WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함
문서번호
표준 작업 지침서(A) (WI NO)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(A) PAGE 1 OF 188

공사명(PJT. NAME) POWER & WATER PLANT 도면(DWG No) N/A
제품명(ITEM NAME) COMMON 중량(WEIGHT) N/A
부품명(PART NAME) COMMON 재질(MAT’L)) N/A
공정명(OPER. NAME) DOOSAN PACKING GUIDE LINE

Document Revision Status

Rev. Description Rev. Year
0 First Issue 2011
1 Changed Packing Material 2012
Added detailed contents list
Added and revised requirements for preservation and packing
2 methods 2014
Revised expression of packing forms and packing style table
Changed sequence and number of contents

Added and revised requirements for preservation and packing

3 methods 2016
Changed packing style table in detail

5
4
3 2016-03-02 Revise & Added Contents 장 수 인 박 방 주 임 형 일
2 2014-08-07 Revise & Added Contents 김 태 훈 박 방 주 임 형 일
1 2012-02-06 Change for Packing Material 장 수 인 박 방 주 김 원 기
0 2011-03-03 First Issue 정 성 원 임 형 일 김 원 기
REV 개정 내용 PSE DEPT. PSE DEPT. PSE DEPT.
Date(개정일자)
NO. (DESCRIPTION) PREPARED BY REV’D & APP’D BY
Doosan Heavy Industries & Construction Co., Ltd.
WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 2 OF 188

CONTENTS

1.0 Scope …..………………………………………………………………....…….. Page 3 (Common)

2.0 Purpose ..…………………………………………………………………….….. Page 3 (Common)
3.0 Reference Document ……………………………………………………….… Page 3 (Common)
4.0 Preservation ………………………………………………………………….… Page 3 ~ 5 (Common)
5.0 Packing …………………………………………………………………………..
5.1 Classification of Packing Forms ………………………………..……. Page 5 ~ 10 (Common)
5.2 General …………………………………………………………....……. Page 11 ~ 27 (Common)
5.3 Packing for Headers, Tubes & Panels ………………………..…….. Page 27
5.4 Packing for Steam Drum ……………………………………...….…... Page 28
5.5 Packing for Steel Structure ……………………………………..……. Page 28 ~ 32
5.6~8 Packing for Pipe ………………………………………………………. Page 33 ~ 34
5.9 Packing for item of Condenser …………………………………...….. Page 35 ~ 36
5.10 Packing for Air & Gas Duct …………………………………............... Page 36
* Image Packing for Panel, H-Beam, Plate, etc. …………………………. Page 37 ~ 40 (Common)
5.11 Packing for Module Assemblies ……………………………………... Page 41
5.12 Packing for Bolt ………………………………………………………… Page 41 ~ 42
6.0 Marking …………………………………………………………………………. Page 43 ~ 45 (Common)
7.0 Shipping …………………………………………………………………..……. Page 46 ~ 48 (Common)
* Table 1 Care Mark ………………………………………………………………… Page 49 (Common)

Appendix.Ⅰ Box Construction …….……………………………………….…. Page 50 (Common)

Appendix.Ⅱ Wooden framed boxed for packing…………….…….……….. Page 51 ~ 55 (Common)
Appendix.Ⅲ Skid Mounted Construction………….………………………… Page 56 (Common)
Appendix.Ⅳ Wooden Bundle…………………………………….….…………. Page 57 (Common)
Appendix.Ⅴ Position of Shipping and Care Mark……………………..…… Page 58 (Common)
Appendix.Ⅵ Packing Style Table……………………………………………… Page 59 ~ 188 (Common)

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 3 OF 188

1.0 Scope(범 위)

This instruction is intended to specify the requirement of packing, marking and shipping of the
DOOSAN Power & Water Plant
이 지침서는 DOOSAN Power & Water Plant 품목의 포장, 마킹 및 운송에 대한 요구사항을 담고 있다.

2.0 Purpose(목 적)

The purpose of this instruction is to provide the method of packing, marking and handling to protect from
any corrosion, contamination, physical damage or any effect which could lower the quality or cause
deteriorate during shipment, handling and storage.
이 지침서는 부식, 오염, 물리적 손상이나 운송, 취급 및 저장 시 제품을 손상시키거나 제품의
품질을 저하시킬 수 있는 영향으로부터 제품을 보호하기 위한 포장에 관한 방법을 기술한다.

3.0 Reference Document(참고 서류)

3.1 The Contract Specification

3.2 ISPM 15(International Standards for Phytosanitary Measures)
3.3 KS(F3101 : Ordinary Plywood, T1084 : Silicagel desiccants of packaging, T1085 : Volatile corrosion
inhibitor, T1201 : Construction of Wooden framed boxes for packing)
KS(F3101 : 보통합판, T1084 : 포장용 실리카겔 건조제, T1085 : 기화성방청제, T1201 : 포장용 나무틀
상자의 설계)

4.0 Preservation(보 존)

4.1 All surfaces of products shall be cleaned before packing without oil, rust and contaminant.
포장 전에 제품 표면에 오염된 기름, 녹 등을 제거한다.

4.2 Sufficient amount of the grease shall be applied to all of threaded areas.
모든 나사산에는 충분한 량의 그리스를 도포한다.

4.3 All machined surfaces shall be applied Tectyl 506 or equivalent to prevent rust.
가공면에는 녹 발생을 방지하기 위해서 Tectyl 506 또는 그에 상응하는 물질을 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 4 OF 188

4.4 The bagged V.C.I in the net shape bag shall be hung or the powdered V.C.I shall be scattered inside of
the Carbon Steel Tank, Vessel, Drum, Heat Exchanger, Tube and Pipe Spool, etc. which the inside of the
product has no protection from painting or corrosion inhibitor after finishing cleaning inspection. The
amount of V.C.I is Min. 30g/㎥
(Insertion of V.C.I can be excluded in which the product is filled with Nitrogen.)
※ Type of V.C.I insertion : Various types as liquid type, strip type, etc. shall be acceptable. The amount
of the insertion differs upon the manufacturer’s guide.
※ Caution : In case of powder type insertion, the powder should be sprinkled evenly not to be stuck
inside of the product, and liquid/power types of V.C.I shall be not acceptable to product without inside
flushing plan.
Carbon Steel Tank, Vessel, Drum, Heat Exchangers, Tube, Pipe Spool 등 도장이나 방청제로 보호되지
않은 표면이 있는 제품 내부에는 청정검사가 완료된 후, 봉지 형태의 V.C.I(기화성 방청제)를 그물망
에 넣은 상태로 매달거나 powder 형태의 V.C.I 를 골고루 뿌린다. 투입량은 Min. 30g/㎥이다.
(질소로 충전된 제품 내부에는 V.C.I 투입을 제외할 수 있다.)
※ V.C.I 투입형태 : 액상(Liquid)형, 전선(Strip)형 등 다양한 형태로도 사용할 수 있으며, 투입량은
제작사 기준에 따른다.
※ 주의 : Powder 형태로 투입 시 제품 내부에 고착되지 않도록 골고루 뿌려야 하며, 내부 Flushing
이 없는 제품은 액상/Powder 형태의 V.C.I 를 투입하지 않는다.

4.5 After assembling the man-way, attach a sticker giving information about the quantity of V.C.I used
in the tank at a visible spot near the man-way cover.
Man-way 를 조립한 후 Man-way Cover 주위 잘 보이는 곳에 탱크 내부에 투입된 V.C.I 수량과 주의
마크를 스티커를 사용해서 부착한다.

4.6 Remove all V.C.I before installation(or construction) and replace the new V.C.I every 6 months if the
storage period goes over than 6 months.
기기 설치 전에 V.C.I 를 제거하고, 보관기간이 6 개월을 초과할 경우에는 매 6 개월마다 교체한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 5 OF 188

4.7 Bagged desiccants will be put inside of the boxes to protect from corrosion during shipment and
temporary storage before erection. The amount of desiccant is Min. 300g/㎥.
(Desiccant can’t contact with products directly.)
※ Caution : Desiccant should be applied inside of the barrier(Vinyl, V.C.I Film, A-Foil, etc.) that covering
the product, and no material that includes moisture as wood shall be placed inside of barrier.
선적기간 및 설치 전 임시저장 시 부식을 막기 위해 봉지 형태의 건조제가 박스 내에 놓여야 한다.
투입량은 Min. 300g/㎥을 적용한다.
(건조제는 제품과 직접 접촉되지 않도록 한다.)
※ 주의 : 건조제는 반드시 제품을 싸고 있는 Barrier(Vinyl, V.C.I Film, Al-Foil 등) 내부에 투입하고,
Barrier 내부에는 목재와 같이 수분을 포함한 자재를 투입하지 않는다.

4.8 Desiccant bags must be removed before installation at sites.

Site 에서 설치 전에 건조제는 제거 해야 한다.

5.0 Packing(포 장)

5.1 Classification of Packing Forms(포장형태의 분류)

5.1.1 Water Proof Box(방수박스)

Water Proof Boxes shall be sealed completely and be applied to products that need water proofing,
rust-prevention and products that damage prevention from vibration, shock and pressure of weight is
required. And accessories and small parts shall be packed in this packing form.
이 포장형태는 방수, 방습, 녹 발생 방지 및 진동, 제품무게나 충격으로 인한 손상방지가 필요한
품목에 대해 적용한다. 그리고 액세서리와 소부재도 포함된다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 6 OF 188

5.1.2 Open Crate(개방박스)

Open Crates shall be applied to products and parts that are resistant to rain, dust, sunshine,
vibration, pressure and shock. And these forms shall be applied to products that need external check
during the transportation.
개방박스는 비, 먼지와 햇빛, 진동, 충격에 견딜 수 있는 품목에 적용한다. 그리고 수송 시 육안
체크가 필요한 경우도 포함된다.

5.1.3 Skid(스키드)
Skids shall be applied to products that are strong enough to endure water, sun and damages due to
contact or shock when handling products directly.
스키드는 물과 햇빛의 부분적인 영향이나 직접 핸들링 행할 시 발생하는 접촉이나 충격으로
인한 손상의 우려가 없는 품목에 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 7 OF 188

5.1.4 Bundle(번들)
Bundles shall be applied to products that are simple and strong enough to endure damages
due to contact or shock when loading or unloading.
번들 포장은 단순한 형태이면서 선적이나 하역 시 접촉이나 충격에 강한 제품에 적용한다.

5.1.5 Moisture Proof Box(방습포장)

Moisture Proof Boxes shall be sealed completely and be applied to products that need water
proofing, moisture proofing, rust-prevention and products that damage prevention from vibration,
shock and pressure of weight is required. And electric panels and spare parts shall be packed in this
packing form.
방습 포장은 방수, 방습, 녹 발생 방지 및 진동, 제품무게나 충격으로 인한 손상방지가 필요한
품목에 대해 적용한다. 그리고 전기판넬과 예비품에 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 8 OF 188

☞ Bagged desiccants shall be put inside of the Al-foil. The amount of desiccant is over 300g/㎥.
Al-foil 내부에는 Bag 형태의 건조제를 300g/㎥이상 투입한다.

5.1.6 Pallet(팔렛트)
Pallets shall be applied to products such as thin plates or pipes that are not strong enough to protect
products by simple skids or bundles during the transportation and storage which can effect
deformation of product. And special cares are needed to prevent damage when stacking the product.
운송이나 적재 시 단순 Skid, Bundle 만으로는 제품을 충분히 보호할 수 없는 두께가 얇은 Plate
와 Pipe 류와 같은 제품은 Pallet 를 적용해야 하며, 2 단 적재 시 제품의 형상을 고려하여 흠집이
발생되지 않도록 주의해야 한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 9 OF 188

5.1.7 Steel Frame(철제 프레임)

Steel frame shall be applied to products such as stack, duct, module, CE, DE, coal burner and
casing etc. that are easily damaged due to big size and heavy weight. Special care is needed to
prevent damage in product’s shape with multistage loading.
중량과 부피가 크고 변형 발생이 예상되는 Stack, Duct, Module, 전기집진기(CE,DE), 코일버너,
Casing 등에 적용되며, 다단 적재 시 제품의 형상을 고려하여 흠집이 발생하지 않도록 유의한다.

50 4500 50

Sample 1 L2
Sample

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 10 OF 188

전기집진기(CE, DE) 전기집진기(CE, DE)

Duct Sample Coal burner Sample

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 11 OF 188

5.2 General(일반 사항)

5.2.1 The size of Knots must not exceed 1/3th the width of timbers.
옹이의 크기가 목재 폭의 1/3 을 초과하는 것은 사용하지 않는다.

5.2.2 All timbers for packing should be made of Douglas fir or Spruce or Hemlock(in Canada or America).
And, the plywood that satisfies standard/semi-waterproof/1st grade in KS F3101 should be used.
In case of imported plywood, plywood that satisfies BB/CC grade in IHPA or equivalent level should
be used.
[The thickness of plywood shall satisfy standard(±4%) of KS, and 9T plywood can be allowed not
less than 8.5T, 12T plywood can be allowed not less than 11.5T]
모든 포장작업에 사용하는 각재는 미송(캐나다/미국 산 더글라스 퍼, 스프러스, 헴록)을 적용한다.
그리고, 합판은 KS F3101 규격을 만족하는 일반, 준내수, 1 급이 사용되어야 한다.
수입합판의 경우 IHPA 기준 BB/CC 등급 또는 동급 이상의 자재가 적용되어야 한다.
[합판의 두께는 KS 기준(±4%)에 따르며, 9T 합판은 8.5T 까지, 12T 합판은 11.5T 까지 허용]

5.2.3 The wood packing materials used in packing or shipment for Export must be either heat treated or be
fumigated according to ISPM-15.(the wood packing materials for country that are not requested to
apply ISPM-15 can be excluded)
- Heat treatment with minimum 56℃ in core temperature for more than 30 minutes.
- Fumigation with MB(Methyl Bromide) gas treatment.
수출품 포장/운송에 사용되는 모든 목재류는 ISPM-15 에 따라서 열처리 또는 훈증 처리되어야
한다.(ISPM-15 미 적용국가에 공급되는 목재포장재는 제외할 수 있다.)
- 목재의 중심부 온도가 최소 56℃ 이상에서 30 분 이상 열처리
- 또는 메틸 브로마이드 이용하여 훈증

5.2.4 The Wood for skid or bracing shall not have the direct contact with products. The product surfaces
directly contacting wood should be protected by placing a cushioning material(Toilon or Rubber pad).
However, rubber pads shall not contact with products directly.
스키드용 목재나 보강목은 제품과 직접 접촉해서는 안 되며, 제품과 접촉되는 부위는 완충재(토
일론 또는 고무패드)를 사용해서 보호해야 한다. 단, 고무패드는 제품과 직접 접촉하지 않도록
적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 12 OF 188

5.2.5 All packing materials should maintain its function even if those materials are stored for maximum 12
months at outdoors.
(However, in case of packing for product that required storage of less than 12 months, packing
material which maintain its function during storage period can be applied.)
모든 포장용 자재는 옥외에서 최대 12 개월 동안 보관되어도 그 기능을 유지할 수 있어야 한다.
(단, 12 개월 미만의 보관을 필요로 하는 제품 포장에는 그 기간에 맞는 포장재를 적용할 수 있다.)

5.2.6 Products shall be packed se separately to stack according to their weight and bulk
제품의 중량 및 부피에 따라 형상 별로 적재가 가능하도록 구분하여 포장한다.

5.2.7 Products such as bulky material, specialties(strainers & traps), special valves, general service
pumps(sump pump), crane and hoist should be packed for each packages.
벌크성 자재, Specialties(Strainers & Traps), Special Valves, General Service Pumps(Sump Pump),
Crane, Hoists 와 같은 자재는 반드시 Package 를 구별하여 포장한다.

5.2.8 The tags be attached to each product to make field identification easy, and the tags shall be adhered
firmly to prevent being detached easily during handling and transportation.
현장 식별을 위해 각 제품들에 태그를 부착해야 하며, 외부 요인에 의해 떨어지지 않도록 밀착
하여 붙여야 한다.

5.2.9 Stainless steel materials and equipment shall be packed separately from carbon steel materials.
스테인레스강과 장비는 탄소강 소재와는 분리하여 포장한다.

5.2.10 Products that are packed in group with more than 2 shall not exceed 1.5 m in height and 15 ton in
weight.
두 개 이상을 묶어서 포장하는 제품은 가급적 최대높이는 1.5 m 이하로 하고, 최대중량은 15 ton
이하로 한다.

5.2.11 Spare items and main items shall be packed separately. Spare items shall be packed in moisture
proof box normally, but the spare items which cannot be worried poor quality due to environment
conditions during the contracted warranty period can be packed in the water proof box.
예비품은 본품과 별도 포장해야 한다. 일반적으로 예비품은 방습포장을 적용하지만, 예비품 중
계약된 보증 기간 내 주변 환경에 따른 품질 불량이 우려되지 않는 제품은 방수포장 할 수 있다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 13 OF 188

5.2.12 Small loose items(all items under 1.5m) shall be packed in boxes.
소부재(1.5m 이하 모든 부재)는 박스 포장 한다.

Wrong(불량) Correct(양호)

소부재(1.5m 이하) Box 포장

5.2.13 The equipment shall be properly blocked and braced to prevent damage during transportation,
handling and storage.
장치들은 수송, 취급 및 보관 시 손상을 입지 않도록 적절하게 고정한다.

5.2.14 If lots of products are piled up in the boxes, products should be fixed tightly with plywood or wood
pieces to prevent physical damage from rolling caused by moving or transportation.
박스 내부에 다수의 제품이 포장 될 경우, 제품과 제품 사이에 합판이나 목재로 단단히
고정하여 이동이나 운송 시 흔들림으로 인한 물리적 손상이 발생하지 않도록 한다.

5.2.15 In case of wooden boxes, all the products shall be covered fully with barrier(Vinyl, V.C.I Film, Al-Foil,
etc.) to make the most of the prevention of the product from the moisture that could be flowed into
from the outside and could be created inside of the box.
박스 포장 시 모든 제품은 Barrier(Vinyl, V.C.I Film, Al-Foil 등)로 제품 전체를 덮어서 내부로 유입
되는 수분, Box 내부에서 발생하는 수분과 제품의 접촉을 최대한 방지한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 14 OF 188

5.2.16 Standard packing type of Systems(Assembly Type) is water proof box. In case of packing in wooden
skid, the entire product shall be covered with tent fully.
시스템류(Assembly Type)는 Water Proof Box 포장을 기본으로 하며, Wooden Skid 적용 시 제품
전체를 천막으로 보호한다.

5.2.17 All boxes should be designed according to ‘AppendixⅠ, Ⅱ’ of this document.

모든 박스는 본 절차서의 ‘AppendixⅠ,Ⅱ’에 따라 설계되어야 한다.

5.2.18 All wooden boxes for export shall be tightly wrapped and fastened with steel straps or cord straps
according to below a table.
(For the domestic box, this clause shall be applied to the project with additional request from
customer.)
수출용 박스는 하기 표에 따라 스틸밴드 또는 코드스트랩으로 단단히 체결한다.
(국내용 박스의 경우, 별도의 고객 요구가 있는 Project 에는 적용할 수 있다.)

H < 700 mm Do not apply

700mm ≤ H < 1,500 mm Apply 1 Point
H ≥ 1,500 mm Apply 2 Point as equal interval
Doosan Heavy Industries & Construction Co., Ltd.
WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 15 OF 188

5.2.19 All boxes shall be packed which is able to pile up with several layers in the holds of vessels when
shipping or transportation
모든 박스는 선, 하역 및 운송 시 선박 내부에서 다단적치가 가능하도록 포장한다.

Correct(양호)
Wrong(불량)

Wrong(불량) Correct(양호)

5.2.20 The empty space caused by unevenness of products in the boxes should be filled up with wood
pieces in order to prevent the breakage caused by stacking during ocean transportation.
제품의 요철로 인한 박스 내부의 빈 공간은 목재로 보강하여 해상운송 시 박스의 적치로 인한
파손에 대비한다.

Wrong(불량) Correct(양호)

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 16 OF 188

5.2.21 The wooden boxes shall be covered with tent(PE Tarpaulin Min. 200g/㎡, Allowable range : -5%) to
prevent from weather effects such as rain during transportation and storage.
Only with specific need, PVC Tarpaulin shall be applied.(PVC Tarpaulin Min. 530g/㎡, Allowable
range : -5%)
※ Process : After assembling top plate of box, install a corner protector at upper corner, and its top
should be covered with vinyl and tent. And the edge of tent’s hem shall be fixed with webbing
belt.
※ Caution: unit area of tent in circulation on the market is 1.8 ㎡(Min. 360g/1.8 ㎡)
Wooden box 로 포장된 제품은 운송 중이거나 보관 시 우천 등에 직접적인 영향을 받지 않도록
Tent(PE Tarpaulin 사양 : Min. 200g/㎡, 허용 범위 : -5%)로 보호한다.
단, 특별한 요구 조건이 있을 경우에는 PVC Tarpaulin 을 사용할 수 있다.(PVC Tarpaulin 사양 :
Min. 530g/㎡, 허용 범위 : -5%)
※ 절차 : 상판 조립 후 상부 Corner 부위에 우금을 설치하고, 그 상부에 반드시 비닐을 씌우고
천막으로 덮어야 한다. 그리고 천막 끝 단은 웨빙벨트로 고정한다.
※ 주의 : 시중에 유통되는 단위 면적은 1.8 ㎡이므로 유의할 것(Min. 360g/1.8 ㎡)

PE Tarpaulin Min. 200g/㎡

5.2.22 For product packed in wooden skid or bundle, the timber which can have at least 120 mm of the
minimum distance between bottom of product and ground shall be used for packing.
Wooden Skid/Bundle 형태로 포장되는 제품은 제품과 지면 사이의 거리가 최소 120mm 이상이
될 수 있는 목재를 사용해서 포장한다.

