PROJECT /

AKARIA-NARJIS COMPOUND

LOCATION \
AL NARJES , RIYADH – KSA.

OWNER \
SAUDI REAL ESTATE CO.

CONSULTING \
ARCH-CENTRE
‫إﺳﺘﺸﺎرات ﻣﻌﻤﺎرﯾﺔ وھﻨﺪﺳﯿﺔ‬

‫اﻟﺤﺴﺎﺑﺎت اﻟﻬﻴﺪروﻟﻴﻜﻴﺔ ﻟﻸﻋﻤﺎل اﻟﺼﺤﻴﺔ‬

Plumbing Calculation Sheet
AL-AKARIA RESIDENTIAL COMPOUND

Codes and design standards.

The following codes will be used in the design of the plumbing

IPC International Plumbing Code

IBC International Building Code

NFPA99 Standard For Health Care Facilities

ASTM American Society for Testing Materials.

SASO Saudi Arabian Standard Organization

ASPE American Society for Plumbing Engineers.

PIPE SIZING WATER SUPPLY FOR EACH

Water supply fixture unit (WSFU) for (Villa)

Cold water pipe

* Using IPC design Table (103.3(2))
Total
Fixture WSFU No.
(HWFUV)
W.C - Private (F. tank) 2.2 7 15.4
Lavatory - Private 0.7 11 7.7
Shower - Private 1.4 5 7
Kitchen Sink - Private 1.4 1 1.4
Washing machine 1.4 1 1.4
H.B 2 1 2
TOTAL 34.9

Total fixture unit = 34.9

Max. Discharger = 24.9 GPM
1 pipe inlet (Ø) = 2 in
* Take main inlet pipe diameter = 2 in
* Take main inlet pipe diameter = 50 mm
Water supply fixture unit (WSFU) for ( Each
Apartment(plot 1-6))

Cold water pipe

* Using IPC design Table (103.3(2))
Total
Fixture WSFU No.
(HWFUV)
W.C - Private (F. tank) 2.2 44 96.8
Lavatory - Private 0.7 60 42
Shower - Private 1.4 30 42
Kitchen Sink - Private 1.4 15 21
Washing machine 1.4 15 21
H.B 2 2 4
TOTAL 226.8

Total fixture unit = 226.8

Max. Discharger = 70 GPM
1 pipe inlet (Ø) = 2 in
* Take main inlet pipe diameter = 2 in
* Take main inlet pipe diameter = 50 mm

Water supply fixture unit (WSFU) for

(Apartment(plot 7))

Cold water pipe

* Using IPC design Table (103.3(2))
Total
Fixture WSFU No.
(HWFUV)
W.C - Private (F. tank) 2.2 45 99
Lavatory - Private 0.7 61 42.7
Shower - Private 1.4 26 36.4
Kitchen Sink - Private 1.4 20 28
Washing machine 1.4 20 28
H.B 2 2 4
TOTAL 238.1

Total fixture unit = 238.1

Max. Discharger = 75 GPM
1 pipe inlet (Ø) = 2 in
* Take main inlet pipe diameter = 2 in
* Take main inlet pipe diameter = 50 mm
Water supply fixture unit (WSFU) for ( Each
Apartment(plot 8,9))

Cold water pipe

* Using IPC design Table (103.3(2))
Total
Fixture WSFU No.
(HWFUV)
W.C - Private (F. tank) 2.2 46 101.2
Lavatory - Private 0.7 64 44.8
Shower - Private 1.4 32 44.8
Kitchen Sink - Private 1.4 15 21
Washing machine 1.4 15 21
H.B 2 2 4
TOTAL 236.8

Total fixture unit = 236.8

Max. Discharger = 75 GPM
1 pipe inlet (Ø) = 2 in
* Take main inlet pipe diameter = 2 in
* Take main inlet pipe diameter = 50 mm

Water supply fixture unit (WSFU) for

( Community Center and Swimming Pool)

Cold water pipe

* Using IPC design Table (103.3(2))
Total
Fixture WSFU No.
(HWFUV)
W.C - Private (F. tank) 2.2 1 2.2
W.C - Public (F. tank) 5 21 105
Lavatory - Private 0.7 2 1.4
Lavatory - Public 2 35 70
Shower - Public 4 8 32
Kitchen Sink - Public 4 1 4
Mixer for ablution 3 10 30
H.B 2 3 6
TOTAL 250.6

Total fixture unit = 250.6

Max. Discharger = 75 GPM
1 pipe inlet (Ø) = 2 in
* Take main inlet pipe diameter = 2 in
* Take main inlet pipe diameter = 50 mm
Water supply fixture unit (WSFU) for ( point-1)

Cold water pipe

* Using IPC design Table (103.3(2))
Total
Building WSFU No.
(HWFUV)
Villa 34.9 0 0
Apartment(plot 1-6) 226.8 0 0
Apartment(plot 7) 238.1 1 238.1
Apartment(plot 8,9) 236.8 1 236.8
Community Center and
250.6 0 0
Swimming Pool
TOTAL 474.9

