Contributors
The staff at Taylor Devices is very Mark Berquist
proud to have collaborated with Taylor Devices, Inc.
experts in the field of damping to
produce this manual. We thank Richard DePasquale
everyone for their inspiration and Taylor Devices, Inc.
contributions. Sean Frye
Taylor Devices, Inc.
Amir Gilani
Miyamoto International
Alan Klembczyk
Taylor Devices, Inc.
David Lee
Taylor Devices, Inc.
Aaron Malatesta
Taylor Devices, Inc.
John Metzger
Taylor Devices, Inc.
Robert Schneider
Taylor Devices, Inc.
Chris Smith
EQC Global
Douglas Taylor
Taylor Devices, Inc.
Shanshan Wang
University of California, Berkeley
Craig Winters
Taylor Devices, Inc.
3
4
Foreword
Over the last 32 years or so, I have had the unique honor to work
at Taylor Devices, Inc. Over that period, we have seen substantial
evolution within the Company, its products, its customers, and its
culture.
In the early to mid-1990’s, we had the opportunity to adapt some
of our new and old fluid damper designs for use in structures to
provide for better earthquake resistance. Based on the results of
laboratory tests, analytical studies, and field performance during
wind and seismic events, this technology has shown remarkable
improvement in structural control. Indeed, fluid dampers reduce
deflection, stress, and acceleration at the same time without
substantially increasing cost or even at all.
It can be quite astonishing to see the dramatic effect that even
a small amount of damping can have on the performance of a
structure during dynamic events. However, it is also surprising to
see the use of inferior products and technologies being used for
improving performance when well-proven designs already exist.
When considering the use of a potentially life-saving component, I
remind people that what is acceptable for use in the US military and
aerospace sector ought to be appropriate for saving lives. It is important to note that fluid dampers
allow a structure to return to its initial condition after a large event. Demolishing a structure or
replacing energy absorbing elements after an event at a great cost is simply not necessary.
As structural engineers have now progressed out of the infancy phase of designing dampers into
structures for seismic control, I feel that we have a responsibility to share the benefits with as many
concerned influences as possible. As managers, engineers, or academia, we have a responsibility to
move mankind forward with the knowledge we have obtained. However, we should always do so with
the highest standards of honesty and integrity while also holding each other to the highest standards.
For this reason and many others, I am asking all our readers to share this knowledge while recognizing
that we do indeed share a high level of responsibility to make the earth a better place by helping to
save human lives in the event of natural phenomena for which we have little control.
With this in mind, we are proud to announce that Taylor Devices is now offering a unique opportunity
to the structural engineering community at large. For engineers who are willing to incorporate our
potential life-saving products into their structure, we can help optimize the performance of a structure
if an existing building model (in ETABS) is provided for consideration at no charge. Upon completion
of the analytical process, we will return the modified model to the Structural Engineer for verification
and approval. Subsequently, a PE stamp will be required. We hope that many SE’s take advantage
of this opportunity as we know it will advance the use of this technology and make structures safer.
This Damper Manual attempts to accommodate our common goals while recognizing that we all have
important choices to make. Taylor Devices is always available to help make the right choices. We
recognize the merits of our products. We hold our products and ourselves to the highest quality
standards.
This Manual is not intended to represent fluid dampers as simple commodities and therefore encourage
the use of inferior products. Although the technology has proven itself, the process and products shall
always be held to the highest standard. Taylor Devices recognizes that important responsibility.
Alan Klembczyk
President, Taylor Devices, Inc.
5
6
1 Introduction
The end of the Cold War in 1990 heralded a restructuring period for the American military and
defense industry. One of the outcomes of this new era was that political and economic change
allowed previously restricted technologies to become available to the general public. This conversion
of defense technology is typified by highly advanced products and services that suddenly appeared in
the marketplace, seemingly out of nowhere. Perhaps the best known of these is the now ubiquitous
Internet, which in reality came from 1970's defense technology intended for use by government
agencies in the event of nuclear war.
In the civil engineering field, high capacity fluid dampers have transitioned from defense related
structures to commercial applications on buildings and bridges subjected to seismic and/or wind
storm inputs. Because fluid damping technology was proven thoroughly reliable and robust through
decades of Cold War usage, implementation on commercial structures has taken place very quickly.
Indeed, over the last 30 years, utilizing various types of added-damping devices in structures has
emerged as a useful, reliable and predictable tool in significantly improving the resiliency of structures
to a dynamic input. Much research and testing have been performed that verifies the benefits of
incorporating added-damping devices in structures. Linear and non-linear fluid viscous dampers
continue to demonstrate excellent performance in reducing deflection, acceleration response, inter-
story drift and stress. Damping device designs that have been well proven through decades of use
are available in configurations that provide forces that depend on input velocity, deflection, or a
combination of both.
Although various building codes have emerged throughout the world that address methods and
response requirements of structures when utilizing damping devices, these codes do not provide a
general comparison in improved resiliency that is realized through their use.
The concept of damping within a structural system can have different meanings to the various
engineering disciplines. To the civil engineer, damping may mean only a reference note on a seismic
or wind spectral plot, “5% damped spectra” being the most common notation. To the structural
engineer, damping means changes in overall stress within a structure subject to shock and vibration,
with frequent arguments whether a structure will have “2%, 3%, 4%, but not more than 5%”
structural damping. On the other hand, mechanical engineers do not necessarily view damping as
a benevolent feature, since machines, by definition, are supposed to transmit forces and motions
efficiently, without energy losses. Thus, the need for damping in a machine often signifies that an
engineering design error has been made.
In the classical mechanical engineering text “Vibration Theory and Applications,” William Thomson
[1] avoids a single, direct definition of damping by offering the following descriptions: “Vibrating
systems are all more or less subject to damping because energy is dissipated by friction and other
7
resistances. Since no energy is supplied in free vibration, the motion in free vibration will diminish
with time, and is said to be damped.
It follows from these descriptions that a damper is an element which can be added to a system to
provide forces which are resistive to motion, thus providing a means of energy dissipation. Assuming
that this working definition will suffice for general use, the next area of interest is to generally
describe the functional output of a damper. As with the definition of damping, the functional output
of a damper is somewhat controversial, since different output equations exist within the context of
the various engineering disciplines.
Alternatively, damping can be defined as that attribute of a dynamic system that results in a decrease
in the amplitude of oscillation. This results in the removal of some amount of energy in that system.
In keeping with the law of conservation of energy, this energy is actually transformed into another
form. Consequently, the term “damper” can be defined as that mechanism or internal property that
provides this transfer of energy. Typically, damping converts mechanical energy into heat. This
heat is then dissipated to the surroundings through any of the 3 modes of heat transfer defined as
conduction, convection and radiation.
Fluid viscous dampers operate by providing a resisting force only when moving. They do not add
stiffness to a structure, and they do not carry any static load.
Like automobiles driven on a bumpy road, buildings in seismic regions are a dynamic problem. Who
would ever buy or manufacture a car without shock absorbers? The dynamic laws of physics are the
same for each.
It is with great pleasure that Taylor Devices offers this damper manual as a guide for engineers with
various levels of experience in order to take advantage of this technology that has been successfully
transitioned from previous applications to now improve the dynamic performance of structures and
to help save lives throughout the world.
REFERENCES
1. Thomson, William, 1965, Vibration Theory and Applications, Prentice-Hall, Englewood Cliffs,
New Jersey.
8
2 Fluid Damping Devices
A Century of History
It is axiomatic that during times of war, new technology develops extremely quickly, since the fates
of nations may well depend upon which antagonist can mass-produce improved weapons more
quickly. In the case of fluid dampers, the evolution of large bore artillery and naval guns in the late
1800's provided the need for the product, and the various major governments were only too eager
to provide the development funding.
Several unsuccessful concepts of arresting gun recoil were attempted, involving both coil springs and
rubber blocks. Meanwhile, the inventors of that time were investigating the new field of hydraulic
components, and by the late 1860's, experiments were taking place using hydraulic dampers to
arrest gun recoil. It is reported by Hogg [1] that the British Army was the first to use hydraulic recoil
dampers on gun carriages in 1862. The first mass-produced hydraulic recoil damper was used on the
75 mm French field gun, Model M1897. This weapon was hailed as a true technological marvel and
is considered to be the first modern artillery piece. The carriage of the weapon included a slide to
support the gun itself, and a 48-inch stroke fluid damper combined with a light spring to attenuate
recoil energy and return the gun to battery. The French M1897 went on to serve in both World
War I and World War II. Many variations of the weapon exist since many countries “borrowed”
the design after capturing one or more examples during World War I. One of the more unusual
uses for the low recoil French M1897 was by the U.S. Army Air Corps during World War II. The
Air Corps needed a ground attack aircraft with as much firepower as possible. The solution to the
problem involved mounting a complete M1897 with recoil dampers into the nose of the U.S. Model
B-25 “Mitchell” Bomber, firing forward. The modified aircraft proved successful, and the use of the
hydraulic dampers eliminated damage to the aircraft.
By the end of World War I, tens of thousands of fluid dampers were being used on field artillery
pieces, naval guns, coastal guns and railway guns. Some dampers of this period were even of the
9
semi-active type, where changing the gun elevation angle would change the resultant damping
force. This was accomplished by using a gear train between gun carriage and the damper. The gear
train would rotate an adjustment rod or screw protruding from the damper cylinder. As the gun was
elevated, the damper would become “stiffer”, and use less displacement. This feature allowed the
gun carriage to be reduced in size and weight, since at high elevation angles, the carriage no longer
needed to maintain clearance to the ground for the entire recoil stroke.
Toward the end of World War I, another advantage of fluid dampers was discovered. This was that
reduced recoil allowed weapons to easily fire larger projectiles, with larger propellant charges to
obtain greater range. Indeed, from March to July of 1918, the City of Paris was attacked by the
German Army with a weapon of “super gun” proportions. Details did not become available until
the war ended, and then only after intense efforts by the allies. The weapon was named the Paris
Gun, and included a 130-foot long barrel, which fired a 210 mm diameter shell at a range up to
85 miles. The gun itself, with fluid dampers, weighed over 140 tons, not including the weight of
the tremendous carriage that carried the weapon. Three of the Paris Guns were built, but all were
withdrawn from service as the allied armies approached their locations. Mysteriously, none were
recovered by the allied forces after the war ended.
The earliest auto suspensions were simply carried over from horse-drawn wagons. The suspension
consisted of multiple leaf elliptical or semi-elliptical springs. Damping was limited to the inter-
leaf friction which occurred as the spring leaves ground over one another as the spring deflected.
Damping would obviously have a high variance from day-to-day, depending on whether the spring
was dry, wet, rusty, dirty, or recently cleaned and oiled.
This day-to-day damping change proved unacceptable to the consumer, and external friction pad or
rubber dampers were added to the suspension. These provided a small but noticeable improvement
over using the spring itself as a damper, plus it was possible to make the damper adjustable for wear.
The “ideal” damping material was usually pure asbestos washers or pads, compressed between two
iron plates. One plate was fixed to the car frame by a bolt, the other was attached to an actuating
arm. A large draw bolt went through the center of the damper assembly, and tightening or loosening
of the bolt served to adjust the damping force.
The high maintenance and marginal improvement obtained with friction and rubber dampers caused
automotive parts suppliers to look for improved damping systems, and fluid dampers quickly entered
the scene. The biggest problem with adapting the fluid damper for automotive use proved to be
poor quality seals. The guns of World War I usually needed a major overhaul every 500 rounds or
so, due to barrel wear, and this was an opportune time to change damper seals, which usually were
leaking badly after 500 cycles. Considering that the seals of the day consisted of cut lengths of
hemp rope forced into a pocket with a hammer, this was no surprise! “Improved” seals of the 1920's
consisted of a stack of round leather washers forced into position with a packing nut. These were an
improvement over hemp strands, but still could not provide the cyclic life necessary for automotive
use.
10
In 1925, Ralph Peo of the Houdaille Company in Buffalo, New York, invented a solution to the
seal problem. Instead of improving the seal, he redesigned the damper to use a rotating piston
rod and vane assembly, thus replacing long travel, sliding seal motion with a short 60-120 degree
rotary travel. The Houdaille rotary damper was actuated by crank arms attached to the moving
components of the suspension. The short rotary travel of the seal allowed for roughly 10,000 miles
of road travel before seal replacement became necessary. Within a short period, most automobiles
were using the Houdaille rotary damper. Figure 2.1 is one of the original patent sheets depicting
Peo’s 1925 invention.
In 1949, the Delco Division of General Motors finally designed a sliding seal damper that had an
adequate life for automotive use, thus ending the rotary damper era. Present-day automotive shock
absorbers have an internal construction that is very similar to the gun recoil buffers of World War I,
except that modern seals provide substantially greater life.
Figure 2.1
Patent Sheet – R. Peo’s Rotary Shock Absorber
During the 1960's, it became impossible to provide large enough mechanical springs to provide the
11
optimal isolation, so fluid dampers were converted to liquid-spring dampers, an extremely powerful
yet compact isolation component. In a liquid spring-damper, the operating fluid is compressed
and orificed simultaneously. By selecting special fluids with high compressibility, it was possible to
produce both high spring and damping forces in an extremely small package. Without becoming
too specific (for security considerations), some of the liquid spring-dampers of the late 1980's could
simultaneously provide spring forces of 50 tons and damping forces of 150 tons from a package of
only seven inches in diameter! Operating fluid pressures of up to 50,000 psi were relatively common.
In comparison, a high-powered hunting rifle has peak firing pressures in the 40,000 psi range. Some
of these products for large land based missiles had more than four feet of displacement, with output
forces up to 500 tons.
The successful use of high capacity fluid dampers and liquid spring-dampers on land based missile
facilities led to additional applications on shipboard and submarine missiles and related equipment
items. By the end of the Cold War, a typical U.S. Naval warship would have more than 1,000 fluid
damping devices installed on its missiles and primary electronics systems. These devices range from
1 ton to 50 tons of output force.
During the 1990's, the end of the Cold War combined with the political and economic climate caused
a dramatic downsizing of U.S. defense capabilities. At the same time, security restrictions on the
sale and commercial use of Cold War era technology had been greatly relaxed.
Taylor Devices’ defense expertise involved the design and manufacture of large, fluid damping
devices for protection of missiles, electronics systems, and large structures against the effects of
weapons explosion. The company’s staff elected to pursue commercial applications related to
seismic and high wind protection of structures. The damper style selected dated from the 1970's,
and was developed on a sole-source basis by the firm for use on the U.S. Air Force’s MX Ballistic
Missile, and the U.S. Navy’s Tomahawk Cruise Missile. On the latter program, the company has
produced more than 29,000 fluid damping devices for use on the shipboard launched Tomahawk.
Early on, it was decided to pursue joint research on fluid damped building and bridge structures
with the National Center for Earthquake Engineering Research (NCEER). NCEER was conveniently
located on the campus of the State University of New York at Buffalo, just a short distance from Taylor
Devices’ facilities. The research involved taking existing military production fluid damping devices,
and simply installing them onto scaled models of civil engineering structures, as supplemental
components. The structures were then subjected to seismic transient testing on the University’s
large seismic shake table. All tests proved excellent, with dramatic reductions of stress and deflection
occurring with added fluid damping in the 15-40% of critical range.
In general, it was found that adding 20% critical damping to a structure will triple its earthquake
resistance, without increasing stress or deflection. Numerous reports were published by NCEER and
the University, documenting the improvements obtainable with fluid dampers. The U.S. Department
of Defense proved very cooperative in allowing Taylor Devices to disclose the origins and applicable
12
design concepts for the damping devices used in the research.
For example, steel building structures were tested with fluid dampers being currently produced for
the B-2 Stealth Bomber. Concrete building structures were tested using Tomahawk missile dampers.
Bridge structures were tested with dampers from the CIA’s famed Glomar Explorer Research Vessel.
Other bridge structures were fitted with spring-damper units from submarine based torpedoes.
It became evident that there were no barriers towards commercial implementation of Taylor’s
damping products, and by 1993, an order was received for 186 dampers to be used on all five
buildings of the new Arrowhead Regional Medical Center in Colton, California. Specifications for
these dampers are provided in Figure 2.9, and a photo of a completed damper follows in Figure 2.10.
More than 600 additional building and bridge projects followed the Arrowhead Medical Center order
over the subsequent 20 years. The transition of fluid dampers from military to civilian has proven to
be the quintessential example of literally “turning swords into plowshares.”
Damper Specifications
San Bernardino County Medical Center
Displacement = 48 in.
Diameter = 14 in.
Table 2.1
San Bernardino County Medical Center Damper Specification
13
Figure 2.2
Photograph of Completed Damper
REFERENCES
1. Hogg, I.V., 1971, The Guns 1914-1918, Ballantine Books Inc., New York, New York.
14
3 Design Description of Dampers
Figure 3.1
Typical Fluid Damper & Parts
The Damper shown in Figure 3.1 is shown in its mid-stroke position. The main pressure chamber is
referred to as the Cylinder (not labeled). It is completely full of Fluid including the volumes on both
sides of the Piston Head. The Piston Rod is attached to the Piston Head. On the left end of the
Piston Rod is a Clevis for attachment to the structure. As the damper reciprocates during a dynamic
event, this Clevis, the Piston Rod and the Piston Head move as one component. All the other parts
remain stationary.
As the Piston Head moves, the Fluid on either side of it is forced through orifices in the Piston Head.
On the left side of the Cylinder is a Cap and Seal to encapsulate the Fluid against static and dynamic
pressure. On the right side of the Cylinder is another Cap and Seal. As one end of the Piston Rod
moves into the Cylinder, the other moves out, thus maintaining conservation of volume of the Fluid
without a build-up of static pressure. Both Clevises are typically outfitted with spherical bearings to
allow some level of mis-alignment with the surrounding structure.
Force Rating
Taylor Devices Dampers are available in force ratings up to 1800 KIP (8000 kN). The design of the
structural components of these dampers provides a safety margin to yield of approximately 2:1. All
components of the dampers, including the pressure vessel, have been analyzed for strength using
15
modern-day finite element analysis. Actual damper stress reports are available upon request based
on actual project parameters.
Typical seismic dampers require a velocity exponent of less than 1.0 (see equation 4.1.) This means
that although the safety margin is 2:1 based on force, the actual safety margin based on velocity is
much higher.
Power Rating
Where applicable, damper designs are evaluated for power transmitting capabilities. Oftentimes
this becomes a design driver for wind damper applications whereby substantial power is absorbed
by the damper for extended periods of time as would be experienced during wind storms. The
short-term power capabilities of dampers (during earthquakes) is typically many times higher.
Taylor Devices uses a proprietary power analysis software tool that accurately predicts internal and
external surface temperature versus time with given power input scenarios. For each application,
the power is evaluated to be sure that the damper would be fully capable of absorbing short-term
and long-term (continuous) input without experiencing any degradation in function due to increased
temperatures.
Fire Rating
Taylor Devices dampers have been evaluated for time-based fire rating to be sure that they would be
operable during temporary exposure to fire. These dampers are robust hydraulic devices containing
thick-walled alloy steel cylinders. The components that provide the necessary damping function are
not sensitive to short-term exposure to high heat. Only features such as elastomeric bellows and
paint may be susceptible to damage from short-term exposure.
Fire ratings have been established by using Heisler chart information for temperature-time history of
cylinders exposed to fire at approximately 1900°F (1020°C). A conservative approach was used that
neglected the insulative effects of the working fluid of the damper and therefore assumed that the
damper was a solid steel bar. The failure mode of a damper during exposure to fire would be melting
of the seals, thereby releasing the non-toxic, non-flammable fluid to the surrounding area. No risk
of explosion exists since the melting of the seals would release any high-pressure build-up prior to
there being any high stress in the pressure vessel.
The results of the fire rating analysis of Taylor Devices dampers provides a typical fire rating well in
excess of ½ hour for all models, and even greater than 1 hour for medium to large standard dampers.
This means that even being exposed to direct flame at 1900°F, Taylor Devices dampers will operate
properly for at least ½ hour. It is anticipated that if any area of a structure was exposed to fire for this
period of time that the structure would sustain catastrophic damage. Therefore, damage to dampers
due to exposure to fire should not be regarded as a primary concern.
16
4 Damper Output Characteristics
and Unique Benefits
Fluid dampers operate by providing a resisting force only when moving. They do not add stiffness to
a structure, and they do not carry any static load. However, stiffness can be added to a damper upon
request. A fluid damper consists of a piston moving back and forth through a viscous fluid thereby
generating high pressure. This piston has custom designed orifices that produce an optimized
relationship that produces this pressure (force) that varies with velocity. The greater the velocity,
the greater the resisting force that is produced. This relationship is typically characterized by the
following equation:
where α is referred to as the damping exponent. This exponent can typically be set to anywhere
between 0.2 and 2.0 depending on the specific application. Values of α in the range of 0.3 to 0.5 are
most common for seismic applications in buildings. Bridge applications in U.S. Seismic Zones 3 and 4
use similar damping exponent values. Wind damping applications tend to use exponents in the range
of 0.5 to 1.0, with the lower values being used in structures driven by both wind and seismic inputs.
Fluid dampers for use in tuned mass dampers use exponents as high as 2.0.
Because the fluid damper only produces a resisting force while stroking and does not provide
a restoring (spring) force, energy is absorbed by the damper's fluid and converted to heat. This
absorbed energy is simply the summation of the damping force multiplied by the deflection. Because
dampers can be designed to generate greater than 10,000 psi (69 MPa) of damping pressure, the
force, and therefore the absorbed energy, can be relatively high for a short period of time. This heat
is then safely dissipated to the air around the damper.
It is this absorbed energy that significantly reduces the necessity of the structural elements to absorb
that energy through yielding. Although this seems like a simple concept, the benefits are often not
fully realized. This is because of the fact that it is not only important how fluid dampers absorb
energy, but also when they absorb energy.