5.2.23 In case of wooden skids the timber for skid shall be fixed tightly to the products with bolts or wire
ropes to prevent escaping of timber during transportation and handling.
스키드 포장 시 스키드용 목재는 볼트나 와이어로 제품에 단단히 고정하여 운송이나 취급 시 이
탈되지 않도록 한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 17 OF 188

5.2.24 The timber should be installed within at least 500mm from the both edges of products.
제품 양쪽 끝 단 부위에는 적어도 500mm 이내에 목재가 설치한다.

5.2.25 The bolts used in upper part of wooden skid/Bundle shall be fastened after grooving to avoid
interference during transportation or shipment.
Wooden Skid/Bundle 의 상부목재에 체결되는 Bolt 는 홈파기 작업을 실시하여 운송이나 선적작
업 시 간섭이 발생하지 않도록 한다.

Wrong(불량) Correct(양호)

5.2.26 The distance between wooden skids shall maintain the regular interval to make loading easy while
shipment.
Wooden Skid 간 간격은 일정한 간격을 유지하여 선적 시 적치가 용이하도록 한다.

5.2.27 The interval between bolts for fixing wooden skid and products should be maintained at least 30 cm
or more.
Wooden Skid 고정용 Bolt 와 제품간의 간격은 최소 30mm 이상을 유지 한다.

5.2.28 The minimum size of the bolts is 12 mm, but 16 mm bolts should be applied if the weight of packing
is more than 10 ton or height of packing is more than 1m.
Bolt 의 최소 규격은 12 mm 로 하며, 포장중량이 10 ton 초과 또는 포장높이가 1 m 를 초과할 때
는 16mm 를 사용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 18 OF 188

5.2.29 The contact surfaces between threaded bolts and products should be protected with Toilon.
전산 볼트와 제품 접촉부는 토일론으로 보호한다.

5.2.30 The fixing wood shall be fixed to avoid separating.

제품과 제품 사이의 고정목은 탈락되지 않도록 고정한다.

5.2.31 When products are packed in bundle by multi-stacking, struts(role of skid) between products shall be
aligned vertically and be tightened with bolts entirely to prevent separation. For products that can be
moved during the shipping or handling, each stage shall be fixed with Cord Strap or Steel band, and
struts should be applied between each stages.
When assembling, coated(galvanized or equivalent) bolts, nuts and washer shall be used and
surface of the bolts shall be protected by using the rubber hose
제품을 다단 적재하여 Bundle 포장 시 제품 사이의 받침목(Skid 역할)을 일직선 상에 위치시키고
전체를 Bolt 로 고정하여 이탈을 방지한다. 운송 또는 Handling 중 움직일 수 있는 제품은 각 단
별로 Cord Strap 또는 Steel Band 로 고정하고, 각 단과 단 사이에는 받침목을 필히 적용한다.
체결 시 코팅(아연 도금 등)된 볼트, 너트, 와셔로 체결하고, 볼트의 외부는 고무호스를 사용해서
보호한다.

Wrong(불량) Correct(양호)

Add Strut
Fix Bolt hole

5.2.32 Place cushioning materials between the products and fixed the products with Cord Straps or Steel
Band in order to prevent damages of painted surfaces from direct contact.
제품간 접촉으로 인한 도장면의 손상이 발생하지 않도록 완충재를 대고 Cord Strap 또는 Steel
Band 로 고정한다.

5.2.33 In case of packing in skid or bundle or pallet, the interval between Cord straps or Steel bands should
be below 2 m.
Skid, Bundle, Pallet 포장 시 Cord Strap 또는 Steel Band 의 간격은 2 m 이하로 한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 19 OF 188

5.2.34 In case of fixing product with Steel bands, the pad(plastic, Toilon, Film, etc.) shall be applied to
prevent the direct contact from the product.
제품을 Steel Band 로 고정할 경우에는 Steel Band 와 제품이 직접 접촉되지 않도록 Pad(Plastic,
Toilon, Film, etc.)를 적용한다.

5.2.35 The rubber pads that have the minimum thickness of 5 mm shall be placed between cord straps and
the sharp part of products in order to protect form damages, and packing shall be handled carefully.
손상으로부터 보호하기 위해서 Cord Strap 과 제품의 날카로운 부분 사이에는 고무 패드(min. 5t)
끼워 조심스럽게 취급한다.

5.2.36 Check if there is no loosen bolts due to the wood drying after packing completion and before
shipment. All bolts and nuts should be fastened tightly.
포장 완료 후 선적 전에 목재의 건조로 인한 Bolt/Nut 의 헐거움이 없는지 확인하고, 단단하게
조여지지 않은 부위가 없도록 한다.

5.2.37 Products packed in the Skid/Bundle/Pallet which are vulnerable to weather effects or dust during
transportation and storage shall be covered with tent to prevent.
Skid/Bundle/Pallet 로 포장된 제품 중 운송이나 보관 기간 동안 우천과 먼지 등의 영향에 취약한
제품은 천막으로 보호한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 20 OF 188

5.2.38 Stainless steel products(non-painted) which are vulnerable to seawater or water contaminants shall
be covered with tent when packed in the Skid/Bundle/Pallet.
※ Caution : Direct contact with packing materials that includes chlorine contents(PVC Tarpaulin,
etc.) shall be avoided.
해수나 오염물에 취약한 스테인리스 스틸 제품(미 도장된 제품)은 Skid/Bundle/Pallet 포장 시 천
막으로 제품을 보호한다.
※ 주의 : 염소 성분이 포함된 포장재(PVC Tarpaulin 등)의 직접 접촉은 피한다.

5.2.39 Products(PVC Pipe, etc.) which are vulnerable to ultraviolet rays shall be covered with tent when
packed in the Skid/Bundle/Pallet.
자외선에 취약한 제품(PVC Pipe 류 등)은 Skid/Bundle/Pallet 포장 시 천막으로 제품을 보호한다.

5.2.40 Products with galvanizing shall be required to have protection with tent or vinyl according to its shape
and packing type.
- Skid/Bundle/Pallet : All sides(including bottom side) covering with tent is required for the product
with shape that water could be stagnating
(However, covering with tent shall not be applied for the product with shape that water could not
be stagnating.)
- Wooden Box : All sides(including bottom side) covering of product with vinyl is required inside of
the box.
아연 도금된 제품은 제품 형상 및 포장 Type 에 따라 천막 또는 비닐로 보호작업을 한다.
- Skid/Bundle/Pallet : 물이 고일 수 있는 형태의 제품은 천막으로 전면(하부 포함) Covering 한다.
(단, 물이 고이지 않는 형태의 제품은 천막 작업을 적용하지 않는다.)
- Wooden Box : Box 내부 제품의 외부를 비닐로 전면(하부 포함) Covering 한다.

5.2.41 Products that are covered by tents shall be tied firmly by P.E ropes, cord strap, etc. to avoid being
torn during transportation.
천막으로 보호하는 제품은 바람이나 운송 중의 조건에 의해 천막이 파손되지 않도록 P.E 로프,
Cord Strap 등으로 단단하게 고정한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 21 OF 188

5.2.42 The flanged/non-flanged opening parts of product, pipe, tube, etc. shall be covered with plastic cap
or plywood, and sealed using adhesive tape that are low in halogen and sulfur.
1) Flanged opening
- The flange faces shall be covered with plywood that have the minimum thickness of 12mm, and
3 mm rubber gasket or Tiolon shall be inserted in order to seal. The quantity of bolts shall be at
least 4 points
- Additionally, flanged opening part(including pipe part) shall be covered with vinyl and tent, and
sealed using adhesive tape.
2) Non-flanged opening
- The non-flanged openings shall be covered with plywood or plastic cap or plastic sheet, and
sealed using adhesive tape. In case of using plywood or plastic sheet, opening part should be
sealed as much as possible with vinyl.
제품, Pipe, Tube 등의 Flanged/Non-flanged opening 부위는 플라스틱 캡 또는 합판으로 막고 저
할로겐 및 저 유황의 테이프로 밀봉한다.
1) 플랜지 개구부
- 플렌지에는 최소 12mm 두께의 합판을 대어 볼트로 체결해야 하며, 밀봉을 위하여 3mm
고무 가스켓이나 Toilon 을 끼워야 한다. 볼트의 수량은 적어도 4 Point 로 한다
- 추가로 플랜지 부위는(Pipe 부분 포함) 비닐과 천막으로 덮은 후 테이프로 밀봉한다.
2) 비 플랜지 개구부
- 비 플랜지 개구부는 합판이나 플라스틱 캡 또는 플라스틱 시트로 덮고, 테이프를 사용하여
밀봉한다. 합판이나 플라스틱 시트를 사용한 경우에는 반드시 비닐로 덮고 Taping 하여 밀봉
한다.

[Flanged opening]

Tape

Toilon or Rubber(Cushioning Material)

Plywood

Vinyl(비닐/방청비닐)

Tent

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 22 OF 188

[Non-flanged opening]

Tape Tape

Plywood or Plastic sheet

Plastic Cap
Vinyl

5.2.43 Lifting points shall be marked clearly on all Items.

모든 제품에는 Lifting point 를 명확하게 표기한다.

5.2.44 C.O.G(Center of Gravity) mark shall be marked clearly on all items and outside of packing.
- The weight of product is less than 20 Ton : 2 Point(Front/Back side for handling)
- The weight of product is more than 20 Ton : 4 Point
- For the product which C.O.G is not center : 4 Point(regardless of weight)
모든 제품과 포장 외부에는 무게중심을 표기한다.
- 20 Ton 미만 제품 : 2 Point(핸들링 기준 앞/뒷면)
- 20 Ton 이상 제품 : 4 Point
- 편 하중인 제품 : 중량에 상관없이 4 Point

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 23 OF 188

5.2.45 All products shall be packed properly to prevent damage caused by direct contact with handling
equipment during handling.
(Especially, handling points of products as Vessel, Tank, Big bore pipe, etc. packed in skid shall be
protected with timber, rubber pad, plastic, etc..)
모든 제품은 취급 시 핸들링 장비가 직접 닿아 손상이 발생하지 않도록 적절하게 보호하여 포장
한다.
(특히, Skid 형태로 포장되는 Vessel, Tank, 대구경 Pipe 등의 제품 Handling 부위는 목재, 고무패
드, Plastic 등으로 보호한다.)

Handling 부위
Fork Lift Handling Protection 보호조치 양호

Protection with Rubber Pad Protection with Timber

5.2.46 Areas of products that contact directly with handling equipment while moving or transportation should
be protected with wood pieces, wood boards and plywood.
제품의 이동 및 운송 시 핸들링 장비가 직접 닿는 부위는 목재, 판재, 합판 등을 사용해서 보호
한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 24 OF 188

5.2.47 Sling point of Products weighed more than 3 Ton packed in pallet shall be protected with the wire
cover lower. The specification for wire cover lower refer to the specification of the wooden
box(Appendix.Ⅱ).
Pallet 로 포장된 3 Ton 이상의 제품은 Sling point 에 Wire 보호 구금을 설치한다. 구금의 사양은
Wooden Box 사양(Appendix.Ⅱ)을 참조한다.

5.2.48 The handling positions of the products should be protected with the timber. In case of difficulties,
handling equipment should be covered with cushioning materials for protection of products.
제품 핸들링 부위는 목재로 보호되어야 하고 목재의 설치가 어려울 경우에는 제품의 보호를 위
하여 핸들링 장비에 완충재를 부착한다.

5.2.49 Thin products which have risk of deformation caused by direct contact with handling equipment(Wire,
Fork, etc.) shall be packed in wooden boxes or steel frame.
핸들링 장비(Wire, Fork 등)가 직접 닿아 변형의 우려가 있는 박판의 제품은 박스나 Steel Frame
으로 포장해야 한다.

Open Crate

Steel Frame

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 25 OF 188

5.2.50 In case of steel framed skid, uneven parts should be covered or leveled with nylon ropes or plywood
before covering it with tents in order to prevent product’s damages caused by rain water pools on
tent’s top during transportation and storage at sites. And extra lifting lugs for handling should be
installed to prevent damages of tents or products caused by wire ropes when handling products.
스틸 프레임 스키드 포장의 경우, 운송 또는 현장 보관 시 천막 상부의 빗물 고임에 의한 제품
손상을 방지하기 위해 천막설치 전에 나일론로프 또는 합판을 사용하여 요철부를 제거하거나 평
평하게 해야 하며, 제품 핸들링 시 와이어로프에 의한 천막 또는 제품의 파손을 방지하기 위해
별도의 리프팅 러그를 설치한다.

Lifting Lug

Plywood

5.2.51 For the products which are over 20 tons and are packed in wooden skid, packing drawing for product
should be included in the packing procedure and should be submitted to DOOSAN for approval.
20 톤 이상 Skid 포장 제품은 반드시 포장 도면을 포장절차서에 반영하여 두산에 승인용으로 제
출한다.

5.2.52 Non-ferrous metals should be wrapped in vinyl and protected with tapes in order to prevent air inflow
as much as possible.
비철금속은 반드시 비닐로 감싸고 최대한 공기 들어가지 않도록 테이프 등으로 보호한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 26 OF 188

5.2.53 In case of wooden box, pallet, skid and so on, timber and timber shall be assembled with bolts or nail,
and timber which are more than 90x90mm shall be assembled with bolts according to below table.
Wooden Box, Pallet, Skid 등 포장 시, 목재와 목재는 못 또는 볼트를 사용하여 조립하고,
90x90mm 이상의 목재는 하기 표와 같이 볼트를 사용하여 조립한다.

1) Bottom of Wooden Box/Pallet(Wooden Box/Pallet 밑판)

Division Thickness Assembly method

Header
≥ 90mm with bolts(Min.12mm)
머리목
≤ 60mm with nails
Lifting point with bolts(Min.12mm)
Load Bearing Floor Member ≤ 90mm One half : with bolts(Min.12mm)
Except for Lifting Point
부하목 The others : with nails
90mm < T ≤ 150mm with bolts(Min.12mm)
> 150mm with bolts(Min.16mm)
※ If load bearing floor member is 90x90mm, screws can be used instead of bolts(quantity : 2 ea/point)
2) In case of skid, Min. 12mm bolts shall be applied for assembly between the timbers(more than 90x90mm) normally.
(But, Min. 16mm bolts shall be applied for timbers which are more than 150x150mm)
Skid 포장 시, 목재 사이의 결합(90x90mm 이상)에는 기본적으로 12mm 볼트를 적용한다.
(단, 150x150mm 초과하는 목재는 Min.16mm 볼트 적용)

5.2.54 In case of transportation with dry container, the timber direction of rubbing strip of box/pallet/skid
shall be applied in the same direction as the longitudinal direction of the container.
Dry Container 로 운송할 경우, Box/Pallet/Skid 의 밑받침목 목재 방향은 Container 길이 방향과
동일한 방향으로 적용해야 한다.

Sliding

5.2.55 One copy of packing list shall be put in the vinyl bag and be attached by using steel covers to the
outside of packages.
(In case of box, on copy of packing list shall be put in the box if additional required.)
Packing list 1 부를 비닐 봉지에 넣어 철재 커버로 Package 외부에 부착한다.
(별도의 요청이 있을 경우, Packing List 1 부를 Box 내부에도 넣어야 한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 27 OF 188

5.2.56 Products(Paint/Thinner, Battery, etc.) which are classified as dangerous goods should be packed
according to the related international regulation such as IMDG Code(International Maritime
Dangerous Goods Code), TI(Technical Instructions for the safe transport of dangerous goods by air)
and so on.
위험물로 규정된 제품(페인트/신나, 배터리 등)은 국제해상위험물 규칙(IMDG Code, Internation
-al Maritime Dangerous Goods Code), 위험물항공운송기술지침(TI, Technical Instructions for
the safe transport of dangerous goods by air) 등 관련 국제 기준에 따라서 포장해야 한다.

5.3 Packing for Headers, Tubes & Panels(Header, Tube 및 Panel 포장)

5.3.1 Non-flanged openings should be covered with plastic caps or plywood and be sealed fully.
비 플랜지 개구부는 플라스틱 캡 또는 합판으로 막고 밀봉 한다.

5.3.2 Wooden skids should be installed within 300 mm from both end sides of coils & panels. Especially,
wooden skid of coils shall be installed on more than 5 positions with consideration for stacks of coils.
Coil & Panel 은 양쪽 End Side 에서 300 mm 이내에 Wooden Skid 가 설치되어야 한다. 특히,
Coil 은 Stacking 을 고려하여 Wooden Skid 를 최소 5 군데 이상 설치한다.

5.3.3 For pressure units(Header, Tube, Panel), the minimum thickness of lower timber shall be 150 mm or
more.
압력부(Header, Tube, Panel) 포장 시 하부 목재 최소 규격은 150 mm 이상이어야 한다.

5.3.4 The timbers that support tubes or panels shall be installed at regular intervals in order to stack easily
while transportation.
Tube 나 Panel 을 지지하는 포장용 목재는 운송작업 시 적재가 용이하도록 일정한 간격을 유지
한다.

5.3.5 Install the protection pads on handling equipment for pressure units in order to protect products
during handling.
압력부 핸들링 장비에는 보호대를 설치하여 취급 시 제품을 보호한다.

5.3.6 Mark the warning mark on the panels and coils that have lower protrusions.
하부 돌출부가 있는 Panel 및 Coil 류에는 주의마크를 표기한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 28 OF 188

5.4 Packing for Steam Drum(Steam Drum 포장)

5.4.1 Internal materials(applied short term rust prevented) which are loose part should be packed in the
moisture proof packing, and timbers and packing materials which contain moisture shall not be
packed together in the moisture proof packing.
(Hang on the V.C.I(30g/㎥) & Desiccant(300g/㎥) inside of Al Foil)
Loose part 로 공급되는 Internal 자재(단기 방청 적용)는 방습포장 해야 하며 방습포장 내부에는
각재와 습기가 있는 자재는 같이 포장되어서는 안 된다.
(V.C.I(30g/㎥) & Desiccant(300g/㎥)를 Al Foil 내부에 투입한다.)

【FIG.1】 Packing sketch for steam drum(For Reference)

5.5 Packing for Steel Structure(철골 포장)

5.5.1 The timbers should be installed at every interval of 1.5 ~ 2 m.(Column : Max. 3 m)
버팀목과 버팀목의 사이는 1.5 ~ 2 m(Column : Max. 3 m) 간격마다 설치한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 29 OF 188

5.5.2 The timbers that support beams or girders shall be installed at regular intervals in order to stack
easily while transportation.
Beam 이나 Girder 를 지지하는 포장용 목재는 운송 작업 시 적재가 용이하도록 일정한 간격을
유지한다.

5.5.3 Apply the plywood (min. 12 mm) to the bottom of the base plate such as columns to prevent damage.
Column 등 Base Plate 하부에는 Damage 방지용 합판(Min. 12 mm)을 부착한다.

5.5.4 Add the plastic guards to the contacting surface between metal and metal, and then execute the
banding work.
Metal 과 Metal 사이의 접촉부에는 Plastic 보호대를 추가하여 Banding 작업을 실시한다.

5.5.5 Pack the members including brackets at both ends in separated packing horizontally, and
complement product using the struts.
Bracket 이 양쪽 끝 단에 붙은 부재는 수평으로 별도 포장을 실시하고, 버팀목을 보강한다.

5.5.6 Big sized members and small sized members shall be packed separately. If they are packed together,
pack them stably with members having small difference in the size and tighten with Cord Straps or
Steel Band.
Size 가 큰 부재와 작은 부재는 별도로 포장하고, 같이 포장할 시에는 Size 의 차이가 많이 나지
않는 부재로 안정적으로 포장하고 Cord Strap 또는 Steel Band 를 고정한다.

Wrong(불량) Correct(양호)

5.5.7 In case of pipe braces, gusset plates that are delivered as assembled form shall be disassembled
and packed separately in boxes for efficiency of packing. In this case, marking of member’s number
and lists of member should be written thoroughly.
Pipe Brace 의 경우 조립되어 납품되는 Gusset Plate 는 포장의 효율성을 위해 분리하여 별도로
Box 포장한다. 단, 부재 No. 마킹 및 부재 list 를 철저히 작성한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 30 OF 188

5.5.8 Products should be tightly tied to each other using Cord Strap or Steel Band.
제품과 제품은 Cord Strap 또는 Steel Band 를 사용하여 단단하게 체결한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 31 OF 188

Appendix : Wooden Bundle(Bolt Type)------ Apply to ocean transportation

※ Steel Band(Min. 19mm) can be used instead of Cord Strap(Min. 25mm). In case of using the steel band, steel band cannot
contact with product directly.
Cord Strap(Min. 25mm)은 Steel Band(Min. 19mm)로 대체할 수 있다. 단, Steel Band 적용 시에는 제품과 직접 접촉되지
않도록 한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 32 OF 188

Appendix : Wooden Bundle(Cord strap Type)------ Apply to local transportation

※ Steel Band(Min. 19mm) can be used instead of Cord Strap(Min. 25mm). In case of using the steel band, steel band cannot
contact with product directly.
Cord Strap(Min. 25mm)은 Steel Band(Min. 19mm)로 대체할 수 있다. 단, Steel Band 적용 시에는 제품과 직접 접촉되지
않도록 한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 33 OF 188

5.6 Packing for Carbon/Stainless Steel Pipe(카본/스테인리스 스틸 파이프에 대한 포장)

5.6.1 Flanged/Non-flanged opening of pipe shall be protected according to the general(clause 5.2.42).
파이프의 플랜지/비 플랜지 개구부는 일반사항(5.2.42 항)에 따라 보호되어야 한다.