Total fixture unit = 474.9

Max. Discharger = 100 GPM
1 pipe inlet (Ø) = 2 1/2 in
* Take main inlet pipe diameter = 2 1/2 in
* Take main inlet pipe diameter = 65 mm

Water supply fixture unit (WSFU) for ( point-2)

Cold water pipe

* Using IPC design Table (103.3(2))
Total
Building WSFU No.
(HWFUV)
Villa 34.9 2 69.8
Apartment(plot 1-6) 226.8 2 453.6
Apartment(plot 7) 238.1 1 238.1
Apartment(plot 8,9) 236.8 1 236.8
Community Center and
250.6 0 0
Swimming Pool
TOTAL 998.3

Total fixture unit = 998.3

Max. Discharger = 180 GPM
1 pipe inlet (Ø) = 3 in
* Take main inlet pipe diameter = 3 in
* Take main inlet pipe diameter = 75 mm
Water supply fixture unit (WSFU) for ( point-3)

Cold water pipe

* Using IPC design Table (103.3(2))
Total
Building WSFU No.
(HWFUV)
Villa 34.9 5 174.5
Apartment(plot 1-6) 226.8 4 907.2
Apartment(plot 7) 238.1 1 238.1
Apartment(plot 8,9) 236.8 1 236.8
Community Center and
250.6 1 250.6
Swimming Pool
TOTAL 1807.2

Total fixture unit = 1807

Max. Discharger = 300 GPM
1 pipe inlet (Ø) = 4 in
* Take main inlet pipe diameter = 4 in
* Take main inlet pipe diameter = 110 mm

Water supply fixture unit (WSFU) for ( point-4)

Cold water pipe

* Using IPC design Table (103.3(2))
Total
Building WSFU No.
(HWFUV)
Villa 34.9 11 383.9
Apartment(plot 1-6) 226.8 6 1360.8
Apartment(plot 7) 238.1 1 238.1
Apartment(plot 8,9) 236.8 1 236.8
Community Center and 250.6 1 250.6
TOTAL 2470.2

Total fixture unit = 2470

Max. Discharger = 380 GPM
1 pipe inlet (Ø) = 4 in
* Take main inlet pipe diameter = 4 in
* Take main inlet pipe diameter = 110 mm
Water supply fixture unit (WSFU) for ( point-5)

Cold water pipe

* Using IPC design Table (103.3(2))
Total
Building WSFU No.
(HWFUV)
Villa 34.9 5 174.5
Apartment(plot 1-6) 226.8 0 0
Apartment(plot 7) 238.1 0 0
Apartment(plot 8,9) 236.8 1 236.8
Community Center and
250.6 0 0
Swimming Pool
TOTAL 411.3

Total fixture unit = 411.3

Max. Discharger = 100 GPM
1 pipe inlet (Ø) = 2 1/2 in
* Take main inlet pipe diameter = 2 1/2 in
* Take main inlet pipe diameter = 65 mm

Water supply fixture unit (WSFU) for ( point-6)

Cold water pipe

* Using IPC design Table (103.3(2))
Total
Building WSFU No.
(HWFUV)
Villa 34.9 13 453.7
Apartment(plot 1-6) 226.8 0 0
Apartment(plot 7) 238.1 0 0
Apartment(plot 8,9) 236.8 1 236.8
Community Center and
250.6 0 0
Swimming Pool
TOTAL 690.5

Total fixture unit = 690.5

Max. Discharger = 159 GPM
1 pipe inlet (Ø) = 3 in
* Take main inlet pipe diameter = 3 in
* Take main inlet pipe diameter = 75 mm
Water supply fixture unit (WSFU) for ( point-7)

Cold water pipe

* Using IPC design Table (103.3(2))
Total
Building WSFU No.
(HWFUV)
Villa 34.9 19 663.1
Apartment(plot 1-6) 226.8 0 0
Apartment(plot 7) 238.1 0 0
Apartment(plot 8,9) 236.8 1 236.8
Community Center and
250.6 0 0
Swimming Pool
TOTAL 899.9

Total fixture unit = 899.9

Max. Discharger = 190 GPM
1 pipe inlet (Ø) = 4 in
* Take main inlet pipe diameter = 4 in
* Take main inlet pipe diameter = 110 mm

Water supply fixture unit (WSFU) for ( point-8)

Cold water pipe

* Using IPC design Table (103.3(2))
Total
Building WSFU No.
(HWFUV)
Villa 34.9 31 1081.9
Apartment(plot 1-6) 226.8 6 1360.8
Apartment(plot 7) 238.1 1 238.1
Apartment(plot 8,9) 236.8 2 473.6
Community Center and 250.6 1 250.6
TOTAL 3405

Total fixture unit = 3405

Max. Discharger = 433 GPM
1 pipe inlet (Ø) = 5 in
* Take main inlet pipe diameter = 5 in
* Take main inlet pipe diameter = 125 mm
 ROAD 15 m.
8
5 6 7
4

ROAD 12 m.
ROAD 36 m.

BACKYARD

ECNART NE NI A M
BACKYARD BACKYARD
BACKYARD BACKYARD
BACKYARD BACKYARD BACKYARD BACKYARD BACKYARD
1 2 3
ROAD 30 m.
