2002 Sandvik Tamrock Corp. Tampere Plant P.O.Box 100 FIN - 33311 TAMPERE, FINLAND Trade Reg. No. 2.852 Tel. +358 205 44 121, Telex 22335 Parts Fi Telefax +358 205 44 4771

OTH
FEED
E 2002 SANDVIK TAMROCK CORP. TAMPERE PLANT

P.O.Box 100
FIN-- 33311 TAMPERE, FINLAND Trade Reg. No. 2.852
Tel. +358 205 44 121, Telex 22335 parts fi
Telefax +358 205 44 4771
1002 DMJV 550 036 54dC 1/4
15
42
9 43 47
42 10
47
31 13
33
47
51
60
61
18
20
7
31 22
47 23 56
42 40
47 47 21
42 39 18
49
73
20
38
47
23
22
24
36 35
46 35
47 12
47
3
62 52
59
2
1
6
4
26 27
22
28 23
29 34
47
55
11
57
38
53
43
9 14
37
47 30
46
5

P.O.Box 100
Telefax +358 205 44 4771
2/4 550 036 54dC 1002 DMJV
CYLINDER FEED
LF 1514 / HL1000
550 036 54
Ref Part No. Description Standard designation Qty
1 239 692 97 FEED BEAM LF 1514 1

2 233 541 38 FEED CYLINDERIDLER WHEEL ASSY SEP.PART LIST 1
3 302 903 83 DRILL CARRIAGE SEP.PART LIST 1
4 550 034 90 GUIDE SEP.PART LIST 1
9 233 540 08 PLATE 4

10 550 005 29 STEEL WIRE ROPE D12 L=7968 2
11 550 005 30 STEEL WIRE ROPE D12 L=8152 2
12 321 549 18 PLATE 1
13 236 223 18 CATCH 1
14 207 743 07 NUT M16 L=125 2

15 207 743 08 NUT M16 L=50 2
18 320 776 08 FRAME STRIP 2
20 263 376 27 SLIDE PIECE 8
21 208 353 08 PLATE 4
22 209 104 48 GUIDE PIECE 4

23 209 105 78 PLATE 4
24 237 644 88 HOSE SUPPORT ASSY 1
29 232 539 38 PLATE 1
30 867 273 09 BOLT M20X240 -- 8.8 4
31 550 035 06 HEXAGON HEAD BOLT (HALF THREAD) m16x140 m12.9 30

33 802 198 29 BOLT M16X70 -- 8.8 2
34 800 438 39 BOLT M16X80 -- 8.8 6
35 442 218 50 HEXAGON HEAD SCREW (FULL THREAD) M16X40 -- 8.8 8

40 442 642 20 BOLT M16X90 -- 8.8 4
PARTS TO BE ORDERED SEPARATELY:
5 550 004 61 RETAINING CENTRALIZER SEP.PART LIST 1

6 322 278 48 IDLER WHEEL ASSY. / FRONT SEP.PART LIST 1
7 322 278 47 IDLER WHEEL ASSY. / REAR SEP.PART LIST 1
26 232 839 18 SLIDE PLATE 43x43x2x7060 2
27 232 839 17 SLIDE PLATE 43x43x2x5200 2
28 207 256 58 DATA PLATE 1

P.O.Box 100
Telefax +358 205 44 4771
1002 DMJV 550 036 54dC 3/4
15
42
9 43 47
42 10
47
31 13
33
47
51
60
61
18
20
7
31 22
47 23 56
42 40
47 47 21
42 39 18
49
73
20
38
47
23
22
24
36 35
46 35
47 12
47
3
62 52
59
2
1
6
4
26 27
22
28 23
29 34
47
55
11
57
38
53
43
9 14
37
47 30
46
5

P.O.Box 100
Telefax +358 205 44 4771
4/4 550 036 54dC 1002 DMJV
CYLINDER FEED
LF 1514 / HL1000
550 036 54
42 811 259 69 LOCK NUT VM16 -- 8 34

43 800 485 09 HEXAGON NUT M16 -- 8 4
46 550 130 63 DOUBLE LOCK WASHER FOR BOLT M20 4
51 323 117 41 VALVE ASSY SEP.PART LIST 1

52 258 271 88 BRACKET 1
53 237 389 78 COVER 1
55 239 756 92 COVER ASSY / SAFETY CABLE ASSY SEP.PART LIST 1
56 137 874 51 SUPPORT SEP.PART LIST 1
57 320 011 21 HOSE SUPPORT D=90 1