5.6.2 For inside of carbon steel pipe V.C.I shall be applied , and for inside of stainless steel pipe desiccant
shall be applied.(Refer to Fig. 2)
탄소강 파이프 내부에는 V.C.I 가 투입되어야 하며, 스테인리스 스틸 파이프 내부에는 건조제가
투입되어야 한다.(그림. 2 참조)

【FIG.2】

Carbon Steel Pipe SUS Pipe

Desiccant

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 34 OF 188

5.7 Packing for Small Pipes and Fittings(작은 배관류와 피팅류에 대한 포장)

5.7.1 The small pipes and fittings that are easy to get lost shall be packed in the wooden boxes.
분실하기 쉬운 작은 Pipe 나 Fitting 류의 경우는 목재 박스를 적용해야 한다.

5.8 All piping products shall be packed in pallets or bundles type which is able to pile up with several layers in
the holds of vessels when shipping or transportation.
모든 배관류 제품은 선, 하역 및 운송 시 선박 내부에서 다단적치가 가능하도록 Pallet or Bundle type
으로 포장되어야 한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 35 OF 188

5.9 Packing for Items of Condenser(컨덴서류에 대한 포장)

5.9.1 The opened part of Shell & Hotwell shall be covered with plywood, and then upper part of them shall
be covered with plastic sheets in order to protect from the foreign materials entering to inside of
products. The toilon shall be placed between tube sheet faces and plywood for protection to prevent
damages when packing Shell.(Refer to Fig. 3)
Shell & Hotwell 의 Opening 부위는 합판으로 봉하고, 그 위를 천막으로 보호하여 내부에 이물질
이 투입되지 않도록 한다. Shell 포장 시 튜브 시트면과 보호용 합판 사이에 토일론을 넣어 손상
을 방지한다.(그림. 1 참조)

5.9.2 The upper aspect of the Extended Neck and Transition shall be covered with plastic sheets in order
to protect from the foreign materials entering to inside of products.(Refer to Fig. 4)
Extended Neck 과 Transition 은 상부를 천막으로 보호하여 내부에 이물질이 투입되지 않도록 한
다.(그림. 4 참조)

【FIG.3】

Timber

Plywood
Plastic Sheet

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 36 OF 188

5.9.3 Items of Condenser(Miscellaneous components such as spray pipe, pad, plate & coupling, etc.) shall
be transported safely by choosing the most reasonable type among the boxes, bundles and skids
according to their shape and specification.
컨덴서의 기자재는 품목의 형상 및 특성에 따라 Box, Bundle, Skid 중 가장 합리적인 것을 선택
하여 안전하게 수송할 수 있도록 한다.

【FIG.4】

[Transition] [Neck]

5.10 Packing for Air & Gas Duct(Air & Gas Duct 포장)

5.10.1 The timbers that support beams or girders shall be installed at regular intervals in order to stack
easily while transportation.
Beam 이나 Girder 를 지지하는 포장용 목재는 운송 작업 시 적재가 용이하도록 일정한 간격을
유지해야 한다.

5.10.2 Add the plastic guards to the contacting surface between metal and metal, and then execute the
banding work.
Metal 과 Metal 사이의 접촉부에는 Plastic 보호대를 추가하여 Banding 작업을 실시한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 37 OF 188

FIG.5 : Panel Type (1)------ Packing Style(Pallet)

※ Steel Band(Min. 19mm) can be used instead of Cord Strap(Min. 25mm). In case of using the steel band, steel band cannot
contact with product directly.
Cord Strap(Min. 25mm)은 Steel Band(Min. 19mm)로 대체할 수 있다. 단, Steel Band 적용 시에는 제품과 직접 접촉되지
않도록 한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 38 OF 188

FIG 6 : Panel Type (2)------ Packing Style(Pallet)

※ Steel Band(Min. 19mm) can be used instead of Cord Strap(Min. 25mm). In case of using the steel band, steel band cannot
contact with product directly.
Cord Strap(Min. 25mm)은 Steel Band(Min. 19mm)로 대체할 수 있다. 단, Steel Band 적용 시에는 제품과 직접 접촉되지
않도록 한다.
Doosan Heavy Industries & Construction Co., Ltd.
WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 39 OF 188

FIG 7 : Panel Type (3)------ Packing Style(Wooden Bundle)

※ Steel Band(Min. 19mm) can be used instead of Cord Strap(Min. 25mm). In case of using the steel band, steel band cannot
contact with product directly.
Cord Strap(Min. 25mm)은 Steel Band(Min. 19mm)로 대체할 수 있다. 단, Steel Band 적용 시에는 제품과 직접 접촉되지
않도록 한다.
Doosan Heavy Industries & Construction Co., Ltd.
WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 40 OF 188

FIG 8 : H-Beam, Support, Plate, etc.------ Packing Style(Wooden Bundle)

※ Steel Band(Min. 19mm) can be used instead of Cord Strap(Min. 25mm). In case of using the steel band, steel band cannot
contact with product directly.
Cord Strap(Min. 25mm)은 Steel Band(Min. 19mm)로 대체할 수 있다. 단, Steel Band 적용 시에는 제품과 직접 접촉되지
않도록 한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 41 OF 188

5.11 Packing for module assemblies(MODULE ASS‘Y 포장)

5.11.1 The upper and side aspect of the module assemblies shall be attached by timbers, and the upper
aspect of them shall be covered with plywood(or DANPRA*). And then all aspect of the module
assemblies shall be covered with tent in order to protect from the rain or foreign materials entering to
inside of products.(Refer to the following photographs)
모듈의 상부 및 옆면은 각목을 붙이고 상부는 합판을 덮는다. 그리고 비나 외부 물질의 내부 유
입을 막기 위해 전면을 천막으로 덮는다.(하기 그림 참조)

TIMBER & PLYWOOD TENT COVERING

* Plywood : Apply to Ocean Transportation, DANPRA : Apply to Local Transportation

** Tent : PE Tarpaulin(Min. 200g/㎡) or PVC Tarpaulin(Min. 530g/㎡), Allowable range : -5%

5.12 Packing for Bolt(Bolt 포장)

5.12.1 The thread of bolt shall be protected with bolt net, rubber pad(2t or more), etc. to protect thread after
adequate rust preventative. But, thread shall be covered with the anti-corrosive vinyl before applying
rubber pad.
※ Rubber pad(2t or more) shall be used for bolts(diameter is more than 76mm), and rubber pad(3t
or more) shall be used for bolts(diameter is more than 127mm).
볼트의 나사산은 적절한 방청작업 후 나사산 보호를 위해 볼트 망, 고무패드(2t 이상) 등으로 보
호한다. 단, 고무패드를 적용할 경우에는 나사산을 방청비닐로 감은 후에 적용해야 한다.
※ 지름 76mm 이상인 볼트에는 고무패드(2t 이상)를 적용하고, 지름 127mm 이상인 볼트에는
고무패드(3t 이상)를 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 42 OF 188

5.12.2 Small bolts shall be placed in cartons box or inner wooden box after protective process, and be
packed in the wooden box.
소형 볼트는 보호 작업 후 종이박스나 Inner Wooden Box 에 넣은 후 Wooden Box 로 포장한다.

5.12.3 If diameter of the bolt is more than 76mm, it shall be fixed on timber in groove dug in round or V-
shaped.
지름 76mm 이상인 Bolt 는 라운드 또는 V 형의 홈을 판 목재로 고정한다.

5.12.4 In case of multi stacking in the box, products with exception of timber of each stage shall be wrapped
with vinyl to prevent condensation.
Box 내 다단 적재할 경우, 결로 현상을 방지하기 위해 각 단별로 목재를 제외한 제품만 비닐로
감싼다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 43 OF 188

6.0 Marking (마 킹)

6.1 All packages shall have clear shipping mark. The size of letters shall be normally 2.5 cm or bigger.
If impossible, the letter size will be determined by size of packages. The shipping mark shall be followed
the standard format of each PJT, or apply the standard format below if there’s no particular format.
모든 패키지에는 SHIPPING MARK 를 표기한다. 문자의 크기는 보통 2.5 cm 이상이며, 마킹 상 무리
한 경우는 그 품목에 따른 크기로 한다.
Shipping Mark 는 PJT 별 표준양식을 따르고, 별도 양식이 없는 경우에는 하기의 표준양식을 적용한
다.

SHIPPING MARK

XXXXXXX x XXXMW
POWER PLANT PROJECT

CONTRACT NO.: XXXXXXXXXX

CONTRACT PACKAGE : XXXXXXX

Package No. :
Description :
Net Weight :
Gross Weight :
Dimension : Lx Wx H cm, CBM
Destination :
Country of Origin :

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 44 OF 188

6.2 The shipping mark shall be stenciled on the product directly, attached after printing and coating A4 or A3
paper to the product, or pasted waterproofing sticker on the products.
In case of coating, coating paper shall have enough space(Min. 1 cm) for stapling that the staple does not
go through the paper.
Shipping Mark 는 제품에 직접 스텐실 하거나, A4 또는 A3 용지에 인쇄 후 코팅하여 부착 또는 방수
형 스티커로 제작하여 부착한다.
코팅 Type 으로 적용 시에는 고정을 위한 스테이플러가 종이를 관통하지 않도록 코팅지의 사이즈에
충분한 여유(Min. 1 cm)를 준다.
※ A3 sized paper shall be used for the box that is bigger than height: 1m, front/rear panel: 5 ㎡
높이 1m 이상, 앞/뒷판 면적이 5 ㎡ 이상인 Box 에는 A3 용지를 사용한다.

6.3 The appropriate instruction for handling, transportation and storage shall be marked on outside of the
package using stencil.(Refer to Table 1)
취급, 수송 및 저장에 대한 적절한 지시사항도 Stencil 을 사용하여 외장에 마킹 한다.(Table 참조)

6.4 Care marks should be marked using a red-waterproofing stencil.(Refer to Table) If the background color is
black or dark color, the contrasting color for marks shall be applied.
주의 마크의 색깔은 적색으로 유성 잉크를 사용하여 스텐실 한다. (Table 참조) 만약, 바탕색이 검정색
이거나 어두운 색 일 경우는 대조적인 색으로 스텐실 한다(Steel Structure 의 주의 마크는 검정색 적용).

TABLE
Ink
No. Mark Location Size Remarks
Color Material
* Available material – stencil, plywood,
1 Main Shipping Mark Black
coating paper, sticker(fixed with tape)
High quality
Optimum size for
Sling Mark waterproof ink Both sides
each package
or oil paint
2 Care Mark Center of Gravity Mark Red
Other Mark
Yellow letters on Upper part of Optimum size for
3 Packing List Cover Enamel * Use tinplate
black background one end packing list cover
※ Refer to the Appendix.Ⅴ.
상세한 사항은 Appendix.Ⅴ를 참조할 것

6.5 The content of shipping marks should be recorded accurately in order to avoid the difficulty of identifying
material at the site.(INV.NO, PKG NO, DIMENSION, PKG Q’TY etc.)
Shipping Mark 의 내용은 현장에서 자재식별에 어려움이 발생하지 않도록 정확하게 기록 한
다.(INV.NO, PKG NO, DIMENSION, PKG Q’TY etc.)

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 45 OF 188

6.6 When the shipping marks are manufactured with plywood, management items should be recorded with
black oil-based pen or paint.
합판으로 Shipping Mark 제작 시, 관리항목은 검정색 유성 펜 또는 유성 페인트로 기록 한다.

6.7 When the shipping marks are manufactured with tri-acetate films, the letters shall be recorded with oil-
based pen or paint or be stenciled.
아스테이지로 Shipping Mark 를 제작할 경우, 글씨는 유성 펜 또는 유성 페인트로 기재하거나 Stencil
한다.

6.8 In case of the wooden boxes the shipping marks shall be attached to the surface of plywood directly.
합판 밀폐 포장 시 Shipping Mark 를 합판에 직접 부착한다.

6.9 When using the coating films or tri-acatate films, shipping mark should be fixed by punching with a stapler.
If necessary, its top can be fixed with tapes additionally.
코팅지 혹은 아스테이지 사용 시 필히 스테이플러로 Shipping Mark 테두리 4 면을 고정한다. 필요한
경우에는 그 상부에 테이프로 추가로 고정할 수 있다.

6.10 When skids are fixed with cord straps or steel bands, shipping mark can be fixed with cord straps or steel
bands used.
Skid 를 Cord Strap 또는 Steel Band 로 고정한 경우에는 Shipping Mark 는 Cord Strap 또는 Steel
Band 로 고정할 수 있다.

6.11 If it’s hard to attach the coating films to products such as steel structures, a sticker should be used and
four edges of the shipping marks shall be fixed with tapes.
Steel Structure 와 같이 코팅지 부착이 어려운 경우 Sticker 를 부착하되 테두리 4 면을 테이프로 고정
한다.

6.12 Stencil or sticker shall be used for marking of care marks and warning marks.
주의마크 나 경고마크의 표기 방법은 Stencil 또는 Sticker 를 사용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 46 OF 188

7.0 Shipping(운 송)

7.1 General(일반 사항)

7.1.1 Every handling tools or equipment shall be checked for their capability before using.
취급 도구나 장비 사용 전에 각 장비는 적정성 유무를 확인한다.

7.1.2 The experienced or trained person should be assigned to the working that need special handling or
lifting equipment.
특별한 취급이나 Lifting 장비를 사용 시 경험이 있거나 능숙한 인원이 배치되어야 한다.

7.2 Handling(취급)

7.2.1 Followings shall be considered when handling with devices and equipment.
1) Product’s characteristics such as size, weight and center of gravity.
2) Handling types such as lifting, turning and positioning.
장치나 장비를 사용하여 취급 시 다음과 같은 사항을 고려해야 한다.
1) 품목의 크기, 무게, 균형점과 같은 품목의 특성.
2) 들어 올리기나 회전과 같은 취급 형태.

7.2.2 Handling shall be performed carefully to prevent damage of machined surfaces, deletion of
identification and distortion of products.
취급 시 가공 면의 손상, 표시 혹은 마킹의 지워짐 그리고 형상의 비틀림을 막기 위해 주의하여
수행해야 한다.

7.2.3 The length of wire depends on size of product, and the angels between wires can’t exceed 60°
generally.
Wire 길이는 각 부품의 크기에 따라 선택되어야 한다. Wire 의 각도는 일반적으로 60°를 초과해
서는 안 된다.

7.2.4 Every handling tools or equipment shall be checked for their capability before using.
취급 도구나 장비 사용 전에 각 장비는 적정성 유무를 확인한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 47 OF 188

7.2.5 The experienced or trained person shall be assigned to the working that need special handling or
lifting equipment.
특별한 취급이나 Lifting 장비를 사용 시 경험이 있거나 능숙한 인원이 배치되어야 한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 48 OF 188

Handling Instruction

Sling belt

[Handling Item : Panels, Tubes(Over 10m)]

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 49 OF 188

TABLE 1

NAME OF LETTERS
NO MARK STENCILED REMARKS
MARK STENCILED

Center of At the center of

1 None
Gravity gravity

Where sling wire is

2 Sling None
to be applied

When package cannot

3 Top Up
be placed upside down

For water proof and

4 Keep dry Keep dry
moisture-proof boxes

Handle
5 Fragile For fragile cargo
with care

Heavy Heavy
When center of gravity
6 weight weight
is on one side
this end this end

Do Do
For Precision Goods,
7 Not Not
fragile
Stack Stack

No Folk No Folk Where forklifts

8
Lift Trucks Lift Trucks are not available

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 50 OF 188

Appendix I : Box Construction

Style 1 : Case(A) Style 2 : Case(B)

Style 3 : Crate Style 4 : Open Crate

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 51 OF 188

Appendix II : Wooden framed boxes for packing

1) Case

No. Description
1 Skid 활재
2 Header 머리목
3 Load Bearing Floor Member 부하목
4 Non-Load Bearing Floor Member 바닥재
5 Rubbing Strip 밑받침목
6 Upper Horizontal Member 상단가로대
7 Lower Horizontal Member 하단가로대
8 Strut 세로대
Sheathing; L=Lumber 판재
9
P=Plywood (KS F 3101) 합판
10 Ventilation Cover 환기구 커버
11 Joist Support 보받침대
12 Aux. Strut 보강기둥
13 Top Joist 천정보
14 Vinyl 비닐
15 Tarpaulin Sheet 타포린 천막
16 Webbing Belt 웨빙벨트
17 Corner Protector 우금
18 Edge Protector 각금
Wire Cover Upper 와이어커버(상)
19
Lower 와이어커버(하)
20 Packing List Case 패킹리스트함
21 Fixing Timber For Top Joist 부동목

Top nailing shall be

excluded

1. Panels(Front, Rear, Sides and Top) of the Case are made of plywood.
Case(합판 박스)는 앞, 뒤, 옆, 상판은 합판으로 제작한다.
2. For top panel assembly process, install plywood first and apply corner protectors at the upper corners. Finally, cover its top with vinyl and
install the tent.
상판 조립은 먼저 합판을 조립하고 코너에 우금을 적용한다. 마지막으로, 상부를 비닐로 덮고 천막을 설치한다.
Doosan Heavy Industries & Construction Co., Ltd.
WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 52 OF 188

2) Crate

Top nailing shall be

excluded

1. Panels(Front, Rear, Sides and Top) of the Crate are made of lumber.
Crate(판재 박스)는 앞, 뒤, 옆, 상판은 판재로 제작한다.
2. Water proof paper shall be applied to the inside of panels(Front, Rear and Sides) to prevent water inflow.
앞, 뒤, 옆판 내부에는 물이 유입되지 않도록 방수지로 적용한다.
3. For top panel assembly process, install plywood(3t) first and cover it with vinyl and assemble lumber. Finally, apply corner protector at the
upper corner and install the tent.
상판 조립은 먼저 3t 합판을 조립한 후 비닐을 덮고 판재를 조립한다. 마지막으로, 코너에 우금을 적용한 후 천막을 설치한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 53 OF 188

3) Materials of Wooden Framed Box

[Table 1] Skid/Rubbing Strip of Wooden Framed Box [Unit: mm]

Size of Skid Size of Rubbing Strip
Weight(Ton) Internal length of Box
(1)활재 (5)밑받침목
No.
Lower Limit(≥) Upper Limit(<) Lower Limit(≥) Upper Limit(<) Width Thickness Width Thickness

1 0 0.7 0 - 90 60 90 90
2 0 3,000 90 60 90 90
0.7 1
3 3,000 - 90 90 90 90
4 0 3,000 90 60 90 90
1 2
5 3,000 - 90 90 90 90
6 2 4 0 - 90 90 90 90
7 4 5 0 - 105 105 90 90
8 0 3,000 105 105 105 120
5 7.5
9 3,000 - 120 120 120 120
10 0 3,000 120 120 120 120
7.5 12.5
11 3,000 - 150 150 150 120
12 0 3,000 150 150 150 120
12.5 17.5
13 3,000 - 180 180 180 120
14 0 3,000 180 180 180 120
17.5 25
15 3,000 - 210 210 210 120
16 0 3,000 210 210 210 120
25 35
17 3,000 - 240 240 240 120
18 0 1,500 210 210 210 120
35 45
19 1,500 - 240 240 240 120
20 0 3,000 240 240 240 120
45 60
21 3,000 - 300 300 300 120

1. All boxes shall be designed according to “table 1, 2, 3” of “AppendixⅠ, Ⅱ” in this instruction

모든 박스는 본 절차서의 ‘첨부Ⅰ, Ⅱ’의 ‘표 1, 2, 3’에 따라 설계되어야 한다.
2. The other detailed composition for wooden box except referenced standard of making box shall be applied in consideration of the weight
and form of products.(The KS and JIS standard shall be applied to the manufacture of boxes.)
언급된 박스 제작 기준 외 다른 항목에 대한 상세사항은 제품 형상과 중량을 감안하여 적용한다.
(KS 또는 JIS 기준에 준한 박스 제작기준을 적용한다.)

[Table 2] Top Joist/Horizontal Member/Strut of Wooden Frame Box [Unit: mm]

Size of Horizontal
Size of Top Joint
Weight(Ton) Internal Width of Box Member & Strut
No. (13) 천정보
(6/7)가로대 (8)세로대
Lower Limit(≥) Upper Limit(<) Lower Limit(≥) Upper Limit(<) Width Thickness Width Thickness
1 0 2,000 90 60 90 30
0 5
2 2,000 - 90 90 90 30
4 0 1,800 90 60 90 30
5 5 7 1,800 2,500 90 90 90 30
6 2,500 - 105 105 90 30
7 0 2,000 90 90 90 30
8 7 10 2,000 2,500 105 105 90 30
9 2,500 - 120 120 90 30
7 0 2,000 90 90 90 45
8 10 12 2,000 2,500 105 105 90 45
9 2,500 - 120 120 90 45
10 0 1,600 105 105 90 45
11 12 50 1,600 2,500 120 120 90 45
12 2,500 - 150 150 90 45
10 0 1,600 105 105 120 60
11 50 60 1,600 2,500 120 120 120 60
12 2,500 - 150 150 120 60

3. Joist Support and Aux. Strut shall be applied to the boxes(Internal height is 1,400 mm or over) for domestic and the all boxes for export.
보받침(Joist Support), 보강기둥(Aux. Strut)은 국내박스(내치수 높이 1,400 mm 이상)과 수출박스 전체에 적용한다.
4. Joist Support and Aux. Strut shall be applied to same size of Horizontal Member and Strut.
보받침(Joist Support), 보강기둥(Aux. Strut)은 가로대/세로대(Horizontal Member, Strut)와 동일한 Size 로 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 54 OF 188

5. For the boxes made by plywood, 12T plywood shall be applied. But, 9T plywood can be allowed for boxes(weight of product ≤ 2 Ton)
for domestic.
합판 박스의 경우, 합판은 12 T 를 적용하지만, 국내 2 Ton 이하의 경우 9 T 합판도 허용한다.
6. For the boxes made by lumber, 18T lumber shall be applied. But, 15T lumber can be allowed for boxes(weight of product < 6 Ton).
판재 박스의 경우, 판재는 18t 를 적용하지만, 6 Ton 미만의 경우 15t 판재를 허용한다.
7. For the non-load bearing floor member, 18T lumber shall be applied. But, 15T lumber can be allowed for boxes(weight of product < 6 Ton).
바닥재의 경우, 판재는 18t 를 적용하지만, 6 Ton 미만의 경우 15t 판재를 허용한다.