Imagine a structure moving due to a transient input. A significant response of that structure will
be along its dominant natural frequency as a sine wave. As the structure moves through its initial
position, the deflection stress at this moment in time is zero. It is also at this moment in time that
the structure is moving with greatest velocity and therefore the damper is reacting with its greatest
force. Conversely, as the structure reaches its peak deflection and stress farthest away from its
initial position, the velocity reduces to zero and therefore the damper is reacting with zero force at
that moment in time. Because of this, utilizing fluid dampers actually reduces the amount of stiffness
(steel or concrete) that a structure must have to increase its ability to withstand earthquakes. It also
reduces the force that the foundation must be designed for. This is an efficient means to improve
structural performance in terms of both cost and weight.
17
The benefit of fluid dampers to be out of phase with the structural deflection stress is not the case
with elements that increase stiffness or elements that are not velocity sensitive such as friction
dampers or buckling restrained braces (BRB's).
Returning to Equation 4.1 above, if a comparison is made with sinusoidal input to a fluid damper of
the energy absorbed for each cycle to the damping exponent, it is demonstrated that a fluid damper
with a lower damping exponent absorbs more energy per cycle than one with a higher exponent.
This is illustrated in Figure 4.1 below.
Referring to the red curve in Figure 4.1 where the damping exponent is 0.4, it is demonstrated that
the energy under the force versus displacement curve (hysteresis) is higher than the blue curve
where the damping exponent is 1.0 (i.e. linear damping). However, if a damping exponent of less
than 0.4 is plotted, a point of diminishing returns on this effect is realized. Note the very small
difference between the 0.4 line in red and the 0.3 line in black. Additionally, as stated above, since
the damping force is out of phase with the deflection stresses, it is important that this effect is not
compromised by an exponent that is too low. Therefore, a damping exponent of approximately 0.3
oftentimes provides an optimal combination of maintaining a high amount of energy absorbed per
cycle and at the same time minimizing the stress of adjacent structural members.
Figure 4.1
Comparison of Energy Absorbed with Varying Damping Exponents with Sinusoidal Input
18
Damper output characteristics for a given application will be determined by analysis as outlined
in Chapter 7 of this manual. As stated above, damping exponent values are available between 0.2
and 2.0. However, available damping coefficients are virtually unlimited. That is, fluid dampers can
be manufactured with very high and very low damping coefficients. Usually, if a desired damping
coefficient is extremely high, the stiffness of the surrounding structure becomes a limiting factor
since the relative motion at the damper ends becomes very small if the surrounding stiffness is too
low to transmit the motion into the damper. If a desired damping coefficient is extremely small, the
amount of energy absorbed by the damper is also small, and therefore the benefit provided by the
damper is limited.
It should also be noted that although virtually any combination of damping coefficients and damping
exponent values are available, it is recommended that only one or two combinations are utilized for
an individual project since there are non-recurring engineering and testing costs associated with
the development of each damper type. It is best to amortize those costs over as many dampers as
possible and in many cases damper properties can be grouped effectively to minimize manufacturing
costs and optimize performance.
Chapter 12 of this manual provides series of charts with available damper sizes and their dimensional
information. Dampers are available with any value of C and α as discussed above. However, a small
selection of damper equations is listed in Table 4.1 below to choose from within the force limitations
of each damper series.
Rated Force (KIP) Suggested C Values in KIP - Sec / Inch where F = C x (V)^0.30
55 33.9 27.6 24.4 22.4
110 67.9 55.1 48.8 44.8
165 102.0 83.0 73.0 67.0
220 136.0 110.0 98.0 90.0
330 300.0 165.0 146.0 134.0
440 270.0 220.0 195.0 180.0
715 440.0 360.0 317.0 290.0
900 555.0 450.0 400.0 365.0
1450 895.0 727.0 644.0 590.0
1800 1110.0 900.0 800.0 733.0
Table 4.1
Suggested C Values for Taylor Devices’ Standard Dampers
Note that this table provides damping equations with a damping exponent of 0.3, for reasons stated
above. These equations result in a damper force equaling the rated force at velocities of 5, 10, 15,
and 20 in/sec velocity.
19
20
5 Generalized Effects of Adding
Fluid Dampers to a Structure
Damping is one of many different methods that have been proposed for allowing a structure to
achieve optimal performance when it is subjected to seismic, wind storm or other types of transient
shock and vibration disturbances. Conventional approach would dictate that the structure must
passively attenuate or dissipate the effects of transient inputs through a combination of strength,
flexibility, deformability and energy absorption. The level of damping in a conventional structure is
very low, and hence the amount of energy dissipated during transient disturbances is also very low.
During strong motions, such as earthquakes, conventional structures usually deform well beyond
their elastic limits, and remain intact only due to their ability to inelastically deform. Therefore, most
of the energy dissipated is absorbed by the structure itself through localized damage.
The concept of added-on dampers within a structure assumes that some of the energy input to the
structure from a transient will be absorbed, not by the structure itself, but rather by supplemental
damping elements. An idealized supplemental damper would be of a form such that the force being
produced by the damper is of such a magnitude and occurs at such a time that the damper forces do
not increase overall stress in the structure. Properly implemented, an ideal damper should be able
to simultaneously reduce both stress and deflection in the structure.
Figure 5.1 depicts earthquake spectra capacity and demand curves for a sample building with 20%,
30% and 40% damped demand curves. This figure is reproduced from FEMA 274 [2] and assumes
linear or viscous damping elements are used.
21
Figure 5.1
Spectral capacity and demand curves for
rehabilitated one-story building
Figure 5.2
One-story structure, no dampers,
El Centro 33.3%
Figure 5.3
One-story structure, two
dampers, El Centro 100%
22
The test results from Figures 5.2 and 5.3 used the 1940 El Centro earthquake transient as a test
input. When these results were first obtained, they included tests showing similar performance gains
with other notable earthquakes for which transient records were available. Nevertheless, questions
have arisen in the ensuing years as to whether fluid dampers would be functional with other inputs,
including actual earthquakes such as the 1994 Northridge, California and 1995 Kobe, Japan events,
plus hypothetical inputs such as Aa big, purely impulsive quake or a slow rolling sine wave quake. In
addition, potential customers with wind storm inputs wanted to know if seismic dampers worked in
wind, and Government customers wanted to know if damage from terrorist attacks against buildings
would be reduced by dampers. The actual question being raised was simply: Fluid dampers appear
to be a useful engineering component. Are they truly useful for all types of shock and vibration
inputs? The answer is a definite yes, and it is relatively easy to demonstrate this by considering
generalized qualities of a transient pulse.
The first and most important parameter of a transient is the peak translational velocity. The peak
velocity is of primary importance because this determines the peak amount of energy that must be
managed by the structural system. This velocity can be achieved by either a small acceleration over a
long time period, or by a large acceleration over a short period. Thus, the maximum acceleration rate
of the pulse is the second most important parameter of a transient, since the structure and the fluid
dampers must be designed to accommodate the acceleration without being damaged by impulsive
loadings. Figure 5.4 provides tabular data for maximum velocities and accelerations for catastrophic
inputs. The least important parameters of the transient are those related to the actual shape of the
various portions of the pulse. This is simply because no two discrete transients can be expected
to be identical, these events being chaotic by their very nature. If one considers how a damped
structure behaves under transients having a given maximum translational velocity and maximum
acceleration then, in reality, only two simple extreme cases need to be considered.
Case One: The structure is excited by a step function, with acceleration equal to the maximum
acceleration expected, for a time duration such that maximum translational velocity is obtained.
Case Two: The structure is excited by a forced sine wave at the frequency of the structure’s first
resonant mode, with input amplitude increased until the maximum specified acceleration or velocity
is achieved.
An example of structural response to the first case, the impulsive input, is provided in Figure 5.5,
for both the undamped and fluid damped condition. The response in this case assumed infinite
acceleration, with velocity stepping from zero to maximum value instantaneously, and an elastic
structure. It is readily apparent that the fluid damped structure experiences substantially less force
and deflection than the undamped structure, even though each structure is storing or absorbing
equal amounts of impulse energy.
An example of the second case is provided in Figure 5.6, and depicts the magnification factor on
input amplitude for a system subjected to forced harmonic excitations with linear fluid damping. The
condition of resonance is obtained at a frequency ratio of 1.0, and shows the tremendous benefits
of fluid damping. The equation for magnification at resonance is:
1
magnification factor = 2g
23
Tabular Data for Maximum Velocities and Accelerations
Peak Acceleration Peak Velocity
Figure 5.4
Catastrophic Transients
Figure 5.5
Response to impulsive inputs
Of particular note is that for a typical building with 2% damping, the magnification factor at resonance
is 25 to 1. This number reduces to a much more manageable value of only 2 to 1 at 25% damping.
It is of value to the engineer to note that virtually no structure is built with the safety factor of 25 to
1 necessary to accommodate the 2% damped resonant response. In comparison, most structures
have sufficient safety factors to accept the 2 to 1 magnification for the 25% damped structure
subjected to forced resonance.
From these examples, it is relatively easy to understand that fluid damping will always improve the
response of a structure, under any expected transient.
Three Generic Types of Dampers and How Each of Them Affects a Structure:
Fluid dampers have the unique ability to simultaneously reduce both stress and deflection within a
structure subjected to a transient. This is because a fluid damper varies its force only with velocity,
which provides a response that is inherently out-of-phase with stresses due to flexing of the
structure. Other dampers can normally be classified as either hysteretic, where a fixed damping force
is generated under any deflection, or as visco-elastic, where a damper behaves as a complex spring
and damper combination. In the latter case, force may be a displacement and velocity dependent
parameter. Figure 5.7 provides representative outputs from sine wave excitation of these three
damper types. Inclusive in these non-fluid damper types are yielding elements, friction devices,
plastic hinges, friction slides, bonded rubber, molded rubber, and shaped rubber. None of these
other devices have an out-of-phase response to structural flexural stresses. This is simply because
24
Figure 5.6
Magnification factor for
forced harmonic excitation
the outputs of these devices are dependent upon parameters other than, or in addition to, velocity.
Hence, all of these other types of dampers will decrease deflection in a structure at the same time
they are increasing column stress. The out-of-phase response that is unique to fluid dampers can be
easily understood by considering a building shaking laterally back and forth during a seismic event
or a windstorm.
Column stress is at a peak when the building has flexed a maximum amount from its normal position.
This is also the point at which the flexed columns reverse direction to move back in the opposite
direction. If we add a fluid damper to the building, damping force will reduce to zero at this point
of maximum deflection. This is because the damper stroking velocity goes to zero as the columns
reverse direction. As the building flexes back in the opposite direction, maximum damper force
occurs at maximum velocity, which occurs when the column flexes through its normal, upright
position. This is also the point where column stresses are at a minimum. It is this out-of-phase
response that is the most desirable design aspect of fluid viscous damping.
25
Figure 5.7 Output of the Three Generic Damper Types
26
6 Damper Mounting Arrangements
Many methods exist to implement distributed damping in a structure, the typical underlying concept
is to connect the moving masses (floor levels) with dampers so that as they move or deflect relative
to one-another in a shearing-type motion, the dampers capture this motion and resist in both tension
and compression directions with an opposing force. This concept works well in typical moment
frame, shear wall, or braced frame office or residential type buildings, and can be applied to short,
medium and tall structures. It is noted that all of these systems are passive, meaning that no external
power is needed to make the dampers function. The dampers simply react at any time they are
deflected. Some of the implementation methods include the following:
Chevron frames are depicted in Figure 6.1. In this configuration, the dampers are placed horizontally,
and connected to a frame (chevron) that is intended to be near-rigid with the floor it is connected to.
The advantage with this direct damping orientation is that the horizontal flexibility of the structure
injects this full movement directly into the horizontal orientation of the damper. However, a small
amount of motion can be lost due to the constraints of the attainable stiffness of an economical
chevron frame.
27
Figure 6.1
Dampers in Chevron Braced Frames
Figure 6.2
Dampers in Diagonal Braced Frames
Dampers in Diagonal bracing schemes are depicted in Figure 6.2. In this orientation, the horizontal
movement of the structure only allows an angular component of the full deflection to go into the
damper, but thence takes this motion directly to the next floor level, straight through a strong
tension/compression member. Often this diagonal bracing scheme is considered the most basic, or
simplistic method to apply distributed damping in a structure.
Toggle frames as shown in Figure 6.3 can be used as a mechanism to amplify deflections into the
damper in otherwise stiff, or tiny deflection situations, creating a more efficient damping system.
Toggle Frames utilize a bent-brace mechanism theory to capture deflections in one plane and
translate the deflections into another plane and therefore provide very efficient damping, but these
toggle frames do require an intricately designed and manufactured custom mechanism/system,
in order to perform properly. These toggle frames are not only a patented system (Refer to US
Patents # 5870863 and 5934028), but they also need to be very carefully detailed by an authorized
designer/manufacturer.
28
Figure 6.3
Dampers in Toggle Braced frames
So-called Mega Braces shown in Figure 6.4 can be used to capture deflections over multiple floor
levels and collect the larger motion from these levels and pass that motion through the energy
absorbing damper connected to major structural nodes. This concept is similar to diagonal bracing,
but over a much longer span.
Figure 6.4
Dampers in Mega-Brace Frames
29
Additionally, an outrigger solution to apply damping to taller, more slender building systems can be
used where it is determined that the gross motion of the structure does not fall into the traditional
shearing-type movement pattern, but exhibits more of an overall tension/compression on the
opposing outer columns of the building. Often outrigger damping can be accomplished by creating a
rigid level near the top of a building that moves with the core and connecting dampers between the
rigid level and the outer columns of the building. This useful system is shown in Figures 6.5 and 6.6.
Figure 6.5
Dampers in Outrigger Systems (a)
Figure 6.6
Dampers in Outrigger Systems (b)
30
Dampers can also be distributed in base isolation systems, as depicted in Figure 6.7, where the
damper is used to augment the vertically supporting isolators, and most often provide viscous
(velocity dependent) damping to significantly improve the performance and usefulness of the
isolators.
Figure 6.7
Dampers in Base-Isolation Systems
The Open Space Damper System shown in Figure 6.8 is somewhat similar to the toggle system in
that the system uses motion amplifiers and mechanisms, but in this system, the idea is to push the
damping elements to the perimeter of the frame such that the space inside the frame is opened-up
for windows or doorways, hence the name “open space” damping system. In this system, there is
a (near) vertical pusher bar connecting a cam-rotating mechanism that in-turn is connected to the
beam and to a damper, such that as the top of the frame moves laterally, the damper deflects and
dissipates energy. Open Space Dampers provide very efficient damping, but do require a carefully
oriented and analyzed system, to function properly. These Open Space Damper Frames are a
patented system under US Patent # 9,580,924, and they need to be very carefully detailed by an
authorized designer/manufacturer.
Figure 6.8
Dampers in Open Space Frames
31
The Negative Stiffness concept is a unique new passive damping concept in structural engineering
that takes a still building or frame, and creates a “softening” effect for that frame. The system uses
a series of gapping elements with a preloaded spring and dampers to develop the reactions needed.
The technique here is to allow the structure to have its initial stiffness for wind or other constant
lateral inputs, but for dynamic inputs, the negative, or call it “anti-stiffness“ system actually gives
the structure a little push, using a passive spring system, then restricts that motion with damping.
The result allows damping to more-effectively be used in a stiff frame system, without cutting, or
softening the frame, to let damping do its job. The Negative Stiffness system is shown in Figure 6.9
below.
Figure 6.9
Dampers in Negative Stiffness Frames
Numerous other techniques can be applied to implement distributed damping by using similar
principles and/or different orientations, or structural systems and mechanisms to capture structural
movement and inject that movement into the distributed dampers. Additional techniques and
concepts are currently undergoing research and development, and therefore are not elaborated
upon in this document.
32
7
Design and Analysis of
Building Structures with
Fluid Viscous Dampers
SCOPE
Fluid Viscous Dampers (FVDs) serve to protect new and existing structures during hazardous seismic
events and provide an economical solution for resilient design. Adoption of FVDs for applications
in building and bridge structures has become prevalent in countries like Japan and Taiwan, however
FVDs are under-utilized in many other high seismic regions across the world. One of the factors
contributing to this under-utilization is the lack of familiarity of many structural engineers with
damping devices and the relative ease in which they can be designed and implemented in commercial
structural engineering software.
This document aims to educate structural engineers on the use of FVDs and assist in promulgating
the application of FVDs for seismic protection of buildings and bridges. The discussions in this guide
are intended to be informative and are envisioned to demonstrate general Modeling and design
processes of building structures with FVDs. The reader is referred to industry documented literature,
such as the SEAOC: IBC 2012 Structural/Seismic Design Manual - Volume 5 and FEMA P- 1051: 2015
NEHRP Recommended Seismic Provisions - Design Examples for a more detailed description on the
design application of supplemental damping for building structures.
Disclaimer: This chapter is only intended to serve as an example and is not meant to be applied directly to the design of any
structure. The responsibility of such design with the Design Engineer.
33
PART I: CREATING THE ANALYTICAL MODEL WITH FVDs FOR NLRHA
Overview
Implementation of FVDs in the commercial program ETABS (CSI 2017) is demonstrated by providing
a step-by-step procedure for generating the analytical building model. The selected building model
is a generic example and is not representative of any particular structure.
• The guide demonstrates implementation of FVDs using ETABS; the same approach is applicable
to other CSI Inc. software such as SAP2000 and other commercial software programs.
• The guide demonstrates modelling and design with building structures; however, a similar
approach can be used for bridges, and other types of structures.
• The guide focuses on modelling of FVDs for Nonlinear Response History Analysis (NLRHA),
although dampers can be modelled within ETABS for Response Spectrum Analysis (RSA) as well.
Property Value
Bays in the X direction 7 @ 24 ft
Bays in the Y direction 3 @ 24 ft
Stories 3
Story height 12 ft
Column 24 x24 in square
Beam 14x24 in rectangular
Slab 8 in NWC
Concrete compressive strength 4 ksi
Grade of steel reinforcement 60 ksi
Sds=1.50 g
Sd1=0.6 g
Site seismicity
Site class=D
Risk category=II
Table 7.1.1
Key Properties of the Example Building
34
Creating a New Building Model
It is assumed the user is familiar with the basics of generating an ETABS model of a building. However,
brief discussion on the topic is presented here.
• Under the tab file, open new and initialize model (Figure 7.1.1). In this figure, the user selects
the units, steel and concrete design code and databases used to select the structural members
from the pull-down tabs.
• Select grid only option and specify the number of bays in X and Y direction, bay width in each
direction, number of stories and story height (Figure 7.1.2); press OK and in plan view, the
program will display the grids (Figure 7.1.3).
Figure 7.1.1
Model Initialization
Figure 7.1.2
Selection of Templates Using Grid Only
35
Figure 7.1.3
Grid Pattern in Plan-View
Figure 7. 1.4
Defining Materials Properties
36
Defining Frame (Beam-Column) and Shell (Slab) Objects
• Use Define>Section Properties>Frame to open the dialog box (Figure 7.1.5)
• Click on Frame sections box, and then add new property /section type concrete rectangular,
then enter values as required for section properties (Figure 7.1.6). Under Property Modifiers
click on Modify/Show Modifiers, to modify section properties if required. In the same menu,
click on Modify/Show Rebar to assign reinforcement data (Figure 7.1.7)
• Use Define >Section Properties>Slab Sections, to define slab objects for the floor (Figure 7.1.8)
Figure 7.1.5
Define Selection Menu
Figure 7.1.6
Defining and Modifying Column Sectional Properties
37
Figure 7.1.7
Defining and Modifying Column Sectional Properties
Figure 7.1.8
Defining and Modifying Slab Section Properties
38
Draw Frame and Slab Objects
• Use the Draw > Draw Beam/Column/Brace Objects command or click one of the five buttons
shown in this topic to draw frame objects. When the menu command is used, a menu of five
subcommands displays (Figure 7.1.9). Once a property is selected, the user can then graphically
draw the frame element by clicking on the correct geometrical locations.
• Use the Draw > Draw Floor/Wall Objects command or click one of the five buttons shown in
this topic to draw floor objects. When the menu command is used, a menu of five subcommands
displays (Figure 7.1.10). Once a property is selected, the user can then graphically draw the
floor/wall element by clicking on the correct geometrical locations.
Figure 7.1.9
Drawing of Frame Objects
Figure 7.1.10
Drawing of Floor Objects
39
Display Model
Once all beams, columns, and floors are drawn, assign property fixity to the base of the columns and
the model can be displayed in 3-D (Figure 7.1.11) in plan (Figure 7.1.12), or elevation (Figure 7.1.13
and Figure 7.1.14). Once the floor plan or elevation videos have been defined for one of the stories
or gridlines, the floor plans can be replicated (Z direction) to other stories and the elevations can be
replicated (X and Y directions) along the building gridlines.
At this step, a three-dimensional model of the building has been completed. The model will next be
updated by addition of FVDs.
Figure 7.1.11
3D Model After Replicating Plans
40
Figure 7.1.12
Plans for Beam and Column Object
Figure 7.1.13
Transverse (Y) Elevation
Figure 7.1.14
Longitudinal (X) Elevation
41
Design and Modeling of Fluid Viscous Dampers
FVDs are velocity dependent devices that are used in buildings to dissipate the seismic energy. In
general, the higher the effective damping in a building, the lower the responses (forces, displace-
ments, stresses, and drift ratios). In typical buildings, an inherent damping ratio (g) of 2% to 5% of
critical is expected. FVDs can be placed along the building height to provide substantially larger
amount of effective damping. The following is noted:
• FVDs are frequency independent devices without a stiffness component. So unlike tuned
devices, no tuning of FVDs to any particular frequency is required.
• FVDs are velocity dependent devices and unlike some other devices, there is no significant shift
in the building period (T) when added to structures, and the output forces generated by FVDs
are primarily out-of-phase with the maximum strains on the building structure.
• FVDs are classified as passive devices. So, no external power source is required to activate them.
Dampers are activated when there is relative motion between the two ends of the unit and
seismic energy is converted to heat and safely dissipated into the atmosphere.