59 550 103 95 FASTENER 8
60 887 319 09 SCREW M8X150 4
62 807 366 49 HEXAGON NUT M16 2
66 132 965 58 RUBBER PLATE 8

73 550 224 64 CABLE HOLDER 1

P.O.Box 100
Telefax +358 205 44 4771
0499 TAK 233 541 38 1/1
FEED CYLINDER + IDLER FEELS

LF 1514
233 541 38
2 258 225 44 FEED CYLINDER SEP. PART LIST 1

6 322 278 48 IDLER WHEEL ASSY. / FRONT SEP. PART LIST 1
7 322 278 47 IDLER WHEEL ASSY. / REAR SEP. PART LIST 1
E 1999 TAMROCK OY, SERVICE TAMPERE PLANT

P.O.Box 100
FIN--- 33311 TAMPERE, FINLAND
Telefax +358 205 44 4771
1002 DMTAK 550 034 90b 1 /1
GUIDE
550 034 90
1 550 034 92 GUIDE 2

2 233 546 78 LIFTING RING 1
10 445 816 90 HEX.SOCKET HEAD CAP SCREW M12X20 m8.8 SFS 2219 2
12 442 776 90 BOLT M12X35 m8.8 SFS 2064 2
13 851 068 09 LOCK WASHER FOR BOLT M12 2
14 442 219 80 BOLT M16X50 m8.8 SFS 2064 4

3 330 598 58 IDLER WHEEL D12 CABLE 2

4 321 549 18 PLATE 1
5 209 104 48 GUIDE PIECE 2
2002 SANDVIK TAMROCK CORP. TAMPERE PLANT

P.O.Box 100
FIN–33311 TAMPERE, FINLAND Trade Reg. No. 2.852
Telefax +358 205 44 4771
0801 DMTAK 258 225 44bK

P.O.Box 100
Telefax +358 205 44 4771
258 225 44bK 0801 DMTAK
FEED CYLINDER ASSY LF1514
258 225 44
1 237 221 78 CYLINDER TUBE LF 1500 ASSEMBLY 1

2 237 578 98 PISTON ROD 1
3 550 069 94 FRONT COVER 1
4 264 027 38 PISTON 1
6 235 683 74 LIMIT BUSHING D115/95 x 280 3
10 869 129 19 LOCK NUT M65X2 1

12 881 897 09 SEAL KIT 1
13 816 769 59 STRAIGHT THREAD CONNECTOR 1,1/16–12JIC 2
14 816 909 59 FITTING CAP 1,1/16–12JIC 2
15 816 885 99 QUICK DISCONNECT FITTING 2
16 801 802 69 BONDED SEAL 13,7X22X1,5 D2=15,4 2

17 819 560 89 SWIVEL NUT ELBOW 90 , 1 1/16–12JIC 2

P.O.Box 100
Telefax +358 205 44 4771
0505 DMTAK 322 278 48b 1/1
IDLER WHEEL ASSY. / FRONT
322 278 48
1 322 277 18 BODY 1

2 330 598 58 IDLER WHEEL D12 2
3 422 292 00 CIRCLIP DIN 472 2
4 550 592 34 ROLLER BEARING D=90,d=50,L=20 4
5 209 484 08 COVER 2

8 572 102 40 GREASE NIPPLE DIN 71412 AR 1/8 3

P.O.Box 100
Telefax +358 205 44 4771
0505 DMTAK 322 278 47b 1/1
IDLER WHEEL ASSY. / REAR
322 278 47
1 322 277 18 BODY 1

2 330 598 58 IDLER WHEEL D12 2
3 422 292 00 CIRCLIP DIN 472 2
4 550 592 34 ROLLER BEARING D=90,d=50 ,L=20 4
5 209 484 08 COVER 2

8 572 102 40 GREASE NIPPLE DIN 71412 AR 1/8 3

P.O.Box 100
Telefax +358 205 44 4771
0203 DMTAK 302 903 83bC
DRILL CARRIAGE
HL 1000 / LF 1512
302 903 83
15 21
15
13
17 17 17 17
12
20
16
31
22 11
31
1
3 4
31
30
1 303 804 98 DRILL CARRIAGE FOR HL700 , HL1000 1