[Table 3] Header/Load Bearing Floor Member of Wooden Frame Box [Unit: mm]
Size of Header Size of L.B.F.M.
Weight(Ton) Internal Width of Box
No. (2)머리목 (3)부하목
Lower Limit(≥) Upper Limit(<) Lower Limit(≥) Upper Limit(<) Width Thickness Width Thickness
1 0 2000 90 45 90 45
2 0 2 2,000 4000 90 60 90 60
3 4,000 - 90 90 90 90
4 0 4000 90 60 90 60
2 3
5 4,000 - 90 90 90 90
6 3 4 0 - 90 90 90 90
7 0 4,000 90 90 90 90
4 5
8 4,000 - 105 105 105 105
9 0 3,000 90 90 90 90
10 5 7.5 3,000 4,000 105 105 105 105
11 4,000 - 120 120 120 120
12 0 4,000 105 105 105 105
7.5 10
13 4,000 - 120 120 120 120
14 0 3,000 105 105 105 105
10 12.5
15 3,000 - 120 120 120 120
16 0 4,000 120 120 120 120
12.5 17.5
18 4,000 - 150 150 150 150
19 0 2,000 120 120 120 120
17.5 20
20 2,000 - 150 150 150 150
21 0 1,300 120 120 120 120
22 20 25 1,300 4,000 150 150 150 150
23 4,000 - 180 180 180 180
24 0 1,300 150 150 150 150
25 25 35 1,300 4,000 180 180 180 180
26 4,000 - 210 210 210 210
27 0 4,000 180 180 180 180
35 40
28 4,000 - 210 210 210 210
29 0 3,000 180 180 180 180
40 45
30 3,000 - 210 210 210 210
31 0 4,000 210 210 210 210
45 50
33 4,000 - 240 240 240 240
34 0 4,000 210 210 210 210
50 55
35 4,000 - 240 240 240 240
36 0 3,000 210 210 210 210
55 60
37 3,000 - 240 240 240 240

[Table 4] Corner/Edge Protector and wire cover of Wooden Frame Box [Unit: mm]
구분 under 3ton 3~5ton 5~10ton 10~20ton 20~30ton over 30ton
Wire Cover(Upper) - 700x60x60(3t) 900x75x75(3t) 900x75x75(5t) 1000x75x75(8t) 1200x100x100(10t)
Wire Cover(Lower) - 150x60x60(3t) 200x60x60(5t) 250x75x75(6t) 300x75x75(9t) 700x100x100(10t)
Corner Protector 140x140x140(0.5t)
Edge Protector 100x19x(0.5t)
The size of materials shall be equivalent or more than the table.

Corner Protector Edge Protector

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 55 OF 188

세로대,
가로대

※ Timber of Panels(Front, Rear and Sides) shall be assembled on the skid so that the box is not easily damaged from external loads.
박스가 외부 하중으로부터 쉽게 파손되지 않도록 앞, 뒤, 옆판 각재는 활재 위로 조립되어야 한다.

※ The Strut of panels(Front, Rear and Sides) shall be applied with one timber so that the box can stand the upper loads.
박스가 상부 하중을 버틸 수 있도록 앞, 뒤, 옆판 각재의 세로대는 한 개의 목재를 적용해야 한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 56 OF 188

Appendix III : Skid Mounted Construction

Main Shipping Mark

Sling Mark Center of Gravity Mark

Plywood Cover
Bolts & Nuts
Base Plate

Saddle Waterproof adhesive tape

Skid

Metal Cover
Gasket

Bolts & Nuts

Detail “A”

Center of Gravity Mark

Saddle

Main Shipping Mark Base Plate

Skid

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 57 OF 188

Appendix IV : Wooden Bundle

Sling Mark
Center of Gravity Mark

Main Shipping Mark

Sling Mark
Main Shipping Mark Center of Gravity Mark

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 58 OF 188

Appendix V : Position of Shipping and Care Mark

Care Mark Stacking Limit by Mass Mark*(if required)

(Side) (Front) (Side)

Main Packing List

Cover
Shipping Mark

Packing List Cover

(Back)

Main
Shipping Mark
Center of Gravity Mark

Sling Mark

※ Normally, Main Shipping Mark shall be applied to two opposite side.(It shall be applied to two adjacent side for project with special request.)
보통의 경우, Main Shipping Mark 는 마주보는 두 면에 적용한다.(특별한 요구가 있는 PJT 에는 근접한 두 면에 적용한다.)
※ Normally, Care Marks shall be applied to two opposite side.(It shall be applied according to the required methods for project with special
request.)
보통의 경우, Care Mark 는 마주보는 두 면에 적용한다.(특별한 요구가 있는 PJT 에는 요구하는 방법으로 적용한다.)
※ Stacking Limit by Mass Mark* shall be applied to the project with special request.(refer to the PJT packing procedure).
Stacking Limit by Mass Mark*는 특별한 요구가 있는 PJT 에만 적용한다(PJT 절차서 참조).

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 59 OF 188

Appendix VI : Packing Style Table

※ If the item has various types of packing, requester to buy shall choose its suitable packing type and apply it
to the MPS(Material Purchase Specification).
Item 별 포장 Type 이 다양할 경우, 구매 요청자가 적정 포장 type 선정하여 구매사양서에 반영해야 한다.

1. Boiler Page 2. TG(Turbine & Generator) Page

1.1 Pressure Part 60 2.1 Steam Turbine 91~96

1.2 Steel Structure 60 2.2 Generator 97~98
1.3 Buckstay 61 2.3 Gas Turbine 99~102
1.4 Absorber 61~62 2.4 Gas Turbine Aux. 103~106
1.5 Gypsum Handling System 62 2.5 BOP 107~108
1.6 Air Preheater 63 2.6 Electrical & Control 109~110
1.7 Limestone Slurry Preparation System 64
1.8 Burner 64~65
1.9 Cable & Conduit 65~66 3. EPC Page
1.10 Coal Feeder 66
1.11 HP Bypass & RH Safety Valve 67 3.1 Water Treatment 111~114
1.12 Duct 67~68 3.2 HVAC 115~116
1.13 Earthing & Lightning 68 3.3 FF 117~118
1.14 EP 69~70 3.4 CHS 119~123
1.15 Lifting Device 70 3.5 BOP 124~130
1.16 Fan 71~73 3.6 I & C 131~136
1.17 Gas Gas Heater 74 3.7 Plant Electrical 136~139
1.18 Hanger & Support 75~76
1.19 Pump 76
1.20 Insulation 77 4. Water Page
1.21 RH Attemperator 77
1.22 Limestone Handling 78 4.1 MSF/MED 140~148
1.23 Motor 79 4.2 RO 149~153
1.24 Piping 80 4.3 Common 154~171
1.25 Soot Blower 80 4.4 Water Treatment 171~175
1.26 SCR 81~82
1.27 Tanks 82
1.28 Waste Water Treatment System 83~85 5. HRSG Page
1.29 Terminal Box 86
1.30 SCAH 86 5 HRSG 176~181
1.31 Pulverizer 87~88
1.32 Valve 88
1.33 Elevator 89
1.34 Electric Equipment 90

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 60 OF 188

1. Boiler
1.1 Pressure Part
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Division

Pallet

Drum
Item

Skid
Box
D ● ● ●
Header
E ● ● ●
D ● ● ● ●
Link
E ● ● ● ● ●
D ● ●
Steam Drum
E ● ●
Pressure Part
D ● ● ●
Furnace Wall
E ● ● ●
D ● ●
SH, RH, Economizer Tube
E ● ●
D ●
Hanger
E ●

1.2 Steel Structure

Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle

Division
Pallet

Drum

Item
Skid
Box

D ● ●
Embedded Material
E ● ●
Angle, Base Plate, Bracket, Flat D ● ●
Bar, Pad, Pipe E ● ●
D ● ● ●
Beam, Column, Girder, Brace
E ● ● ●
Steel Structure
D ● ● ●
Ladder, Platform, Hand rail stair
E ● ● ●
D ●
Bolt, Nut & Washer
E ●
D ● ●
Grating
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 61 OF 188

1.3 Buckstay
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Division Item

Pallet

Drum
Skid
Box
D ●
Anchor
E ●
D ● ●
Plate
E ● ●
D ● ● ● ●
Channel
E ● ● ● ●
Buckstay
D ● ● ● ●
H-Beam
E ● ● ● ●
D ● ● ●
Pipe
E ● ● ●
D ●
Misc.
E ●

1.4 Absorber
Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle

Division
Pallet

Drum

Item
Skid
Box

D ● ● ●
Mo Plate
E ● ● ●
D ● ●
Alloy Steel Pipe
E ●
D ●
Absorber Bolt/Nut/Washer
E ●
D ● ● ●
C276 Plate
E ● ● ●
D ●
Mist Eliminate
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 62 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Division

Pallet

Drum
Item

Skid
Box
D ●
Oxidation Air Blower
E ●
D ● ●
Side Agitator(**)
E ● ●
D ● ● ● ● ●
Spray Nozzle
E ● ● ● ● ●
D ● ● ●
Spray Bank
E ● ● ●
Absorber
D ●
Welding Rod
E ●
D ● ●
Pump
E ● ●
D ● ●
Motor
E ● ●
D ● ● ● ● ● ● ●
Steel Structure
E ● ● ● ● ● ● ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.

1.5 Gypsum Handling System

Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle

Division
Pallet

Drum

Item
Skid
Box

D ● ● ● ●
Trippers and Conveyors
E ● ● ● ●
Gypsum D ● ● ● ●
Handling Vibrator
System E ● ● ● ●
D ● ● ● ●
Air Blaster
E ● ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 63 OF 188

1.6 Air Preheater

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Division Item

Pallet

Drum
Skid
Box
D ● ● ● ● ●
Rotor & Housing
E ● ● ● ● ●
D ●
Rotor Driving Units(Reducer)
E ●
D ●
Lubrication Units
E ●
D ●
Bearing, Bearing Housing
E ●
D ●
Trunnion Shaft, Guide Trunnoin
E ●
Air Preheater
D ● ●
Air Motor
E ● ●
D ● ●
Elements & Baskets
E ●
D ●
Water Washing System
E ●
D ●
I&C
E ●
D ● ● ● ●
Misc.
E ● ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 64 OF 188

1.7 Limestone Slurry Preparation System

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Division

Pallet

Drum
Item

Skid
Box
D ● ●
Slide Gate / Bar Gate
E ● ●
D ● ● ●
Vibrator, Vibrating bin Activator
E ● ● ●
D ● ● ●
Emergency Take-off Chute
E ● ● ●
Limestone D ●
Weighing feeder
Slurry E ●
Preparation D ● ● ●
System Pump & Motor
E ● ●
D ●
Classifiers
E ●
D ● ● ●
4-way Product Distribution Box
E ● ● ●
D ● ●
Ball Charging Device
E ● ●

1.8 Burner
Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle

Division
Pallet

Drum

Item
Skid
Box

D ●
Burner Accessory
E ●
D ● ●
Coal Burner Coal Burner
E ● ●
D ● ●
OFA Burner
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 65 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Division

Pallet

Drum
Item

Skid
Box
D ●
Accumulator
E ●
D ●
Gun Cleaning Table
E ●
D ●
Oil Burner & Ignitor
E ●
Oil Burner
D ●
Relief Valve
E ●
D ●
Shu-off Valve
E ●
D ● ●
Valve Skid(Rack) for Oil Burner
E ●

1.9 Cable & Conduit

Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle

Division Item
Pallet

Drum
Skid
Box

D ● ●
Cable
E ● ●
D ● ● ● ●
Cable Tray
E ● ● ● ●
D ●
Cable & Conduit Adapter & Socket
E ●
D ● ● ● ●
Conduit
E ● ● ● ●
D ●
Coupling
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 66 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Division Item

Pallet

Drum
Skid
Box
D ●
Condulet
E ●
D ●
Flexible Connector & Tube
E ●
D ● ● ● ●
Pipe
E ● ● ● ●
D ●
Normal Bend
E ●
Cable & Conduit
D ●
Reducer For Round Junction Box
E ●
D ●
Round Junction Box
E ●
D ● ●
Cable Reel
E ● ●
D ●
Misc.
E ●
(*) can be packed in Pallet, Wooden bundle type in case of shipping/storage with container
(*)는 Container 로 운송/보관을 할 경우 Pallet, Wooden Bundle Type 으로 포장할 수 있다.

1.10 Coal Feeder

Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum

Division Item
Skid
Box

D ●
Coal Feeder
E ●
D ●
Coal Feeder Panel
E ●
D ●
Loose & Spare Parts
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 67 OF 188

1.11 HP Bypass & RH Safety Valve

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Valve
E ●
D ● ● ●
Hp Bypass HPU
& E ● ●
RH Safety D ●
Valve Panel
E ●
D ●
Misc.
E ●

1.12 Duct
Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item
Skid
Box

D ● ● ●
Duct
E ● ● ●
Structure(Hand Rail, Walkway, D ● ● ● ● ● ● ●
H-Beam, etc.) E ● ● ● ● ● ● ●
D ● ● ●
Rigid Hanger
E ● ● ●
Duct
D ●
Spring Hanger
E ●
D ● ● ●
Sliding Pad
E ● ● ●
D ●
Gauge Connection
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 68 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
Expansion Joint
E ● ●
D ● ● ●
Duct Insulation(*)
E ● ● ●
D ●
Misc.
E ●
(*) can be packed in pallet, wooden bundle type in case of shipping/storage with container.
(*)는 Container 로 운송/보관을 할 경우 Pallet, Wooden Bundle Type 으로 포장할 수 있다.

1.13 Earthing & Lightning

Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item
Skid
Box

D ●
Mould & Catridge
E ●
D ● ●
Bus bar & Copper Rod
E ● ●
D ●
Bare Copper Conductor
E ●
D ●
Clamping Accessories
E ●
Earthing & Lightning
D ●
Air Terminal & Base
E ●
D ●
Test Box
E ●
D ● ● ●
Channel
E ● ● ●
D ● ●
Cable
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 69 OF 188

1.14 EP
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Casing
E ● ● ● ●
Casing
D ● ●
Hopper
E ● ●
D ● ● ● ●
Steel Structure Steel Structure
E ● ● ● ●
D ●
CE & DE CE & DE
E ●
D ● ● ●
Rapping System Rapping System
E ● ● ●
D ● ●
Transformer Rectifier
E ● ● ●
D ●
Panel
E ●
D ● ●
Elec. & Instrument Instrument
E ● ●
D ● ●
Motor
E ● ●
D ●
Bus Duct
E ●
D ● ●
Gas Distribution
E ● ●
D ●
Seal Air Blower
E ●
Others
D ●
Seal Air Heater
E ●
D ●
Hoist
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 70 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Valve
E ●
D ● ● ●
Cable Tray, Conduit Pipe
E ● ● ●
D ● ●
Cable
E ● ●
Others
D ● ● ● ●
Piping
E ● ● ● ●
D ● ● ●
Insulation(*)
E ● ● ●
D ●
Misc.
E ●
(*) can be packed in pallet, wooden bundle type in case of shipping/storage with container.
(*)는 Container 로 운송/보관을 할 경우 Pallet, Wooden Bundle Type 으로 포장할 수 있다.

1.15 Lifting Device

Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum

Division Item
Skid
Box

D ●
Electrical Ass’y For Lifting Device
E ●
D ● ● ● ●
Girder Crane For Lifting Device
E ● ● ● ●
Lifting Device
D ●
Hoist For Lifting Device
E ●
D ●
Monorail for Lifting device
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 71 OF 188

1.16 Fan
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Fan Casing Assembly
E ●
D ●
Upper/Lower Fan Casing
E ●
D ●
Upper/Lower Diffuser
E ●
D ●
Upper/Lower Suction Box
E ●
D ●
Rain Hood
E ●
D ● ● ●
Lagging
E ● ● ●
D ● ● ●
Lining Plate
E ● ● ●
Fan
D ● ● ●
Oil Supply Unit
E ● ●
D ● ●
Terminal Box
E ●
D ● ● ●
Expansion Joint
E ● ●
D ● ● ● ●
Duct
E ● ● ● ●
D ●
Fan Foundation Material
E ●
D ● ● ●
Fan Insulation(*)
E ● ● ●
D ● ● ● ●
Platform
E ● ● ● ●
(*) can be packed in pallet, wooden bundle type in case of shipping/storage with container.
(*)는 Container 로 운송/보관을 할 경우 Pallet, Wooden Bundle Type 으로 포장할 수 있다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 72 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Silencer
E ● ● ● ●
D ● ● ● ●
Diffuser
E ● ● ● ●
D ●
Valve & Pipe Fitting
E ●
D ● ● ● ● ●
Pipe
E ● ● ● ● ●
D ●
Intermediate Shaft
E ●
D ●
Panel
E ●
D ●
Motor
E ● ●
Fan
D ●
Compensator
E ●
D ●
Blade & Accessory
E ●
D ●
Anchor Box
E ●
D ●
Anchor Plate
E ●
D ● ●
Actuator(**)
E ● ●
D ● ● ● ●
Oil
E ● ● ● ●
D ●
Cooling Fan Assembly
E ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 73 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Mill Seal Air Fan
E ●
D ●
Penthouse Fan
E ●
D ●
Purge Air Fan
E ●
D ●
Fan Scanner Cooling Air Fan
E ●
D ●
Electric Equipment
E ●
D ●
Loose Parts
E ●
D ● ●
Spare Parts
E ● ●
(*) can be packed in pallet, wooden bundle type in case of shipping/storage with container.
(*)는 Container 로 운송/보관을 할 경우 Pallet, Wooden Bundle Type 으로 포장할 수 있다.
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 74 OF 188

1.17 Gas Gas Heater

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Rotor & Casing
E ● ● ● ●
D ● ● ●
Sealing System
E ● ● ●
D ●
Rotor Drive Unit
E ●
D ● ● ●
Seal air and Drying air system
E ● ● ●
D ●
Bearing Housing
E ●
D ● ●
Sootblower
E ● ●
Gas Gas Heater
D ● ●
Heating Element
E ●
D ●
High Pressure Pump & Motor
E ●
D ● ●
Actuator(**)
E ● ●
D ●
bearing
E ●
D ● ● ● ●
Fan
E ● ● ● ●
D ● ●
Valve
E ● ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 75 OF 188

1.18 Hanger & Support

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Support Beam
E ● ● ● ●
D ● ● ● ●
Pipe Support
E ● ● ● ●
Down comer D ●
Spring Hanger
Pipe Support E ●
D ● ● ● ●
Rod
E ● ● ● ●
D ●
Misc.
E ●
Disk Spring D ●
Disk Spring Hanger
Hanger E ●
D ● ●
RE Strut RE Strut
E ●
D ●
Collector
E ●
D ● ● ● ●
Support Beam
E ● ● ● ●
D ● ● ● ●
Pipe Support
Pressure Part E ● ● ● ●
Rigid Hanger D ●
Spring Hanger
E ●
D ● ● ● ●
Rod
E ● ● ● ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 76 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Support Beam
E ● ● ● ●
D ● ● ● ●
Pipe Support
E ● ● ● ●
Variable Spring D ●
Spring Hanger
Hanger E ●
D ● ● ● ●
Rod
E ● ● ● ●
D ●
Misc.
E ●

1.19 Pump
Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Division Item Drum

Skid
Box

D ●
Pump
E ●
D ●
Pump Pump with electrical assembly
E ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 77 OF 188

1.20 Insulation
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
Aluminum Alloy Sheet(*)
E ● ● ●
D ● ● ●
Aluminum Alloy Ribbed Panel(*)
E ● ● ●
D ● ● ●
Calcium Silicate Pipe Cover(*)
E ● ● ●
Insulation
D ● ● ●
Fiber Board(*)
E ● ● ●
D ● ● ●
Refractory Material(*)
E ● ● ●
D ●
Misc.
E ●
(*) can be packed in pallet, wooden bundle type in case of shipping/storage with container.
(*)는 Container 로 운송/보관을 할 경우 Pallet, Wooden Bundle Type 으로 포장할 수 있다.

1.21 RH Attemperator
Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum

Division Item
Skid
Box

D ● ●
Control Valve
E ● ●
D ● ●
RH Attemperator RH Attemperator
E ● ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 78 OF 188

1.22 Limestone Handling

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Bag Filter
E ●
D ●
Ball Mill
E ●
D ● ● ● ● ●
Shell & Cone
E ● ● ● ● ●
D ● ● ● ●
Conveyors and Accessory
E ● ● ● ●
D ● ● ● ● ●
Bucket Elevator
E ● ● ● ● ●
Limestone Handling
D ●
Belt
E ●
D ●
Chain
E ●
D ● ● ●
Magnetic Separator
E ● ● ●
D ● ● ● ●
Dust collection System
E ● ● ● ●
D ●
Vacuum Belt Filter
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 79 OF 188

1.23 Motors
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Motor for Recirculation Pump
E ● ●
D ● ● ●
Ac Power Distribution Panel
E ●
D ● ● ●
Cab Distribution/Remote I/O Panel
E ●
D ● ●
Cabin Display Box
E ●
D ● ● ●
Communication Cable
E ●
Motors
D ● ● ●
Gantry Motor
E ●
D ● ● ●
Hoist Motor
E ●
D ● ●
Software For Maintenance
E ●
D ● ● ●
Trolley Motor
E ●
D ● ● ●
Trolley/Spreader Panel
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 80 OF 188

1.24 Piping
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ● ●
Integral pipe
E ● ● ● ● ●
D ● ● ● ● ●
Misc. pipe
E ● ● ● ● ●
D ● ● ● ● ●
Scanner Cooling Air Piping
E ● ● ● ● ●
D ●
Piping Hanger
E ●
D ● ● ●
Insulation(*)
E ● ● ●
D ● ●
pipe 용 Expansion joint
E ● ●
D ●
piping 용 Flange
E ●
(*) can be packed in pallet, wooden bundle type in case of shipping/storage with container.
(*)는 Container 로 운송/보관을 할 경우 Pallet, Wooden Bundle Type 으로 포장할 수 있다.