• FVDs do not require regular maintenance and for typical applications, there is no degradation of
the performance with use or typical temperature variations.
• FVDs need not be placed in every level of a building and are often placed in strategic locations
to maximize efficiency of the dampers, or to meet other project constraints.
The behavior of a fluid viscous damper is idealized as a pure dashpot as shown in the constitutive
equation below:
Damping Force (F) = Damping Constant (C) x Velocity (V) α (Eq. 7.1.1)
Equation 7.1.1 provides the relationship between the damper output force and velocity, where C
and α (alpha) are the damping constant and velocity exponent, respectively. An alpha of 1.0 rep-
resents linear dampers, whereas values other than 1.0 indicate nonlinear dampers. See figure 7.1.15
for different behavior of an FVD with constant C value and varied alpha. Specifications for alpha
typically range from 0.3 to 1.0; in general, the lower the exponent the more efficient the viscous
damping for seismic energy dissipation.
42
Figure 7.1.15
Damper Force-Velocity Relation
FVDs are activated by the relative motion at the two ends of the damper and work best to mitigate
dynamic response of more flexible buildings like steel or concrete special moment frames; base- iso-
lation systems are also significantly improved with additional viscous damping.
FVDs are ideal candidates to address building irregularities. For buildings, with a soft story, placement
of dampers at only the bottom level significantly reduce the soft story response, without decreasing
structure period, and therefore total base shear. For buildings with plan irregularities, placement of
dampers opposite the more rigid side of the building can be used to reduce the torsional amplifica-
tion of the structure during motion. FVDs are efficient in resolving building separation issues as well.
Dampers have been used in stiffer buildings, but oversized dampers or motion amplification con-
figurations would be required to amplify the small relative motion at the two ends of the dampers.
For this type of installation, “no play” connections are also required to ensure that the dampers are
fully engaged.
Damping Configuration
Like any lateral force resisting system, it is important to ensure that dampers are placed in a con-
figuration that does not introduce asymmetry to the structure. The most efficient placement of
dampers would be equivalently about the building’s center of mass to control any torsional motion
of the building; consequently, the placement of dampers will be best along the perimeter of typical
structures.
43
In most applications at least two dampers are placed in each direction and on each side of building’s
center of mass for system redundancy. For buildings with a larger footprint, more than two dampers
will often be used in order limit the damper force output. Limiting force output from the dampers
can lead to more economical structural member sizes and connections. The exact placement of
FVDs, like bracing elements, are subject to architectural constraints.
As building height increases so does the fundamental period; correspondingly inter-story floor ve-
locities are less, and damping efficiency increases. For low-rise buildings, FVDs are typically placed
at more floor levels than needed for mid- and high-rise buildings. FVDs are usually not required at
every floor and are often terminated before the top levels or alternated at different floor levels.
FVDs can be arranged in many different configurations and some of the most common configura-
tions include diagonal, double-diagonal, Chevron, and the inverted Chevron. These configurations
are demonstrated in Chapter 6 of this guide. For tall buildings, damped outriggers and mega damp-
ers spanning many floors can be extremely efficient. In this chapter the Chevron, diagonal, and dou-
ble diagonal configurations will be discussed.
NLRHA is not required to develop conceptual damping system designs. There are several methods
for estimating dynamic response of a structure with supplemental damping using linear or response
spectrum analysis (RSA) procedures. ASCE 7-16 has documented procedures in chapter 18 Section
18.7 Alternative Procedures based on the modal strain energy method. The section’s source docu-
ment MCEER Technical Report 00-0010 outlines the procedure for implementation of the method
thoroughly.
Using this method only a modal analysis and assumed damping configuration is required to deter-
mine a conceptual design for desired performance objectives. In general, an estimate of total equiv-
alent damping for each mode is determined and directly applied to the spectral response of each
mode shape for RSA.
Figure 7.1.16
Idealize 2DOF System with Assumed Damping Configuration and Modal Shape Variables
44
If FVD elements are modeled in ETABS, linear damping coefficients can be provided and ETABS will
use the modal strain energy method to apply total equivalent viscous damping for each mode based on
damper configuration and properties during RSA. These design and analysis procedures are outside the
scope of this document as NLRHA is required for buildings in regions of high seismicity and provides
more consistent and accurate results. However, these procedures are helpful for preliminary sizing in
all projects.
The Maxwell Stiffness reflects the elastic flexibility of the damping devices’ fluid column and
connecting mechanisms, Ks, and the extender brace, Kextender, often used to connect the damping
device from one story to another as shown in figure 7.1.18 below.
Figure 7.1.18
Exponential Damper Link Model versus Damper and Extender Brace Installation
45
The components of stiffness from the damper and the extender brace act in series as shown in
equation 7.1.6.
(Eqn. 7.1.6)
The elastic flexibility of the damper varies based on the Rated Force that can be carried. Table
7.1.1 provides component Maxwell stiffness for each damper. The component of stiffness from the
extender brace shall be determined based on it's length and section properties.
(Eqn. 7.1.7)
Table 7.1.1:
Maxwell Stiffness for Taylor Devices Fluid Viscous Dampers
A closed-form solution can be derived for a linear damper link subjected to a harmonic excitation,
whereby the output force can be described as a function of relative displacement, x, and relative
velocity as shown in equation 7.1.8 below:
(Eqn. 7.1.8)
where k' and c' are, respectively, the "storage stiffness" and "adjusted damping coefficient" of the link
as defined by the following equations:
46
The relationship between Maxwell stiffness and damping efficiency is nonlinear as shown in Figure
7.1.20. Figure 7.1.20 illustrates the reduction in total energy dissipation, or damping efficiency, as a
function of the Maxwell stiffness.
A closed-form solution cannot be derived for a nonlinear damper subjected to a harmonic excitation
and numerical methods are required for calculation of force output as a function of input velocity. The
reader may refer to MCEER Monograph No. 1 for specifics of how to implement numerical methods
for the Maxwell model of viscoelasticity. Figure 7.1.21 shows the force-displacement response of a
nonlinear damper subjected to the same harmonic excitation with varied Maxwell stiffness. Again,
as the Maxwell stiffness decreases, so does the amount of energy dissipation.
When using extender braces in conjunction with dampers, designers should verify the extender
braces for both axial strength and stiffness for optimal design efficiency. In most cases, Ke will be
controlled by minimum strength requirements, which follow standard AISC procedures. In cases
where extender brace lengths are long, greater than 20 feet, and displacements are small, less than
2 inches, it might be more cost efficient to increase the size of the extender brace to reduce energy
dissipation loss.
47
Defining FVDs in ETABS
In ETABS, use the following steps to define the FVD properties:
Click on Define >Link >Link Properties, Link Property Name (Say Damp), Link Type, on drop down
menu select Damper-Exponent Type (Figure 7.1.23)
For Damper-Exponential (Fluid Viscous Dampers), select directional properties U1, and check box for
Non-Linear and click on Modify/Show for U1. (Figure 7.1.24)
Enter the values for Series Spring Stiffness, Damping, and Damping Exponent on Nonlinear Properties
data form (Figure 7.1.25).
For this example, the following properties are used to define the force-velocity relation of the FVD:
1. damping constant, C = 100 kips – (sec/in) α
2. velocity exponent, α = 0.5
3. Series Spring Constant, K = 2000 k/in
The linear damper properties can be provided for use with response spectrum analysis, although
ETABS will not consider nonlinear exponents and damper forces will not be provided as output.
48
The values of mass and weight account for damper mass and can be left at zero or a small value can be
specified to assist in analysis convergence. Typical damper weights would range from several hundred
pounds to several thousand pounds, depending on the damper size needed/used.
Figure 7.1.23
Selecting of Damper Type
Figure 7.1.24
Defining Damper Properties
49
Figure 7. 1.25
Defining Damper Nonlinear Properties
Figure 7.1.27
Select Damper Properties
50
The damper locations and properties can be displayed by viewing elevation (Figure 7.1.28) or 3D
(Figure 7.1.29) views. Diagonal dampers are shown here. X-dampers are drawn similarly.
Figure 7.1.28
Damper Location in Longitudinal (X) Elevation
Figure 7.1.29
Dampers in 3D Model
The user can then graphically draw the link element by clicking on the correct geometrical locations
for the first and second ends of the damper. One of the damper ends will be located at the middle
of the beam (Figure 7.1.31)
51
Figure 7.1.30
Turn Midpoint and End Snap On
Figure 7.1.31
Dividing the Frame at Mid
Figure 7. 1.32
Damper Location Along Longitudinal Elevation
52
See the figures 7.1.33 and 7.1.34 for both a typical frame evaluation and the analytical model. The
lateral support below the beam at mid-span need not be included, but it is important to capture the
eccentric force from the dampers about the beam end.
• Define the coordinate for the work-point node at the intersection of the two dampers and the
two braces approximately 10 inches below the bottom of the mid-span of the beam.
• In the edit menu, select replicate and include the distances required for the workpoint node.
• Next, replicate these nodes in each direction by the length of damper plus the half width of the
gusset plate connection to obtain the second end of each damper.
• In the property definition menu, use material steel and define both the Chevron brace size
(Typically square HSS or WF section) and also the section properties for the stiff connections.
• Draw the frame elements and horizontal dampers. Provide moment release for the HSS braces
at each end in the M3 direction, not the M2 direction.
• Repeat the same procedure by drawing or replicating dampers in the other bays.
Figure 7. 1.33
Typical Frame Elevation
Figure 7. 1.34
Analytical Model
53
The damper locations and properties can be displayed (Figure 7.1.35).
Figure 7. 1.35
Damper Location Along Longitudinal Elevation
At this stage the analytical model of the building structure with FVDs is complete. The next step is to
define seismic loading for the structure.
54
Seismic Loading
Building Codes, ASCE 7 and ASCE 41, require NLRHA for design and assessment of building
structures with fluid viscous dampers in high seismic zones. Performing NLRHA using direct-
integration methods can be time-consuming, however there is a much faster NLRHA method that
can accurately predict seismic behavior of buildings structures with fluid viscous dampers.
Fast-nonlinear analysis (FNA) is a modal analysis method that uses modal Ritz vectors to accurately
predict the behavior of a structure under dynamic seismic loading with small amounts of material
nonlinearity and nonlinear FVDs through link objects. This analysis technique is permitted in building
codes and underscores that once dampers are added to a structural system, the demand on the
members is significantly reduced; it is anticipated in most scenarios, the structure will remain
essentially elastic. FNA is used in this design guide and is part of the standard of practice in many
design offices. For more information on FNA refer to the CSI Analysis Reference Manual.
In order to accurately capture the combination of vertical and seismic loads, a preload of the vertical
loads using the ramp function shall be applied before seismic loading. See CSI Analysis Reference
Manual for details on using the ramp function to apply vertical loads appropriately using FNA. FNA
for seismic loading requires definition of several input variables including building mass, modal case,
and seismic acceleration histories.
Mass Source
The user shall specify the total seismic mass to be considered in the NLRHA. The seismic mass
includes the self-weight of the structural elements (beams, columns, braces, slabs, walls, etc.),
superimposed dead load and a portion of live load (if applicable).
Click on Define >Mass Source, add or modify mass sources data if required by clicking on submenu
(Figure 7.1.36). The user also has the option of selecting whether only lateral mass is considered or
if vertical contribution of mass is also included in analysis (for cases when there is a gravity preload
preceding the lateral analysis).
Figure 7.1.36
Defining Mass Source
55
Modal Cases
Click on Define >Modal Cases, to open the modal dialogue box. Click on Modify/Show Case to open
the modal case data (Figure 7.1.37). Next:
• Under subcase type select Ritz
• Check P-Delta as needed
• Under Loads applied, select Ux and Uy (and Uz if necessary) and select all links.
Link elements (in this case FVDs) must be activated to contribute to the dynamic response. This is
achieved in the modal case definition
For the number of modes, select a reasonable number to capture desired mass participation. Usually,
two degrees of freedom (axial force and axial deformation) are required for each damper. Additionally,
sufficient number of modes needs to be selected to capture the response of the building. In most
cases, in addition to the number of modes associated with dampers, selecting 30-60 modes will be
sufficient to capture the building response.
Figure 7.1.37
Modal Case Data
56
Response History Function
Although response spectrum analysis is not used directly in this design guide, the response spectrum
function will be used as part of development of seismic acceleration histories
• Define>Function>Response Spectrum to open menu (Figure 7.1.38) select ASCE 7-10 and
specify a name.
• Modify/Show Function open sub-menu and input site-specific parameters (Figure 7.1.39)
Figure 7. 1.38
Response Spectrum Definition
Figure 7.1.39
Site-Specific Response Spectrum Function
57
Acceleration Histories
On most projects the ground motion suites are selected and scaled to match site-specific seismic
characteristics by either a geotechnical engineer or seismology specialist for the structural engineer’s
final analysis and design report. There are several methods for developing these ground motion
suites and the reader is referred to the ASCE building code specifications and commentary for more
detailed discussion on this subject. For the initial phases of a project a couple ground motions can
be selected and scaled using the spectral matching tool in ETABS.
Define>Function>Time History to open the dialogue box and select From File from the drop-down
menu (Figure 7.1.40).
Select Add New Function click on Browse to locate the file and load it and then complete the format
of the file in the remaining boxes. The option to view file allows the file to be opened to check and
the acceleration vs time is displaced graphically (Figure 7.1.41)
Figure 7.1.40
Defining Time History Functions
58
Figure 7.1.41
Importing a Record From Analysis
59
Figure 7.1.42
Program Included Acceleration Records
Figure 7.1.43
Selection of Matching Menu
60
Figure 7.1.44
Program Matched Record
This approach was used to match both components of Newhall record for this example. Next the
FNA load cases are generated.
Load Cases
Define>Load Case to open the load case menu. Select add new load case and the load case menu
(Figure 7.1.45) Note that the load case type is Time History and FNA selected from pull down
menus. The two matched records are used as input functions and scaled (g=386 in/sec2). Analysis is
conducted for 20 sec and a time step of 0.01 is used for analysis. The inherent damping is assumed
to equal 5% of critical as it is done for concrete frame structure. The choice of inherent damping
does not affect the response significantly, because much larger effective damping is introduced in
this particular analysis by the viscous dampers. In general, an assumption of 5% inherent damping
is probably higher than reality, and the base model should probably assume 1% to 3% inherent
damping.
61
Figure 7.1.45
Load Case Definition for Lateral Loading
At the conclusion of this step, the definition of the model has been completed and user can start
analysis.
Analysis
ASCE Building codes require design and analysis based on the use of seven sets of two-component
ground motion suites; structural response are based on the average value of the seven ground
motions. In this guide, a single two component motion suite will be used for illustration.
62
Figure 7.1.46
Analysis Cases
Analysis Results
Results of seismic NLRHA including story drift ratios, member demands, total viscous damping, etc.
can be reviewed to verify that a structure meets desired performance objectives. If the results are
acceptable, then no additional iterations of damper properties are required, and damper results
can be assessed for specification. If the results do not meet performance objectives, then damping
properties may need to be modified. There are several sophisticated algorithms to optimize damper
properties. The simplest change is to increase or decrease the damping constant and leave the
velocity exponent unchanged. A larger damping constant should be applied if building response is
not acceptable, and a smaller damping constant if damper forces are deemed too large. For typical
applications, it is economical to group the dampers in a few groups.
Damper Response
Display>Show Tables to check analysis, check results, check link results (Figure 7.1.47) Link results
can be exported to an Excel file.
A summary of damper results for the THS-1 load case, including displacement (U1) and force (P)
is provided in Table 7.1.2. Designers will likely decide to use more than one size of damper for any
given building structure. For example, one size damper can be used on the bottom floor and a smaller
size on the upper floors. Alternatively, different damper sizes can be used in the two directions. In
this example, for simplicity, only one damper size will be specified.
From analysis results, maximum damper displacement is +/-2.4 in, thus a total stroke of approximately
5 in. total. Force is approximately 450 kips.
63
Figure 7.1.47
Selecting Link Results
Story Output U1 P
Case (in) (kips)
Story3 THS-1 0.5 214
Story2 THS-1 1.1 297
Story1 THS-1 2.4 448
Table 7.1.2
Damper Results Summary in.
64
Cumulative Energy Plot
Display>Cumulative Energy Components to see the figure 7.1.48 below and make sure to select the
appropriate Load Case at the bottom left corner.
Total cumulative energy is displayed in this plot. From this plot one can determine total viscous
damping ratio by scaling the ratio of energy dissipated by the global damping versus viscous damping.
In this case global damping is specified at 5, and as viscous damping is approx. 4 times larger, the
total viscous damping is approximately 4 x 5% = 20% damping.
Figure 7.1.48
Cumulative Energy Plot
65
PART 2: NEW CONSTRUCTION - SPECIAL MOMENT FRAMES WITH FVDs
The combination of a primary structural system and a supplemental damping system is an attractive
and efficient solution for seismic protection of buildings in regions of high seismicity. Pairing fluid
viscous dampers (FVDs) with either steel or reinforced concrete special moment resisting frames
(SMF) results in a highly damped, low-frequency building that limits seismic demand on structural
and nonstructural components. FVDs can be incorporated into seismic design to produce large
equivalent viscous damping; reducing the demand on the special moment frames significantly.
Design Approach
The general approach is to design the SMF members for the minimum strength requirements of the
building code only, meeting all the relevant requirements of ASCE 7-16 except the limitations for
the story drift ratios (SDRs). FVDs are then used to reduce the SDRs to comply with deformation
requirements.
An additional design check is required to assure that the structural system is satisfactory to carry
the demands from the dampers; the designer should check force demands on connecting structural
elements and the foundation system. However, since the force in the FVDs is primarily out-of-
phase with the maximum dynamic displacements, the demand on the primary structural system
and the foundation are generally not increased, and the initial design for the ASCE 7-16 strength
requirements is sufficient.
Construction Costs
One of the main advantages of using supplemental fluid viscous damping with special moment frames
is the reduction in the steel or concrete tonnage. Since the design of a SMF is generally governed by
the SDR, larger steel or concrete sizes than required to resist building code level design forces would
be required to meet this requirement. When using FVDs to control SDR, smaller member sizes can
be used.
A secondary advantage is that unlike bracing elements, FVDs need not be placed directly in line with
the primary structural system or at each floor level, so long as the diaphragm, collectors, etc. can carry
the load between both systems. This provides greater flexibility to meet architectural objectives that
other lateral systems will not permit.
Resiliency
Evaluation procedures defined by FEMA P-58 – Seismic Performance Assessment of Buildings make
evaluating seismic performance of building structures explicit and can be used to show building
owners and clients the benefits of improved seismic performance. Building structures designed with
fluid viscous dampers will experience a significantly lower level of member nonlinearity (damage)
compared to a code design building without dampers. A decrease in nonlinearity of the primary
structural system greatly reduces the chance of any residual deformations post-seismic activity. The
drifts, accelerations, and the demand on the structural system and other components are all reduced
such that total loss after an earthquake will be significantly less.
66
Overview
The design of a new steel SMF with FVDs is presented. The building considered in this report is
intended to represent realistic construction with seismic risk category II occupancy.
• Testing and QC
The additional dead and live load on the floor and roof are 40/80 and 20/20 psf, respectively. The
building seismic mass is approximately 10,000 kips.
The spectral acceleration (Sa) as a function of period (T) can be obtained for all period ranges of
interest. The design spectrum is shown in Figure 7.2.2.
67
Plan
Elevation
Figure 7.2.1.
Building Geometry
68
Design of Special Moment Frames
The building model was generated as discussed in the damper guideline. Next the seismic loading
was defined using the program’s ASCE 7 automatic seismic loading based on the equivalent lateral
load procedures. The seismic load cases were defined using ASCE 7-16 procedure for steel SMF
buildings. The load combinations of ASCE 7-16 were used for design process. The steel members
were assigned auto select sizes and the programs design module was allowed to iterate and determine
the member sizes. It is noted that the design met the strength requirements of the code including the
provisions for strong column-weak . It is further assumed that since this is a new building, continuity
plates are provided, and if necessary, doubler plates will be added to the columns webs. However, to
keep the design economical, a limited number of beam and column sizes were used, as is the practice
in the field. For example, same side beams were used at a floor for a given SMF. Furthermore, columns
were sized to reduce the requirements for doubler plates, again consistent with field practice. Figure
7.2.3 presents the demand to capacity ratios (DCRs) for the building. The gravity joists are not shown
in the model. There is a choice of explicitly including the joists in the model or adding bracing points
for the beam to account for these members.
Figure 7.2. 2
Design Response Spectrum for the Example Building
Figure 7.2.4 presents the distribution of SDR along the building height. The SDR was computed
based on the unreduced (inelastic demand) per ASCE 7-16 requirements. The plots are shown for
two percentages of damping of critical. The first curve corresponds to 5% equivalent damping that is
the basis for the code design. As seen in the figure, the SDR for 5% of critical damping ratio exceeds
the building code threshold of 2% for SDR at nearly all the floors and SDR is larger at the middle
floors.
69
Figure 7.2. 3
Steel Member Design Check
Figure 7.2. 4
Computed SDR
70
To comply with the building code provisions, FVDs will be added to the building to reduce SDR. When
a global equivalent viscous damping ratio is 20%, SDR is reduced to 2%, which provides compliance
with the code limit of 2.0% for SDR for DE event. As a starting point, an approximate damping ratio of
20% (linear damping for the initial trial) will be targeted for the FVDs. This is somewhat smaller than
the required FVD damping because of the following reasons:
• Discrete damping is less effective than global damping. Global equivalent damping is an idealized
case and is used to obtain an initial estimate for the required size of FVDs. It is not intended to
be used in design or analysis, as it assumes an idealized orthogonal damping matrix and uniform
damping for the building. This overestimates the performance of discretely distributed FVDs
that produce a non-orthogonal damping matrix and complex mode shapes. Bounding analysis is
required by ASCE 7-16 which reduces the effectiveness of damping,.
