Introduction
This chapter is about learning to become familiar with the layout and contents of
API 510. It forms a vital preliminary stage that will ultimately help you understand
not only the content of API 510 but also its cross-references to the other relevant
API and ASME codes. API 510 is divided into nine sections (sections 1 to 9), five
appendices (appendices A to E), one figure and two tables. Even when taken
together, these are not sufficient to specify fully a methodology for the inspection,
repair and re-rating of pressure vessels. To accomplish this, further information
and guidance has to be drawn from other codes. So that we can start to build up
your familiarity with API 510, we are going to look at some of the definitions that
form its basis. We can start to identify these by looking at the API 510
contents/index page. This is laid out broadly as shown in Fig. 2.1.
2.2
Section 1: scope
This is a very short (one-page) part of the code. The main point is in section 1.1.1,
which states that all refining and chemical process vessels are included in the
scope of API 510 except those vessels that are specifically excluded from the
coverage of API 510. Note that this list (look at section 1.2.2) links together with a
longer list in appendix A (look near the back of the document). Essentially, vessels
that are excluded from the coverage of API 510 are: . Mobile plant . Anything
designed to other parts of ASME . Fired heaters
10
11
. Machinery, i.e. pumps, compressors, etc. . Pipes and fittings There are also some
specific exemptions on size. Read the list in appendix A and relate them to Figs 2.2
and 2.3 below. Appendix A (b6) gives an overall pressure temperature
exemption for vessels that contain water (or water with air provided as a ‘cushion’
only, i.e. accumulators). Appendix A (b7) covers hot water storage tanks. Appendix
A (b8) gives a more general exemption based on minimum pressures and
diameters. Finally: Appendix A (d) covers a further general exemption based on
pressure and volume. Remember, section 1.2.2 at the front of API 510 only gives
you half the story about exemptions. You have to look at the detail given in API
510 appendix A to get a fuller picture.
2.3
Section 3: definitions
13
For API 510 exam purposes, assume that ‘The Competent person’ (organization) is
taking the role of the authorized inspection agency mentioned in API 510 section
3.6. Section 3.7: authorized pressure vessel inspector This refers to the USA
situation where, in many states, vessel inspectors have to be certified to API 510.
There is no such legal requirement in the UK. Assume, however, that the
authorized vessel inspector is someone who has passed the API 510 certification
exam and can therefore perform competently the vessel inspection duties covered
by API 510. Section 3.9: condition monitoring locations (CMLs) These are simply
locations on a vessel where parameters such as wall thickness are measured. They
used to be called thickness measurement locations (TMLs) but have now been
renamed CMLs. CMLs pop up like spring flowers in a few places in API 510 and
572, with emphasis being placed on how many you need and where they should
be. Section 3.19: engineer In previous editions of API 510, reference was made to
the ‘pressure vessel engineer’ as someone to be consulted by the API inspector
for detailed advice on vessel design. This person has now been renamed ‘The
Engineer’. There’s progress for you. Section 3.20: examiner Don’t confuse this as
anything to do with the examiner that oversees the API certification exams. This is
the API terminology for the NDT technician who provides the NDT results for
evaluation by the API-qualified pressure vessel inspector. API recognizes the NDT
technician as a separate entity from the API authorized pressure vessel inspector.
API codes (in fact most American-based codes) refer to NDT (the European term)
as NDE (non-destructive examination), so expect to see this used throughout the
API 510 training programme and examination.
14
15
of authorization). This links in with the general philosophy of ASME VIII, requiring
formal certification of companies who want to manufacture/repair ASME-stamped
vessels. Section 3.56: re-rating The word re-rating appears frequently throughout
API codes. Re-rating of the MAWP or MDMT (minimum design metal temperature)
of pressure vessels is perfectly allowable under the requirements of API 510, as
long as code compliance is maintained. In the USA, the API authorized inspector is
responsible for re-rating a pressure vessel, once happy with the results of
thickness checks, change of process conditions, etc. In the European way of
working, this is unlikely to be carried out by a single person (although, in theory,
the API 510 qualification should qualify a vessel inspector to do it). Re-rating may
be needed owing to any combination of four main reasons – we will look at this in
detail in Chapter 5. Section 3.62: transition temperature API codes are showing
increasing acceptance of the problem of brittle fracture of pressure equipment
materials. The new API 510 9th edition introduces the well-established idea of
transition temperature, the temperature at which a material changes from
predominantly ductile to predominantly brittle. As a principle, it is not advisable
to use a material at an MDMT below this transition temperature (although we will
see that there are possible ‘get-outs’ in the ASME VIII part of the syllabus) .