1.25 Soot Blower

Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum

Division Item
Skid
Box

D ●
Panel
E ●
D ● ●
Soot Blower Soot Blower
E ● ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 81 OF 188

1.26 SCR(Selective Catalytic Reduction)

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Steel Structure
E ● ● ● ●
D ● ●
Ammonia Injection Grid
E ● ●
D ●
Dilution Air Blower
Ammonia E ●
Injection &
Reactor D ●
Sootblowing System
E ●
D ● ● ●
Static Mixer
E ● ● ●
D ● ●
NH3/AIR Mixer
E ●
D ●
Ammonia Unloading Compressor
E ●
D ● ●
Ammonia Storage Tank
E ● ●
D ● ●
Vaporizer
E ● ● ●
Ammonia D ● ●
Accumulator
Storage E ● ● ●
D ● ●
Waste Ammonia Dilution Tank
E ●
D ●
Sump Pump
E ●
D ● ●
NH3/AIR Mixer
E ●
D ● ● ●
Catalyst Catalyst(*)
E ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 82 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Nozzle, Valve
E ●
D ● ● ● ●
Steel Structure
E ● ● ● ●
Misc.
D ● ●
Instrument
E ● ●
D ● ● ●
Piping
E ● ● ●
(*) can be packed in pallet, wooden bundle type in case of shipping/storage with container.
(*)는 Container 로 운송/보관을 할 경우 Pallet, Wooden Bundle Type 으로 포장할 수 있다.

1.27 Tanks
Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item
Skid
Box

D ● ●
Carbon Plate
E ● ●
D ● ●
Top Side Agitator(**)
E ● ●
Steam Coil Air Preheater D ● ●
Tanks
Drain Tank E ● ●
Flash Tank D ● ●
(CBD Tank) E ● ●
Blowdown Tank D ● ●
(IBD Tank) E ● ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 83 OF 188

1.28 Waste Water Treatment System

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Steel Tanks
E ● ●
D ● ●
GRP Tanks
E ● ●
D ● ●
Pressure Vessels
E ● ●
D ● ●
Motors & Pumps
E ● ●
D ●
Rectifier
E ●
D ●
Generator
E ● ●
D ●
Chlorinator
Waste Water E ●
Treatment System D ● ●
Valves
E ● ●
D ● ● ● ●
Piping
E ● ● ● ●
D ● ●
Instruments
E ● ●
D ●
Panel
E ●
D ● ●
Cables
E ● ●
D ● ● ●
Cable Trays
E ● ● ●
D ● ●
Pipe & Support
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 84 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Steel Structure
Waste Water E ● ● ● ●
Treatment System D ●
Misc.
E ●
D ●
LCS Local control station(LCS)
E ●
Submerged Drag Chain D ● ● ●
Conveyor E ● ● ●
D ● ● ●
Belt Conveyor
E ● ● ●
D ● ● ●
Bucket Elevator
E ● ● ●
D ● ● ●
Heat Exchanger
E ● ● ●
D ● ● ●
Clinker Grinder(Crusher)
E ● ● ●
ASH Handling D ● ●
Vibrating Screen, Bin Activator
System E ● ●
Tank, Silo, Hopper, Bin, Shell D ● ●
Plates E ● ●
D ● ●
Air Gravity Slide
E ● ●
Pipe Spool, CIA Pipe, Pipe D ● ● ● ● ●
Fittings E ● ● ● ● ●
Pipe Rack, Pipe Support, Raw D ● ● ● ● ●
Material E ● ● ● ● ●
Steel Structure, Platform, D ● ● ● ● ●
Handrail, Embedded Material E ● ● ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 85 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ● ●
Dosing System, Agitator(**)
E ● ● ● ● ●
D ● ●
Lifting Device
E ● ●
D ●
Valves, Rotary Feeder, Strainer
E ●
Electric Motor, Vibrator, Geared D ● ●
Motor, Gear Reducer E ● ●
Slide Gate, Cut-off gate, Ash D ●
unloader, Emergency Chute E ●
ASH Handling
System D ● ●
Electrical & Control Panel, PLC &
Instrument Panel, Field Instrument E ● ●
D ● ●
Electric Heater
E ● ●
Field Installation Materials D ● ● ● ●
(For Electrical & Instrumentation) E ● ● ● ●
Vent/Dust Filter, Duct, Damper, D ● ● ●
Expansion Joint E ● ● ●
D ● ● ●
Fan, Blower, Air Compressor, Pump
E ● ● ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 86 OF 188

1.29 Terminal Box

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Terminal Box
E ●
D ●
Terminal Box Channel
E ●
D ●
Misc.
E ●

1.30 Steam Coil Air Heater(SCAH)

Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item
Skid
Box

D ●
Steam Coil Air Heater(SCAH)
Steam Coil E ●
Air
Heater(SCAH) D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 87 OF 188

1.31 Pulverizer
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Division

Pallet

Drum
Item

Skid
Box
D ● ● ●
Mill Stand
E ● ● ●
D ● ● ● ●
Mill Stand - Foundation Frame
E ● ● ● ●
D ● ●
Mill Stand - Pedestal
E ●
D ●
Mill Stand - Gas Duct
E ●
D ●
Mill Stand - Ring Duct
E ●
D ● ●
Mill Body, Cpl.
E ● ●
D ● ●
Table, Cpl.
E ● ●
D ● ●
Grinding Tire
E ● ● ●
Pulverizer
D ●
Grinding Roller
E ●
D ●
Rocker Arm
E ●
D ●
Spring Assembly, Cpl.
E ●
D ● ●
Reject Box, Cpl.
E ● ● ●
D ●
Lm-Drive, Cpl.
E ●
D ● ● ● ●
Mill Platform
E ● ● ● ●
D ● ● ● ●
Seal Air Pipe
E ● ● ● ●
D ● ● ● ●
Miscellaneous Pipe
E ● ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 88 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Division

Pallet

Drum
Item

Skid
Box
D ● ●
Miscellaneous Material
E ● ●
D ●
Hydraulic Cabinet
E ●
D ● ●
Classifier
E ● ●
Pulverizer
D ● ●
Motor
E ● ●
D ●
Gear Box
E ●
D ● ●
Knife Gate Valve
E ●

1.32 Valve
Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Division Item Drum

Skid
Box

D ●
Hydraulic Valve
E ●
D ●
Casting Manual Valve
E ●
D ●
Check Valve
E ●
D ●
Forging Manual Valve
E ●
Valve
D ● ●
Motor Operated Valve
E ● ●
D ●
Control Valve
E ●
D ●
Butterfly Manual Valve
E ●
D ●
Safety Relief Valve Package
E ●
Doosan Heavy Industries & Construction Co., Ltd.
WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 89 OF 188

1.33 Elevator
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Machine Room & Pit
E ●
D ●
Hoistway
E ●
D ●
Count Weight
E ●
D ●
Hall Entrance Jamb & Door
E ●
D ●
Car Cage & Sill Cover
E ●
Elevator
D ●
Machine Room Electric(C/P)
E ●
D ●
Machine Room Motor
E ●
D ●
Hoist Way & Entrance Electric
E ●
D ● ●
Spare Parts
E ● ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 90 OF 188

1.34 Electric Equipment

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Division Item

Pallet

Drum
Skid
Box
D ●
Cabinet
E ●
D ● ● ●
Base Frame
E ● ●
D ● ●
DCS Cable
E ● ●
D ● ●
PC/Monitor/Printer Box
E ● ●
D ●
Misc.
E ●
D ● ●
Others
E ● ●
Others
D ●
Instrument
E ●
D ● ●
Accessory Accessory
E ● ●
D ●
Analyzer
E ●
D ●
CCTV
E ●
D ●
System Flame Scanner
E ●
D ●
Boiler Tube Leak Detection
E ●
D ● ●
Lighting
E ● ●
D ● ●
Indoor Unit
E ●
Air Conditioner
D ● ●
Out Door Unit
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 91 OF 188

2. TG(Turbine & Generator)

2.1 Steam Turbine
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
HIP Rotor
E ● ●
D ●
Coupling Bolt
E ●
D ●
HIP Rotor SSS Clutch
E ●
D ●
Flexible Coupling
E ●
D ●
HIP Bucket
E ●
D ●
HP Diaphragm
E ●
D ●
Partition/Spacer Band
E ●
HP Diaphragm
D ●
Nozzle Box
E ●
D ●
Packing Ring
E ●
D ● ●
HIP Casing Ass'y
E ● ●
D ● ●
HP Outer Casing
E ● ●
D ● ●
HP Casing HP Inner Casing
E ● ● ●
D ●
Packing Head
E ●
D ●
Packing Box
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 92 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Front Standard
E ●
Front Standard
D ●
Base Plate
E ●
D ●
LP Rotor
E ● ●
D ●
Coupling Bolt
E ●
D ●
LP Rotor SSS Clutch
E ●
D ●
Flexible Coupling
E ●
D ●
LP Bucket
E ●
D ●
LP Diaphragm
E ●
D ●
LP Diaphragm Packing Ring & Spring
E ●
D ●
Partition/Spacer Band
E ●
D ●
Middle Standard Middle Standard
E ●
D ●
LP Hood
E ●
D ●
LP Inner Casing
E ●
D ●
LP Casing Bearing Cap
E ●
D ●
Coupling Guard
E ●
D ●
Coupling Housing
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 93 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Packing Box
E ●
D ●
Packing Casing
E ●
LP Casing
D ●
Steam Guide
E ●
D ● ● ● ● ●
Misc.
E ● ● ● ● ●
D ● ● ●
HP Valve
E ● ● ●
D ● ● ●
LP Valve
E ● ● ●
D ●
HP/LP V/V Int. Part
E ●
Valve
D ●
HP/LP V/V Minor
E ●
D ●
Blow Down Valve
E ●
D ●
Ventilation Valve
E ●
D ●
Bearing TBN Bearing
E ●
D ● ●
Lube Oil Tank
E ● ● ●
D ●
Lube Oil Storage Tank
E ●
Lube Oil System
D ●
Lube Oil Conditioner
E ●
D ● ●
Lube Oil Cooler
E ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 94 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Spring Hanger
E ●
D ●
Pipe Support
E ●
D ●
Hanger & Support Rod
E ●
D ● ● ● ●
Support Beam
E ● ● ● ●
D ●
Misc.
E ●
D ● ●
Boiler Feed Water Pump Turbine
E ● ●
D ● ●
BFPT L/O Tank
E ● ●
D ●
BFPT L/O Conditioner
E ●
D ●
BFPT Control System
E ●
BFPT(FWPT)
D ● ●
BFPT Stop & Control Valve
E ● ●
D ● ● ●
Exhaust Duct
E ● ●
D ●
Embedded Material
E ●
D ●
Misc.
E ●
D ● ●
HPU with Piping
E ● ●
Auxiliary
D ● ●
Aux. Steam Control Valve
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 95 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Aux. Motor operated Valve
E ●
D ● ●
Manual Valve
E ●
Auxiliary
D ●
Gland Steam Condenser
E ● ●
D ●
Auxiliary Minor
E ●
D ● ● ● ●
Main Steam Piping
E ● ● ● ●
D ● ● ● ● ●
Crossover Piping
E ● ● ● ● ●
D ● ● ● ●
Lube Oil Piping
E ● ● ● ●
D ● ● ● ●
Gland Steam Piping
E ● ● ● ●
Pipe
D ● ● ● ●
Steam Aux Piping
E ● ● ● ●
D ● ● ● ●
Oil Aux Piping
E ● ● ● ●
D ● ● ●
Hydraulic Oil Tube
E ● ● ●
D ● ● ●
Piping Minor
E ● ● ●
D ● ● ●
Insulation(*)
E ● ● ●
D ● ●
Others Lagging
E ●
D ●
TBN Foundation Plate
E ●
(*) can be packed in pallet, wooden bundle type in case of shipping/storage with container.
(*)는 Container 로 운송/보관을 할 경우 Pallet, Wooden Bundle Type 으로 포장할 수 있다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 96 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
TSI
E ●
D ● ●
Rotor stand
E ●
D ●
Yoke
E ●
Others
D ●
Wrench & Tool
E ●
D ● ●
Spare Part
E ● ●
D ●
Performance Test Instrument
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 97 OF 188

2.2 Generator
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Stator Frame
E ●
D ●
Key & Spring Bar
E ●
D ●
Stator Bar
E ●
D ● ●
Phase Con. Ring
E ● ●
Stator Frame
D ● ● ●
Top Cover
E ●
D ●
Stator Core & Stacking
E ●
D ●
Stator Winding
E ●
D ●
Terminal Box
E ● ●
D ●
End Shield
E ●
D ● ● ●
H2 Seal Casing
E ●
End Shield
D ●
Bearing & H2 Seal Ring
E ●
D ●
Oil Deflector
E ●
D ●
Rotor Shaft(Rough Machining)
E ● ● ●
Gen. Rotor
D ●
Gen Rotor Assembly
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 98 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Gen Gas Control System
E ● ●
D ● ●
Stator Winding Liquid Cool system
E ●
D ● ●
Stator Water Cooler
E ●
D ● ●
Seal Oil System
E ●
Auxiliary
D ●
Collector Housing
E ●
D ●
BHR Ass'y
E ●
D ●
AC/DC Bus Duct
E ●
D ● ●
Misc.
E ● ●
D ●
H2 Cooler
E ●
D ●
Foundation Plate
E ●
Others
D ●
Special Tool
E ●
D ● ●
Spare Part
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 99 OF 188

2.3 Gas Turbine

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
Gas Turbine D ●
Gas Turbine Assembly
Assembly E ●
D ●
Rotor Ass'y
E ●
D ●
Comp. Row Disk
E ●
D ●
Turbine Disk
E ●
D ●
Spindle Bolt
E ●
D ●
Spindle Nut
E ●
Rotor
D ●
Comp. Row Blade
E ●
D ●
Torque Tube
E ●
D ●
Seal Disk
E ●
D ●
Air Baffle
E ●
D ●
Misc.
E ●
D ●
Inlet Casing(Cylinder)
E ●
D ●
Thrust Bearing
E ●
Inlet Section
D ●
Inlet Journal Bearing
E ●
D ●
Inlet Air Manifold
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 100 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Inlet Guide Vane
E ●
Inlet Section
D ●
Misc.
E ●
D ●
Compressor Cylinder(Casing)
E ●
D ●
Compressor Blade Ring
E ●
D ●
Compressor Section Diaphragm
E ●
D ●
Compressor Support
E ●
D ●
Misc.
E ●
D ●
Comp Comb Cylinder
E ●
D ●
Torque Tube Cover
E ●
D ●
Bypass Valve
E ●
D ●
Combustor Ass’y
E ●
Combustor Section
D ●
Igniter & Flame Detector
E ●
D ●
Transition Piece
E ●
D ●
U Support
E ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 101 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Turbine Cylinder
E ●
D ●
Turbine Support
E ●
D ●
Support Ring
E ●
D ●
Turbine Section Turbine Blade Ring
E ●
D ●
Isolation Ring
E ●
D ●
Turbine Seal housing
E ●
D ●
Misc.
E ●
D ●
Exhaust Cylinder
E ●
D ●
Exhaust Journal Bearing
E ●
D ●
Forward Exhaust Manifold
E ●
Exhaust Section
D ●
After Exhaust Manifold
E ●
D ● ● ●
Piping-Exh. Manifold
E ● ● ●
D ●
Misc.
E ●
D ●
Over Speed Trip
E ●
Others
D ● ●
Hot Part
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 102 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Special Tool
E ●
D ●
GT Foundation Materials
E ●
D ●
Others Coupling Cover
E ●
D ● ●
Spare Part
E ● ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 103 OF 188

2.4 Gas Turbine Aux.

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Supply Module
E ● ● ●
D ● ●
Function Module
E ● ● ●
Lube Oil System
D ●
Anchor Bolt
E ●
D ● ● ● ●
Ladder
E ● ● ● ●
D ●
Control oil system
E ●
Control Oil System
D ●
Anchor Bolt
E ●
D ●
Water washing skid
Water Washing E ●
System D ●
Anchor Bolt
E ●
D ●
Control Panel
E ●
D ●
Rack
Fire Fighting E ●
System D ●
Clean Agent System
E ●
D ●
Storage Tank
E ●
D ● ●
GT Enclosure(Insulation)
GT Enclosure & E ● ●
HVAC System D ● ●
Ventilation Duct
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 104 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
Walkway & Handrail
GT Enclosure & E ● ●
HVAC System D ● ● ● ●
Steel Structure
E ● ● ● ●
D ● ●
GT Inlet Air Duct
E ● ●
D ● ● ●
GT Inlet Air Duct Walkway & Handrail
E ● ●
D ● ● ● ●
Steel Structure
E ● ● ● ●
GT Vent. Fan & D ● ● ●
GT Vent. Fan & Motor
Motor E ● ●
D ●
Turning Device Ass'y
E ● ●
Turning Device
D ●
Anchor Bolt
E ●
D ●
Filter House
E ● ●
D ●
Transition Duct
GT Intake Air E ●
Filter System D ●
Filter Element
E ●
D ●
Anchor Bolt
E ●
D ●
EB01
E ●
D ● ●
EB01 Support
GT Exhaust E ● ●
Duct D ●
EB02 UPR/LWR
E ●
D ● ●
EB02 Support
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 105 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
IE01
E ●
D ● ● ●
EE00
GT Expansion E ●
Joint D ● ● ●
EE01
E ●
D ●
Other
E ●
D ● ● ● ●
GT Pipe GT Piping
E ● ● ● ●
D ● ● ●
Fuel Gas Unit
E ●
D ●
Fuel Gas Unit Anchor Bolt
E ●
D ● ●
A B Fuel Gas Rack
E ●
D ●
IGV Actuator(**)
E ● ●
Servo Actuator
D ●
Bypass Actuator(**)
E ● ●
D ●
Fuel Control Valve Ass'y
E ●
D ●
Control Valve On/Off Valve
E ●
D ●
Others Valve
E ●
D ●
GT Cooling Air Cooler Ass'y
GT Cooling Air E ●
Cooler D ●
Anchor Bolt
E ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 106 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Template
GT Cooling Air E ● ● ● ●
Cooler D ● ● ●
GT Cooling Air Filter
E ● ● ●
D ●
Gas Detection Panel
E ●
Gas Detector
D ●
Monitor
E ●
D ● ●
Speed Element & Proximeter
E ● ●
D ●
Speed Pick Up Barrier
E ●
D ●
Misc.
E ●
D ● ● ●
Fuel Gas Strainer
E ● ● ●
D ●
Flow Meter
E ●
D ●
Seal Air Filter
E ●
D ●
Thermocouple
E ●
Others
D ●
Casing Cooling Fan
E ●
D ● ●
Fuel Gas Heater
E ● ●
D ●
Pressure Transmitter
E ●
D ●
Temp. Transmitter
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 107 OF 188

2.5 BOP
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Shell & Hot Well
E ●
D ●
Transition
E ●
D ●
Neck
E ●
Condenser
D ●
Water Box
E ●
D ●
Expansion Joint
E ●
D ●
Misc.
E ●
D ●
Condenser Vacuum Pump
E ●
D ●
Water Box Vacuum Pump
E ●
Condenser Aux. D ● ●
Vacuum Control Tank
System E ●
D ● ●
Cathodic Protection System
E ●
D ● ● ●
Steam Jet Air Ejector
E ● ●
D ●
HP Heater
E ●
D ●
Heat Exchanger LP Heater
E ●
D ●
Drain Cooler
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 108 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Deaerator & Storage Tank
E ●
D ●
Heat Exchanger DH Heater
E ●
D ●
Heat Exchanger
E ●
D ●
Shop Tank
E ●
Tank
D ●
Steel Plate for Site Tank
E ●
D ● ● ●
Platform & Ladder Platform & Ladder
E ● ● ●
D ●
Strainer Section Assembly
E ●
D ●
Ball Recirculation Unit
E ●
CTCS/DF
D ●
Control Panel
E ●
D ●
Debris Filter Assembly
E ●
D ●
Instrument & Gauge
E ● ●
D ●
Manual Valve
E ● ●
D ●
Safety & Relief Valve
E ● ●
Others
D ● ● ● ●
Embedded Material
E ● ● ● ●
D ● ● ●
Insulation(*)
E ● ● ●
D ●
Gasket
E ●
(*) can be packed in pallet, wooden bundle type in case of shipping/storage with container.
(*)는 Container 로 운송/보관을 할 경우 Pallet, Wooden Bundle Type 으로 포장할 수 있다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 109 OF 188

2.6 Electrical & Control

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Exciter
E ●
Excitation D ● ●
Excitation Transformer
System E ●
D ●
AC/DC Bus Duct
E ●
D ●
SFC
E ●
SFC D ● ●
SFC Transformer
System E ●
D ● ●
Cable
E ● ●
D ●
TCS Panel
E ●
Turbine Control D ●
TCS Workstation
System E ●
D ●
TCS Module(For Spare)
E ●
D ●
VMS Panel
E ●
D ●
Vibration VMS Workstation
E ●
Monitoring
System D ●
VMS Sensor & Cable
E ●
D ●
VMS Module
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 110 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
Generator Control Panel(Synchro & D ●
Metering PNL) E ●
D ●
Generator Protection Panel
E ●
D ●
Motor Control Center
Electrical E ●
System D ●
Power Distribution Panel
E ●
D ●
DC Motor Starter Panel
E ●
D ●
NGTR Panel
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 111 OF 188