2 265 683 58 GUIDE L=322 2
3 447 909 00 SLOTTED SCREW M10X30 – 5.8 12
4 448 629 50 HEX.SOCKET SETSCREW M16X25 – 12.9 6
11 152 410 98 REAR BRACKET LF1500 , KS180 2
12 442 685 40 BOLT M20X130 – 8.8 2

13 442 937 30 BOLT M24X70 – 8.8 2
15 442 936 00 BOLT M24X60 – 8.8 4
20 550 236 15 SUPPORTING BLOCK 1

21 442 936 00 BOLT M24X60 – 8.8 2
22 815 470 29 SPIRAL PIN 12X40 4
30 879 025 09 THREAD ELEMENT M20 6
31 880 735 59 THREAD ELEMENT M24 10

P.O.Box 100
Telefax +358 205 44 4771
0998 TAK 323 117 41A 1/1
VALVE ASSY
323 117 41

1 887 284 09 VALVE ASSY 1

2 887 283 79 LOAD CONTROL VALVE INCL. PART 101 1
3 886 546 99 SEQUENCE VALVE P=420 BAR 1
5 816 885 99 MEASUREMENT QUICK ACTION COUPL HI– FLEX 24– 201066 2
6 879 178 69 STRAIGHT THREAD CONNECTOR 3/4 –16 JIC 2
7 816 769 59 STRAIGHT THREAD CONNECTOR 1,1/16–12JIC 2
101 887 285 29 SEAL KIT FOR PART 2 1
1998 TAMROCK OY, SERVICE TAMPERE PLANT

P.O.Box 100
FIN–33311 TAMPERE, FINLAND
Telefax +358 205 44 4771
1103 DMTAK 550 352 61b

P.O.Box 100
Telefax +358 205 44 4771
550 352 61b 1103 DMTAK
SUCTION HEAD, PIN AND RETAINING CENRALIZER ASSEMBLY

PANTERA 1500
550 352 61
1 550 034 29 GROUND PIN PITO 15 1

2 550 068 32 MOVEABLE SUCTION HEAD 1
3 550 263 43 BASEPLATE CUP 1
4 134 887 18 SUCTION CUP PE 400/88 1
5 550 077 41 CYLINDER SEP.PART LIST 1
6 233 078 18 LOCK RUBBER 1

7 135 026 28 BAND 1
8 233 098 38 PIECE 2
9 550 068 76 PLATE 2
10 049 076 28 PIN D25 L56 2
11 422 056 20 CIRCLIP 25X1,2 DIN 471 4

12 550 004 61 RETAINING CENTRALIZER (PITO) SEP.PART LIST 1
14 550 325 03 SLIDE PIECE 2
15 550 324 35 PLATE 8x60x230 2
19 550 066 90 MOUNTING BRACKET 1
30 800 437 09 HEXAGON HEAD BOLT 16X65 m8.8 SFS 2063 5

31 800 536 09 HEXAGON HEAD BOLT M12X90 SFS 2063 1
40 801 775 89 LOCK NUT M16 m8 9
41 442 221 70 HEXAGON HEAD BOLT M16X120–8.8 SFS 2063 4
42 800 821 49 HEXAGON NUT m8 SFS 2067 1

51 800 450 39 HEXAGON HEAD BOLT M20X60 m8.8 SFS 2063 6
53 800 537 39 HEXAGON HEAD SCREW M16x35 m8.8 SFS 4

P.O.Box 100
Telefax +358 205 44 4771
0101 DMHS 550 077 41
HYDR.CYLINDER
550 077 41
1 321 125 88 CYLINDER TUBE 1

2 049 402 68 TERMINAL 1
3 054 107 08 PISTON ROD 1
4 550 039 78 PISTON D 40 1
6 054 106 78 COVER 1
7 817 946 19 WIPER 25–6 1

8 155 327 98 GUIDE BAND 1
9 522 131 00 O–RING 34,2X3–1 , NBR , 70 SHORE A 2
10 817 945 99 U–SEAL 25X33X5,7 1
11 422 241 30 CIRCLIP 42X1,75 4
12 850 698 89 SPHERICAL PLAIN BEARING 2

13 049 774 68 RING RC 412 4
14 572 102 40 GREASE NIPPLE AR 1/8 2
15 801 811 49 PLUG R1/8” 1
16 550 044 68 SLIDE RING 40,0 X 35,0 X 5,6 1
17 550 044 65 PISTON SEAL 40,0 X 29,0 X 4,2 , 93 SHORE A 1

