dimension. ▪When elevations show the exterior of a residential unit, they are simply called elevations. ▪Interior elevations show the inside of a building. ▪Elevations are the exterior views of a building. ▪They are necessary in as much as they show the height of the building and its appearance on each side. ▪Normally, the four elevations are sufficient to describe the appearance of the residential building ▪Elevation drawings are orthographic drawings. ▪They show the exterior of a building. ▪The elevation s that part of the building that people see and observe, hence, it is the part they use to judge the structure 1. Window and Door Size – must be chosen from a manufactures catalog which offers great variety of sizes. The sizes must be standard that it conforms to the provisions of the building code. 2. Window and Door Representation –in elevation may be drawn simply. 3. Material Representation – may be shown by drawing only a few lines, like bricks. 4. Footings and Walls are hidden lines used to indicate location of footings. 5. Labeling views can be done in two methods by labeling it with views as in front, rear, left and right side elevations, or by using compass orientation as in north, south, east, and west directions. 6. Dimensioning on elevations are limited to vertical dimensions are shown on the plan. 7. Changes are additions necessary after all the other drawings have been completed.