3. EPC
3.1 Water Treatment
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Steel Tanks
E ● ●
D ● ●
GRP Tanks
E ● ●
D ● ●
Pressure Vessels
E ● ●
D ● ●
Motors & Pumps
E ● ●
D ●
Rectifier
E ●
Water
D ●
Treatment Generator
System, E ● ●
D ●
Waste Water Chlorinator
E ●
Treatment
System, D ● ●
Valves
E ● ●
Condensate D ● ● ● ●
Polishing Plant, Piping
E ● ● ● ●
Chemical D ● ●
Instruments
Dosing System, E ● ●
D ●
Chlorination Panel
E ●
Plant
D ● ●
Cables
E ● ●
D ● ● ●
Cable Trays
E ● ● ●
D ● ●
Pipe & Support
E ● ●
D ● ● ● ●
Steel Structure
E ● ● ● ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 112 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ● ●
Rake Screen
E ● ● ● ● ● ●
D ● ● ● ● ●
Trash Rake
E ● ● ● ● ● ●
D ● ● ● ● ●
Stop Log
E ● ● ● ● ● ●
D ● ● ● ● ●
Guide
E ● ● ● ● ● ●
D ● ● ● ● ●
TBS(Traveling Band Screen)
E ● ● ● ● ● ●
D ● ● ● ● ●
Stop Log Rack
E ● ● ● ● ● ●
D ● ●
Motors & Pumps
E ● ●
D ● ●
Valve
E ● ●
Intake Facility
D ● ● ● ●
Piping
E ● ● ● ●
D ● ●
Instrument
E ● ●
D ●
Panel
E ●
D ● ●
Cables
E ● ●
D ● ● ●
Cable Trays
E ● ● ●
D ● ●
Pipe & Support
E ● ●
D ● ● ● ●
Steel Structure
E ● ● ● ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 113 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Sampling Conditioning Rack
E ● ●
D ● ●
Sampling Container
E ● ●
D ●
Hot Well Sampling Skid
E ●
D ● ●
Motors & Pumps
E ● ●
D ● ●
Valve
E ● ●
D ● ● ● ●
Piping
E ● ● ● ●
Sampling D ● ●
Instrument
System E ● ●
D ●
Panel
E ●
D ● ●
Cables
E ● ●
D ● ● ●
Cable Trays
E ● ● ●
D ● ●
Pipe & Support
E ● ●
D ● ● ● ●
Steel Structure
E ● ● ● ●
D ●
Misc.
E ●
Workshop Machines(Lathe, Milling, D ● ●
Welding & etc.), Motors & Pumps E ● ●
Workshop & Chemical Laboratory Equipment, D ● ●
Chemical Analyzers & etc. E ● ●
Laboratory D ● ● ● ●
Equipment Piping
E ● ● ● ●
D ● ●
Furniture, Work Benches, Valves
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 114 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Panel
E ●
Workshop & D ● ●
Cables
Chemical E ● ●
Laboratory D ● ● ● ●
Equipment Steel Structure
E ● ● ● ●
D ●
Misc.
E ●
(*) can be packed in Pallet, Wooden bundle type in case of shipping/storage with container
(*)는 Container 로 운송/보관을 할 경우 Pallet, Wooden Bundle Type 으로 포장할 수 있다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 115 OF 188

3.2 HVAC
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Air Handling Unit
E ● ●
D ● ● ● ●
Rooftop Air Conditioning Unit
E ● ●
D ● ●
Split Type Air Conditioning Unit
E ● ●
Air Conditioning D ● ●
Fan Coil Unit
Unit E ● ●
D ● ●
Unit Heater
E ● ●
Constant Temperature & Humidity D ● ●
Unit E ● ●
D ● ● ● ●
Air Cooled Condensing Unit
E ● ●
D ● ● ●
Air Cooled Chiller
E ● ●
D ● ● ●
Chiller Unit Water Cooled Chiller
E ● ●
D ● ● ●
Absorption Chiller
E ● ●
D ● ● ● ●
Wall Mounted Fan
E ● ●
D ● ● ● ●
Duct In-Line Fan
E ● ●
Ventilation Unit
D ● ● ● ●
Centrifugal Fan
E ● ●
D ● ● ● ●
Roof Mounted Fan
E ● ●
D ● ● ●
Expansion Tank
E ●
Other
D ● ● ●
Heat Exchanger
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 116 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Chemical Dosing Unit
E ● ●
D ● ●
Chilled Water Pump
E ● ●
D ● ● ● ●
Cooling Tower
E ● ●
D ● ● ● ●
Pipe
E ● ● ● ●
D ●
Pipe Fitting
E ●
D ● ●
Other Valve
E ● ●
D ● ● ● ●
Duct
E ● ● ● ●
D ●
Duct Fitting
E ●
D ● ● ●
Damper
E ● ● ●
D ● ● ●
Insulation(*)
E ● ● ●
D ●
Misc.
E ●
(*) can be packed in pallet, wooden bundle type in case of shipping/storage with container.
(*)는 Container 로 운송/보관을 할 경우 Pallet, Wooden Bundle Type 으로 포장할 수 있다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 117 OF 188

3.3 FF(Fire Fighting)

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Indoor Hydrant Cabinet
Indoor/Outdoor E ●
Hydrant System D ●
Hose(Hose Reel)
E ●
D ●
Sprinkler Nozzle
Sprinkler E ●
System D ●
Alarm Check Valve
E ●
D ●
Water Spray Nozzle
Water Spray E ●
System D ●
Deluge Valve
E ●
D ● ●
Gas Gas Bottle
E ●
Extinguishing
System D ●
Nozzle
E ●
D
Foam Concentrate
E
D ●
Foam System Foam Storage Tank
E ●
D ●
Foam Nozzle
E ●
D ● ●
Extinguisher Extinguisher
E ●
D ● ●
Electrical Motor Pump
E ● ●
D ● ●
Diesel Engine Pump
E ● ●
Fire Pump
D ● ●
Jockey Pump
E ● ●
D ●
Diesel Oil Tank
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 118 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
Fire Alarm Control & Detection D ●
Panel E ●
D ● ●
Detector
Fire Alarm & E ● ●
Detection D ● ●
Cable & Accessories
E ● ●
D ● ●
Miscellaneous Electrical Equipment
E ● ●
D ● ● ● ●
Pipe
E ● ● ● ●
D ●
Pipe Fitting
E ●
Valve(Gate Valve, Butterfly Valve, D ●
Others
etc.) E ●
D ● ● ●
Insulation(*)
E ● ● ●
D ●
Misc.
E ●
(*) can be packed in pallet, wooden bundle type in case of shipping/storage with container.
(*)는 Container 로 운송/보관을 할 경우 Pallet, Wooden Bundle Type 으로 포장할 수 있다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 119 OF 188

3.4 CHS(Coal Handling System)

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
Drive Unit(Motor, Brake, Coupling, D ●
Reducer, Common Bed) - Shop
Assembled E ●
D ●
Local Control Station(LCS)
E ●
D ●
Coupling
E ●
D ●
Thrust Drum Brake
E ●
D ●
Gear Reducer
E ●
D ● ●
Drive Base(Common Bed)
E ● ●
D ●
Back Stop
E ●
Belt Conveyor Conveyor Pulley Ass'y (With D ●
Components Bearing, Plummer Block, Backstop)
- Shop Assembled) E ●
D ●
Idler Roller
E ●
D ● ● ●
Idler Stand
E ● ● ●
D ● ●
Conveyor Belt
E ● ●
D ●
Belt Cleaner
E ●
D ●
Screw Take-Up Device
E ●
D ●
All Fastening Materials
E ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 120 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
Skid Base Under The Common Bed
E ● ● ●
D ● ● ●
Pulley Frame And Basement
E ● ● ●
Take-Up Structure And Device With D ● ● ●
Weight Box E ● ● ●
D ● ● ● ●
Stringer & Support
E ● ● ● ●
Conveyor Cover(Hood Cover, Side D ● ● ●
Belt Conveyor Cover, Bottom Deck Plate, Etc) E ● ● ●
Fabrication
Items D ● ● ● ●
Deck Plate
E ● ● ● ●
D ● ● ● ●
Chute And Skirt Board
E ● ● ● ●
D ● ● ● ●
All Liner Plate
E ● ● ● ●
D ● ● ● ●
Safety Guard
E ● ● ● ●
D ●
Misc.
E ●
Dust Collector Ass'y(Include Body D ● ●
And Hopper) E ● ●
D ●
Filter, Cage, Flexible Joint, Etc.
E ●
Dust Return Equipment With Drive D ●
Dust Collection Unit And Base Frame E ●
System and D ● ● ● ●
Access Way, Platform, Stairway,
Vacuum
Ladder, Etc. E ● ● ● ●
Cleaning
System D ●
Auto Damper with Air Cylinder
E ●
D ● ●
Inlet/Outlet Duct
E ● ●
Dust Suction Hood with Manual D ● ● ●
Damper E ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 121 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Fan & Drive Unit with Common Bed
E ●
D ● ● ● ●
Stack And Support Structure
E ● ● ● ●
Dust Collection All Air Supply System with Piping D ● ●
System and Material And Support E ● ●
Vacuum
Cleaning All Fastening D ●
System Materials(Bolt/Nut/Washer, etc.) E ●
D ●
Electrical & Control Panel
E ●
D ●
Misc.
E ●
Spray Water Pump with Control D ● ●
Panel And Base Frame E ● ●
D ●
Dust All Spray Nozzle And Piping
E ●
Suppression
System D ●
All Electrical And Control Equipment
E ●
D ●
Spray Monitor Gun
E ●
D ●
Electrical Motor
E ●
D ●
Control Panel
E ●
Field Instruments (Limit Switch, D ●
Sensor, Fan, Ventilation, Air
Conditioner, Etc.) E ●
Stacker & D ● ●
Reclaimer Cable/Hose Reel
E ● ●
D ●
Cellular/Rubber Buffer
E ●
D ●
Slew Bearing
E ●
D ●
Air Conditioner
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 122 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Gear Reducer
E ●
D ●
Shrink Disc
E ●
D ●
Hyd. Unit/Hyd. Cylinder
E ●
Pipe & Fitting, Distributor & Pipe D ● ●
Cover (Hyd.) E ● ●
D ●
Hyd. Cylinder
E ●
D ●
Plummer Block
E ●
D ●
Lubrication Unit
E ●
D ● ●
Cabin
E ● ●
Stacker & D ● ● ●
Conveyor Belt
Reclaimer E ● ● ●
D ●
Idler Roller
E ●
D ● ●
Idler Stand
E ● ●
D ●
Belt Scale
E ●
D ● ●
Take Up Device
E ● ●
D ●
Belt Cleaner
E ●
D ●
Conveyor Pulley
E ●
D ● ● ●
Cable Ducts & Accessory
E ● ● ●
D ●
Wheel
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 123 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Shaft & Pin
Stacker & E ●
Reclaimer D ●
Misc.
E ●
Conveyor Frame and D ● ● ● ●
Structure(Girder) for All Conveyors E ● ● ● ●
Stairway, Walkway, Grating, D ● ● ● ●
Structure
Handrail, etc. E ● ● ● ●
D ● ● ● ●
Maintenance & Access Platform
E ● ● ● ●
D ●
Vibrating/Belt Feeder
E ●
D ●
Magnetic Separator
E ●
D ●
Vibrating Screen(Two-Stage Type)
E ●
D ●
Divert Gate with Motor Cylinder
E ●
D ●
Belt Scale
E ●
D ●
Electrical Hoist
E ●
D ●
Others V - Scraper
E ●
D ●
Sampling System(Modular Type)
E ●
Steel Fabrication Item of Package D ● ● ● ●
Equipment E ● ● ● ●
Mechanical Rotating Item of D ●
Package Equipment E ●
Electrical Rotating Item of Package D ● ●
Equipment E ● ●
Electrical And Control Panel of D ●
Package Equipment E ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 124 OF 188

3.5 BOP
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Main Pump
E ● ●
D ●
Base Plate with accessories
E ●
CWP D ● ●
(Cooling Water Main Motor
Pump) E ● ●
D ● ●
Instrument(Pressure Gauge)
E ● ●
D ●
Control Panel
E ●
D ● ●
CCW H/Ex Plate type heat exchanger
E ●
Self Cleaning D ● ● ●
Auto Self Cleaning Strainer
Strainer E ● ●
D ●
MOV Valve with Actuator
E ●
D ●
Valve with Actuator
E ●
D ● ● ●
HPU Skid
E ● ●
D ●
C.NRV Oil Can
E ●
D ●
Hydraulic Tube(Rubber)
E ●
D ● ●
Control Cable
E ● ●
D ● ● ●
Valve Body
E ● ●
Bypass & D ● ●
Valve Actuator(**)
PRDS E ● ●
D ●
Valve Control Panel
E ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.
Doosan Heavy Industries & Construction Co., Ltd.
WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 125 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
HPU
E ● ●
D ●
Oil Can
E ●
Bypass & D ● ●
Hydraulic Tube(Stainless Steel)
PRDS E ●
D ●
Control Cable
E ●
D ●
HPU control panel
E ●
D ● ● ●
Valve Body
E ● ● ●
D ● ●
Valve Actuator(**)
E ● ●
NRV
D ●
Solenoid Valve
E ●
D ●
Air Tube
E ●
D ●
Safety Valve Safety Valve
E ●
D ● ●
Silencer
E ● ●
Silencer
D ●
Anchor Bolt, Flange
E ●
Gas Distribution D ● ● ●
N2 Gas Distribution Skid
Skid E ● ●
D ● ●
Engine Skid
E ● ●
D ● ●
Instrument
E ● ●
Engine
D ● ● ● ●
Interconnection Piping
E ● ● ● ●
D ● ● ●
Piping Insulation(*)
E ● ● ●
(*) can be packed in pallet, wooden bundle type in case of shipping/storage with container.
(*)는 Container 로 운송/보관을 할 경우 Pallet, Wooden Bundle Type 으로 포장할 수 있다.
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 126 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Valve
E ● ●
D ● ●
Exhaust Muffler
E ● ● ●
D ●
Intake Silencer
E ● ●
D ● ● ●
Generator
E ● ● ●
D ●
Generator Cooler
E ●
D ●
Cable
E ●
D ● ●
Table Cooler(Radiator)
E ● ● ●
D ●
Panel
E ●
Engine
D ●
Switch Gear / MCC
E ●
D ● ●
Fuel Tank
E ● ●
D ● ●
Circuit Breaker
E ● ●
D ●
Battery
E ●
D ●
Small Air Compressor(for Starter)
E ● ●
D ● ●
Air Receiver
E ● ● ●
D ●
Special Tools
E ● ●
D ● ●
Commissioning Kit
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 127 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Main Pump
E ● ●
D ●
Base Plate with accessories
E ●
D ● ●
Main Motor
E ● ●
BFP D ● ●
(Boiler Feed Instrument(Pressure Gauge)
water Pump) E ● ●
D ● ●
Lube oil Skid
E ● ●
D ● ● ● ● ●
Aux piping & etc.
E ● ● ● ● ●
D ●
VFD Panel(Option)
E ●
D ● ●
Main Pump
E ● ●
D ●
Base Plate with accessories
CEP E ●
(Condensate D ● ●
Main Motor
Extraction E ● ●
Pump) D ● ●
Instrument(Pressure Gauge)
E ● ●
D ●
Control Panel
E ●
D ● ●
Fuel Gas Compressor
E ● ●
D ●
Panel
E ●
Fuel Gas D ●
Base Plate with accessories
Compressor E ●
Fuel Gas Emergency Shut-off Valve D ● ●
Skid E ● ●
Fuel Gas Filter Separators & D ●
Scrubber E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 128 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Fuel Gas Condensate Tank
E ●
D ● ●
Fuel Gas Condensate Pumps
E ● ●
D ● ● ●
Fuel Gas Heater
E ● ● ●
D ●
Fuel Gas chromatograph
Fuel Gas E ● ●
Compressor D ●
Fuel Gas flow computer
E ●
D ●
Fuel Gas Buffer Tank
E ●
D ● ●
Fuel Gas Booster compressor
E ● ●
D ● ●
GPRS
E ● ●
D ● ●
Air compressor
E ●
D ● ●
Air Dryer
E ●
D ●
Base Plate with accessories
Air Compressor E ●
System D ● ●
IA Receiver Tank
E ● ●
D ● ●
SA Receiver Tank
E ● ●
D ●
PLC & Control panel
E ●
D ●
Gantry Crane
E ●
D ● ● ●
Crane & Hoist Span for Gantry Crane
E ● ● ●
D ●
Overhead Crane
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 129 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
Span for Overhead Crane
E ● ● ●
D ●
Hoist
E ●
Crane & Hoist
D ●
Chain Block
E ●
D ●
Control Panel
E ●
D ●
Hydrogen Generator
E ●
D ●
Hydrogen Compressor
E ● ●
D ●
PLC & Control panel
E ●
D ●
H2/CO2 system Hydrogen Storage Vessel
E ●
D ● ● ● ● ●
Pipe
E ● ● ● ● ●
D ●
Base Plate with accessories
E ●
D ● ●
Container Control Room
E ● ●
D ● ●
GSP Pump
E ● ●
(General
Service Pump) D ● ●
Motor
E ● ●
D ● ●
Pump
E ● ●
Sump Pump
D ● ●
Motor
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 130 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Pump
E ● ●
D ● ●
Motor
E ● ●
ACC
(Air Cooled D ●
Base Plate with accessories
Condenser), E ●
D ●
Cooling Tower, PLC & Control panel
E ●
Fin Fan Type D ● ●
Fan
Heat E ●
Exchanger
D ● ● ● ● ●
Pipe & Tube
E ● ● ● ● ●
D ● ● ● ● ●
Structure Materials
E ● ● ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 131 OF 188

3.6 I & C
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
DCS workstation
E ●
D ●
Monitor (Keyboard, Mouse)
E ●
D ●
Printer
E ●
Cabinet (Controller, I/O, Extension, D ●
Marshalling, Network Cabinet, etc.) E ●
DCS & D ●
Peripheral Master Clock Equipment
Equipment E ●
D ●
Annunciator Panel
E ●
Furniture (Operator Console, Desk, D ●
etc.) E ●
D ● ●
Cable
E ● ●
D ●
Misc.
E ● ●
D ●
Large Screen
E ●
D ●
Large Screen Wall Controller
E ●
D ●
Misc.
E ● ●
D ●
Camera
E ●
D ●
Cabinet
E ●
D ●
Workstation with Monitor, Printer
E ●
CCTV
D ● ● ●
Conduit
E ● ● ●
D ● ●
Cable
E ● ●
D ●
Misc.
E ● ●
Doosan Heavy Industries & Construction Co., Ltd.
WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 132 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Slave Clock
E ●
D ●
Cabinet
E ●
D ●
Network Equipment
E ●
Slave Clock
D ● ●
Cable
E ● ●
D ●
Poles
E ●
D ●
Misc.
E ● ●
D ●
VMS Workstation
E ●
VMS Cabinet(I/O Module, Server, D ●
etc.) E ●
D ●
Monitor(Keyboard, Mouse)
E ●
VMS
D ●
Printer
E ●
D ● ●
Cable
E ● ●
D ●
Misc.
E ●
D ● ●
Modulating Control Valve
E ● ●
Control Valve
D ● ●
On-off Control Valve
E ● ●
Field D ●
Instrument Transmitter
(Transmitter) E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 133 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Level/Pressure Switch
E ●
Field D ●
Pressure/Temp. indicator
Instrument E ●
(Local D ●
Instrument) Temp. Transmitter
E ●
D ●
Thermowell
E ●
D ● ●
Field Flow Orifice
E ● ●
Instrument
(Flow Element) D ● ●
Flow nozzle
E ● ●
D ●
Diff. Pressure Transmitter
E ●
D ●
Flow Computer
E ●
D ●
Energy Calculator
E ●
D ●
Instrument Box /Stanchion
Metering E ●
System D ●
Cabinet
E ●
D ● ●
Cable
E ● ●
D ● ● ●
Metering Skid
E ●
D ● ●
Misc.
E ● ●
D ● ●
Cable
E ● ●
D ●
EHT TR Panel
Electrical Heat E ●
Tracing D ●
EHT PDP(Control Panel)
E ●
D ● ● ●
Conduit
E ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 134 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Weather station equipment
E ● ●
D ● ●
Workstation
E ● ●
Weather D ●
Control Box
Station E ●
D ● ●
Interface Cable
E ● ●
D ●
Misc.
E ●
D ● ● ●
Container
E ● ● ●
D ●
System Cabinet
E ●
D ●
Sensor
E ●
D ● ●
CEMS Tube
E ●
D ● ●
Raceway(for sampling tube)
E ●
D ●
Calibration Gas Bottle
E ●
D ●
Misc.
E ●
D ● ●
Tube
E ●
D ● ●
Instrument Pre-Insulated Tube
E ●
Installation
Materials D ● ●
Pipe(Nipple)
E ●
D ● ●
Support
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 135 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Needle/Globe Valve
E ●
Instrument D ●
Installation Condensate Pot
Materials E ●
D ●
Misc.
E ●
D ● ●
Cable
E ● ●
Control Cable
D ●
Misc.
E ●
D ● ● ● ●
Cable Tray
E ● ● ● ●
Cable Tray & D ●
Support
Accessories E ●
D ●
Misc.
E ●
D ● ● ● ●
Conduit
E ● ● ● ●
D ●
Pull box
Conduit & E ●
Accessories D ● ●
Support
E ●
D ●
Misc.
E ●
D ●
Instrument Box
E ●
D ●
Instrument Rack
E ●
D ●
Temp. Transmitter Box
Instrument Box E ●
& Enclosure D ●
Junction Box
E ●
D ● ● ●
Stanchion with Sunshade
E ● ● ●
D ●
Misc.
E ● ●
(*) can be packed in Pallet, Wooden bundle type in case of shipping/storage with container
(*)는 Container 로 운송/보관을 할 경우 Pallet, Wooden Bundle Type 으로 포장할 수 있다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 136 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Workbench
E ●
D ●
Furniture (Chair, etc.)
E ●
I&C Laboratory D ● ● ●
Storage Cabinet
Equipment E ● ● ●
D ● ●
Portable Equipment
E ● ●
D ●
Misc.
E ●