21 857 302 19 PLUG 9/16–18JIC 1
22 816 701 89 STRAIGHT THREAD CONNECTOR 9/16–18JIC 1
550 050 69 SEAL KIT 1

P.O.Box 100
Telefax +358 205 44 4771
0103 DMTAK 550 004 61c

P.O.Box 100
Telefax +358 205 44 4771
550 004 61c 0103 DMTAK
RETAINING CENTRALIZER
PITO15
550 004 61
1 550 003 10 ARM SEP.PART LIST 2

2 550 004 34 FRONT PLATE SEP.PART LIST 1
3 550 004 38 REAR PLATE SEP.PART LIST 1
4 237 770 28 HYDR.CYLINDER SEP.PART LIST 1
5 550 004 43 SHAFT DIAM. 40/45, L= 140 2
6 550 004 42 SHAFT DIAM. 55 , L= 216,5 2

7 550 004 45 PLATE LIMIT PLATE 2
8 550 006 11 PIPE 40/22, L= 118 2
10 869 106 19 SPIRAL PIN 10X70 4
11 810 512 09 SPRING PIN 12X70 2
20 800 544 69 BOLT M16X180 – 8.8 1

22 867 273 09 BOLT M20X240 – 8.8 4

51 801 265 39 BOLT M20X1,5X55 m8.8 SFS 2066 4
52 051 154 38 JAW 11/4” extension rod equipment 2

052 317 48 JAW R.H 2” extension rod equipment 1
052 318 78 JAW L.H 2” extension rod equipment 1
091 067 08 JAW 3” AND 3 1/2” drill tube equipment 2
613 418 58 JAW 11/2” extension rod equipment 2
623 924 18 JAW 13/4” extension rod equipment 2

234 996 38 JAW R.H 2” and3 1/2” guide tube 1
234 997 68 JAW L.H 2” and3 1/2” guide tube 1
052 317 48 JAW R.H 2” and3 ” guide tube 1
052 318 78 JAW L.H 2” and3 ” guide tube 1
236 176 18 JAW L.H 60 mm (2 3/8”) without guide tube 1

236 176 17 JAW R.H 60 mm (2 3/8”) without guide tube 1
236 078 48 JAW R.H 60 mm (2 3/8”) and 3 1/2” guide tube 1
236 079 78 JAW L.H 60 mm (2 3/8”) and 3 1/2” guide tube 1

P.O.Box 100
Telefax +358 205 44 4771
0501 DMTAK 550 003 10a
ARM
BUSHINGS
550 003 10
4
2
4 2
3
1 237 772 88 ARM 1

2 344 839 78 BEARING BUSHING 2
3 550 003 21 BUSHING 65/56 , L=38 1
4 453 689 98 BEARING BUSHING 2
5 572 102 40 GREASE NIPPLE AR 1/8 1

P.O.Box 100
Telefax +358 205 44 4771
0402 DMTAK 550 004 34a
FRONT PLATE
550 004 34
1 550 004 35 FRONT PLATE 1

2 344 839 78 BEARING BUSHING D65 d55 L40 2

P.O.Box 100
Telefax +358 205 44 4771
0402 DMTAK 550 004 38a
REAR PLATE
550 004 38
1 550 004 41 REAR PLATE 1

2 344 839 78 BEARING BUSHING D65 d55 L40 2

P.O.Box 100
Telefax +358 205 44 4771
0102 DMTAK 237 770 28cA
HYDR.CYLINDER
80/50
237 770 28
1 237 769 68 TUBE 1

2 155 044 48 PISTON 1
3 162 395 08 COVER 1
4 169 428 08 PISTON ROD 1
5 514 010 20 LOCK NUT M40X1,5 1
6 514 408 40 LOCK WASHER MB 8 1

7 613 061 08 BEARING BUSHING L=50 2
8 572 102 40 GREASE NIPPLE AR 1/8 2
11 817 317 59 PISTON RING 1
12 803 135 09 U–SEAL 50X60X10 1
13 807 823 69 WIPER 50X60X10/7 1

14 522 271 70 O–RING 69,2X5,7–1 , NBR , 70 SHORE A 1
15 428 702 10 O–RING 49,5X3–1 SMS 1586 2
17 800 118 39 O–RING 79,5X3–1 , NBR , 70 SHORE A 1
18 814 797 09 GUIDE RING 3
19 816 701 89 STRAIGHT THREAD CONNECTOR 9/16–18JIC 2

