PULLING TOOLS

FISHING NECKS

Internal Fishing External Fishing


Neck Neck
B Series Pulling Tools

Used to Retrieve
External Fishing
Necks
Upward Jarring
Shear Release
Used when Junk or
Debris is around
Fish Neck

Type ‘B’ Pulling


Tool
Type ‘BE’ Pulling
Tool
R Series Pulling Tools

• Used to Retrieve
External Fishing
Necks
• Upward Jarring
Shear Release
R Series Pulling Tools

Pinned Sheared
R Series Pulling Tools

Core Lengths

B S J

RJ Core
RS Core

RB Core

‘R’ Series Pulling


Tool
S Series Pulling Tools

Used to Retrieve
External Fishing
Necks
Downward Jarring
Shear Release
S Series Pulling Tools

Pinned Sheared
S Series Pulling Tools

Core Lengths

B S

SS
Core
SB
Core

‘S’ Series
Pulling Tool
R & S Series Pulling Tools

Differences

Sleeve Sleeve Only


No Cap ‘S’ Series
Shear Pin Cap
‘R’ Series

R Series S Series
S Series Pulling Tools

Double Shear-Down
Adapter

Replaces Top
Sub
Safety Shear -
by allowing the
ability to shear
by contact with
the core or the
‘SS’ Double Shear
cylinder Down Adapter

Additional Shear
Pin Capability

‘SB’ Pulling Tool


S Series Pulling Tools

‘SSJ’

• Used to Retrieve
External Fishing Necks
• Downward Jarring
Shear Release
• Can be Sheared by
Contact with the Core
or the Cylinder
• Longer Reach
S Series Pulling Tools

‘SSJ’

Double Shear Down


Adapter

‘J’ Core

‘SB’ Pulling Tool ‘SSJ’ Pulling Tool


S Series Pulling Tools

‘SSJ’

‘SSJ’ Pinned ‘SSB’ Sheared


G Series Pulling Tools

‘GS’

Used to Retrieve
Internal Fishing
Necks
Downward Jarring
Shear Release
G Series Pulling Tools

‘GU’

Used to Convert GS
Pulling Tool to a GR
Pulling Tool
Upward Jarring
Shear Release
G Series Pulling Tools

‘GR’

Used to Retrieve
Internal Fishing Necks
Upward Jarring Shear
Release
G Series Pulling Tools

GU Adapter

GS Pulling Tool GR Pulling Tool


G Series Pulling Tools

Pinned Sheared
JD Series Pulling Tools

Used to Retrieve
External Fishing
Necks
Downward
Jarring Shear
Release

OPERATION

Latched
Engaging
Shouldering

Pinned Sheared
JU Series Pulling Tools

Used to Retrieve
External Fishing
Necks
Upward Jarring
Shear Release
SKIRT OPTIONS

Turned
Down
Bell

Pinned
Sheared
J Series Pulling Tools

Core Lengths

‘S’ CORE ‘C’ CORE ‘L’ CORE