• Bounding analysis is required by ASCE 7-16 which reduces the effectiveness of damping.
• The inherent building damping is likely less than the assumed 5% values.
• Research has shown that adding dampers for a total damping ratio of approximately 20% improves
performance of buildings when subject to large earthquakes.
Damper Configuration
The final size of dampers will be determined by nonlinear response history analysis (as discussed later).
For analysis, an initial damper size is required. Figure 7.2.5 presents the proposed damper configuration.
Note the following:
• The dampers placed symmetrically and along the perimeter are most effective.
• There are two dampers in each direction on each side of the building’s center of mass, satisfying
the redundancy requirements defined by ASCE 7-16.
Figure 7.2. 5
Placement of Dampers
71
• Dampers are placed on the gravity bays as not to interfere with the SMF bays.
• The dampers are placed at all floors. Given that this is a five-story building, and because the
SDR are similar at different stories, this setup seems intuitive. During analysis, dampers at
upper stories could potentially be eliminated. This is the usual practice in design, however,
was not considered in this report.
• The dampers are placed diagonally. This configuration is effective since the damper axis is
at only 23 degrees from horizontal. The diagonal configuration also simplifies the design of
connection elements for dampers. In practice, architectural constraints might necessitate
moving of dampers to different bays. The effect of such relocation of dampers on the
performance is minimal as long as the damper symmetry is maintained and the redundancy
requirements are met, given that the building has rigid floor diaphragms.
• Dampers are placed on the same bay at all levels. Some engineers prefer staggering the
dampers along different bays along the building height to limit the force imparted to the
columns. For the stagger arrangement, collectors need to be provided to transfer the damper
force from the floor above to the floor below. In this report, the single bay approach is used.
• See Section 6.0 of this manual for other damper placement options.
As discussed in Part 1, many methods and procedures have been developed for preliminary sizing
and configuration of dampers for buildings. This example uses stiffness proportional damping, a
method derived from the modal strain energy method to obtain the preliminary size of dampers.
Stiffness proportional damping follows the following constitutive relation for determining linear
damper constraints at each floor level in each direction:
(Eqn. 7.2.1)
Whereby,
• ζ is the viscous damping ratio
• ki is the story stiffness obtained from static analysis of the building
• ni is the number of dampers in each direction
• T is the building period
• Ѳi is the angle of the dampers (Note this assumes all dampers are at the same angle for
a particular floor level)
For this design example the following information is provided, plus Table 7.2.1 below:
• Desired Damping Ratio, ζ = 22%
Note: For new construction of low-rise buildings, an additional 20-25% damping of critical
is considered the most efficient for design.
• Building period, T, of 2.1 sec
Floor Level ki Ѳi ni Cj
(k/in) (degrees) (kip-sec/in)
5 422 23 4 18
4 391 23 4 17
3 414 23 4 18
2 458 23 4 20
1 800 23 4 35
Table 7.2. 1 Calculation of Preliminary Damping Coefficient
72
Note from the table that the damping coefficient, C, is similar for the four upper levels, but larger
for the first level since that level is stiffer due to the fixity at the column base; story drifts are also
lower at that level and therefore one damping constant, C = 18, will be specified. In practice, it might
be desirable to use more than one size damper or C value along the building height or in the two
directions, if significantly different reduction in SDR is needed. However, even in such cases, it is a
good practice to limit the number of damper specifications to economize the design. The value of C =
18 k-sec/in is for linear dampers. In this example we want to use a velocity exponent, α = 0.5, in order
to limit the damper force, but also maintain the same energy dissipation.
A simple method can be used to equate a linear damper with a nonlinear damper. Nonlinear damping
is amplitude dependent so we can recognize our desired SDR of 2%. This means the displacement of
the damper, d, is equal to 2% x story height x cosine(Ѳ).
For this case, the damper displacement, d, is 3.1 in. Then the energy dissipated in one cycle of motion,
Wj, can be compared between both a nonlinear and linear damper as shown in Figure 7.2.6 below.
The energy dissipated in one cycle of motion, Wj, is calculated as the area within force-displacement
loop. Reference MCEER Technical Report 00-0010 for calculation of Wj for both nonlinear and linear
dampers.
Figure 7.2.6
Force-Displacement Loop for One Cycle of Motion
For this example, the initial damping constant value of 50 with a velocity exponent, α =0.5, is used. As
a check, once can calculate the maximum damper force for each damper. Since the building period is
2.1 sec, then the damper velocity can be computed:
Even though, both dampers produce the same amount of energy dissipation, the damper force is
approximately 10% smaller for the nonlinear damper, compared to the linear damper, showing the
higher efficiency of nonlinear (low exponent) dampers.
73
Bounding Procedures
Seismic protective devices (isolators and dampers) are propriety products manufactured by a select
group of vendors. Similar to all manufacturing, certain variation in properties from nominal can be
expected. ASCE 7-16 recognizes this and specifies:
A maximum and minimum analysis and design property shall be established for each modeling parameter
as necessary for the selected method of analysis. Maximum velocity coefficients, stiffness, strength, and
energy dissipation shall be considered together as the maximum analysis and design case, and minimum
velocity coefficients, strength, stiffness, and energy dissipation shall be considered together as the
minimum analysis and design case.
The PMF can vary significantly from product to product and from one manufacturer to another. The
standard recognizes the good quality control in manufacturing of FVD by Taylor Devices Inc. (See
Figure C18.2-1 of ASCE 7-16, the lowest permitted value of 15% for the PMF can be used. The PMF
applies to the damping constant only and the velocity exponent is not changed. Thus, the following
two cases are considered:
• Lower bound analysis C=85%C nominal or C=43. This case governs for the SDR as the lower
damping ratio is used.
• Upper bound analysis C=120% (1/85%) C nominal or C=60.This case results in larger damper
forces and governs the design of all components and members that transmit the damper
force to ground.
Seismic Loading
For design and analysis of new structures with FVDs, engineers can use either the nonlinear response
history analysis (NLRHA) procedure or alternative procedures based on the modal strain energy
method. The use of modal strain energy methods are subject to certain limitations. For example,
dampers are required at all levels, there is a cap on the effective damping ratio, and application is
limited to lower seismic regions. Methods other than NLRHA are developed to provide approximate
analysis and the standard recognizes this by referring to them as alternate procedures and emphasizes
the use of NLRHA procedure.
The NLRHA procedure requires that the dampers be modeled as nonlinear elements to capture
their velocity dependence and hysteretic behavior. However, the primary structural system can be
modeled as linear elements because the use of FVDs reduces the demand on the buildings, and thus
limits the extent of nonlinear response. This approach is used in this report.
For this example, 7 pairs of strong motion suites were chosen from the PEER Ground Motion
Database. The records were selected from strong motion data that can be expected at the site.
The records were then spectrally matched to the target spectrum of Figure 7.2.2 using the ETABS
application shown in Part 1. Figure 7.2.7 shows the response spectra for the 14 acceleration records
tightly matched the target response spectrum.
74
Figure 7.2.7
Spectrally Matched Ground Motion Records
Analysis Results
Two models, with upper bound and lower bound damping coefficients, were analyzed for the
seven two-component spectrally matched ground motion suites. A load combination was defined
averaging the ground motion results for each model, including the effect of vertical loads. The
lower bound model was used to check design of the primary structural system, compute the SDR,
and check damper stroke requirements; the upper bound model was used to check the damper
force demands.
Figure 7.2.10 presents the demand to capacity ratios (DCR) for the load combination of the average
of the NLRHA cases. For clarity, data from only the SMF elements are shown. Note the following:
75
Figure 7.2.8
Reduction in SDR After the Addition of Dampers
Figure 7.2.9
Force-Displacement Plot - Second Floor Damper
76
Building
Typical Frame
Figure 7.2.10
Design Check
77
DCR values are smaller for this analysis but the damper forces are larger. As such, components
such as diaphragms, collectors, and foundation elements need to be checked for the damper force
computed from the upper bound analysis. Table 7.2.2 presents the damper responses.
Floor DE Damper Force DE Damper Disp. DE Damper Velocity 150% x DE ≈ MCE MCE Damper Force 120% MCE Damper Force
Level
(kips) (in) (in/sec) Damper Velocity (in/sec) (kips) (kips)
Table 7.2.2
Computed Damper Responses
Figure 7.2.11 is Taylor Devices, Inc standard damper sizes. Material requirements for the dampers
are controlled by force and stroke and thus the cost of fluid viscous dampers is dependent on
these parameters. The cost is minimally affected by specification of the damping constant and the
velocity exponent. Also, note that Taylor Devices typically adds a factor of safety of approximately
2.0 to the damper capacity shown in the figure 7.2.11.
78
FLUID VISCOUS DAMPERS & LOCK-UP DEVICES
CLEVIS – CLEVIS CONFIGURATION
NOTE:
VARIOUS STROKES ARE AVAILABLE, FROM ±2 TO ±36 IN.
FORCE CAPACITY MAY BE REDUCED FOR STROKE
LONGER THAN STROKE LISTED IN THE TABLE. ANY
STROKE CHANGE FROM THE STANDARD STROKE
VERSION DEPICTED CHANGES THE MIDSTROKE
LENGTH BY 5 IN. PER ±1 IN. OF STROKE.
SPHERICAL
TAYLOR MID- MAXIMUM MAXIMUM
BEARING CLEVIS BEARING CLEVIS
FORCE DEVICES STROKE STROKE CLEVIS CYLINDER WEIGHT
BORE THICKNESS THICKNESS DEPTH
(KIP) MODEL LENGTH (IN) WIDTH DIAMETER (LB)
DIAMETER (IN) (IN) (IN)
NUMBER (IN) (IN) (IN)
(IN)
55 17120 1.50 34.13 ±3 1.67 1.31 4 3.25 4½ 90
110 17130 2.00 42.00 ±4 2.16 1.75 5 4.00 5¾ 180
165 17140 2.25 47.00 ±4 2.31 1.97 6 5.10 7¼ 300
220 17150 2.75 48.75 ±4 2.78 2.40 7¼ 5.88 8¼ 425
330 17160 3.00 51.75 ±4 3.03 2.62 8 6.38 9½ 550
440 17170 3.50 62.00 ±5 3.56 3.06 9¼ 7.50 11¼ 900
715 17180 4.00 62.00 ±5 4.60/4.38* 3.50 11¼/12¾* 9.00/8.25* 13¾ 1550
900 17190 5.00 74.00 ±5 5.56 4.38 12¾ 10.75 16¾ 2700
1450 17200 6.00 84.00 ±5 6.06 4.75 13¾ 12.00 20¼ 4100
1800 17210 7.00 90.25 ±5 7.00 5.25 16¼ 13.50 22¼ 5500
REV 5-2017
Figure 7.2.11
Viscous Damper Sizes, Taylor Devices
Design Consideration
Special moment frame design and the damper specifications were adequate and did not require
iteration in this example. Typically, one or two cycles of iterations can be necessary before final
design is complete.
Amongst other details, the designer will need to consider the following details for final design:
• Check damper connections, columns, diaphragms, collectors, and foundations connected
to damping devices to resist damper force specifications elastically.
• Design of the extender brace. The extender brace serves to attach the damper unit to the
structure. It must be strong enough to withstand the damper force without buckling and
adequately stiff as discussed in Part 1. The actual extender brace stiffness is computed
using the size and length of the brace.
Steel Tonnage
Table 7.2.3 lists the column and beam sizes for two models: one designed without dampers
meeting both the strength and drift requirements of the building code, and one meeting only the
code strength requirements and utilizing dampers to control drift. The reduction in steel tonnage
compensates for the additional cost of the dampers.
79
LFRS member sizes Code Damper
L1-L3 W24x229 W24x146
Columns
L4-Roof W24x176 W24x131
L1-L3 W24x94 W24x76
Beams
L4-Roof W24x76 W24x62
Beams 78 63
Steel Tonnage Columns 109 73
total 187 136
Table 7.2.3
Steel Members for Moment Frames
80
PART 3: SEISMIC RETROFIT - MOMENT FRAME WITH FVDs
Steel special moment frame (SMF) buildings constructed prior to the 1994 Northridge Earthquake
typically used welded unreinforced flange (WUF) beam-to-column connections. The Northridge
and Kobe earthquakes revealed that this then-popular construction was subject to premature
brittle failure. FEMA 351 (FEMA 2000) presents methodology for the retrofit of such buildings.
The application of fluid viscous dampers is one of the most highly recommended seismic retrofit
options for efficiency and construction flexibility. In most cases a foundation retrofit is not required,
significantly shortening the construction schedule and reducing cost.
The intent of seismic upgrades employing supplemental energy dissipation devices, also called dampers,
is to reduce the amount of deformation induced in the structure during its response to ground shaking.
In this respect, it is similar to upgrades accomplished through global structural stiffening. However,
rather than introducing stiffening to a structure, this upgrade technique reduces deformation through
the dissipation of energy within a series of devices that are introduced into the structure as part of the
upgrade.
Fluid viscous dampers (FVDs) provide an ideal solution for the seismic retrofitting of SMF buildings.
They serve to reduce the story drift ratios (SDRs) and thus the demand on the vulnerable connections
by increasing the damping in the system.
• The SMF buildings are flexible by nature and thus FVD will become easily activated by
motion of the building
• FVDs do not add stiffness to the system and thus the period of the building will remain
unchanged. For more flexible building, this retrofit approach will maintain the building period
away from the constant amplitude plateau and thus limit the seismic forces. By contrast,
when retrofit strategies, which increase lateral stiffness, are implemented, the building
period will shift towards the plateau and thus result in an increase in the seismic demand.
• The force in FVDs is velocity dependent and thus primarily out-of-phase with the inertial
forces of the building. Thus, the increase in demand on the existing members and foundations
is generally less than conventional seismic retrofitting
• FVD can be sized to further limit the force in the dampers and building
• The addition of supplementary damping reduces the peak floor accelerations and thus
protects the vulnerable acceleration-sensitive nonstructural components and building
content.
• Since the seismic energy is dissipated by the FVDs, the structural damage is reduced or
eliminated. This is in contrast to well-engineered ductile buildings for which energy
dissipation occurs by the nonlinear behavior in the ductile elements. To attain such ductility,
the engineer accepts the inevitable associated controlled damage.
81
Overview
In this Part, the seismic retrofit of an existing steel SMF with FVDs is presented. The building consid-
ered in this report, is intended to represent a realistic construction with seismic risk category II occu-
pancy, commercial or residential occupancy.
82
Plan
Elevation
Figure 7.3.1
Building Geometry
83
Site Seismic Characteristics
US Geological Survey (USGS) web tools can be used to determine the mapped spectral accelerations
for 0.2 sec, SS, and 1.0 sec, S1, based on the longitude and latitude of the site. The seismic demand
criteria were based on a typical location in Los Angeles, California, with mapped short-period (SS) and
1-second (S1) spectral accelerations of 1.5g and 0.6g, respectively. The structure was classified as
Risk Category II and located on Site Class D, resulting in site coefficients of Fa and Fv of 1.0 and 1.5,
respectively. Thus, BSE-2N (approximately 2475 year) short- and 1-second spectral accelerations
equaled 1.5g and 0.9g, respectively. The BSE-1N (approximately 475 year) short- and 1-second
spectral accelerations were equal to 1.0g and 0.6g, respectively. The spectral acceleration (Sa) as a
function of period (T) can be obtained for all period ranges of interest. The design spectrum is shown
in Figure 7.3.2.
Figure 7.3.2
BSE 1N Response Spectrum for the Example Building
Figure 7.3.3
Computed SDR
84
Damping Configurations and Properties
The final size of dampers will be determined by nonlinear response history analysis as discussed
later. For analysis, an initial damper size is required. Figure 7.3.4 presents the proposed damper
configuration. Note the following:
• The dampers are placed along the perimeter. This is the most effective and allows the owner
to showcase that this is a state-of-the-art retrofit.
• There are at least 2 damper bays in each direction on each side of the building center of
mass. Thus, the redundancy requirements of ASCE 41-17 are satisfied.
• Dampers are placed in the Chevron (double diagonal) configuration because it was required
to keep the middle portions of the bays open. Only dampers at the bottom three levels are
used in the first pass. During analysis, dampers at upper stories could potentially be added.
However, dampers will not be placed at the top story due to architectural constraints.
Figure 7.3.4
Placement of Dampers
85
Preliminary Damping Estimate
When supplementary damping is added to structures, an estimate in the reduction in dynamic
response can be determined using the numerical damping coefficient, B1, defined by ASCE 41-17
section 2.4.1.7.1. Below is the Damping Coefficient, B1, for varying levels of damping. A given dynamic
response can be divided by the damping coefficient to approximate reduced response.
5% 1.0
10% 1.2
20% 1.5
30% 1.8
40% 2.1
50% 2.4
Table 7.3.1
Numerical Coefficients for Various Damping Ratios
Since the objective of the seismic retrofit is to reduce maximum SDR from 2% to 1%, a numerical
coefficient of approximately 2 is desired. This value corresponds to a damping ratio of 30%-40%. FVDs
were initially sized to provide damping ratio of approximately 35% of critical
• Since there are only three levels of dampers, the same dampers were used at all levels.
• A velocity exponent (a) of 0.4 was used to limit the damper force at large earthquakes (high
damper velocities).
• The nominal damping coefficient, C, used for each damper is 70 kip-sec/in.
Seismic Loading
For retrofit of existing structures that use energy dissipation devices, engineers can use either the
nonlinear response history analysis (NLRHA) procedure or alternative procedures based on the modal
strain energy method. The use of methods other than NLRHA are subject to certain limitations. The
NLRHA procedure requires that the dampers be modeled as nonlinear elements to capture their
velocity dependence and hysteretic behavior. However, the primary structural system can be modeled
as linear elements because the use of FVDs reduces the demand on the buildings, and thus limits the
extent of nonlinear response.
Input Histories
For this report, 7 pairs of strong motion records were chosen from the PEER Ground Motion Database.
The records were selected from strong motion data that can be expected at the site. These records
were then scaled to the target spectrum of Figure 7.3.5 using the method described in Part 1.
86
Figure 7.3.5
Scaled Records
Analysis Results
Two models, with upper bound and lower bound damping coefficients, were analyzed for the seven
two-component spectrally matched ground motion suites. A load combination was defined averaging
the ground motion results for each model, including the effect of vertical loads. The lower bound
model was used to check design of the primary structural system, compute the SDR, and check damper
stroke requirements; the upper bound model was used to check the damper force demands.
87
Figure 7.3.6
Reduction in SDR After the Addition of Dampers
Table 9-4 of ASCE 41-17 provides information on the m-factors for beams, columns, and connections.
Although the m-factors for beams and columns are high for compact sections. The design is governed
by the m-factor for the WUF connection at live safety performance and is given by:
Eq. 1. m=4.3-0.083d
This factor could be further reduced per Section 9.4.2.4 of the standard as follows:
Eq. 1. m=compactness factor*panel zone factor* continuity plate factor* beam span factor
For example, with this building, for connections of W30 beam, compact beams and col beams and
columns, non-compliant panel zone, complaint, beam span-to-depth ratio, and connection without
continuity plates, the m-factor is computed from:
Eq. 2. m=(1.0)*(0.8)*(1.0)*(0.8)*(4.3-0.083*30)=1.2
Note: if the m-factor is less than one, use one instead. Therefore, the building will need to remain
essentially elastic at the BSE 1N level to meet the life safety performance. Figure 7.3.7 presents the
DCR for the load combination of the average of the NLRHA cases. For clarity only data for the SMF
elements are shown. As seen in the figure, the retrofitted building met its performance goal, as all the
members remained elastic. The seismic retrofit protected the vulnerable WUF connections without
the need to repair these connections.
88
Building
Figure 7.3.7a
DCR for BSE 1N (allowable m-factor 1.2 for life safety)
Figure 7.3.7b
DCR for BSE 1N (allowable m-factor 1.2 for life safety)
89
Figure 7.3.8
Force-Displacement Relation, Second Floor Damper
DCR values are smaller for this analysis but the damper forces are larger. As such, components
such as diaphragms, collectors, and foundation elements need to be checked for the damper force
computed from the upper bound analysis. Table 7.3.2 presents the damper responses.
Floor BSE-1N: Damper Force BSE-1N: Damper Velocity 200% x BSE-1N: Damper Velocity 200% x BSE-1N: Damper Force BSE-1N: Damper Displacement
Level
(kips) (in/sec) (in/sec) (kips) (in)
ROOF -- -- -- -- --
L4 -- -- -- -- --
L3 162 8.1 16.3 214 1.3
Table 7.3.2
Computed Damper Responses
One size of damper can be specified for this building retrofit since all the dampers have the same
properties and similar force and stroke demands. When specifying damper properties with Taylor
Devices, Inc. the drawings and specifications should indicate the following:
• Number of dampers, n = 24
• Nominal Damping constant, C = 70 kip-sec/inα
• Velocity Exponent, α = 0.4
• 200% BSE-1N Damper Stroke = +/-3 in
Note: The maximum computed displacement at BSE-1N is approximately 1.5 in. ASCE 41-17
requires that the damper displacement specification be 200% of the BSE-1N level demand.
90
FLUID VISCOUS DAMPERS & LOCK-UP DEVICES
CLEVIS – CLEVIS CONFIGURATION
NOTE:
VARIOUS STROKES ARE AVAILABLE, FROM ±2 TO ±36 IN.
FORCE CAPACITY MAY BE REDUCED FOR STROKE
LONGER THAN STROKE LISTED IN THE TABLE. ANY
STROKE CHANGE FROM THE STANDARD STROKE
VERSION DEPICTED CHANGES THE MIDSTROKE
LENGTH BY 5 IN. PER ±1 IN. OF STROKE.