856 700 69 SEAL KIT INCL.PARTS 11–18 1

P.O.Box 100
Telefax +358 205 44 4771
1204 DMTAK 239 756 92cG 1/1
COVER ASSY / SAFETY CABLE ASSY
239 756 92
1 238 523 18 SAFETY BAR 1

9 550 392 43 SAFTEY WIRE ASSY SEP. PART LIST 1
14 800 537 39 BOLT M16X35 m8.8 SFS 2064 5
30 800 525 79 BOLT M10X40--- 8.8 1

32 812 622 69 NUT VM10 m8 DIN 980 2

P.O.Box 100
Telefax +358 205 44 4771
1005 DMTAK 550 392 43a
SAFETY WIRE ASSEMBLY
550 392 43
1 550 392 32 MOUNTING PLATE 1

2 550 316 07 SAFETY LIMIT SWITCH 1
2.1 550 665 88 COVER INCL.PUSH BUTTON 1
2.2 550 665 86 CONTACT BLOCK 1
3 446 137 50 HEXAGON SOCKET HEAD SCREW M8X20 m8.8 SFS 2
4 882 127 59 HOIST 2

5 882 125 09 CABLE HOLDER 2
6 882 140 89 WIRE 0.7m
7 800 917 29 HEXAGON NUT M8 m8 SFS 2067 2
8 882 126 29 CABLE SUPPORT 2
9 885 632 99 HEXAGON HEAD SCREW M8X110–8.8 SFS–ISO 4017 1


P.O.Box 100
Telefax +358 205 44 4771

HOSE SUPPORT ASSY

GRADLE 90
137 874 51

Ref Order No. Description Standard designation Qty
1 137 243 38 ARM INCL.PARTS 10,11 1

3 132 266 98 PIN D=25 1
4 132 267 18 PIN D=20 1
5 818 056 99 SPRING PIN 6.0 2
10 442 218 50 BOLT M16X40 m8.8 SFS 2064 2
11 811 259 69 NUT VM16 m8 DIN 980 2
2 136 724 78 BRACKET 1

P.O.Box 100
Telefax +358 205 44 4771
1198 TAK 258 625 51a 1/2

P.O.Box 100
Telefax +358 205 44 4771
2/2 258 625 51a 1198 TAK
MOVEABLE GUIDE MOUNTING
258 625 51
1 237 342 41 QUIDE ASSY. SEP.PART LIST 1

5 235 766 61 CONTROL VALVE SEP.PART LIST 1
8 879 367 89 SOLENOID VALVE ADAPTER (1.5m) 3x0.75 MPM 452P15011SO2 (OEM) 2
11 816 719 09 SWIVEL NUT RUN TEE 9/16–18JIC 2
12 816 722 29 SWIVEL NUT BRANCH TEE 9/16–18JIC 1
13 858 881 09 SWIVEL NUT BRANCH TEE 3/4–16JIC 1

14 818 001 09 UNION NUT 3/4–16JIC 1
15 853 780 09 TUBE END REDUCER 3/4X9/16JIC 1
25 591 095 29 HOSE ASSY 86T–06 AB–750–JIC 1
26 591 095 29 HOSE ASSY 86T–06 AB–750–JIC 1

27 590 851 99 HOSE ASSY 86T–06 AA–1500–JIC 1
28 590 821 69 HOSE ASSY 86T–06 AA–1600–JIC 1
29 590 847 49 HOSE ASSY 86T–06 AA–500–JIC 1
30 590 866 39 HOSE ASSY 86T–06 AA–400–JIC 1

P.O.Box 100
Telefax +358 205 44 4771
0399 TAK 237 342 41bB 1/1
GUIDE ASSY
ROD 60 mm
237 342 41
1 235 828 08 HYDRAULIC CYLINDER ASY SEP.PART LIST 2

2 237 343 78 BODY 1
3 235 830 08 COVER PLATE 1
4 235 834 08 JAW 2
5 233 018 68 PLATE 2
6 236 074 38 COVER 2

20 800 495 09 BOLT M16X140 m8.8 SFS 2063 4
21 442 256 30 BOLT M16X55 m8.8 SFS 2064 8
25 800 485 09 NUT M16 m8 SFS 2067 4

P.O.Box 100
Telefax +358 205 44 4771
0602 DMKTP 235 828 08aA
CYLINDER ASSY
235 828 08
1 237 344 08 CYLINDER 1

