Ministry Of Higher Education

University Of Al-ESSRAA
Department Of CIVIL Engineering

Computer Applications

Stedent
Murtada Jawad Khadim
Stage Fourth Year

Supervisor
SARRAA DEYAA

1441--------------------------------------------------------------------------------------------------------2020
Example: According to Staad_Pro V8i software, Plot the geometrical modeling
of the steel frame structure shown below,where (z-1bay 3m).where steel plate
thickness 3.0 cm steel, steel member section (vertical double
W16*40)(horizontal standard MC12*40-in x and z direction),(inclined double
angle L3*2.5*1/4).

Note: means member in z-direction where

1- D.L. self weight

2- L.L : 2.0 N/m2 plate loads and external loads are shown in the figure.
3- = 1.4 D.L + 1.7 L.L

1
2
Staad space

JOINT COOR

1 000;2 400;3 800;4 030;5 430;6 830;7 060;8 460

9 860;10 090;11 490;12 890

REPALL1 003

MEMBIR INC

1 1 4;2 2 5;3 3 6;4 4 7;5 5 8;6 6 9;7 7 10;8 8 11;9 9 12

10 4 5;11 5 6;12 7 8;13 8 9;14 10 11;15 11 12;16 8 10

REP ALL 11 18

ELEMENT INC
35 25 26 27 28; 36 27 28 29 30

SUPPORT
1 2 3 13 14 15 FIX

3
CONSTANTS
E STEEL ALL DEN

DEN STEEL ALL

POI STEEL ALL

ALPHA STEEL

ALL MEM PROP

1 TO 9 22 TO 30 TABLE W16*40
10 TO 15 27 TO 32 TABLE MC12*40
16 TO 17 33 TO 34 TABLE DL3*2.5*0.25

ELE PROP
35 36 THIC 0.3

LOAD 1
SELF WEIGHT GY -10

LOAD 2
JOINT LOAD
10 GX 17
23 GY -15

MEM LOAD
11 UNI GY -2 0.5 3
18 UNI GX 3.5 0 3

FLOOR LOAD

YR 4 4 FLOAD -2.0 YR

LOAD COMB 3

1 1.4 2 1.7

DESIGN BEAMS , COLUMNS AND SLAB , WHERE FY=300 MPA

FC=35 MPA , TIE REIN FOR COLUMNS CLEAR COVER 40 CM TRACK 2

4
AND ESTIMATE THE VOLUME OF THR CONCRETE AND REIN BARS

PERFORMANCE ANALYSIS

LOAD LIST 3
PRINT LNA RESULTS

UNIT MM NEWTON

START CONCRETE DESIGN

CODE , ACI

CLB 20 ALL

CLS 20 ALL

CLT 20 ALL

FY MAIN 300 ALL

FC 35 ALL

REIN 0 MEM 1 TO 9 18 TO 26

TRACK 2 ALL

DESIGN BEAM 10 TO 15 27 TO 32
DESIGN COL. 1 TO 9 18 TO 26
DESIGN ELE 35 36

CONCRETE TAKE OFF

END CONCRETE DESIGN

FINISH
PERFORM ANALYSIS

5
PRINT ANALYSIS RESULTS
UNIT MMS NEWTON
PARAMETER 1

CODE AA SHTO

FY LD 420 ALL
RATIO 1 ALL

TRACK 2 ALL

CHICK CODE ALL

PARAMETER 2
CODE AASHTO
SELECT OPTIMIZED
PARAMETER 3
CODE AASHTO
STEEL TAKE OFF LIST ALL

FINISH