16
in other countries where the owner/user ends up being the predominant duty
holder under the partially sighted eye of the law. The idea is that the owner/user
should have a maintained QA/inspection/repair management system covering . . .
just about everything. There is nothing particularly new about the list of
requirements of this (listed as section 4.2.1 a to s); they are much the same as
would be included in an ISO 9000 audit or similar act of organizational theatre.
They are also the same as those given in the API 570 Piping Inspection code. Note
a couple of interesting ones, however. Section 4.2.1(j): ensuring that all
jurisdictional requirements for vessel inspection, repairs, alteration and re-rating
are continuously met Remember that the term jurisdiction relates to the legal
requirements in different states of the USA. In the UK this would mean statutory
regulations such as the PSSRs, HASAWA, COMAH, PUWER and suchlike. Section
4.2.1(n): controls necessary so that only materials conforming to the applicable
section of the ASME code are utilized for repairs and alterations This is clear. It
effectively says that only code-compliant material and procedures must be used
for repairs and alterations if you want to comply with API 510. Note that (along
with definition 3.3), it does not specify exclusively the ASME code; this is a
significant change from previous API 510 editions which recognized only ASME as
the ‘applicable code’. You can think of this as a way of trying to make API 510
more relevant to countries outside the US, but remember that API 510 does not
actually say this. The exam paper will be about what is written in the code, not
your view of how it fits into the inspection world in other countries. Reminder: API
510 says that: only materials conforming to the applicable codes and
specifications should be used for repairs and alterations. 17
18
An Introduction to API 510
should they, as they leave that to the inspector?) may need convincing that they
are ultimately responsible for the long list of responsibilities in 4.2.1. However,
they find out pretty quickly after a pressure-related incident. Section 4.2.4:
responsibilities of the API authorized pressure vessel inspector This section
appears in many of the API codes. The overiding principle (see Fig. 2.5) is that the
API-certified pressure vessel inspector is responsible to the owner/user for
confirming that the requirements of API 510 have been met. You will see this
as a recurring theme throughout this book (and there will almost certainly be
examination questions on it). Section 4.2.4 places the requirements for candidates
to have minimum qualifications and experience, before they are allowed to sit the
API 510 exams (see appendix B where these requirements are listed). Now, using
your code, try to answer these familiarization questions.
2.5 API 510 sections 1–4 familiarization questions Q1. API 510 section 1.2.2 and
appendix A: exclusions Which of these vessels is excluded from the requirements
of API 510? (a) A fired tubular heat exchanger in an oil refinery & (b) A 200-litre air
receiver at less than 0.5 bar gauge pressure & (c) A separator vessel on an
offshore platform (in USA waters) & (d) All vessels operating at less than 250 psi &
Q2. API 510 section 1.2.2 and appendix A: exclusions Which of these vessels
containing steam is excluded from requirements of API 510? (a) A 100-litre vessel
at 18 bar (b) A 100-litre vessel at 250 psi (c) A vessel of any size as long as the
pressure is less than 300 psi (d) A vessel of any pressure as long as the capacity is
less than 120 gallons
Q3. API 510 section 2: references Which API code (not in the API 510 syllabus)
covers welding on equipment in service? (a) API 579 & (b) API 574 & (c) API 2201
& (d) SNT-TC-1A &
20
Q4. API 510 section 3.2: alterations Which of these is likely to be classed as an
alteration to a pressure vessel? (a) Replacing the entire vessel head with one of
the same design & (b) Replacing existing nozzles with smaller ones & (c) Replacing
existing nozzles with larger ones & (d) An increase in design pressure &
Q5. API 510 section 3.37: definitions of MAWP In simple terms, MAWP means
much the same as? (a) 90 % design pressure (b) 150 % design pressure (c) Design
pressure (d) Hydraulic test pressure
&&&&
Q6. API 510 section 3.37: definitions of MAWP At what position is MAWP
calculated for in a vertical pressure vessel? (a) At the bottom of the vessel & (b) At
the top of the vessel & (c) Halfway up the vessel & (d) At the pressure gauge
position, wherever it happens to be &
Q7. API 510 section 3.37: definitions of MAWP A pitted vessel is measured at an
average of 10 mm thick and has a ‘designed’ corrosion allowance of 1.6 mm. It is
now installed in a corrosion-free environment. What thickness is used when
calculating the MAWP? (a) 13.2 mm & (b) 11.6 mm & (c) 10 mm & (d) 8.4 mm &
Q8. API 510 appendix B3: inspector recertification How often must an API 510-
certified vessel inspector be ‘recertified’ by API? (a) Every year & (b) Every 3 years
& (c) Every 5 years &
21
Q9. API 510 section 4.4: responsibilities During the repair of a pressure vessel,
who is the API-certified vessel inspector responsible to? (a) The owner/user of the
vessel & (b) API & (c) The repair contractor & (d) All the parties, as the inspector is
acting in an ‘honest broker’ capacity &
Q10.