2 235 832 58 PISTON 1
3 235 831 28 COVER 1
4 882 787 79 PISTON SEAL 520 55–45–12 80NBR 878–POM–20 1
5 816 284 09 U–SEAL NI300 40–50–10 1
6 806 478 29 WIPER 92AU/504 SIMRIT 1

7 869 935 39 O–RING 49,5X3 1
8 816 711 99 STRAIGHT THREAD ELBOW 9/16/18 1
9 886 225 69 HEXAGON SOCKET HEAD SCREW M12X160 m12.9 SFS 2219 4
10 851 068 09 DOUBLE LOCK WASHER M12 4
11 800 821 49 HEXAGON NUT m8 SFS 2067 4

12 816 701 89 STRAIGHT THREAD CONNECTOR 40X–S10–1/4”(9/16–18JIC) 1
13 817 180 79 SWIVEL NUT ELBOW 9/16–18 JIC 1
20* 883 758 89 SEAL KIT TAMROCK CYL. 55/40 1

P.O.Box 100
Telefax +358 205 44 4771
1205 DMMM 235 766 61bB
CONTROL VALVE
235 766 61
DRAWING 3–235 766–B
DIRECTION B
DIRECTION A
1 884 964 49 BASE PLATE 1

2 882 542 49 DOUBLE PILOT OPERATED CHECK VALVE 1
3 882 536 49 DIRECTIONAL VALVE INCL. PART 800 1
4 871 241 09 HEXAGON SOCKET HEAD SCREW M5X70 m12.9 SFS 4
5 856 040 09 STRAIGHT THREAD ADAPTER F40X–S10–3/8 3
6 857 302 19 PLUG 4

7 816 713 49 STRAIGHT THREAD ELBOW 9/16/18 1
8 817 180 79 SWIVEL NUT ELBOW 90 9/16–18 JIC 2
9 816 719 09 ADAPTER TEE 9/16–18 JIC 2
800 888 010 89 SEAL KIT FOR PART 3 1

P.O.Box 100
Telefax +358 205 44 4771

2002 Sandvik Tamrock Corp. Tampere Plant P.O.Box 100 FIN - 33311 TAMPERE, FINLAND Trade Reg. No. 2.852 Tel. +358 205 44 121, Telex 22335 Parts Fi Telefax +358 205 44 4771

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

2002 Sandvik Tamrock Corp. Tampere Plant P.O.Box 100 FIN - 33311 TAMPERE, FINLAND Trade Reg. No. 2.852 Tel. +358 205 44 121, Telex 22335 Parts Fi Telefax +358 205 44 4771

Uploaded by

Copyright:

Available Formats

OTH

E 2002 SANDVIK TAMROCK CORP. TAMPERE PLANT

E 2001 SANDVIK TAMROCK CORP. TAMPERE PLANT

Ref Part No. Description Standard designation Qty

1 239 692 97 FEED BEAM LF 1514 1

9 233 540 08 PLATE 4

14 207 743 07 NUT M16 L=125 2

22 209 104 48 GUIDE PIECE 4

31 550 035 06 HEXAGON HEAD BOLT (HALF THREAD) m16x140 m12.9 30

37 800 537 39 HEXAGON HEAD SCREW (FULL THREAD) M16X35 -- 8.8 4

PARTS TO BE ORDERED SEPARATELY:

5 550 004 61 RETAINING CENTRALIZER SEP.PART LIST 1

28 207 256 58 DATA PLATE 1

E 2001 SANDVIK TAMROCK CORP. TAMPERE PLANT

E 2001 SANDVIK TAMROCK CORP. TAMPERE PLANT

Ref Part No. Description Standard designation Qty

42 811 259 69 LOCK NUT VM16 -- 8 34

51 323 117 41 VALVE ASSY SEP.PART LIST 1

57 320 011 21 HOSE SUPPORT D=90 1

66 132 965 58 RUBBER PLATE 8

E 2001 SANDVIK TAMROCK CORP. TAMPERE PLANT

FEED CYLINDER + IDLER FEELS

Ref Part No. Description Standard designation Qty

2 258 225 44 FEED CYLINDER SEP. PART LIST 1

E 1999 TAMROCK OY, SERVICE TAMPERE PLANT

Ref Part No. Description Standard designation Qty

1 550 034 92 GUIDE 2

14 442 219 80 BOLT M16X50 m8.8 SFS 2064 4

PARTS TO BE ORDERED SEPARATELY:

3 330 598 58 IDLER WHEEL D12 CABLE 2