3.7 Plant Electrical

Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item
Skid
Box

D ● ●
GIS/AIS Main Body
E ● ● ●
D ●
GIS/AIS Associated Panel
E ●
D ●
Misc.
E ●
D ●
TR Main Body
E ●
D ●
Radiator
E ●
D ● ●
Transformer Oil
E ● ●
D ●
Associated Panel
E ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 137 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
IPB
E ●
D ●
IPB Associated Panel
E ●
D ●
Misc.
E ●
D ●
GCB
E ●
D ●
GCB Associated Panel
E ●
D ●
Misc.
E ●
D ●
SWGR/MCC/DB Panel
E ●
SWGR/MCC/DB
D ●
Misc.
E ●
D ●
PRP, Metering Panel
E ●
PRP/METERING
D ●
Misc.
E ●
D ●
HSBT Panel
E ●
HSBT
D ●
Misc.
E ●
D ●
ECMS/FMS Panel
E ●
ECMS/FMS
D ●
Misc.
E ●
D ●
DC&UPS Panel
E ●
DC&UPS
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 138 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
EHV Cable
E ● ●
EHV Cable
D ●
Misc.
E ●
D ● ●
Power & Electrical Cable
Power & E ● ●
Control Cable D ●
Misc.
E ●
D ● ● ● ●
Conduit
E ● ● ● ●
Conduit
D ●
Misc.
E ●
D ● ● ● ●
Cable Tray
E ● ● ● ●
Cable Tray
D ●
Misc.
E ●
D ●
Lighting, Lighting Fixture
E ●
D ●
Associated Panel
E ●
Lighting & D ● ●
Cable, Wire
Small Power E ● ●
D ● ● ● ●
Conduit
E ● ● ● ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 139 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Cable, Wire
E ● ●
Earthing & D ●
Lightning Rod
Protection E ●
D ●
Misc.
E ●
D ●
Communication Rack
E ●
D ● ●
Telephone, Speaker, Amp
E ● ●
D ● ●
Communication Cable, Wire
E ● ●
D ● ● ● ●
Conduit
E ● ● ● ●
D ●
Misc.
E ●
D ●
Security Panel
E ●
D ● ●
CCTV, Workstation
Security E ● ●
System D ● ●
Cable, Wire
E ● ●
D ●
Misc.
E ●
Fire Stop D ●
Fire Stop Materials
Materials E ●
D ●
Associated Panel
E ●
Cathodic D ● ●
Cable, Wire
Protection E ● ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 140 OF 188

4. Water
4.1 MSF/MED
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Flange
E ●
D ●
Cathodic Protection System
E ●
D ●
Chemical Anchor
E ●
D ● ● ● ●
Plate
E ● ● ● ●
D ● ● ●
Round Bar
E ● ● ●
D ● ● ●
Round Pipe
E ● ● ●
D ● ●
Round Tube
E ●
D ● ● ●
Seamless Pipe
E ● ● ●
Evaporator
D ●
Demister
E ●
D ●
Gasket
E ●
D ● ● ● ● ●
H-Beam
E ● ● ● ● ●
D ●
Fitting
E ●
D ●
Coupling
E ●
D ●
Orifice Plate
E ●
D ●
Tube Sheet
E ●
D ●
Sight Glass
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 141 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Sump Screen
E ●
D ●
Evaporator V.C.I
E ●
D ●
Misc.
E ●
D ● ● ● ●
Plate
E ● ● ● ●
D ● ● ●
Round Bar
E ● ● ●
D ● ● ●
Round Pipe
E ● ● ●
D ● ●
Round Tube
E ●
D ● ● ●
Seamless Pipe
E ● ● ●
D ●
Brine Heater Tubesheet
E ●
D ●
Fitting
E ●
D ● ●
Metallic Expansion Joint
E ● ●
D ●
Gasket
E ●
D ●
Flange
E ●
D ●
Misc.
E ●
D ● ●
Bed Limiter
E ● ●
D ● ●
Deaerator Con Reducer
E ● ●
D ●
Fitting
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 142 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Plate
E ● ● ● ●
D ● ● ●
Pipe
E ● ● ●
D ● ● ●
Round Bar
E ● ● ●
D ● ● ●
Seamless Pipe
E ● ● ●
D ●
Gasket
E ●
D ● ● ● ● ●
Deaerator H-Beam
E ● ● ● ● ●
D ● ● ● ● ●
Packing Support
E ● ● ● ● ●
D ●
Pall Ring(***)
E ●
D ●
Flange
E ●
D ●
Spray Nozzle
E ●
D ●
Misc.
E ●
D ● ● ● ●
Plate
E ● ● ● ●
D ● ● ●
Pipe
E ● ● ●
D ● ● ●
Tanks Round Bar
E ● ● ●
D ● ● ●
Seamless Pipe
E ● ● ●
D ● ● ●
Flat Bar
E ● ● ●
(***) can be packed in gunny bag or bare style.
(***)는 마대나 Bare 상태로 공급할 수 있다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 143 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ● ●
Channel/Angle
E ● ● ● ● ●
D ●
Flange
E ●
D ●
Gauge Hatch
E ●
D ● ● ● ●
Grating
E ● ● ● ●
Tanks
D ●
Fitting
E ●
D ● ●
Mesh Screen
E ●
D ●
Gasket
E ●
D ●
Misc.
E ●
D ● ● ●
Condenser
E ● ● ●
D ●
Gauge
E ●
D ● ● ●
Ejector
E ● ● ●
D ●
Valve
E ●
Vacuum D ● ● ● ● ●
Column
system E ● ● ● ● ●
D ● ● ● ●
Handrail, Stair & Platform
E ● ● ● ●
D ● ● ● ● ●
H-Beam
E ● ● ● ● ●
D ● ● ●
Silencer
E ● ● ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 144 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
Ball Collector
E ● ● ●
D ●
Ball Gauge
E ●
D ●
Ball Monitor
E ●
D ● ●
Ball Strainer
E ● ●
D ●
Valve
E ●
D ●
Coupling
E ●
D ● ●
Cable
E ● ●
D ● ● ● ●
Conduit
E ● ● ● ●
D ●
Differential Pressure Transmitter
E ●
Ball Cleaning D ●
Gasket
System E ●
D ●
Indicating Lamps
E ●
D ●
Injection Nozzle
E ●
D ●
Local Control Panel
E ●
D ●
Mechanical Seal
E ●
D ●
Mechanical Seal Face
E ●
D ●
Sleeve
E ●
D ●
Sponge Ball
E ●
D ●
Sunshade
E ●
D ●
Misc.
E ●
Doosan Heavy Industries & Construction Co., Ltd.
WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 145 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
Tank
E ● ● ●
D ● ●
Agitator(**)
E ● ●
D ●
Agitator Shaft
E ●
D ● ● ●
Piping
E ● ● ●
D ● ● ●
Support
E ● ● ●
D ● ●
Cable
E ● ●
D ● ● ● ●
Cable Tray
E ● ● ● ●
D ● ● ● ●
Conduit Pipe
Acid Cleaning E ● ● ● ●
System D ● ● ● ● ●
Platform, Hand Rail, Ladder
E ● ● ● ● ●
D ● ● ●
Dampener
E ● ● ●
D ● ●
Damister Carrier
E ●
D ●
Eye Shower
E ●
D ● ●
Flow Indicator
E ● ●
D ● ●
Fume Scrubber
E ●
D ●
Level Gauge/Switch
E ●
D ●
Local Panel
E ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 146 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Chamber For Acid Storage System
E ● ● ● ●
D ● ● ● ●
Mobile Acid Skid Cleaning System
E ● ● ● ●
D ● ●
Pressure Transmitter
E ● ●
D ●
Pump
E ●
D ● ●
Pump With Motor
E ● ●
Acid Cleaning D ●
Seal Port
System E ●
D ● ● ●
Skid For Acid Storage System
E ● ● ●
D ● ● ●
Skid For Chemical Dosing System
E ● ● ●
D ● ● ●
Hopper
E ● ● ●
D ●
Valve
E ●
D ●
Misc.
E ●
D ● ● ● ● ●
H-Beam
E ● ● ● ● ●
D ● ● ● ● ●
Angle
E ● ● ● ● ●
D ● ● ● ● ●
Channel
E ● ● ● ● ●
Steel Structure
D ● ● ● ● ●
Plate
E ● ● ● ● ●
D ●
Teflon Pad
E ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 147 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ● ●
Angle
E ● ● ● ● ●
D ● ● ● ● ●
Plate
E ● ● ● ● ●
D ● ● ● ● ●
Pipe
E ● ● ● ● ●
D ● ● ● ● ●
Channel
E ● ● ● ● ●
Platform
D ● ● ● ● ●
Flat Bar
E ● ● ● ● ●
D ● ● ●
Grating
E ● ● ●
D ● ● ● ● ●
Hand Rail / Stair
E ● ● ● ● ●
D ●
Misc.
E ●
D ● ● ● ●
Plate
E ● ● ● ●
D ● ● ●
Pipe
E ● ● ●
D ● ● ●
Round Bar
E ● ● ●
Pre-Heater D ● ● ●
Round Pipe
E ● ● ●
Seawater D ● ●
Heater Round Tube
E ●
Final D ● ● ●
Seamless Pipe
condenser E ● ● ●
D ●
Tube Sheet
E ●
D ●
Fitting
E ●
D ● ●
Metallic Expansion Joint
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 148 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Gasket
Pre-Heater E ●
Seawater D ●
Heater Flange
Final E ●
condenser D ●
Misc.
E ●
D ● ● ●
Seamless Pipe
E ● ● ●
D ● ● ●
Pipe
E ● ● ●
D ● ● ● ●
Plate
E ● ● ● ●
D ● ● ●
Round Bar
E ● ● ●
D ● ● ●
Flat Bar
E ● ● ●
D ●
Flange
E ●
D ● ● ●
Angle/Channel
E ● ● ●
Tank
D ●
Chain
E ●
D ●
Gauge Hatch
E ●
D ● ● ●
Grating
E ● ● ●
D ●
Fitting
E ●
D ● ●
Mesh Screen
E ●
D ●
Gasket
E ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 149 OF 188

4.2 RO
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Stuarator Tank
E ●
D ● ●
Agitator(**)
E ● ●
D ●
Scraper
E ●
D ● ● ●
Dispersion Pipe
E ● ● ●
D ● ● ●
Air Compressor
E ●
D ● ● ●
Pipe
E ● ● ●
D ● ●
Pump
E ● ●
D ● ●
Motor
E ● ●
DAF
D ●
LCP
E ●
D ● ●
Instrument
E ● ●
D ●
Analyzer
E ●
D ●
Gasket
E ●
D ● ● ●
Penstock
E ● ● ●
D ● ●
Stop Log
E ● ●
D ● ●
Temporary Strainer
E ● ●
D ●
Bot/Nut
E ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 150 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
Anchor Bolt
E ●
D ●
DAF Valve
E ●
D ●
VFD
E ●
D ● ●
Vessel
E ● ●
D ●
Membrane
E ●
D ● ●
Dummy Module
E ● ●
D ●
Special Tool
E ●
UF Skid(Rack, Piping, Valve D ●
UF
Assembly) E ●
D ● ●
Instrument
E ● ●
D ●
Bolt, Nut, Gasket
E ●
D ● ●
Anchor Bolt
E ●
D ● ● ●
Pilot Plant (Container) If Required.
E ● ●
D ●
Filter Housing
E ●
D ●
Filter Element
E ●
D ●
Cartidge Filter Bolt/Nut
E ●
D ●
Gasket
E ●
D ●
O ring
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 151 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Membrane Ro Membrane Assembly
E ●
D ●
DWEER Assembly
E ●
D ●
DWEER Rack(Steel Structure)
E ●
D ● ●
Cable
E ● ●
D ●
Anchor Bolt
E ●
D ●
DWEER Bolt/Nut
E ●
D ●
Victaulic Coupling
E ●
D ● ●
Actuator(**)
E ● ●
D ●
Valve
E ●
D ● ●
LCP
E ● ●
ERI Assembly(Element, Grp D ● ●
Vessel) E ● ●
D ●
ERI Rack(Steel Structure)
E ●
ERI
D ●
Anchor Bolt
E ●
D ●
Bolt/Nut
E ●
D ●
Turbo Charger Assembly
E ●
D ●
Turbo Charger Valve(With Electrical Actuator)
E ●
D ●
Thrust Bearing
E ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 152 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Rotor
E ●
D ●
Turbo Charger Anchor Bolt
E ●
D ●
Bolt/Nut
E ●
D ●
Tank
E ●
D ● ●
Agitator Assembly(**)
E ● ●
D ●
CIP Electrical Heater
E ●
D ●
Anchor Bolt
E ●
D ●
Bolt/Nut
E ●
D ●
Sampling Panel
E ●
Sampling panel
D ●
Sampling Tube
E ●
D ● ● ●
Membrane Test Skid
E ● ●
D ●
Pipe
E ●
Membrane test D ●
Bolt/Nut
skid E ●
D ●
Gasket
E ●
D ●
Anchor Bolt
E ●
D ●
Service Water Pump
Service water E ●
system D ●
Hydro Pneumatic Tank
E ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 153 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Skid
E ●
Service water D ●
Valve
system E ●
D ● ●
Pipe
E ● ●
D ●
Workshop Equipment
E ●
Workshop D ●
Cabinet
Equipment E ●
D ●
Desk
E ●
D ●
Scissor Lift Scissor Lift
E ● ●
Laboratory D ●
Laboratory Equipment
Equipment E ●
Auto-Strainer Assembly(Steel Or D ●
Grp Housing, Strainer, Motor Or Air
Actuator) E ●
D ●
Valve
E ●
D ● ●
Steel Support
E ● ●
D ● ●
LCP
Auto-Strainer E ● ●
D ● ●
Cable
E ● ●
D ● ●
Instrument
E ● ●
D ●
Bolt/Nut
E ●
D ●
Gasket
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 154 OF 188