SPHERICAL
TAYLOR MID- MAXIMUM MAXIMUM
BEARING CLEVIS BEARING CLEVIS
FORCE DEVICES STROKE STROKE CLEVIS CYLINDER WEIGHT
BORE THICKNESS THICKNESS DEPTH
(KIP) MODEL LENGTH (IN) WIDTH DIAMETER (LB)
DIAMETER (IN) (IN) (IN)
NUMBER (IN) (IN) (IN)
(IN)
55 17120 1.50 34.13 ±3 1.67 1.31 4 3.25 4½ 90
110 17130 2.00 42.00 ±4 2.16 1.75 5 4.00 5¾ 180
165 17140 2.25 47.00 ±4 2.31 1.97 6 5.10 7¼ 300
220 17150 2.75 48.75 ±4 2.78 2.40 7¼ 5.88 8¼ 425
330 17160 3.00 51.75 ±4 3.03 2.62 8 6.38 9½ 550
440 17170 3.50 62.00 ±5 3.56 3.06 9¼ 7.50 11¼ 900
715 17180 4.00 62.00 ±5 4.60/4.38* 3.50 11¼/12¾* 9.00/8.25* 13¾ 1550
900 17190 5.00 74.00 ±5 5.56 4.38 12¾ 10.75 16¾ 2700
1450 17200 6.00 84.00 ±5 6.06 4.75 13¾ 12.00 20¼ 4100
1800 17210 7.00 90.25 ±5 7.00 5.25 16¼ 13.50 22¼ 5500
REV 5-2017
Figure 7.3.9
Fluid Viscous Damper Sizes (Taylor Devices)
91
DESIGN CONSIDERATIONS
Amongst other details, the designer should consider the following for seismic assessment:
• Check the existing elements such as columns, diaphragms, collectors, and foundations for
program output forces (including seismic and demand from dampers) and strengthen as
required.
• Design all new members and connections connected to damping devices for the specified
damper forces.
• Design of the extender brace. The extender brace serves to attach the damper unit to the
structure. It must be strong enough to withstand the damper force without buckling and
adequately stiff as discussed in Part 1. The actual extender brace stiffness is computed using
the size and length of the brace.
ASCE 41-17 requires prototype testing of new devices. These tests are extensive and time
consuming and can therefore add unnecessary cost/time to a project. However, since in almost all
cases, a damper similar to a unit previously tested by Taylor Devices is specified, these tests can be
eliminated.
ASCE 41-17 also requires QC production testing of dampers. Taylor Devices tests 100% of their
units prior to shipment to the job and these tests can be witnessed by the design engineer, if desired.
Refer to Taylor Devices sample specifications for typical damper production testing.
92
REFERENCES
American Society of Civil Engineers (ASCE) 2018, ASCE/SEI 41-17, Seismic Evaluation and Retrofit of
Existing Buildings Arlington, VA
American Society of Civil Engineers (ASCE) 2017, ASCE/SEI7‐16, Minimum Design Loads For
Buildings and Other Structures, Arlington, VA
Computes and Structures Inc. (CSI) 2017, ETABS : Integrated Design, Analysis, and Drafting of
Building Systems, Walnut Creek, CA https://www.csiamerica.com/products/etabs
Federal Emergency Management Agency (FEMA), FEMA 351, Recommended Seismic Evaluation and
Upgrade Criteria for Existing Welded Steel Moment-Frame Buildings, Washington DC.
MCEER 2001, Development and Evaluation of Simplified Procedures for Analysis and Design of
Buildings with Passive Energy Dissipation Systems, Technical Report, MCEER 00-0010
2012 IBC – SEAOC Structural Seismic Design Manual – Volume 5, Examples for Seismically
Isolated Buildings and Buildings with Supplemental Damping
93
94
8 Fluid Damper Performance vs.
Other Technologies
With an increasing number of applications of Taylor fluid viscous dampers (FVD) in a wide variety
of projects, the superior performance and applicability of these velocity-dependent devices for
seismic- and wind-resistant design are more recognized by structural engineers. This chapter
highlights the critical characteristics of FVDs by comparing their characteristic with several other
commonly used passive energy-dissipating devices, including buckling restrained braces (BRB),
friction dampers, yielding dampers, visco-elastic dampers (VED), viscous wall dampers (VWD), and
tuned mass dampers (TMD). Several key advantages of FVDs include: reduced seismic demands due
to period shifting; minimal interaction with primary structural system; less dependency on frequency
and temperature; more flexibility in terms of locations, configurations and size selection. Moreover,
FVDs are easier to implement, require less effort for maintenance during service period and need no
external power, control actuators or sensors.
95
Figure 8.1
Typical axial force-displacement behavior of
a conventional brace versus a BRB [2].
A noted feature of a BRB system is that it provides static stiffness to a bare frame, increasing
its lateral stiffness and thus attracting larger seismic forces due to period shifting. This could be
illustrated by Figure 8.2, which shows a code-complied design spectrum. For a typical low-rise to
high-rise building, the fundamental period usually falls into the velocity-constant or displacement-
constant range, stiffening the structure will shift its fundamental period to the left (from blue dashed
line to the red dashed line), and the seismic force demand would be amplified; see the changes from
the blue arrow to the red arrow.
Figure 8.2
Typical design response spectrum shape.
96
Consequently, though the additional damping BRBs provide that helps reduce the drift ratio of a
structure, BRBs are less efficient in reducing the base shear and floor accelerations of a building
compared to FVDs. Take one case study for example. In a recent study [3], the cost-efficiency of three
different energy dissipation devices to upgrade an existing tall steel moment frame was examined,
including the case using (1) FVDs; (2) BRBs; and (3) viscous wall dampers (VWDs). Fig. 3 shows
the distribution of peak floor accelerations for different cases, including: (a) the original building
before adding any supplemental energy dissipation devices (black line); (b) the building incorporating
FVDs (blue line); (c) the building with BRBs (pink line); and (d) the building with VWDs (red line). The
locations for installation and effective damping ratios were kept the same for case (b), (c) and (d).
It is clearly shown that the addition of BRBs stiffened the building and increased the seismic force
demand. This has led to larger accelerations throughout floors, with a majority of floors exceeding
the values of the original building.
Figure 8.3
Distributions of peak floor accelerations [3].
On the contrary, FVDs are velocity-dependent devices. The typical hysteresis behavior of a linear
FVD (Figure 8.4) indicated that such a device does not provide static stiffness, avoiding additional
seismic forces in the structure. Moreover, FVDs provide damper forces that are out-of-phase with
displacement, hence damper forces would not increase the story forces and floor accelerations; see
blue line of Figure 8.3.
Figure 8.4
Typical axial force-displacement
behavior of a FVD.
97
Control residual drift
As we can see from the hysteresis loop of a BRB (Figure 8.1), this device has low post-yield stiffness
and lacks re-centering capability. Consequently, the residual drift ratios of a building with BRBs after
an earthquake event would be large. In contrast, a FVD has much better re-centering capability, and
could result in much reduced residual drift ratios.
Figure 8.5
Distributions of peak column axial D/C
in a case-study building: (+) tension (-)
compression [3].
Friction Dampers
A friction damper is another kind of displacement-dependent energy dissipation device. Fig. 6(a)
shows a friction device (also known as “Pall device”), which is placed at the intersection of the cross
braces. When an earthquake occurs, the brace in tension forces the damper at the joint link to slip,
which activate the four links and force the compression brace to shorten. In this way, the brace
buckling could be avoided, energy could be dissipated in both tension and compression braces. The
hysteresis loop of a friction damper is illustrated in Figure 8.6(b).
98
Figure 8.6
Illustration of (a): a friction damper (photo courtesy of James Kelly); and (b) hysteresis loop of a friction damper.
Similar as a BRB, a friction damper exhibits a few disadvantages compared to a FVD, including:
• Inducing larger seismic forces;
• Increasing the peak floor accelerations;
• Increasing base shears;
• Resulting in larger residual drift ratios;
• Increasing the column axial forces connected with them.
In addition to above-mentioned drawbacks, a friction damper exerts a constant force for all levels of
earthquake excitations, and thus the friction force at each story level needs to be carefully selected
to achieve the optimal performance. Besides, a friction damper usually comes in the X-crossing
configuration, taking up more spacing than a diagonal or a chevron-type configuration.
Yielding Dampers
A yielding damper dissipates energy through the yielding properties of mild steel. The typical hysteresis
loop is shown in Figure 8.7. As with a BRB or a friction damper, a yielding damper moves in-phase
with displacement, incurring larger seismic forces and likely leading to larger floor accelerations and
base shears. Moreover, they develop forces that are concurrent with structural movement, and cause
a large portion of forces to be transferred to structural members connected with these dampers.
Whittaker et al. [4] tested on 3-story model with one kind of yielding damper: added damping and
stiffness devices (known as “ADAS”), and revealed a 14% increase of column axial load compared to
the bare frame without ADAS. Also, these dampers lack re-centering capabilities and would result in
large residual drift ratios of a building after an earthquake excitation.
Additionally, most yielding dampers utilize metallic materials, and would require replacement after a
major event, thus increasing the associated life-cycle cost.
99
Figure 8.7
Hysteresis loop of a yielding damper
Viscoelastic Dampers
Besides devices depend on purely displacement, there are other kinds of devices that perform based
on both displacement and velocity. One of such devices is viscoelastic damper (VED). A VED consists
of layers of viscoelastic solid, and sandwiched between steel plates. It dissipates energy through
relative shear deformation of viscoelastic material. In general, viscoelastic solid materials exhibit
both storage stiffness and loss stiffness, and their mechanical properties would depend on both
frequency and temperature [5]. As a comparison, a FVD system out-performs a VED system in the
following aspects.
Where Ka' and Ka" are the storage stiffness (provide additional stiffening) and loss stiffness (provide
additional damping) of the brace-damper subsystem, and their mathematical expressions are
illustrated as [6]:
Note: Kd"=Cω
In the case of a FVD system, no additional brace stiffness exists, i.e., Kd '=0. As such, the above
expressions are reduced to:
100
Comparing Eqn. (3) and Eqn. (2), we can see that the static stiffness (Ka') is zero for a FVD system
when ω is zero, but not the case for a VED system. A direct result of zero static stiffness is that the
modal properties of a structure after adding FVDs keep the same. On the contrary, incorporation of
VEDs stiffens the structure, and increases its seismic input. Besides, under a dynamic loading case
(i.e., ω is greater than zero), as long as driving braces stiffness Kb is fairly large, the storage stiffness
(Ka') in Eqn. (3) is approximately zero, indicating that the in-phase component in a FVD system is
negligible when subject to external excitations. However, in a VED system, both the storage stiffness
and loss stiffness exist regardless of the size of driving braces. This in-phase components enlarge the
interaction between VEDs and the structural members, and result in larger forces within elements
that are connected with the dampers, as discussed in previous sections.
Figure 8.8
a SDOF system with a viscoelastic damper [6].
A VED could exhibit a significant dependency on frequency and temperature. For example, it was
reported that a VED changed its storage and loss shear stiffness by a factor larger than 7 when
the frequency changes from 0.1 HZ to 4 HZ; and exhibit a close to 50-fold decrease in stiffness in
the temperature range of about 0 °C to 50 °C [5]. Such a large change of mechanical properties of
VEDs when subjected to environmental settings (e.g., temperature) would diminish their additional
damping effect, and adversely impact the structure. Consider when VEDs are used in a tall building,
the building might have asymmetric stiffness due to dramatic changes of damper properties over
story height.
Moreover, VWDs were found to cause critical issues when used in an existing building with
vulnerable members (e.g., Pre-Northridge connections). Wang and Mahin [3] identified that using
wall-type of dampers on a case-study Pre-Northridge steel moment frame could change the typical
beam deflection shapes, increase shear or/and moment on vulnerable beam-to-column connections,
and thus making these exiting connections more likely to fail. Consequently, the damping effect
101
these VWDs could provide would be significantly diminished.
On the contrary, a velocity-dependent FVD provides a dampening force that is out-of-phase with
displacement, a much more desirable solution to retrofit existing vulnerable buildings. Moreover,
additional strengthening can be provided easily when connecting FVDs to the beam-to-column
connections by utilizing their end bracings, thus vulnerable connections could be addressed at the
same time as when the dampers are installed.
Additionally, later system tuning could be required should the fundamental period of a building
change, e.g., a building softens due to yielding of some members under a large seismic event.
Moreover, manufacturing a TMD is usually complicated and expensive. It is shown that the cost to
producing the device constitutes to about 82% of the entire design and construction procedure in
terms of using TMD [7]. Whereas, the FVDs are not only much cheaper in unit cost, but also the
manufacturing would contribute to a smaller amount in the whole procedure.
In terms of the configuration of placing FVDs, dampers could be arranged in a single diagonal form to
make the construction process simpler. Alternative configurations such as the chevron configuration
or V-shape configuration help maximize a damper’s deformation and could allow for more space to
include doors or windows. On the other hand, if a structure is relative stiff, a toggle-brace-damper
system could be utilized to amplify the damper deformation. If, in some cases the structure is quite
large, dampers could be installed across multiple stories to increase their deformation and thus
energy dissipation capacities. Besides in the superstructure in a building, FVDs are often used in
bridges to control their vibrations when subjected to external excitations. They could also be used in
combination with base isolation systems to reduce the isolator’s displacement or inducing additional
damping. When two structures are closely located, FVDs could be used in the gap between these
adjacent structures to eliminate potential ponding during an earthquake or wind event.
102
Summary
FVDs have found their wide applicability in engineering practice to improve the structural behavior
under a wind or earthquake event. They provide a list of attractive features than other types of
energy-dissipating devices.
When compared with a displacement-dependent device (e.g., BRB, friction damper, and yielding
damper etc.), a FVD could limit the increase of seismic forces, reduce floor accelerations in addition
to reducing story drift ratios, control residual drift ratios and limit interaction with other structural
members.
Additionally, a FVD has more flexibility to select locations, configurations and sizes when compared
to a TMD system.
Reference
[1] Xie, Q. (2005). State of the art of buckling-restrained braces in Asia. Journal of Constructional
Steel Research, 61:727-748.
[2] ANSI/AISC. (2010). Seismic provisions for structural steel buildings. American Institute of Steel
Construction, Chicago, Illinois.
[3] Wang, S. and Mahin, S (2016). Seismic upgrade of an existing tall building by different energy
dissipation devices. Proceedings of 2016 SEAOC Convention, Paper No. 29, Oct. 12-15, 2016,
Maui, Hawaii.
[4] Whittaker, A. S., Bertero, V. V., Alonso, J. L. and Thompson, C. L. (1989). Earthquake simulator
testing of steel plate added damping and stiffness elements. Report No. UCB/EERC-89/02,
University of California, Berkeley.
[5] Constantinou, M.C., Symans, M.D. (1992). Experimental and analytical investigation of seismic
response of structures with supplemental fluid viscous dampers, NCEER-92-0032, Department
of Civil Engineering, State University of New York, Buffalo, NY.
[6] Fu, Y. M. (1996). Frame retrofit by using viscous and viscoelastic dampers, Proceedings of 11th
World Conference on Earthquake Engineering, No. 428.
[7] Tse, T.T.T., Kwok, K.C.S., and Tamura, Y. (2012). Performance and cost evaluation of a smart
tuned mass damper for suppressing wind-induced lateral-torsional motion of tall structures.
Journal of Structural Engineering, 138 (4), 514-525.
103
104
9 The Typical Process for
Incorporating Dampers into
Buildings
Overview
Code prescribed building seismic design implies extensive structural and nonstructural damage after
a design level earthquake, with loss of operational capability and likely major repair or replacement.
By contrast, building seismic design incorporating supplemental damping systems delivers buildings
requiring minimal post-earthquake inspection that are fully operational within hours at little or no
additional cost.
Buildings with a supplemental fluid viscous damping system with between 10 to 40 percent of
critical damping experience over 50% less displacement than a code prescribed building design; up
to a 40% smaller base shear; over a 50% reduction in floor accelerations; and a much lower damage
level due to the larger damping ratio. The structural and nonstructural components of the building
are better protected while reduced displacements and forces mean less steel and concrete offsetting
the damping system cost.
Fluid Viscous Dampers (FVDs) do not change the stiffness of the building, are velocity dependent
and therefore self-centering, have a property variation of less than ± 15%, are easy to install, and
require no maintenance.
SCOPE
The main sections of this document are as follows:
1. Key Aspects of Building Seismic Design incorporating Fluid Viscous Damping Devices:
105
Key Aspects of Building Seismic Design Incorporating Fluid Viscous
Damping Devices
Fluid viscous damping devices (FVDs) can be incorporated into both new buildings and existing
buildings.
FVDs are placed between any two points where relative motion exists during a transient event such
as an earthquake or wind event. Diagonal brace mountings are popular as is the use of FVDs in a
chevron brace arrangement . Base-isolated structures are also optimized by using FVDs along the
plane of motion in conjunction with the base isolation bearings. For relatively stiff buildings toggle
brace assemblies can be used to magnify small displacements by as much as 5x while simultaneously
producing the required damping force. Many special custom configurations are also available.
Spherical bearings at each end of the FVD permit the damping device to angulate relative to the
structure without binding. These bearings permit the rotation in every direction. In many cases the
spherical bearings may be used at one end, only.
The standard that provides minimum load requirements for the design of buildings and other
structures that are subject to building code requirements, including the Seismic Design Requirements
for Structures with Damping Systems, is ASCE 7-10, Minimum Design Loads for Buildings and Other
Structures, Chapter 18.
ASCE 41-13, Seismic Evaluation and Retrofit of Existing Buildings, Chapter 14, Seismic Isolation
and Energy Absorption, Section 14.3, Passive Energy Dissipation Systems, and ASCE 41-17, Seismic
Evaluation and Retrofit of Existing Buildings, Chapter 15, Energy Absorption, specifies nationally
applicable provisions for the seismic evaluation and retrofit of buildings.
The design of Damping Devices and their connections are sized to resist the force demands,
displacements, and velocities from the maximum considered earthquake ground motions.
Elements of the Damping System are designed to remain elastic for design loads including unreduced
seismic forces of the Damping Devices.
A fluid viscous damping device is a velocity dependent device in which the resultant force is
proportional to some power of velocity. FVDs behave by converting kinetic energy into heat,
typically over multiple cycles of response. A FVD dissipates energy by pushing silicone fluid through
a custom orifice geometry to obtain either linear (α = 1.0) or non-linear (α ≠ 1.0) viscous damping.
F = CVα
where: F is the Damping Force, in pounds
V is the Relative Velocity, inches per second
C is the damping Coefficient, constant
α is the Velocity Exponent, constant
106
As α decreases the damping efficiency increases.
For example, and FVD with an α = 1.0 has a damping efficiency of 78.5%, while an FVD with an
α = 0.1 has a damping efficiency of 97.1%.
A low damping α provides a more consistent damping force over a larger range of input velocities.
For example, an FVD with α = 1.0 provides 2x the damping force if the actual velocity input is 2x the
design velocity. For an FVD with α = 0.1, if the actual velocity input is 2x the design velocity, the FVD
still provides approximately 1x the damping force.
Values from 0.3 to 0.9 typically work best for building applications. The standard α for starting a
building design is 0.5.
Nominal design properties of FVDs shall be established from either project-specific prototype test
data or prior prototype tests on a device of similar size and construction. These nominal design
properties are confirmed by prototype tests later in the design or construction phase of the project.
The use of a bounded analysis addressing the expected variation in nominal design properties enables
the design process for structures with FVDs to proceed in a similar fashion to a conventional project.
The typical practice for FVDs sourced from manufacturers, is to use upper-bound design property =
1.15× nominal design property and lower-bound design property = 0.85× nominal design property
to cover variations caused by specification, device characteristics, environment, and aging. The
variation is typically applied only to the C value and not to the α value. To provide an additional
margin of safety, ASCE 41-13, 14.3.1 requires FVDs to be capable of sustaining larger displacements,
velocities, and forces than the maxima calculated for the Design Basis Earthquakes.
For example, in a chevron application either a flanged tube steel section or pipe section damping
device driver is bolted to the flange end of the damping device to achieve the pin to pin dimension
of the brace element. For an FVD with spherical bearings at each end and an integral extender in
between the spherical bearings the supplied device extends the full pin to pin dimension.
The aesthetic appearance of an FVD with an integral extender in an exposed condition may be more
architecturally pleasing and should be considered in the early layout stage.
Each damped story should have at least four energy dissipation devices in each principal direction of
107
the building, with at least two devices located on each side of the center of stiffness of the story in
the direction under consideration. When less damping devices are used, an increase in displacement
and velocity capacity is required by code due to the reduced level of redundancy in the damping
system. The damped stories may not need to extend the full height of the building depending upon
the building configuration.
In the case of a soft story application, the damping devices may be located at the soft story, only,
however overall building performance is improved if the damping devices are additionally located
either one or two levels above the soft story.
Damped bays do not always stack in adjacent stories. The load path should be complete but flexibility
in the location of the damped bays is an advantage in laying out the supplemental damping system.
The use of a larger number of smaller damping devices will be more cost effective than a smaller
number of larger damping devices.
The general philosophy of the EDWG document was to confine inelastic deformation primarily to
the energy dissipation devices, while the main structural members remained elastic for the Design
Basis Earthquake. Furthermore, since passive energy dissipation technology was still relatively new,
a conservative approach was taken on many issues. For example, an experienced independent
engineering review panel was required for all projects to conduct a review of the energy dissipation
system design and the associated prototype testing programs.
A simpler approach was included as Appendix to Chapter 2 of FEMA 222A NEHRP Recommended
Provisions for Seismic Regulations for New Buildings, 1994 Edition, also recommending a testing
program similar to that proposed by EDWG.
Concurrently a significant effort funded by FEMA was underway to create technical guidelines for
the seismic upgrading of buildings. Energy dissipation systems were included in the range of available
techniques to improve seismic performance. The results of these efforts were published in Chapter 9
of FEMA 273 NEHRP Guidelines for the Seismic Rehabilitation of Buildings, October 1997.
