Assignment-5

Course Title: Digital Electronics and Pulse Technique Lab

Course Code: CSE 224

Submitted To: Pranta Saha

Lecturer
School of Science, Engineering and Technology

East Delta University, Chittagong

Submitted By:
M.K. Ataul Karim
ID: 163001112
Submission Date: 28th July, 2020.
Exercise 2.1: f= A’B’+AC+BC; Using this function, make a LUT in DSCH.
Snip and show at least one logic output while running the simulation.
Answer:
Here,
f= A’B’+AC+BC
According to this function the truth table will be:
A B C Output (f)
0 0 0 1
0 0 1 1
0 1 0 0
0 1 1 1
1 0 0 0
1 0 1 1
1 1 0 0
1 1 1 1

DSCH circuit diagram for this equation:

LUT properties:

Timing Diagram of this function:

Exercise 2.2: Observe the following truth table:

(i) Implement the truth table using a 4-to-1 MUX

(ii) (ii) Convert the 4-to-1 MUX into a 2-to-1 MUX logic circuit (DSCH
needed)

Answer:
(i) Implement the truth table using a 4-to-1 MUX:
w1 w2 w3 f

Select pin 0 0 0 0 f=0

00
0 0 1 0
Select pin 0 1 0 0 f=w3
01
0 1 1 1
Select pin 1 0 0 0 f=w3
10
1 0 1 1
Select pin 1 1 0 1 f=1
11
1 1 1 1
4-to-1 MUX representation diagram of this truth table:

(ii) Convert the 4-to-1 MUX into a 2-to-1 MUX logic circuit in DSCH:
When, select pin w1=0, f= w2.w3
when, select pin w1=1, f= w2+w3
Timing diagram of this circuit:

Exercise 2.3: Observe the following truth table:

(i) Implement the truth table using a 4-to-1 MUX

(ii) Convert the 4-to-1 MUX into a 2-to-1 MUX logic circuit (DSCH needed)
Answer:
(i) Implement the truth table using a 4-to-1 MUX:
w1 w2 w3 f

Select pin 0 0 0 0 f=w3

00
0 0 1 1
Select pin 0 1 0 1 f=w3’
01
0 1 1 0
Select pin 1 0 0 1 f=w3’
10
1 0 1 0
Select pin 1 1 0 0 f=w3
11
1 1 1 1

4-to-1 MUX representation diagram of this truth table:

(ii) Convert the 4-to-1 MUX into a 2-to-1 MUX logic circuit in DSCH:
When, select pin w1=0, f= w2 XOR w3
when, select pin w1=1, f= w2 XNOR w3

Timing diagram of this circuit:

Exercise 2.4: f= A’B+BC’. Implement the function using a 2-to-1 MUX where
A is the select switch. (DSCH + truth table needed)
Answer:
Here, the function is f= AB’+BC’.
From this function we find this truth table where A is the select pin,
A B C f

Select pin 0 0 0 0 f= B+C

A=0
0 0 1 1
0 1 0 1
0 1 1 1
Select pin 1 0 0 0 f= BC’
A=1
1 0 1 0
1 1 0 1
1 1 1 0

2-to-1 MUX circuit of this function in DSCH:

Timing diagram of this function:
