator 2 Seconds
Test Elapsed

Button Released Flashing Slowly

Flashing Slowly Removing
HW Reset Traffic

7 Seconds HW Reset Traffic

Indicator
Elapsed Removed
Test
Indicator
ON
Hardware Test
Full Maintenance
Reset
Mode

Ge4098

Figure 4 Maintenance Button Work Flow

6 21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27

 Function Description

For more information about the maintenance button, refer to Indicators,

Buttons, and Switches.

21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27 7

 Digital Unit Description

8 21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27

 Technical Data

3 Technical Data

Technical data for the DU is listed in Table 2.

For information about power consumption, see Power Consumption Guideline

for RBS 6000.

Table 2 Technical Data

Digital Unit Supported Dimensions
Radio
Interface
Connecti
ons Height Width Depth Weight

CPRI
DUL 20 01 2.5 Gbps 350 mm 31 mm 280 mm < 3 kg
DUS 31 01 2.5 Gbps, 5 350 mm 31 mm 280 mm < 3 kg
(1)
Gbps , 10
DUS 31 02 (1)
Gbps
DUS 41 01 2.5 Gbps, 5 350 mm 31 mm 280 mm < 3 kg
(1)
Gbps , 10
DUS 41 02 (1)
Gbps
(1) Depending on the Software Package and Radio Unit type.

21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27 9

 Digital Unit Description

10 21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27

 DU Interfaces

4 DU Interfaces

The signalling and power interfaces for the DU are listed in Table 3.

Table 3 DUL 20 01 Interfaces

Marking Connector Description Optical Indicator
PWR ET20 A -48 V DC No
Power
GPS RJ-45 Global Positioning No
System (GPS)
External interface
EC RJ-45 Enclosure Control No
Bus (ECB)
Internal interface
AUX RJ-45 Auxiliary No
Internal interface
LMT A RJ-45 Console No
Internal interface
LMT B RJ-45 Local Maintenance Yes
Terminal (LMT)
External interface
TN A RJ-45 Transmission, Yes
Ethernet
External interface,
electrical
(1)
F - Fault Yes

(2) Optical indicator,

red
(1)
O - Operation Yes

(2) Optical indicator,

green

21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27 11

 Digital Unit Description

Marking Connector Description Optical Indicator

(1)
I - Maintenance Yes
(2)
Optical indicator,
yellow
Optical indicator,
blue
(2)
- Maintenance No
button
For information
about the
maintenance
button, see Section
2.1 on page 5.
IDL HSIO Inter DU Link (IDL) No
Internal interface,
DU to DU
TN B SFP Transmission, Yes
Ethernet
External interface,
optical
(1)
RI A - RI F SFP Radio interface x 6 Yes
(2)
A-F Internal interface
between DU and
Radio Unit (RU),
electrical
External interface
between DU and
Remote Radio Unit
(RRU), optical
(1) DUL 20 01 product number KDU 137 533/3.
(2) DUL 20 01 product number KDU 137 533/4.

Table 4 DUS 31 01, DUS 31 02, DUS 41 01, and DUS 41 02 Interfaces
Marking Connector Description Optical Indicator
-48 V ET20 A -48 V DC No
Power
GPS RJ-45 Global Positioning No
System (GPS)
External interface

12 21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27

 DU Interfaces

Marking Connector Description Optical Indicator

EC RJ-45 Enclosure Control No
Bus (ECB)
Internal interface
(1) (2)
LMT RJ-45 Console and LMT Yes
Internal and
external interfaces
TN A RJ-45 Transmission, Yes
Ethernet
External interface,
electrical
TN B SFP Transmission, Yes
Ethernet
External interface,
optical
TN C SFP Transmission, Yes
Ethernet
External interface,
optical
- Fault Yes
Optical indicator,
red
- Operation Yes
Optical indicator,
green
- Maintenance Yes
Optical indicator,
yellow
Optical indicator,
blue
- Maintenance No
button
For information
about the
maintenance
button, see Section
2.1 on page 5.

21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27 13

 Digital Unit Description

Marking Connector Description Optical Indicator

(3)
- Status Yes
Optical indicator,
yellow
COMP SFP+ Transmission, Yes
Ethernet
External interface,
optical
IDL HSIO Inter DU Link (IDL) No
Internal interface,
DU to DU
A-F SFP Radio interface x 6 Yes
(4)
SFP+ Internal interface
between DU and
Radio Unit (RU),
electrical
External interface
between DU and
Remote Radio Unit
(RRU), optical
(1) The LMT port has combined LMT A and LMT B functionality. The LMT port is configured as
LMT B by default. An LMT splitter cable is used to access LMT A. For detailed information, see
Hardware Maintenance Instructions.
(2) The optical indicator is only in use when the LMT port is used as LMT B.
(3) Not supported by LTE.
(4) SFP+ is needed for CPRI over 2.5 Gbps.

For more information on which Small Form-factor Pluggable (SFP) module to

use, see Spare Parts Catalog.

For more information about optical indicators, refer to Indicators, Buttons, and
Switches.

14 21/1551-LZA 701 6001-V1 Uen AL | 2014-11-27