This guideline was more extensive than the EDWG guideline and was more extensive than the
FEMA 222A approach, but it could not be referenced or quoted for the proposed FEMA 302 NEHRP
Recommended Provisions for Seismic Regulations for New Buildings and Other Structures, 1997
Edition, because FEMA 273 had not been published or made generally available at the time FEMA
302 went to ballot.
As a result, the FEMA 302 Appendix to Chapter 13, Passive Energy Dissipation Systems, only provided
brief statements as to the benefits of damping for improved performance, suggested rational design
procedures be used, and recommended an independent panel for design and test program review.
108
It was recognized that this Appendix was only a placeholder for more thorough requirements in the
2000 edition of FEMA 368.
The Appendix to Chapter 13 of FEMA 368 NEHRP Recommended Provisions for Seismic Regulations
for New Buildings and Other Structures, 2000 Edition, Structures with Damping Systems, was
published in March 2001. It was intended to be applicable to all types of energy dissipation systems,
to provide design criteria comparable to conventional design performance, to provide design criteria
for enhanced seismic performance, to distinguish between the design of members that are part
of the energy dissipation system and the design of members independent of that system. It also
required an independent engineering review of the design and testing programs.
Since then, many of the provisions have been updated and incorporated into the current codes
and standards, however the independent panel for design review remains. Although, the number of
panel reviewers now is specified as “one or more”.
As described in ASCE 7-10, Section 18.8 or ASCE 14-13, Section 14.3.7, a design review of the
damping system and related test programs shall be performed by an independent team of registered
design professionals in the appropriate disciplines and others experienced in seismic analysis
methods and the theory and application of energy dissipation systems. The design review shall
include, but need not be limited to, the following:
1. Review of site-specific seismic criteria including the development of the site-
specific spectra and ground motion histories and all other project-specific design
criteria;
2. Review of the preliminary design of the seismic force resisting system and
the damping system, including design parameters of the damping devices and
prototype testing;
3. Review of the final design of the seismic force-resisting system and the damping
system and all supporting analyses; and
4. Review of damping device test requirements, device manufacturing quality control
and assurance, and scheduled maintenance and inspection requirements.
In the early applications of energy dissipation, many design review panels included three individuals
to cover the range of expertise required in the design review, including the site-specific seismic and
other criteria and the prototype testing of the devices. Design review may now be performed by just
one individual. For more significant structures, a local jurisdiction may require a design review panel
with two or three individuals, but for many structures incorporating energy dissipation devices, one
well qualified and experienced design reviewer is adequate.
Although review of the prototype test program is mandated, the design reviewer is no longer required
to witness the prototype tests.
The design review is not a difficult, timely or costly process. Many suitably qualified design
professionals are available to perform the review. If required, Taylor Devices, Inc. can provide a list
of design professionals that have served in this capacity on previous projects.
109
The fabrication and quality control procedures used for all prototype and production devices shall
be identical. These procedures shall be approved by the design professional before the fabrication
of prototype devices.
Prior to installation in the building, damping devices shall be tested to ensure that their force-
velocity- displacement characteristics fall within the limits set by the registered design professional
responsible for the design of the structure. The scope and frequency of the production-testing
program shall be determined by the registered design professional responsible for the design of the
structure.
The estimated time of FVD production should always be verified with Taylor Devices. The production
time is heavily dependent on the orders being produced at the time of request and the size of the
damping device.
The critical information required to place an order or to receive a quotation includes but is not
limited to, the damping device size, stroke, C value, and α value.
Taylor Devices typical payment terms are 1/3 deposit due with order placement, 1/3 due when
machining parts begins and 1/3 due when units are ready for shipment. The duration of FVD
production commences with the receipt of the first payment installment.
It is recommended that the registered design professional responsible for the design of the structure
develop and subsequently manage a design process schedule.
At the inception of the project meet with the authority having jurisdiction (AHJ) and determine
their design review requirements, process, and timeline. The design review may be conducted by
the AHJ. Alternatively, the review is performed by an outside consultant(s). The consultant(s) may
be a bench consultant(s) already under contract with the AHJ or may be hired specifically for the
project requiring an RFP and selection process. It is important to gain a clear understanding of the
arrangement and timing of the Design Review as soon as possible.
Typically, the design review is conducted by two consultants, one to review the site seismic hazards
and associated geotechnical design parameters and one to review the design and other aspects
of the damped seismic force resisting system (DSFRS). However, each AHJ may have a different
approach to the design review.
The design review should be conducted concurrently with the design. Early approval of the site
seismic hazards and associated geotechnical design parameters, the approach to establishing the
nominal design properties through prototype testing or prior tests of devices of a similar size, and
the Basis of Seismic Design of the DSFRS document is recommended.
The layout of the proposed damping device bay configuration should be finalized, and the design
completed.
110
A phased review to the structural design of the project is preferred. The design of the DSFRS can be
separated from the balance of the project. Once the design of the DSFRS has been accepted,
the damping devices can be ordered. The earlier the damping devices can be ordered the more
flexibility in the construction phase schedule will be realized.
With the implementation of a phased review, no additional design time compared to a traditional
design project is incurred.
The AHJ may not agree to a phased review so it is important to reconcile the timing of the design
schedule, the acceptance of the design and the delivery of the damping devices at the jobsite as
early as possible.
Taylor devices tests 100% of their units prior to shipment to the job and these tests can be witnessed
by the registered design professional responsible for the design of the structure. Current typical
practice is to perform quality control testing on all devices, but there is no codified requirement to
do so.
Definitions
Damping System: The collection of structural elements that includes all the individual damping
devices, all structural elements or bracing required to transfer forces from damping devices to the
base of the structure, and the structural elements required to transfer forces from damping devices
to the seismic force-resisting system.
Damping Device: A flexible structural element of the damping system that dissipates energy due
to relative motion of each end of the device. Damping devices include all pins, bolts, gusset plates,
brace extensions, and other components required to connect damping devices to the other elements
of the structure.
References
FEMA 222A, 1994, NEHRP Recommended Provisions for Seismic Regulations for New Buildings,
1994 Edition, Federal Emergency Management Agency, Washington, DC.
FEMA 273, 1997, NEHRP Guidelines for the Seismic Rehabilitation of Buildings, Federal Emergency
Management Agency, Washington, DC.
FEMA 302, 1998, NEHRP Recommended Provisions for Seismic Regulations for New Buildings and
Other Structures, 1997 Edition, Federal Emergency Management Agency, Washington, DC.
FEMA 368, 2001, NEHRP Recommended Provisions for Seismic Regulations for New Buildings and
Other Structures, 2000 Edition, Federal Emergency Management Agency, Washington, DC.
American Society of Civil Engineers (ASCE) 2013, ASCE/SEI 7-10, Minimum Design Loads for
Buildings and Other Structures, Reston, VA.
American Society of Civil Engineers (ASCE) 2014, ASCE/SEI 41-13, Seismic Evaluation and Retrofit
of Existing Buildings, Reston, VA.
American Society of Civil Engineers (ASCE) 2018, ASCE/SEI 41-17, Seismic Evaluation and Retrofit
of Existing Buildings, Reston, VA.
111
112
10 Photographs
113
Bremerton Naval Hospital – Bremerton, WA - Retrofit Close-up of a damper at 999 Sepulveda - Retrofit
114
San Francisco Civic Center Complex – San Francisco, CA – New Build
115
San Bernardino Justice Center – San Bernardino, CA – New Build
116
Caltrans District 4 Office Building – Oakland, CA - Retrofit
117
San Miguel Mall – Lima, Peru – New Build
118
Public Safety Building – Salt Lake City, UT – New Build
119
B. Dampers in Chevron Braces
120
Patio Mayor Building – Santiago, Chile – Retrofit Hotel Woodland – Woodland, CA – Retrofit
121
C. Base Isolation Dampers
122
Hayward City Hall – Hayward, CA – New Build
123
Tokyo Rinkai Hospital – Tokyo Japan – New Build
124
D. Dampers with Motion Amplification Devices
125
Olympic Building – Cyprus – New Build
E. Bridge Dampers
126
Hangzhou East Bridge – China – New Build
127
Tianjin Railway Bridge – Tianjin, China – New Build
128
Las Vegas Pedestrian Bridge TMD – Las Vegas, NV – New Build
129
F. Miscellaneous Damper Installations
130
181 Fremont Street – San Francisco, CA – New Build
131
Ichilov Hospital – Israel – Retrofit
132
11 Mounting Hardware
Taylor Devices fluid viscous dampers are provided with a spherical bearing in each end that provides
at least ±5° of rotation in both directions to account for misalignment of installation and for
movement during an event. This misalignment can be seen in Figure 11.1.
Figure 11.1
133
In order to maintain the ±5° rotation, it is important to make sure that no surrounding geometry
interferes with the movement of the clevises. A common interference can come from the bracket
that is housing the end of the damper. To prevent this, it is important for the bracket manufacturer
and the damper manufacturer to coordinate their efforts. Taylor Devices has produced the following
chart drawing (Figure 11.2) to aid in the design and manufacture of brackets that will allow ±5°
minimum rotational clearance.
8 7 6 5 4 3 2 1
REVISIONS
PER TAYLOR
MOUNTING PIN
C SUPPLIED BY TAYLOR C
B B
CL "H" LINE
BORED HOLE
A A
"D2" (MIN.)
PER CUSTOMER
PER TAYLOR
TANG WIDTH "G" MIN.
PER CUSTOMER PER TAYLOR
FOR REFERENCE
CHECKED
devices inc. PHONE 716-694-0800
FAX 716-695-6015
A THIS IS A TYPICAL INSTALLATION DETAIL FOR A TAYLOR DEVICES UNIT. Q.A. A
THIS SHOULD BE USED AS A GUIDELINE FOR CONNECTION DETAILS. ONLY MFG APPR.
DEVIATIONS FROM THE SHOWN CONFIGURATIONS ARE ACCEPTABLE, BUT ENGINEER J.C.M. 07/4/3 FIELD INSTALLATION GUIDE
THE FACTORY SHOULD BE CONSULTED. (COTTER PINS AND WASHERS MAY APPROVED J.C.M. 07/4/3
BE SUBSTITUTED FOR RETAINING RINGS). "SUPPLIED ITEMS" ARE PROVIDED MATERIAL:
SIZE CAGE CODE DRAWING NO: REV.
BY TAYLOR DEVICES WITH THE UNITS. B 06742 PIN AND BRACKET GUIDE B
NOTES: UNLESS OTHERWISE NOTED
SCALE: 1:4 SHEET 1 OF 1
8 7 6 5 4 3 2 1
Figure 11.2
If a gusset plate already exists at the installation location, Tang Plates can be a good substitute for
a bracket. With tang plates, the pin, shims and tang plates can be assembled prior to lifting the
damper into position. With the tangs attached to the damper, only nuts, bolts and washers need to
be used to attach the assembly to the structure. An example of a tang plate can be seen in Figure
11.3.
To ensure that the bearing stays in the middle of the bracket or tang plates, Taylor Devices provides
two shims along with each pin kit. The shims are to be placed on either side of the bracket such
that it always has enough space on either side to rotate and provide the required 5° of rotation. The
assembly can be seen in Figure 11.4.
134
Figure 11.3
Figure 11.4
Pin Kit Arrangement and Installation Details
135
To facilitate a close fit and ensure that the dampers can function at smaller displacements, Taylor
Devices holds a very tight tolerance on its bearings and pin kits. It is common to have tolerances of
±0.001 inches on pin kits. Because the tolerance is so tight, bracket holes must be bored after any
welding of plates to ensure the holes are perfectly aligned. Examples of some typical pin kits can be
seen in Figure 11.5 and 11.6.
Figure 11.5
Taylor Devices strives to meet its customer's needs and will design unique solutions to unique
problems. If there are concerns that a major earthquake could hit during the construction or retrofit
of a building, Taylor Devices can provide a system that can be activated within a short period of time.
Using our Pin-in-a-Pin system, the dampers can be installed in the structure with a thin walled pin
that is designed to hold the unit in place but would buckle under the load from an earthquake. Once
all dampers are installed, it is a simple manner to quickly go to each installation site and slide a solid
center pin into the thin walled pin activating the system and providing instant damping protection.
An example of one of these thin walled/solid core pins can be seen in Figure 11.7.
136
Figure 11.6
Figure 11.7
137
Taylor Devices provides two different systems for retaining pins in the assembly. The first is a
retaining ring system that are wound onto each end of the pins. The second system includes washers
and cotter pins. Examples of the two systems can be seen in Figure 11.8, 11.9, and 11.10.
Figure 11.8
Pin Kit Retaining Ring Assembly
138
TYPICAL PIN KIT WITH COTTER PINS
Figure 11.9
Un-installed position
Figure 11.10
Installed position
139
140
12 Available Sizes and Dimensions
Depicted below are four Taylor Devices’ brochures that represent the available sizes and dimensions
for our Fluid Viscous Dampers and Lock-Up Devices.
SPHERICAL
TAYLOR MID- MAXIMUM MAXIMUM
BEARING CLEVIS CLEVIS BEARING PLATE
FORCE DEVICES STROKE STROKE CLEVIS CYLINDER WEIGHT "A" "B" "D"
BORE THICKNESS DEPTH THICKNESS "C" (mm) THICKNESS
(kN) MODEL LENGTH (mm) WIDTH DIAMETER (kg) (mm) (mm) (mm)
DIAMETER (mm) (mm) (mm) (mm)
NUMBER (mm) (mm) (mm)
(mm)
250 17120 38.10 787 ±75 43 102 83 33 114 44 178±3 127±.25 † 20.6±.25 38±.76
500 17130 50.80 997 ±100 55 127 102 44 146 98 282±3 203±.25 † 31.8±.25 38±.76
750 17140 57.15 1016 ±100 59 152 129 50 184 168 343±3 254±.25 127±.25 28.7±.25 61±.76
1000 17150 69.85 1048 ±100 71 184 150 61 210 254 419±3 318±.25 159±.25 31.8±.25 76±1.5
1500 17160 76.20 1105 ±100 77 203 162 67 241 306 432±3 330±.25 165±.25 34.9±.25 76±1.5
2000 17170 88.90 1346 ±125 91 235 191 78 292 503 457±3 343±.25 171.5±.25 38.1±.25 102±1.5
3000 17180 101.60 1441 ±125 117 286 203 89 350 805 508±3 406±.25 203±.25 41.4±.25 102±1.5
4000 17190 127.00 1645 ±125 142 324 273 111 425 1088 ** ** ** ** **
6500 17200 152.40 1752 ±125 152 350 305 121 515 1930 ** ** ** ** **
8000 17210 177.80 1867 ±125 178 415 343 135 565 2625 ** ** ** ** **
MADE IN USA
REV 3-2020
Figure 12.1
Dampers with Clevis – Base Plate Configuration (Metric)
141
FLUID VISCOUS DAMPERS & LOCK-UP DEVICES
CLEVIS – BASE PLATE CONFIGURATION
NOTE:
VARIOUS STROKES ARE AVAILABLE, FROM ±2 TO ±36
INCHES. FORCE CAPACITY MAY BE REDUCED FOR
STROKE LONGER THAN STROKE LISTED IN THE TABLE.
ANY STROKE CHANGE FROM THE STANDARD STROKE
VERSION DEPICTED CHANGES THE MIDSTROKE LENGTH
BY 5 INCHES PER ±1 INCH OF STROKE.
REV 3-2020
Figure 12.2
Dampers with Clevis – Base Plate Configuration
142
FLUID VISCOUS DAMPERS & LOCK-UP DEVICES
CLEVIS – CLEVIS CONFIGURATION, METRIC UNITS
NOTE:
VARIOUS STROKES ARE AVAILABLE FROM ±50 TO ±900mm
FORCE CAPACITY MAY BE REDUCED FOR STROKE LONGER
THAN STROKE LISTED IN THE TABLE. ANY STROKE CHANGE
FROM THE STANDARD STROKE VERSION DEPICTED CHANGES
THE MIDSTROKE LENGTH BY 5 mm PER ±1 mm OF STROKE.
SPHERICAL
TAYLOR MID- MAXIMUM MAXIMUM
BEARING CLEVIS BEARING CLEVIS
FORCE DEVICES STROKE STROKE CLEVIS CYLINDER WEIGHT
BORE THICKNESS THICKNESS DEPTH
(kN) MODEL LENGTH (mm) WIDTH DIAMETER (kg)
DIAMETER (mm) (mm) (mm)
NUMBER (mm) (mm) (mm)
(mm)
250 17120 38.10 867 ±75 43 33 102 83 114 41
500 17130 50.80 1067 ±100 55 44 127 102 150 82
750 17140 57.15 1194 ±100 59 50 152 129 184 136
1000 17150 69.85 1238 ±100 71 61 184 150 210 193
1500 17160 76.20 1314 ±100 77 67 203 162 241 250
2000 17170 88.90 1575 ±125 91 78 235 191 285 408
3000 17180 101.60 1575 ±125 117/111* 89 286/324* 228/210* 350 701
4000 17190 127.00 1880 ±125 142 111 324 210 425 1225
6500 17200 152.40 2134 ±125 152 121 350 305 515 1810
8000 17210 177.80 2293 ±125 178 135 415 343 565 2495
MADE IN USA
REV 3-2020
Figure 12.3
Dampers with Clevis – Clevis Configuration (Metric)
143
FLUID VISCOUS DAMPERS & LOCK-UP DEVICES
CLEVIS – CLEVIS CONFIGURATION
NOTE:
VARIOUS STROKES ARE AVAILABLE, FROM ±2 TO ±36 IN.
FORCE CAPACITY MAY BE REDUCED FOR STROKE
LONGER THAN STROKE LISTED IN THE TABLE. ANY
STROKE CHANGE FROM THE STANDARD STROKE
VERSION DEPICTED CHANGES THE MIDSTROKE
LENGTH BY 5 IN. PER ±1 IN. OF STROKE.
SPHERICAL
TAYLOR MID- MAXIMUM MAXIMUM
BEARING CLEVIS BEARING CLEVIS
FORCE DEVICES STROKE STROKE CLEVIS CYLINDER WEIGHT
BORE THICKNESS THICKNESS DEPTH
(KIP) MODEL LENGTH (IN) WIDTH DIAMETER (LB)
DIAMETER (IN) (IN) (IN)
NUMBER (IN) (IN) (IN)
(IN)
55 17120 1.50 34.13 ±3 1.67 1.31 4 3.25 4½ 90
110 17130 2.00 42.00 ±4 2.16 1.75 5 4.00 5¾ 180
165 17140 2.25 47.00 ±4 2.31 1.97 6 5.10 7¼ 300
220 17150 2.75 48.75 ±4 2.78 2.40 7¼ 5.88 8¼ 425
330 17160 3.00 51.75 ±4 3.03 2.62 8 6.38 9½ 550
440 17170 3.50 62.00 ±5 3.56 3.06 9¼ 7.50 11¼ 900
715 17180 4.00 62.00 ±5 4.60/4.38* 3.50 11¼/12¾* 9.00/8.25* 13¾ 1550
900 17190 5.00 74.00 ±5 5.56 4.38 12¾ 10.75 16¾ 2700
1450 17200 6.00 84.00 ±5 6.06 4.75 13¾ 12.00 20¼ 4100
1800 17210 7.00 90.25 ±5 7.00 5.25 16¼ 13.50 22¼ 5500
REV 5-2017
Figure 12.4
Dampers with Clevis – Clevis Configuration
144
13 Case Studies
The following is a list of select case studies. Full versions of the studies are located in Appendix A.
1. Cost Delta for Achieving Higher Structural Performance Levels – Major cities in California
are now mandating that existing buildings with the highest seismic risks be retrofitted in
conformance with local ordinances. As a consequence to the recent engineering community’s
push for cities and building owners to become more resilient against seismic events, many
owners are now more conscious about their buildings’ anticipated seismic performance.
Owners are now beginning to ask engineers what it means to design above the minimum code
standards. For an owner to make an educated decision on building design, engineers need to
convey the increased cost of a higher structural performance in simple terms. This paper covers
a scenario in which an existing Pre-Northridge Steel Moment Frame building was evaluated
for three different performance objectives under California’s hospital building standards. This
paper highlights the differences in structural scope between each performance level as well
as the expected percent increase in construction costs. Engineers can use this case study
as an example when speaking to their clients about relative costs between different seismic
performance levels.
2. Seismic retrofit and FEMA P-58 risk assessment of mid-rise soft-story concrete towers – The
two frame office towers, constructed in the 1970s per the 1967 edition of the UBC, use perimeter
reinforced concrete moment frames to resist seismic loading. The buildings are rectangular
in plan and have certain characteristics that adversely affect their seismic performance, in
particular the presence of a soft-story response at the first floor (approximately 50% taller
than typical floors), and limited ductility typical of buildings of that era. Risk analysis showed
that for the towers the PML exceeded 20%. Nonlinear response history analysis (NLRHA) of
the towers was conducted and showed that in the existing configuration, the story drift ratios
(SDRs) at the first floor exceeded 2%, shear hinging of the first floor beams was expected and
that the SDRs would need to be reduced to approximately 1.4% for the first floor to limit the
extent of nonlinear response. Seismic retrofit included addition of 300-kip viscous dampers in
both directions to the first floor of the building. Analysis showed that the retrofitted structure
had a first floor SDR of approximately 1.3% and that the soft story response and plastic shear
hinging of first floor beams were mitigated. FEMA P-58 analysis of the retrofitted buildings
were then conducted using the results—SDR, story acceleration, and residual drifts—from the
NLRHA. It was seen that the 90th percentile repair cost (PML) was significantly reduced and
was now less than 15%.
145
sf (13,470 m2) historic building. Dynamic and nonlinear static analytical results verified that
the building had a weak soft-story with inadequate post-yield capacity, and large torsional
response. The analysis indicated that the existing building is not seismically adequate to
withstand anticipated lateral forces generated by earthquake excitations at the site. A “collapse
prevention” performance upgrade for a 475-year return event was desired. Nonlinear fluid
viscous dampers were placed at the first story level to reduce the seismic demand and obtain
a more uniform response. Visco-elastic fluid viscous dampers were strategically placed at one
side of the building to reduce the torsional irregularity of the building. The proposed cost
effective, state-of-the-art retrofit will improve the seismic performance of the building.