4.3 Common
Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Valve (Cs / Ci / Di / SS)
E ●
(**)
Gear Box & Actuator & Cylinder D ●
& Bracket & Protect Cover E ●
Valve
D ●
Strainer & Trap (Cs, Ss)
E ●
D ●
Expansion Joint (Cs, Ss)
E ●
D ● ● ● ●
Piping Piping (Cs, Csg, Ss, D1)
E ● ● ● ●
D ●
DMF Vessel Ass'y
E ●
D ● ● ● ●
Plate
E ● ● ● ●
D ● ● ●
Round Bar
E ● ● ●
D ● ● ●
Seamless Pipe
E ● ● ●
D ●
Dual Media Filter(***)
E ●
D ●
DMF Vessel Manhole Cover
E ●
D ● ● ● ● ●
Angle
E ● ● ● ● ●
D ●
Gasket
E ●
D ●
Flange
E ●
D ●
Special Boss
E ●
D ●
Misc.
E ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.
(***) can be packed in gunny bag or bare style.
(***)는 마대나 Bare 상태로 공급할 수 있다.
Doosan Heavy Industries & Construction Co., Ltd.
WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 155 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Pump
E ●
D ● ●
Motor
E ● ●
D ●
Coupling
E ●
D ● ● ● ●
Aux Pipe
E ● ● ● ●
D ●
Aux Valve
E ●
Pump and D ●
Gasket
Motor E ●
D ●
O ring
E ●
D ●
LCP
E ●
D ●
VFD
E ●
D ● ●
Cable
E ● ●
D ● ● ●
Oil Unit
E ● ●
D ● ●
Static Mixer
E ● ●
Static Mixer
D ●
Anchor Bolt
E ●
D ● ●
Tank
E ● ●
D ● ●
Agitator(**)
Chemical E ● ●
Dosing System D ●
Agitator Shaft
E ●
D ● ● ●
Piping
E ● ● ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 156 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
Support
E ● ● ●
D ● ●
Cable
E ● ●
D ● ● ● ●
Cable Tray
E ● ● ● ●
D ● ● ● ●
Conduit Pipe
E ● ● ● ●
D ● ● ● ● ●
Platform, Hand Rail, Ladder
E ● ● ● ● ●
D ● ● ●
Dampener
E ● ● ●
D ● ●
Damister Carrier
E ●
D ●
Eye Shower
E ●
Chemical D ● ●
Flow Indicator
Dosing System E ● ●
D ● ●
Fume Scrubber
E ●
D ●
Level Gauge/Switch
E ●
D ●
Local Panel
E ●
D ● ● ● ●
Chamber For Acid Storage System
E ● ● ● ●
D ● ● ● ●
Mobile Acid Skid Cleaning System
E ● ● ● ●
D ● ●
Pressure Transmitter
E ● ●
D ●
Pump
E ●
D ● ●
Pump With Motor
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 157 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Seal Port
E ●
D ● ● ●
Skid For Acid Storage System
E ● ● ●
D ● ● ●
Skid For Chemical Dosing System
Chemical E ● ● ●
Dosing System D ● ● ●
Hopper
E ● ● ●
D ●
Valve
E ●
D ●
Misc.
E ●
D ● ● ● ●
Stop Gate
E ● ● ● ●
D ● ● ● ●
Guide
E ● ● ● ●
D ● ● ●
Lift Beam
E ● ● ●
D ● ● ●
Trash Rack
E ● ● ●
D ● ● ● ●
Bar Screen
E ● ● ● ●
D ● ●
Screen facility Trash Rake
E ● ●
D ●
Mobile Rail
E ●
D ● ● ●
Revolving Rake
E ● ● ●
D ● ●
Sluice Gate Of Trash Container
E ● ●
D ● ●
Pump
E ● ●
D ● ● ● ●
Pipe
E ● ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 158 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Valve
E ●
D ● ● ● ●
Pipe Support
E ● ● ● ●
D ● ● ● ●
Air Blowing System
E ● ●
D ● ●
Motor
E ● ●
D ● ● ● ●
Storage Frame
E ● ● ● ●
D ●
Panel
E ●
D ●
Junction Box
E ●
D ● ●
Screen facility Instrument
E ● ●
D ●
Hook Up Material
E ●
D ● ●
Lubricant
E ● ●
D ● ●
Paint
E ● ●
D ●
Anchor Plate
E ●
D ● ● ● ●
Embedded Guide
E ● ● ● ●
D ● ● ● ●
Wedge Plate
E ● ● ● ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 159 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Transformer
E ● ●
D ●
Rectifier
E ●
D ● ● ● ● ● ●
Generator Skid
E ● ● ● ● ● ●
D ● ● ●
Bus Bar And Bus Ducts
E ● ● ●
Steel Structure (Incl. Ladder, D ● ● ● ● ●
Handrail) E ● ● ● ● ●
D ● ●
Tank
E ● ●
D ●
Air Blower
E ●
D ● ● ●
Damper
E ● ● ●
Electro D ● ●
Pump
Chlorination E ● ●
D
Emergency N2 Purge Cylinder
E
D ●
Panel
E ●
D ● ●
Instrument
E ● ●
D ●
Ejector
E ●
D ● ● ● ●
Pipe
E ● ● ● ●
D ●
Valve
E ●
D ●
Safety Shower
E ●
D ● ● ● ●
Pipe Support
E ● ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 160 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Electrical Bulk Material
E ● ●
D ● ● ●
Diffuser
E ● ● ●
Electro D ●
Gasket
Chlorination E ●
D ● ●
Electrical Cable
E ● ●
D ●
Misc.
E ●
D ● ●
Pump
E ● ●
D ● ●
Activated Carbon Filter
E ● ●
D ● ●
CO2 Absorber Tower
E ● ●
D ● ●
Limestone Filter
E ● ●
D ●
Degasifier
E ●
D ●
Degasifier Fan
E ●
Post treatment
D ●
Sand Filter
E ●
D ●
Air Scour Blower
E ●
D ● ●
Silo
E ● ●
D ●
Valve
E ●
D ●
Bag Filter
E ●
D ●
Dehumidifier
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 161 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
Bucket Elevator
E ● ● ●
D ● ●
Screw Conveyor
E ● ●
D ● ● ●
Regulating Hopper
E ● ● ●
D ●
Vibrator
E ●
D ●
Two-Way Diverter
E ●
D ● ●
Tank
E ● ●
D ● ● ● ●
Piping
E ● ● ● ●
D ●
Gasket
E ●
Steel Structure (Incl. Ladder, D ● ● ● ● ●
Post treatment
Handrail) E ● ● ● ● ●
D ●
Panel
E ●
D ●
Instrument
E ●
D ● ●
Cable
E ● ●
D ● ●
Electrical Bulk Material
E ● ●
D ●
Agitator(**)
E ●
D ● ●
Lime Saturator
E ● ●
D ● ● ●
Bag Splitter Skid
E ● ● ●
D ●
Misc.
E ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 162 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
Chlorine Ton Container
E ● ● ●
D ● ● ●
Evaporator
E ● ● ●
D ● ●
Chlorinator
E ● ●
D ●
Injector
E ●
D ● ●
Pump
E ● ●
D ● ●
Gas Scrubber
E ● ●
D ●
Panel
E ●
D ● ●
Instrument
E ● ●
Gas D ●
Eye Shower
Chlorination E ●
D ●
Valve
E ●
D ● ● ●
Chlorine Gas Strainer
E ● ● ●
D ●
Vacuum Regulator
E ●
D ● ● ●
Air Exhaust Fan
E ● ● ●
D ● ● ●
Container Grab
E ● ● ●
D ● ●
Chlorguard System
E ● ●
D ● ●
Tank
E ● ●
D ● ● ● ●
Piping (Bulk/Spool)
E ● ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 163 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
Steel Structure(Incl. Ladder, D ● ● ● ● ●
Handrail) E ● ● ● ● ●
D ● ●
Cable
Gas E ● ●
Chlorination D ● ●
Electrical Bulk Material
E ● ●
D ●
Misc.
E ●
D ● ●
Compressor
E ● ●
D ● ●
Air Dryer
E ● ●
D ● ●
Receiver Tank
E ● ●
D ●
Panel
E ●
D ● ● ● ●
Pipe
E ● ● ● ●
Compressed D ●
Valve
Air System E ●
D ● ● ● ●
Pipe Support
E ● ● ● ●
D ● ●
Electrical Bulk Material
E ● ●
D ●
Gasket
E ●
D ● ●
Electrical Cable
E ● ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 164 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Plate
E ● ● ● ●
D ● ● ●
Pipe
E ● ● ●
D ● ● ●
Round Bar
E ● ● ●
D ● ● ●
Seamless Pipe
E ● ● ●
D ● ●
Bed Limiter
E ●
D ●
Flange
E ●
D ● ●
Con Reducer
E ● ●
D ● ● ● ●
Angle
E ● ● ● ●
D ●
Re- Demister
E ●
mineralization
system D ● ● ● ● ●
H-Beam
E ● ● ● ● ●
D ● ● ● ● ●
Packing Support
E ● ● ● ● ●
D ●
Filter Element
E ●
D ●
Fitting
E ●
D ●
Gasket
E ●
D ●
Pall Ring(***)
E ●
D ●
Perforated Sheet
E ●
D ● ● ●
Strainer
E ● ● ●
D ●
Misc.
E ●
(***) can be packed in gunny bag or bare style.
(***)는 마대나 Bare 상태로 공급할 수 있다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 165 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
Switch Monitor Input/Output D ● ●
Module E ● ●
Swivel Assembly For Flame D ●
Detector E ●
D ● ●
Sensor
E ● ●
D ● ●
Detector
E ● ●
D ●
Mounting Base
E ●
D ● ●
Priority Switch Monitor Module
E ● ●
D ● ●
Sounder Control Module
E ● ●
D ● ●
Loop Isolator Module
E ● ●
D ●
Fire Fighting Addressable Manual Pull Station
E ●
D ●
Remote Led Indicator
E ●
D ● ●
Flexvu Ud10 Universal Display
E ● ●
Auxiliary Escape Panaromasque D ●
Full-Face Mak E ●
D ●
Scba Cylinder 6Ltr (Empty)
E ●
D ● ● ●
Senator 200, Steel Enclosure
E ● ● ●
D ● ●
Ps25 Intelligent Power Supply
E ● ●
D ●
Extinguishing Control Panel
E ●
STI Universal Stopper, Dome D ● ● ●
Cover, Enclosed Back Box E ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 166 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
Ex. Proof Sounder, Db3 Range, Up D ● ● ●
To 118 Db(A), In Grp Material, E ● ● ●
D ●
Horn Strobe Indoor
E ●
D ● ●
Flasher Indoor
E ● ●
D ● ●
Probe Type Heat Detector
E ● ●
Manual Release Station, D ●
Standard Pull Station, Dual Action E ●
Standard Manual Alarm Station D ●
Fire Fighting
Surface Back box, Interior E ●
D ● ●
Cable
E ● ●
D ● ● ● ●
Piping
E ● ● ● ●
D ●
Valve
E ●
D ● ● ● ●
Flexible Conduit
E ● ● ● ●
D ●
Misc.
E ●
D ● ●
Crane Complete Assembly
E ● ●
D ● ● ●
Angle/Channel
E ● ● ●
D ● ● ● ●
Crane & Hoist Steel Joint
E ● ● ● ●
D ● ●
Level Transmitter Stopper
E ● ●
D ●
Isolator Switch
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 167 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Cable
E ● ●
D ● ● ● ●
Bar Assembly
E ● ● ● ●
D ● ● ● ●
Rail Track
E ● ● ● ●
D ● ● ● ● ●
Crane & Hoist Platform Girder/Beam
E ● ● ● ● ●
D ● ● ●
Leg Platform/Staircase
E ● ● ●
D ● ●
Bus Bar System
E ● ●
D ●
Misc.
E ●
D ● ●
Tank
E ● ●
D ● ● ●
Mea Re Boiler With Burner
E ● ● ●
D ●
Air Blower
E ●
D ● ●
Flue Gas Cooling Tower
E ● ●
D ● ●
Pump
CO2 production E ● ●
plant D ● ●
CO2 Absorber Tower
E ● ●
D ● ●
CO2 Stripper Tower
E ● ●
D ● ●
Moisture Separator Tower
E ● ●
D ● ●
Ppm Washing Tower
E ● ●
D ● ● ●
CO2 Condenser
E ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 168 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
CO2 Compressor
E ● ●
D ● ●
CO2 Dryer
E ● ●
D ● ● ●
Activated Carbon Filter
E ● ● ●
D ● ● ●
Refrigerant System
E ● ● ●
D ● ●
CO2 Evaporator
E ● ●
D ● ●
Pressure Regulating Station
E ● ●
D ●
Emergency Shower
E ●
D ● ●
Cooling Tower
E ● ●
CO2 production D ● ● ● ●
Piping
plant E ● ● ● ●
D ●
Valve
E ●
D ● ●
Instrument
E ● ●
D ●
Panel
E ●
D ●
Junction Box
E ●
D ● ●
Cable
E ● ●
D ●
Electrical Bulk Material
E ●
D ● ● ● ● ●
Steel Structure
E ● ● ● ● ●
D ●
Misc.
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 169 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Support & Steel Structure
E ● ● ● ●
Others
D ● ●
Platform
E ● ●
D ●
Transformer
E ●
D ●
Rectifier
E ●
D ●
Switchgear
E ●
D ●
Bus Duct
E ●
D ●
DC/UPS System - Panel
E ●
D ● ●
DC/UPS System - Battery
E ● ●
D ●
Variable Frequency Drive
E ●
D ●
Electrical Other Electrical Panel
E ●
D ● ● ● ●
CCTV System
E ● ● ● ●
D ●
Power Distribution Board
E ●
D ●
Fault Monitoring System
E ●
D ●
Emergency Diesel Generator
E ●
D ●
MCC
E ●
D ● ●
Power Cable
E ● ●
D ● ● ● ●
Cable Tray And Conduit
E ● ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 170 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
Lighting Fixture & Acc.
E ● ● ●
D ● ●
Lighting Pole
E ● ●
D ● ● ● ●
Earthing System & Acc.
E ● ● ● ●
Electrical
D ● ●
Cathodic Protection Panel
E ● ●
D ● ● ●
Cathodic Protection Acc.
E ● ● ●
D ●
Fire Sealing Material
E ●
D ●
DCS System
E ●
D ●
Vibration Monitoring System
E ●
D ●
Local Control Panel
E ●
Flow Meter - Flow Body Sensor D ● ●
Part E ●
D ●
Flow Meter - Flow Converter Part
E ●
D ●
I&C Process Switch
E ●
D ●
Process Transmitter
E ●
D ●
Analyzer Transmitter
E ●
D ● ●
Pre-Assembled Analyzer Panel
E ● ●
D ● ●
Terminal Box
E ● ●
D ● ●
Local Instrument Panel (LIP)
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 171 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Hook-Up Material
E ● ●
D ● ●
I&C I&C Cable
E ● ●
D ● ●
Communication System & Acc.
E ● ●

4.4 Water Treatment

Packing Type
국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item
Skid
Box

D ●
Pump
E ●
D ● ●
Motor
E ● ●
D ●
Coupling
E ●
D ● ● ● ●
Aux Pipe
E ● ● ● ●
D ●
Aux Valve
Pump and E ●
Motor D ●
Gasket
E ●
D ●
O Ring
E ●
D ●
LCP
E ●
D ● ●
Cable
E ● ●
D ● ●
Oil Unit
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 172 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
Bridge Travel Grit Removal
E ● ● ●
D ●
LCP
E ●
Grit Removal
D ● ●
Grit Pump
E ● ●
D ● ● ●
Compactor
E ● ● ●
D ● ● ●
Drum Screen
E ● ● ●
D ●
LCP
E ●
Drum Screen
D ●
Solenoid Valve & Nozzle
E ●
D ● ●
Washing Pump
E ● ●
D ● ● ●
Oil Separator
E ● ● ●
Oil Separator
D ●
Misc.
E ●
D ● ● ●
Disc Diffuser
E ● ● ●
D ●
Diffuser Lateral Pipe Grid
E ●
D ●
Misc.
E ●
D ● ● ●
Blower
E ● ● ●
D ●
Coupling
E ●
Air Blower
D ● ● ● ●
Aux Pipe
E ● ● ● ●
D ●
Aux Valve
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 173 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
LCP(PLC Panel)
E ●
D ●
VFD
E ●
Air Blower
D ● ●
Oil Unit
E ●
D ● ●
Sound Enclosure
E ● ●
D ● ● ●
Mixer
E ● ● ●
D ●
LCP
Submersible E ●
Mixer D ● ●
Cable
E ● ●
D ●
VFD
E ●
D ● ● ● ●
Membrane Skid(Or Rack)
E ● ● ●
D ● ● ● ●
MBR Membrane
E ● ● ●
D ● ● ●
Diffuser Assembly
E ● ● ●
D ● ●
Actuator(**)
E ● ●
D ●
Spindle
E ●
Sluice Gate
D ● ● ● ●
Guide Frame
E ● ● ● ●
D ●
Gear Unit
E ●
D ● ●
Grinder
E ● ●
D ●
Sludge Grinder LCP
E ●
D ●
Gasket
E ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.
Doosan Heavy Industries & Construction Co., Ltd.
WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 174 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ● ●
Decanter Trough
E ● ● ● ●
D ● ● ● ●
Support Structure
Floating E ● ● ● ●
Decanter D ● ● ● ●
Discharge Pipe
E ● ● ● ●
D ●
LCP
E ●
D ● ●
Polymer Preparation Chamber
E ●
D ●
Polymer LCP
E ●
Preparation
unit D ● ● ● ●
Powder Hopper
E ● ● ● ●
D ● ●
Agitator(**)
E ● ●
D ● ●
Filter Vessel
E ● ●
D ●
Filter Internals
E ●
Pressurized D ●
Filter Nozzle
Sand Filtration E ●
D ●
Sand and Gravel(***)
E ●
D ● ●
Air Blower
E ● ●
D ● ● ●
Vessel(FRP)
E ● ● ●
D ● ● ● ●
Media(Inorganic/Organic)
Odour Control E ● ● ● ●
System D ●
Spray Nozzle
E ●
D ● ●
Fan
E ● ●
(**) shall be packed in moisture proof box in case of being assembled with electrical part.
(**)는 전장품이 조립되어 있을 경우 방습포장을 적용한다.
(***) can be packed in gunny bag or bare style.
(***)는 마대나 Bare 상태로 공급할 수 있다.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 175 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
Discharge Stack (FRP Vessel D ● ● ●
Type) E ● ● ●
D ● ●
Pump
E ● ●
D ● ●
Duct
Odour Control E ● ●
System D ● ● ●
Damper
E ● ● ●
D ●
LCP
E ●
D ●
VFD
E ●
D ● ●
Drive Unit
E ● ●
D ● ● ● ●
Sludge Scraper
E ● ● ● ●
D ●
Drive Shaft
E ●
Clarifier
D ● ● ●
Picket Fence
E ● ● ●
D ●
Shaft With Drive Sprocket
E ●
D ● ● ● ●
Angle Bracket
E ● ● ● ●
D ● ● ●
Thickener Assembly
E ● ● ●
Mechanical D ●
LCP
Thickener E ●
D ● ● ● ●
Flocculation Chamber
E ● ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 176 OF 188

5. HRSG

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Module
E ●
D ●
Pressure Part Harp Ass'y
E ●
D ●
Header
E ●
D ●
Top Casing
E ●
D ●
Side Casing
E ●
Casing
D ● ●
Insulation
E ● ●
D ●
Liner Plate
E ●
D ●
Template
E ●
D ●
Shell Plate
E ●
D ● ●
Personal Protect
E ● ●
D ● ●
Stack Platform
E ● ●
D ● ●
Grating
E ● ●
D ● ● ●
Ladder
E ● ● ●
D ● ● ●
Handrail
E ● ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 177 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Side Panel
E ●
D ●
Roof Panel
E ●
Duct
D ●
Floor Panel
E ●
D ●
Liner Plate
E ●
D ● ●
Electrical Equipment
E ● ●
D ● ●
Instrument
E ● ●
D ●
Valve
E ●
Mechanical D ●
Fitting
Equipment E ●
D ●
Bolt/Nut
E ●
D ●
Tool
E ●
D ●
Gaskets
E ●
D ● ●
Insulation Insulation & Fire Brick Castable
E ● ●
D ● ● ● ●
Burner(Front Plate)
E ● ● ● ●
Duct Burner
D ● ● ● ●
BMS Shelter & Loose Part
E ● ● ● ●
D ● ●
Blow down Tank
E ● ●
D ● ●
Tank Expansion Tank
E ● ●
D ● ●
Flash Tank
E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 178 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ●
Embedded Material
E ● ●
Angle, Base Plate, Bracket, Flat D ● ●
Bar, Pad, Pipe E ● ●
D ● ● ●
Beam, Column, Girder, Brace
E ● ● ●
Steel Structure
Ladder, Platform, Handrail Stair, D ● ● ●
Splice Plate E ● ● ●
D ●
Bolt, Nut & Washer
E ●
D ● ●
Grating
E ● ●
D ● ● ● ● ●
Link
E ● ● ● ● ●
D ● ●
Raw Material
E ● ●
Link & D ● ● ●
External Pipe
Manifolds E ● ● ●
D ● ● ● ●
Carbon Steel Pipe
E ● ● ● ●
D ● ●
Manifold
E ● ●
D ●
Boiler Feed water Pump
E ●
D ●
DH Eco. Circuit Pump
E ●
D ●
Pump DH Eco. Shunt Pump
E ●
D ●
CPH Recirculation Pump
E ●
D ●
Blow down Pump
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 179 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ● ● ●
Elevator Elevator
E ● ● ●
D ● ●
HP, LP, IP Drum
E ● ●
Drum
D ●
Remote Drum Indicator
E ●
D ●
Level Gauge Level Gauge
E ●
D ● ● ●
Stack Silencer
E ● ● ●
Silencer
D ● ●
Vent Silencer
E ● ●
D ●
Pneumatic Control Valve
E ●
D ●
Valve Manual Valve
E ●
D ●
Motor Operated Valve
E ●
D ●
Valve Safety Valve
E ●
D ●
Trap Steam Trap & Strainer
E ●
D ●
Strainer
E ●
D ●
Auto Strainer
E ●
D ●
Strainer Control Panel
E ●
D ●
Cover Gasket
E ●
D ●
Loose & Spare Parts
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 180 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Damper
E ●
D ●
Damper Electric Actuator & Instrument
E ● ●
D ●
Accessories
E ●
D ● ●
Deaerator Deaerator
E ● ●
D ●
Spring Hanger
E ●
Spring Hanger D ● ●
Rod
& Support E ●
D ●
Clamp
E ●
Spring Hanger D ●
Guide & Support, Beam
& Support E ●
D ●
Plate Heat Exchanger
DH Plate Heat E ●
Exchanger D ●
Loose Parts
E ●
D ●
Electric Hoist Electric Hoist
E ●
D ● ● ● ● ●
Pipe
E ● ● ● ● ●
Pipe & Fitting
D ● ●
Fitting
E ● ●
Expansion D ● ● ●
Expansion Joint & Bellows
Joint E ● ● ●
Thermocouple D ●
Thermocouple & Thermo well
& Thermo well E ●
N2 Charger & D ● ●
N2 Charger And Storage Unit
Storage Unit E ● ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 181 OF 188

Packing Type

국내(Domestic)
수출(Export)

Water Proof

Steel Frame
Open Crate

Steel Skid
proof Box

Container
Moisture

Wooden
Bundle
Pallet

Drum
Division Item

Skid
Box
D ●
Lifting Jig
E ●
D ●
Stand Up Jig
E ●
Lifting Device
D ●
Top Beam
E ●
D ●
Wire & Shackle
E ●
D ● ●
Analyzer System
E ● ●
D ●
Power Distribution Board
E ●
Electric D ● ●
Lighting System
Equipment E ● ●
D ●
Local Instrument Panel
E ●
D ●
Field Instrument
E ●

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 182 OF 188

Packing Style & Process Remarks

1. Moisture
방습 포장용 자재(Al Foil, 토일론, VCI Wrap 등)
Proof Box 1. 방습포장 자재준비
(Prepare packing material for moisture proof
packing)
(AL Foil, Toilon, V.C.I Wrap & Box ETC.)
2. Wrapping & Al foil 설치
가. 박스 밑판 AL Foil 설치 및 Wrapping
(Installation AL foil & VCI Wrapping on Box)
나. 내부공기 제거
(Remove inside air)
다. Heat Sealing
(Heat Sealing)

3. 내부 고정 및 Box 조립
(Fix products in the box & Assemble the box)
가. 박스 내부 제품고정
(Fix products in the box)
나. Box 옆판 및 상판 조립
(Assemble side and top panel of the box)

Al Foil 내부에는 각재와 습기가 있는 자재는

같이 포장되어서는 안 된다.
The timber and packing materials that contains
moisture shall not be packed inside Al Foil.

박스 내부고정
(Fix items in the box)

Item : Valve & Pump with electrical assembly, Electric Component all Item

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 183 OF 188

Packing Style & Process Remarks

2. Water
1. 자재 준비(Box 제작 및 ①자재 준비(Box 제작 및 제품보호)
Proof Box
제품 보호)
(Prepare packing material
for making the box and
protection for products)

2. 제품 적층 및 제품 고정 ②제품 적층 및 제품 고정
가. 제품 적층
(Stack products)
나. 제품 고정
(Fix products in the box)

3. Box 조립 및 천막 설치 ③Box 조립 및 천막설치

(Assemble the box and
cover with tent)
가. 박스 조립
PE Tarpaulin
(Assemble the box)
Min. 200g/㎡
나. 천막 설치
(Cover with tent)

Item : Valve & Pump with Mechanical assembly, Mechanical Component all Item,
Embedded Material & Anchor bolt, H.S. Bolts/Nuts/ Washers & ETC.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 184 OF 188

Packing Style & Process Remarks

3. Open
1. 자재 준비(Box 제작 및 ①자재 준비(Box 제작 및 제품보호)
Crate
제품 보호)
(Prepare packing material
for making the box and
protection for products)

2. 제품 적층 및 제품 고정 ②제품 적층 및 제품 고정
가. 제품 적층
(Stack products)
나. 제품 고정
(Fix products in the box)

3. Box 조립 ③Box 조립
(Assemble the box)

Crate Item : Silencer, Aux Boiler & ETC

Open Crate Item : Exp. Joint, Divert Damper, Duct Burner & ETC.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 185 OF 188

Packing Style & Process Remarks

4. Pallet
1. 자재 준비(Pallet 제작 및 ①자재 준비(Pallet 제작 및 제품보호)
제품 보호)
(Prepare packing material
for making the pallet and
protection for products)

2. 제품 적층 ②제품 적층
(Stack products)

3. 제품 고정 ③제품 고정
(Fix products on the
pallets)

Item : Exp. Joint, Silencer, Divert Damper, Duct, Steel Structure, Grating, Handrail &
ETC.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 186 OF 188

Packing Style & Process Remarks

5. Wooden
1. 자재 준비 ① 자재 준비 -> 제품 적층 -> 제품 고정
Bundle
(Wooden bundle
제작 및 제품 보호)
(Prepare packing
material for making
wooden bundle
and protection for
products)

2. 제품 적층
(Stack products)

3. 제품 고정
(Fix product on the
wooden skid)

Item : Steel Structure, Pressure Part Tube, Panel & ETC.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 187 OF 188

Packing Style & Process Remarks

6. Wooden
1. 자재 준비
Skid
(Wooden Skid
제작 및 제품 보호)
(Prepare packing
material for making
the wooden skid and
protection for
products

2. 제품 적층
(Stack products)

3. 제품 고정
(Fix products on
the wooden skid)

Item : Drum, Pressure Part Header, Vessel & ETC.

Doosan Heavy Industries & Construction Co., Ltd.

WIBFBAAPK0001/-/3/ S/N:/HQ20160302-0119/

[Confidential]Suin Jang/2016-03-02 09:31/Bangjoo Park/2016-03-02 10:07/Hyungill Lim/2016-03-04 10:43/Painting & Shipping Engineering Team
▶본 자료는 두산중공업㈜의 자산이므로 목적 外 사용 및 무단 복제를 절대 금함

REV. 0 1 2 3

문서번호
표준 작업 지침서(B) (WI NO.)
WIBFBAAPK0001

STANDARD WORK INSTRUCTION(B) PAGE 188 OF 188

Packing Style & Process Remarks

7. Steel
1. 자재준비
Frame
(Steel Frame 제작)
(Prepare packing
material for making
the steel frame)
H

W
L

2. 제품 적층
(Stack products)

50 4500 50

3. 제품고정
(Fix products on
the steel frame)

Item : Duct, Stack, Casing(With Insulation), Platform, Handrail, Duct burner, CE, DE &
ETC.

Doosan Heavy Industries & Construction Co., Ltd.