4. Seismic Upgrade of an Existing Tall Building by Different Energy Dissipation Devices – The
Pacific Earthquake Engineering Research (PEER) Center has expanded its Tall Building Initiative
(TBI) program to include the seismic performance of existing tall buildings. A 35-story steel
moment resisting frame, designed in 1968, and had representative details of buildings between
1960 to 1990 was selected for detailed seismic evaluation in the framework of Performance
Based Earthquake Engineering (PBEE). It was identified that the case study building failed
to meet the performance objectives suggested by ASCE 41-13, and had a number of seismic
vulnerabilities that endangered its structural integrity at two basic safety earthquake hazard
levels (BSE): BSE-1E and BSE-2E. Therefore, exploration of retrofit strategies and their cost-
effectiveness are fostered. In this paper, three kinds of supplemental energy dissipation devices
are investigated to upgrade the seismic performance of the case study building, including fluid
viscous dampers (FVDs), viscous wall dampers (VWDs) and buckling restrained braces (BRBs).
The retrofit design started by selecting locations to install supplemental devices. Then the total
effective damping ratios needed to achieve the target roof displacements in two directions
were estimated based on a damping scale factor (DSF). One retrofit strategy by using FVDs
was investigated as a first trail, and the mechanical characteristics of each damper device were
calculated based on the overall effective damping ratio and the story wise distributions of
dampers. Next, other two retrofit strategies by using VWDs or BRBs were investigated. Sizing
of different devices at one location was performed following the principle of equal energy
dissipation. The effectiveness of each strategy to meet the retrofit intent of ensuring structural
stability at BSE-2E were compared. Moreover, probabilistic damage and loss analysis were
conducted using Performance Assessment Calculation Tool (PACT) to relate the structural
responses to economic losses. After a detailed examination, it was found that upgrading the
case study tall building using FVDs was the most effective retrofit strategy to control structural
responses, and reduce damage and economic losses after BSE-2E events.
5. Practical Implementation of ASCE-41 and NLRHA Procedures for the Design of the LLUMC
Replacement Hospital – The Loma Linda University Medical Center Campus Transformation
Project (LLUMC CTP) is a new 17 story base-isolated 1,000,000 square foot replacement
acute care hospital located less than 1 km from the San Jacinto Fault. The seismic design and
analysis of the structure used LS-DYNA to efficiently perform nonlinear response history
analysis (NLRHA) with 110 individual ground motion analyses incorporating DE, MCE,
upper bound, lower bound, and varying ground motion direction. Implementation of triple
pendulum isolators, fluid viscous dampers, buckling restrained braces, and SidePlate moment
frames in LS-DYNA will be described. As required for OSHPD-1 facilities, the NLRHA results
demonstrated Immediate Occupancy performance at DE and Life Safety performance at MCE
using element backbone curves and acceptance criteria from ASCE 41 as amended by the
California Building Code. Inconsistencies in element acceptance criteria for combined lateral
systems and other code implementation challenges will be discussed. A cloud computing and
database framework, using Penguin-on-Demand and Amazon Web Services, was developed
146
to manage the 8 terabytes of data generated from each set of 110 ground motion analyses
performed on each design iteration. Automated processes enabled the team to reduce the time
between design iterations to 2 weeks for the complete suite of NLRHA, post-processing, report
generation, and design optimization. The team’s approach to analysis data management, design
optimization procedures based on NLRHA results, automated post-processing, and automated
report generation will be detailed.
6. Viscous Damper with Motion Amplification Devices for High Rise Building Applications –
Adding damping by the use of various damping devices has become an accepted method to
reduce wind-induced vibrations in tall buildings. An interesting example of a 39-storey office
tower is presented where large projected accelerations are the result of the vortex shedding
off an adjacent existing 52-storey building. Viscous dampers and a motion amplification system
are utilized to suppress the anticipated accelerations. A description of the damping system and
its analytical complexities are discussed. Non-linear analysis of the tower, with time history
forcing functions, derived from the wind tunnel, is presented. The dichotomy of the wind and
seismic design requirements on the damping system is discussed. Cost data for the system is
also presented.
7. Integrated Design and Construction at the 250 West 55th Street Tower – The recently
completed 40 story office tower at 250 west 55th street in Manhattan demonstrates
the best in innovative structural design, and use of 3-D coordination tools for design
and construction. This paper describes the integrated process that was followed
and some of the challenges that were met along the way, and will be of interest to
design professionals and others interested in integrated construction processes.
The integrated 3-D process started with the use of Revit from the Schematic design stage, and
was followed through the design, procurement, and construction phases, with all major sub
contractors producing 3-D or 4-D models. These models were carefully integrated by the general
contractor, and enabled savings in schedule, reduction of field conflicts, and reduced project risks.
The progress of the project was further complicated by a suspension of construction for two
years after completion of the foundations. This paper describes some of the unusual steps taken
to manage this process and allow for an accelerated schedule upon restart of construction.
8. Design of an Essential Facility with Steel Moment Frames and Viscous Dampers Using 2000
NEHRP – This new 2-story, 40,000ft2 police headquarters becomes the first building in the
United States to apply 2000 NEHRP procedure to design an essential facility with Fluid Viscous
Dampers (FVDs). The structure is located in Vacaville, California, which is in a region of high
seismic activity and classified as zone 4 per 1997 Uniform Building Code. The lateral force
resisting system (LFRS) consists of special steel moment frames with FVDs. In accordance with
2000 NEHRP, the LFRS is sized and designed with strength requirements of the code level force.
FVDs are provided to control displacement of the structure. This design philosophy leads to a
low frequency structure with low acceleration. FVDs reduce the displacement level to less than
0.01 story drift ratio. Earthquake performance and cost effectiveness are the primary concerns
in designing this building. Site specific response spectra and time histories are synthesized for
a 500-year and a 2,500-year return event. Performance Based Design using both linear and
nonlinear time history analyses is conducted to ensure “immediate occupancy” performance.
A cost study shows that much of the FVD’s cost is offset by reducing the weight of the LFRS
while providing a far superior performance than the “code-compliant” structures.
147
- Richard Neutra’s iconic Tower of Hope on the Christ Cathedral (formerly “Crystal Cathedral”)
campus in Garden Grove, California has been an important Orange County landmark since it was
built in 1968. The thirteen-story tower – the tallest building in Orange County when it was built
– has been called an “overlooked masterwork in Neutra’s oeuvre” by architectural historians.
Like many concrete buildings built prior to the 1971 Sylmar Earthquake in California, the
Tower of Hope’s concrete frames lack the ductility needed to safely dissipate seismic
energy. After acquiring the Crystal Cathedral campus in 2012 the Roman Catholic Diocese
of Orange undertook a comprehensive renovation and seismic retrofit project to provide
21st century seismic resilience to the historic tower. This challenging seismic retrofit and
renovation project was completed in 2015. The retrofit work included the installation
of fluid viscous dampers on the second through fifth floors of the tower in combination
with fiber-reinforced polymer strengthening of targeted concrete columns and walls.
This paper focuses on two challenges unique to the Tower of Hope. First, it was imperative
that the retrofit design respect the historically significant mid-century modernist architecture,
preserving those features that were emblematic of that period of significance. Seismic retrofit
construction was limited to areas that didn’t affect Neutra’s open floor plate design aesthetic
or lessen the inside-outside connectivity of each of the spaces. This openness was particularly
challenging to preserve in the glass-walled first floor lobby where seismic forces are at their
most intense. The second unique challenge was the large damper connection forces that had
to be developed into the existing cast-in-place concrete frames without damaging the existing
steel rebar. The strategies described by the authors are generally applicable to other historic
buildings from the mid-century modernist movement and to the use of fluid viscous dampers
to retrofit concrete frames.
10. Strong Medicine – An article from Modern Steel Construction magazine discussing the use of
viscous dampers for the seismic upgrade of the Naval Hospital located Bremerton, WA.
11. Design of Structures with Dampers per ASCE 7-16 and Performance for Large Earthquakes
- An impediment to the use of seismic protection devices has been the difficulty for practicing
engineers to design buildings with isolation system or damping devices. ASCE/SEI task
committees charged with development of new generation of codes for seismic design and
retrofit of buildings have updated the relevant code sections with one goal being to encourage
the use of such devices. An effort was undertaken to develop a step-by-step design guideline
for such design. Following the preparation of guideline, incremental analysis of four steel SMF
building models was undertaken. The benchmark model was designed using the strength and
drift requirements of ASCE 7-16. The other models were based on provisions of Chapter 18
of ASCE 7-16. For one model the lower base shear value was used, and for a third model, the
drift ratios were further limited to obtain enhanced performance. Lower- and upper-bound
analyses as required by ASCE 7-16 were conducted to size the dampers. The models were
then subjected to incremental nonlinear analysis and key response parameters were evaluated.
In all cases, the use of dampers resulted in reduction in the hinging of SMF members. It was
notes that the best performing model was the model designed for 100% of nominal base shear
and above minimum effective damping had superior performance, remaining elastic at design
earthquake, and having almost no residual displacement at very large earthquakes.
148
14 Taylor Devices’ Literature
149
150
We’re on top of structural control
151
As The World Churns: A New Level of Seismic Protection
Originally developed for NASA in the 1960s, Taylor Fluid Viscous Dampers are now used by civil
engineers worldwide to protect their work and the people who rely upon its safety Over 600
buildings, bridges and other crucial structures around the world are now using Taylor dampers
Taylor Devices a 01 inductee into the Space Technology +all of Fame has been recogni]ed
and certiԴed by NASA for these space program innovations that now save lives on (arth
Taylor Devices has established a track record for reliability and stateoftheart performance
Our unshakeable reputation has been validated through rigorous research, full scale testing,
and published work by organi]ations such as
■ The Multidisciplinary Center for (arthTuake (ngineering Research MC((R
along with S((SL & N((S at the State University of New <ork at Buffalo
■ (arthTuake (ngineering Research Center ((RC at UC Berkeley
■ The +ighway ,nnovative Technology (valuation Center +,T(C
Taylor Devices’ Seismic Dampers and our
■ The National Center for Research on (arthTuake (ngineering NCR(( located in Taiwan
President, Douglas Taylor, were inducted into
■ The Caltrans Seismic Response ModiԴcation Device SRMD test facility at UCSD
the Space Technology +all of Fame in 201
Our Vice-President, Richard +ill, received the ■ (Defense test facility located in -apan
Corporate Award
Why seismic dampers?
There are simply no disadvantages to using Taylor Seismic Dampers for structural control
due to their viscous behavior Building codes throughout the world now recogni]e and even
encourage their use A straightforward dynamic analysis of a structure using standard software
demonstrates the signiԴcant beneԴt of seismic dampers, and the technology is now being
widely used to optimi]e structures Taylor Fluid Viscous Seismic Dampers provide a reliable,
ine[pensive, environmentallyfriendly and easytoinstall solution
Dampers that produce a linear relationship with respect to velocity are available Please note
that standard damping exponents can be set anywhere between and 20, as reTuired by the
speciԴc application
152
Seismic Dampers
Ready, Steady, Reliable.
Seismic dampers soak up earthTuake-
induced motion to prevent structural
damage Compact yet powerful, our Եuid
viscous dampers increase structural damping
levels to as much as 0 percent of critical
Protect new or existing structures against earthTuakes simply and inexpensively Taylor Devices’ Fluid
Viscous Dampers provide complete protection for buildings, bridges, towers, elevated freeways -
virtually any structure that is subMect to earthTuake damage
■ Diagonal brace dampers are available in output levels up to 2 million pounds force
with strokes of up to 20 inches
■ Base isolation dampers are available in output levels up to 2 million pounds force
with strokes of up to inches
For unusual seismic applications, motion ampliԴcation devices and open space frames can be
incorporated These products also have non-seismic applications as wind dampers on tall buildings,
bridges and other structures
Taylor Seismic Dampers reTuire no maintenance - ever Our exclusive design uses a minimum number
of moving parts and our patented dry seal has over 0 years of successful performance in some of
the world’s most demanding applications
153
Tuned Mass Dampers
The tuned mass damper reduces deԵection of the building under wind inputs by essentially
applying force to the building in a direction always opposite to the wind-induced motion
Tuned mass dampers are not normally used to provide seismic protection
TMDs are also in pedestrian bridges, ballrooms, stadiums and other structures to reduce vertical,
lateral andor torsional vibrations caused by human activities andor wind
154
Lock-Up Devices
Instant Protection.
Lock-up devices LUD and snubbers are
dampers with extremely restrictive oriԴces
that function much like a seatbelt These
products are used to limit relative motion
between masses during a transient event
while allowing free motion in the normal
mode This allows dynamic loads to be
shared at multiple locations rather than
concentrated at Դxed locations
,n the 1990s, Taylor Devices began using snubbers, originally developed during the 1960’s for
protection of large steam pipes in nuclear power plants, as locking devices to limit the relative
motion of highway bridge sections under various types of transient motion - usually seismic in
origin When used on civil engineering structures, the product is usually called a lock-up device
LUD or shock transmission unit STU
Most applications have been in regions of low or moderate seismic risk The devices allow
essentially unrestricted motion when the bridge structure expands and contracts thermally,
but locks the structural masses together under seismic or wind storm conditions
Our lock-up devices have the same basic dimensions as our Եuid viscous dampers Available
in force ranges of 10 kip to 2000 kip with thermal stroke capability of up to inches
155
Facilities
More than All Taylor products are made in the United States at our two manufacturing centers located in
North Tonawanda, New <ork Our facilities cover 1 total acres and over 10,000 sTuare feet
600 buildings and are minutes from both the Buffalo Niagara ,nternational Airport and Niagara Falls
,nternational Airport
Common Facilities
Both Taylor manufacturing centers are capable of centerless and center grinding, honing,
diamond lapping, bar and plate handling, in-house welding and heat treatments
Quality Assurance
Taylor facilities and business management systems are registered to the following standards
■ ,SO 9001 - audited and certiԴed by NSF ,nternational Strategic Registrations for AS910200
■ AS9100 - audited and certiԴed by NSF ,nternational Strategic Registrations for AS910200
■ ,SO 1001 - environmental management standard audited and certiԴed by NSF ,nternational
Strategic Registrations
■ N+B-300 1C - NASA Tuality standard for spacecraft and satellite applications
Testing Facilities
Taylor facilities set the world’s standard for testing of shock absorber and shock isolation
systems Facilities include
■ Vertical drop rails ■ +ydraulic multipliers
156
157
158
COST EFFECTIVE
Originally developed for NASA and the US Military,
leading structural engineers use Taylor Dampers as
a cost effective way to protect all types of buildings,
their contents and their occupants from damage
caused by earthquakes.
Since the early 90s, modern-day damping technology
has been protecting buildings and saving lives in
high-seismic areas throughout the world. Taylor
Dampers, much like shock absorbers on a car, absorb
energy to protect a structure. Without them, you’re in
for a bumpy ride.
159
ADDED VALUE
Taylor Dampers provide much better building
performance — even to the point of allowing immediate
occupancy after a major earthquake — for little or no
H[WUDFRVW7D\ORU'DPSHUVUHGXFHVWUHVVGHԵHFWLRQ
and acceleration, protecting the structure and content.
160
161
Taylor Retrofit Solutions for
Non-Ductile Concrete Buildings
Taylor Devices is a world leader in the manufacturing of high quality seismic
protection products. Our qualified team offers extensive experience with the design
of damping systems for seismic upgrades of existing concrete buildings. Taylor
Devices offers training and design tools to project stakeholders through technical
presentations and project specific consulting at no cost.
www.taylordevices.com
90 Taylor Drive | North Tonawanda, NY 14120 | Phone: +1-716-694-0800 | sales@taylordevices.com
162
Building Specifics
• Located in Sacramento,CA
• Built in the early 1970s
• Two 14 Story RC Towers
• Roughly 175,00 SF Each
• Engineering Performed by
Miyamoto International
CS 555
Capitol Mall
case study
555 Capitol Mall in Sacramento California consists of two 14 story concrete office towers totaling over 380,000 square feet.
It was constructed in the early 1970s to the 1967 version of the Universal Building Code. The facilities had several factors
that enhanced its seismic performance such as its rectangular floor plan and its symmetrical design, however, there were
concerns regarding several other structural deficiencies.
The biggest concern regarding the structure’s seismic performance was due in part to the soft-story response of the first
floor which was 50% taller than all of the other floors. These structures are more prone to collapse in the event of an
earthquake. Additionally, the structure also experienced drift great than 2% in both orthogonal directions. These responses
are deemed too high for non-ductile concrete buildings.
The buildings in their existing configuration had a Probable Maximum Loss (PML) value that exceeded 20% and it was
determined that the structure was more than likely to experience moderate to significant damage in the event of a design-
level earthquake. This combination of concerns led building management to consider and ultimately pursue a seismic
upgrade of the structure.
Eight Fluid Viscous Dampers were added to the first floor of each tower, totaling 16 dampers. These devices were aesthetically
integrated into the existing building structure and presented minimal disturbance to facility operations during installation.
Additionally, building management opted to cancel their earthquake insurance, roughly $145,000 a year, given the direct
investment in a seismic improvement technology to protect the structure. With a project cost of roughly $800,000, building
management was able to achieve a full return on investment in 6 years.
RESULTS:
www.taylordevices.com
90 Taylor Drive | North Tonawanda, NY 14120 | Phone: +1-716-694-0800 | sales@taylordevices.com
163
Taylor Retrofit Solutions for
Non-Ductile Steel Buildings
Taylor Devices is a world leader in the manufacturing of high quality seismic protection
products. Our qualified team offers extensive experience with the design of damping
systems for seismic upgrades of existing steel buildings. Taylor Devices offers training
and design tools to project stakeholders through technical presentations and project
specific consulting at no cost.
www.taylordevices.com
90 Taylor Drive | North Tonawanda, NY 14120 | Phone: +1-716-694-0800 | sales@taylordevices.
164
BUILDING SPECIFICS:
• Located in Bremerton, WA
• Built in the late 1970s
• 9 Stories Tall
• 250,000 sq/ft
• Engineering Performed by
Reid Middleton
CS
case study
Bremerton
Naval Hospital
The Naval Hospital at Bremerton (NHB) is a fully accredited, community-based hospital that serves over 60,000 military
families in the Puget Sound region. Given its proximity to Seattle, in the event of a major earthquake, the medical campus
could anticipate the need to serve over 250,000 people.
In 2001, the hospital shook for 45 seconds as the 6.8 magnitude Nisqually Earthquake struck the Pacific Northwest.
Occupants on the upper floors recalled seeing the building sway as they watched the tree line below and feared for its
collapse. The hospital structure experienced significant lateral drifts during the relatively small, “less than design level”
earthquake, particularly on the upper floors of the tower of the main building. Calculated peak roof displacements from this
modest earthquake shaking were over 6”.
Since the main building was constructed in the late 1960s with “Pre-Northridge Steel Moment Frames,” a detailed inspection
in accordance with FEMA 350 standards was performed and the building was evaluated. During the evaluation of the
structure, it was determined that a conventional seismic retrofit by strengthening or stiffening would have been too costly
and disruptive to hospital operations, therefore alternative retrofit solutions had to be considered.
The use of Taylor Fluid Viscous Dampers proved to be the best design scheme to improve the seismic performance of
the building while minimizing the disruption to hospital operations. In total, 88 Fluid Viscous Dampers were strategically
installed in the existing structure. These dampers reduced the demands on the existing structure by reducing the lateral
displacement of the structure and no retrofitting of the foundation was required.
RESULTS:
www.taylordevices.com
90 Taylor Drive | North Tonawanda, NY 14120 | Phone: +1-716-694-0800 | sales@taylordevices.com
165
STANDING TALL
cy=JY]J=gc.JD]%JY+.&+ɣY.]]cYgcgY]
www.taylordevices.com
166
MEGABRACES
The 181 Fremont Street Tower, located in Downtown San Francisco, is arguably • Reduced weight is
the most resilient tall building on the West Coast of the United States. In the heart advantageous in areas where
of San Francisco, adjacent to the Transbay transit center, it is a prime real estate soft soil conditions and
in the city. Given the relative slenderness and the weight of the structure (steel liquefaction are a concern.
framed), the building is relatively susceptible to wind-induced vibration. Aside
from the damped megabrace, both TMD and TSD were considered. While some • Damping can be integrated as
strategies for reducing accelerations have used TMDs, the location of the building, an architectural feature of a
in a seismic region, favored a robust, distributed damping system. While feasible,
building.
TMD and TSD systems were not pursued, in part because of the high value placed
YTSR ƽSSV WTEGI EX XLI XST SJ XLI FYMPHMRK ERH XLI EHHMXMSREP WXIIP VIUYMVIH XS
support the weight of the TMD or TSD.
The viscous dampers were placed in eight groups of four within the bracing
system. The damping is approximately 8% in two directions for the service level
[MRH*SVPEVKIV[MRHIZIRXWERHIEVXLUYEOIWXLMWIJJIGXMZIP]MRGVIEWIWXS Ɓ
FIGEYWI SJ XLI FIRIƼGMEP RSRPMRIEVMX] MR XLI HEQTIVW8LI EHHIH HEQTMRK
WMKRMƼGERXP]VIHYGIHXLISZIVEPPWXIIPXSRREKIJSVXLITVSNIGX
2 www.taylordevices.com
167
DAMPED OUTRIGGERS
3 www.taylordevices.com
168
TUNED MASS DAMPERS
8E]PSV(IZMGIWWYTTPMIHEXSXEPSJƽYMHZMWGSYWHEQTIVWEWETEVXSJXLMWTVSNIGX
aimed to improve occupant comfort. The outcome was a design that reduced the
VIUYMVIHWTEGI[LMPIQEMRXEMRMRKXVEZIPSJMRGLIWTIEOXSTIEO
4 www.taylordevices.com
169
DIRECT ACTING DAMPING
Open Space
WLMPIRSXWTIGMƼGEPP]YWIHJSVLMKLVMWIFYMPHMRKW8E]PSV
(IZMGIWHSIWSJJIVERSTIRWTEGIGSRƼKYVEXMSRHIWMKRIH
to offer more open bays.
Toggle
Toggle frames can be used as a mechanism to amplify
HIƽIGXMSRW MRXS XLI HEQTIV MR SXLIV[MWI WXMJJ SV XMR]
HIƽIGXMSR WMXYEXMSRW GVIEXMRK E QSVI IƾGMIRX HEQTMRK
system. Toggle Frames utilize a bent-brace mechanism
XLISV] XS GETXYVI HIƽIGXMSRWMR SRI TPERI ERH XVERWPEXI
XLIHIƽIGXMSRWMRXSERSXLIVTPERIERHXLIVIJSVITVSZMHI
ZIV]IƾGMIRXHEQTMRK
Chevron
IRXLMWGSRƼKYVEXMSRXLIHEQTIVWEVITPEGIHLSVM^SRXEPP]
and connected to a frame (chevron) that is intended to be
RIEVVMKMH[MXLXLIƽSSVMXMWGSRRIGXIHXS8LIEHZERXEKI
with this direct damping orientation is that the horizontal
ƽI\MFMPMX] SJ XLI WXVYGXYVI MRNIGXW XLMW JYPP QSZIQIRX
directly into the horizontal orientation of the damper.
However, a small amount of motion can be lost due to the
constraints of the attainable stiffness of an economical
chevron frame.
Diagonal
A very common method of applying distributed damping
to a structure is to connect the dampers to diagonal
corners or center of a structural frame or bay. In this
orientation, the horizontal movement of the structure
EPPS[W ER ERKYPEV GSQTSRIRX SJ XLI JYPP HIƽIGXMSR XS
KSMRXSXLIHEQTIV8LMWXEOIWXLIQSXMSRHMVIGXP]XSXLI
RI\X ƽSSV PIZIP XLVSYKL E WXVSRK XIRWMSRGSQTVIWWMSR
member.
5 www.taylordevices.com
170
PROJECT REFERENCES
Chicony HQ - Taiwan Millennium Place - Boston
7SPYXMSR(MVIGX 8SKKPI
(MEKSREP 7SPYXMSR(EQTIH1IKE&VEGI
&VEGIW
Completion in 2003
Completion in 2002
217 West 57th Street - New York City Park Tower - Chicago
A 100-story mixed-use high-rise A 70-story mixed-use high-rise
located in New York, New York. located in Chicago, Illinois.
7SPYXMSR 8YRIH1EWW(EQTIV[MXL 7SPYXMSR 8YRIH1EWW(EQTIV[MXL
Taylor VDDs Taylor VDDs
171
taylordevices inc.
• With over 700 projects world-wide, we are the • Our policy is to test every single seismic damper
world leader in providing seismic and wind we produce to maximum output requirements
dampers for any structure
• Taylor dampers are designed and tested in output
• Our dampers have been validated through rigorous KTWHJWFYNSLXZUYTRNQQNTSUTZSIX
P3FSI
research, full scale testing and published work by FRUQNYZIJXZUYTNSHMJX
R
highly reputable organizations
• -NLMQ^JKܪHNJSYIFRUJWIJXNLSHFSFGXTWG
• 5WTUWNJYFW^IW^WZSSNSLXJFQXMF[JGJJSVZFQNܪJI tremendous amounts of energy during an
and tested for millions of cycles and are earthquake thus minimizing or eliminating
manufactured only by Taylor Devices damage to the structure
• High strength, mirror polished, stainless steel • Unequalled ability to provide a damper design that
piston rods NXFHHZWFYJHTSYWTQQFGQJJKܪHNJSYYJRUJWFYZWJ
and frequency independent and maintenance free
• Strict control over our design and manufacturing
UWTHJXXJX\NYMWIUFWY^HJWYNܪHFYNTSYT.84 • Taylor dampers have unequalled ability to respond
.84FSIYMJXYWNSLJSYFJWTXUFHJVZFQNY^ to extremely small or very large motions
XYFSIFWI&8
• The only technology that can reduce stress and
• .IJSYNHFQVZFQNY^XYFSIFWIXKTWFQQTZWUWTIZHYX IJܫJHYNTSXNRZQYFSJTZXQ^ IFRUJWKTWHJXFWJTZY
\MJYMJWYMJ^FWJZXJIKTWXUFHJܫNLMYRNQNYFW^ of phase with structural dynamic forces
equipment, buildings or bridges
• 35 year warranty
• 5WTIZHYXHJWYNܪJIG^3&8&FWJST\GJNSLZXJIYT
save lives on ear th
172
taylordevices inc.
173
taylordevices inc.
• Taylor Devices is the world leader in providing • Our policy is to test every single bridge damper we
dampers to control vibrations caused by produce to maximum output requirements
JFWYMVZFPJX\NSIYWFKܪHFSIUJIJXYWNFSX
• Taylor dampers are designed and tested in output
• Our dampers have been validated through rigorous force ratings up to 2 million pounds (8900 kN) and
research, full scale testing and published work by amplitudes up to +/-42 inches (1.06 m)
highly reputable organizations
• Unequalled ability to provide a damper design that
• 5WTUWNJYFW^IW^WZSSNSLXJFQXMF[JGJJSVZFQNܪJI NXFHHZWFYJHTSYWTQQFGQJJKܪHNJSYYJRUJWFYZWJ
and tested for millions of cycles and are and frequency independent and maintenance free
manufactured only by Taylor Devices
• Taylor dampers have unequalled ability to respond
• High strength, mirror polished, stainless steel to extremely small or very large motions
piston rods and 3 part heavy-duty paint system on
external components
• The only technology that can reduce stress and
IJܫJHYNTSXNRZQYFSJTZXQ^ IFRUJWKTWHJXFWJTZY
• Damper output force is proportional to velocity, of-phase with structural dynamic forces
Force = CV ; between 0.2 and 2.0; unlimited
C values available for optimal structural
• Bridge dampers are available with “Lost Motion
Devices or Fuse Elements or Brake Elements” to
performance
eliminate the continuous response to small, every-
• Long stroke bridge dampers have a heavy-wall IF^YWFKܪHFSI\NSINSIZHJI[NGWFYNTSX
steel guide sleeve
• Dampers can also be provided with special stroke
• Identical quality standards for all our products limiting devices or end-of-travel bumpers
\MJYMJWYMJ^FWJZXJIKTWXUFHJܫNLMYRNQNYFW^
equipment, buildings or bridges
174
taylordevices inc.
175
taylordevices inc.
FY[JW^QT\INXUQFHJRJSYXNSHQZINSLMZRFSNSIZHJI • 3TRFNSYJSFSHJT[JWYMJQNKJTKYMJXYWZHYZWJTW
I^SFRNHX^XYJR
[NGWFYNTSKTWGWNILJXFSIGZNQINSLX
• &GXTQZYJ _JWT QJFPFLJ IZJ YT MJWRJYNHFQQ^ XJFQJI
HTSXYWZHYNTS
176
taylordevices inc.
177
OPEN SPACE DAMPER SYSTEM
BY TAYLOR DEVICES
&QQYMJ'JSJܪYXTK)FRUNSL\NYM2NSNRFQ'QTHPFLJTK'F^X
9MNX SJ\ FUUQNHFYNTS TK UWT[JS ܫZNI IFRUJW YJHMSTQTL^ UWT[NIJX FQQ YMJ GJSJܪYX FXXTHNFYJI \NYM
adding damping for seismic and wind protection of structures with minimal blockage of building bays.
Until now, all damping systems such as diagonal braces, chevron braces, wall dampers and toggles braces
would visually and physically obstruct the bays where they are installed, thus resulting in occasional rejection
of the damping system by the architect or owner.
The Open Space Damping System utilizes simple mechanical linkages to allow the system to be located
around the perimeter of the bay, thus resulting in virtually no change in the appearance of the bay.
Simple linkages and mechanisms provide a damping system to remove vibration energy that is effective as a
diagonal brace without consuming an entire bay for implementation of the system.
Extensive seismic testing on the large scale shake table located at the State University at Buffalo SEESL
Laboratory has validated the performance, theory and computational models for the system. Technical
Report MCEER-16-0007 is available upon request and provides complete testing results as well as the system
theory and computational models to be used for analysis of structures with this system.
9MJIWF\NSLFGT[JXMT\XTSJHTSܪLZWFYNTSYMFYNXF[FNQFGQJ8J[JWFQ[FWNFYNTSXTKYMNXHTSܪLZWFYNTSFWJFQXT
available.
Taylor Devices provides complete theoretical and analytical support for system implementation. Contact us
today to engage our services at no cost.
178
Taylor Devices Inc. Contact Us:
90 Taylor Drive | North Tonawanda, NY 14120 Phone: (716) 694-0800
www.taylordevices.com Email: sales@taylordevices.com
01/2020
179
taylordevices inc.
8NRUQJ^JYJKKJHYN[JYMNXKJFYZWJHFSQTHPYMJIJ[NHJKWTRXYWTPNSL\NYMFWJXNXYFSHJKTWHJZUYT
TK
YMJIJ[NHJWFYJIKTWHJ9MNXKTWHJRZXYGJJ]HJJIJIGJKTWJNY\NQQFQQT\YMJIJ[NHJYTXYWTPJ8NSHJYMJ
KTWHJXYMFYWJXZQYKWTR\NSIJ[JSYXFWJY^UNHFQQ^QJXXYMFS
TKYMJJFWYMVZFPJKTWHJYMJ\NSIWJXYWFNSY
WJXYWNHYX YMJ )J[NHJ KWTR XYWTPNSL \MNQJ FQQT\NSL NY YT KZSHYNTS FX F Y^UNHFQ )FRUJW IZWNSL F XJNXRNH
J[JSY
<MJSZXJIYTLJYMJW\NYM)FRUJWXFSIWZGGJWGJFWNSLXFXUFWYTKFGFXJNXTQFYNTSX^XYJRYMNXKJFYZWJ
HFSUWJ[JSYZS\FSYJIRT[JRJSYTKYMJGZNQINSLHFZXJIG^\NSITWYWFKܪH[NGWFYNTSXTSFGWNILJ
This type of device is also useful for very
ܫJ]NGQJ GZNQINSLX \MJWJ NY NX IJXNWFGQJ YT MF[J
YMJ )FRUJW FHY FX F WNLNI QNSP \NYM HMJ[WTS TW
INFLTSFQGWFHNSLJQJRJSYXYTUWT[NIJXYNKKSJXX
KTW \NSI J[JSYX \MNQJ UWT[NINSL IFRUNSL KTW
XJNXRNHJ[JSYX
180
taylordevices inc.
VÚË·æûÃ×½Ʌ]Ëêæ©üJĆcËöÚ
REDUCING MOVEMENT CAUSED BY WIND
.SRTXYXYWZHYZWFQFUUQNHFYNTSXYMJXYJJQTWHTSHWJYJKWFRJTKFGZNQINSLUWJ[JSYYMJGZNQINSLKWTRRT[NSLJSTZLM
YTJSLFLJYMJ)FRUJWX9MJTSQ^YNRJYMFYYMJGZNQINSLMFXXZKܪHNJSYINXUQFHJRJSYYTXYWTPJYMJ)FRUJWXNXIZWNSL
RTIJWFYJYTQFWLJJFWYMVZFPJX
.SXTRJXUJHNFQHFXJX\JJSHTZSYJWFXYWZHYZWJYMFYNX[JW^ܫJ]NGQJTWMFXFZSNVZJIJXNLSYMFYFQQT\XXNLSNܪHFSY
RT[JRJSYIZWNSL\NSIJ[JSYX5WNTWYTYMJIJ[JQTURJSYTKYMJ\NSIWJXYWFNSY)FRUJWXYMFY\JWJNSXYFQQJINSYMJXJ
GZNQINSLXKTWXJNXRNHUWTYJHYNTS\TZQIGJHTSYNSZTZXQ^XYWTPNSLIZWNSL\NSIJ[JSYX&QYMTZLMYMJXRFQQFRTZSYTK
IFRUNSLYMFYNXUWT[NIJIIZWNSL\NSIXYTWRXRF^GJIJXNWFGQJNSXTRJHFXJXYMJWJFWJTYMJWNSXYFSHJX\MJWJYMJ
JSLNSJJWUWJKJWXYTMF[J)FRUJWXFHYFXFWNLNIQNSPIZWNSL\NSIJ[JSYX4SJXZHMHFXJNXYMJ8TZYM'F^4KܪHJ9T\JW
QTHFYJINS8FS/TXJ(&
&ܫTTWX^XYJR\NYMYMNXIJLWJJTKܫJ]NGNQNY^MFXXJ[JWJUWTGQJRX\NYM
\NSIJ]HNYFYNTSXTKZXNGQJXYJJQGZRUJWGFWX\JWJUWJ[NTZXQ^NSXYFQQJI
YT UWJ[JSY \NSI X\F^ 9MJXJ RFPJXMNKY GFWX \JWJ RJFSY YT WJXYWFNS
YMJ ܫTTW RT[JRJSY ZSIJW STWRFQ \NSI J]HNYFYNTS FSI \JWJ NSYJSIJI
YT GWJFP FSI UJWRNY KWJJ ܫTTW RTYNTS NS FS JFWYMVZFPJ 9MJXJ GFWX
Located at 3031 Tisch Way in San Jose, CA, the South
\JWJ WJUQFHJI G^ 9F^QTW \NSIWJXYWFNSY IFRUJWX KTW NRUWT[JI X^XYJR -L1;$o;ubvom;o=v;;u-Ѵ0bѴ7bm]v|ov;-
vvr;m7;7Yoouvv|;lĺ
WJQNFGNQNY^FSIWJXUTSXJ\NYMIFRUJIRT[JRJSYXIZWNSLFSJFWYMVZFPJ
.S TWIJW YT UWJ[JSY \NSI X\F^ NY \FX ST\ SJHJXXFW^ YT FII F \NSI WJXYWFNSY YT YMJ )FRUJWX &KYJW J]YJSXN[J
J]UJWNRJSYFYNTS9F^QTW )J[NHJX IJ[JQTUJI F GFSIY^UJ KWNHYNTS HQFRU YMFY UJWKTWRJI \JQQ FSI MFI [JW^ QNYYQJ IWNKY
ZSIJWYMJQTFIXFXXTHNFYJI\NYM\NSI9MNXY^UJTK\NSIWJXYWFNSYHFSUWT[NIJWJXYWFNSNSLKTWHJZUYT
TKYMJWFYJI
KTWHJKTWF)FRUJW8NSHJYMJKTWHJIJ[JQTUJINSYMJ)FRUJWXFXFWJXZQYTK\NSINXY^UNHFQQ^QJXXYMFS
TKYMJKTWHJ
YMFYNXUWTIZHJIG^YMJRF]NRZRHWJINGQJJFWYMVZFPJF\NSIWJXYWFNSYXJYFY
TKYMJWFYJIKTWHJNXY^UNHFQQ^
XZKܪHNJSYYTUWJ[JSYYMJ)FRUJWKWTRXYWTPNSL&SFIINYNTSFQGJSJܪYTKYMNXY^UJTKWJXYWFNSYNXYMFYNYNXWJZXFGQJFKYJW
FSJFWYMVZFPJZSQNPJF^NJQINSLWJXYWFNSYYMFYRZXYGJWJUQFHJIFKYJWFSJFWYMVZFPJ9MJ\NSIWJXYWFNSYFQXTWJYFNSXNYX
XJYYNSLFKYJWIJHFIJXTKNSFHYN[NY^FSIFQQT\XYMJIJ[NHJYTFHYQNPJFY^UNHFQ)FRUJWIZWNSLFXJNXRNHJ[JSY
181
182
15 Building and Bridge Projects
Figure 15.1
Typical fluid viscous damper
183
8. End Clevis: Heat-treated alloy steel; painted for corrosion protection.
9. Spherical Bearing: Forged from aircraft quality alloy steel, hand fitted and checked
for clearance.
10. Outer Sleeve: Carbon steel, painted for corrosion protection.
2.0 Handling
Although Taylor Devices dampers are very robust in design, care should be taken when handling a
damper. This section gives the recommended handling procedures.
2.1 Shipping
Each damper shall be placed on a wooden skid for shipping and secured with metal banding and blue
shrink-wrap. The skid must remain upright (The 4x4 wooden feet down) at all times to help prevent
damage to the dampers. DO NOT STACK THE SKIDS.
2.2 Storage
The dampers may be stored on their shipping skids for an indefinite period if they are kept in a
suitable environment. The wooden shipping skids will deteriorate over time unless they are kept in
a relatively dry environment.
2.3 Lifting
The dampers will be shipped on wooden skids. See section 7.0 of this manual for the weight of the
dampers. Each skid must be lifted in two locations with an evenly distributed force as typically
performed with a fork truck.
After carefully removing the shrink-wrap and metal banding, the damper may be lifted from its skid
by a single strap located at its balancing point. Care must always be taken when moving a damper
so that there is no damage to the factory fill port that protrudes out of the cylinder.
3.0 Installation
Taylor Devices' Fluid Viscous Dampers are easily installed with a minimum of tools required. For a
Viscous Damper used in a structure, connection points of the damper are as indicated in Section
1.0 and shown in Section 7.0. Refer to Section 7.0 of this manual for drawings of the Fluid Viscous
Dampers and their mounting hardware.
184
• Hammer (2 to 4 lb.)
• Light marine grease (Taylor Blu-Grease supplied with dampers)
• Hoist device with straps
3.3 Damper length adjustment using the available adjustment for Taylor Devices Part
Number 67DP-17170-01
The dampers will be shipped in a mid-stroke position that is shown on the drawings in section 7.0
of this manual. This is the length that should be set between the centers of the holes in the clevis
plates where the damper mounting pins will be attached through. The damper units are equipped
with an adjustment nut that allows for mechanical adjustment of ±½ in. The clevis is free to rotate
for ±½ in of adjustment (each 180o rotation is equal to 0.083 in). After the damper has been adjusted
to the correct length tighten the adjustment set screw to lock the threads. DO NOT exceed ±½ inch
adjustment in either direction. If further length adjustment is required, the damper must be stroked.
The Engineer of Record must approve any use of damper stroke for length adjustment.
185
3.4 Using Damper Stroke for Adjustment Consult the Engineer of Record
Compression - To compress the FVD is slightly more difficult. The FVD can be lifted, as previously
described, by one end and then set down on the ground on the opposite end. Additional weight may
need to be placed on the top clevis as necessary. Care must be taken to avoid damage to the unit,
or toppling/collapse of this setup.
Note that a force of approximately 2%-4% of the maximum rated force of the damper may be
necessary to overcome internal seal gripping forces and allow stroking of the damper.
4.0 INSPECTION
186
discernable or unordinary situation is observed at any time, please consult the factory:
PHONE: 716-694-0800
FACSIMILE: 716-695-6015
5.0 MAINTENANCE
All Taylor Devices Fluid Viscous Dampers have the main cylinder cartridge sealed at the factory and
no field repair or maintenance can be performed. If the damper sustains any damage, the damper
must be returned to the address below:
Taylor Devices' personnel will then contact the owner of the damper concerning the status of
the device.
5.2 Painting
For aesthetic value, the dampers can be repainted if a different color is desired or if any surface
irregularities develop on painted surfaces. The spherical bearings and rod should not be painted.
External surfaces that can be repainted have been factory painted with a corrosion resistant primer,
top color black. All other surfaces are to be carefully covered and masked to prevent paint spray
from contacting these surfaces and from entering the sleeve or spherical bearing assemblies. Always
be sure to remove all masking tape after paint has dried. Failure to remove masking, or painting
surfaces not recommended for painting; could cause improper function of the damper. Feel free
to consult the factory, should there be any additional questions or concerns. Paint information is
included in section 7.0 of this manual for reference.
187
WARRANTY
Taylor Devices Fluid Viscous Dampers
SELLER warrants the fluid viscous dampers against defects in materials and workmanship
under normal use and service for a period of thirty-five (35) years from the date of
installation. Surface coatings are excluded from this warranty.
SELLER warrants that the damping coefficient of the dampers will be within ±15% of
the design value at 70°F within the warranty period. Any obligation under this warranty
terminates if the fluid dampers are directly exposed to fire, flood, or if an earthquake
occurs which exceeds the specified Design Earthquake level. In such instance, BUYER
may reactivate the warranty by hiring SELLER to inspect all fluid dampers and for BUYER
to pay SELLER to recondition any fluid damper that is deemed required.
This warranty shall not apply to any of the SELLER's products which must be replaced
because of normal wear, which have been subject to misuse, negligence or accident or
which shall have been repaired or altered outside of the SELLER's factory unless authorized
in writing by the SELLER.
The benefits to BUYER of this warranty are expressly conditioned upon BUYER's care,
inspection, and maintenance of the fluid damper in strict accordance with SELLER's
inspection and maintenance requirements.
DISCLAIMER OF WARRANTIES
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED,
IMPLIED, WRITTEN, OR ORAL, INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTY OR MERCHANTABILITY OR FITNESS AND IS PROVIDED IN LIEU OF
ALL OBLIGATIONS AND LIABILITIES OF SELLER WITH RESPECT TO DEFECTS
IN MATERIALS OR WORKMANSHIP. THE RIGHTS AND REMEDIES CONTAINED
IN THIS WARRANTY EXCLUDES AND WAIVES ANY RIGHT OF BUYER TO
CONSEQUENTIAL OR INCIDENTAL DAMAGES.
188
189
Figure 15.2
Lock Up Device Drawing
Figure 15.3
Pin Kit Drawing
190
Figure 15.4
Pin Kit Assembly
191
Figure 15.5
Retaining Ring Installation
192
Figure 15.6
Typical Paint Technical Data Sheet
193
194
Appendix A
Case
Studies
195
CASE STUDY: 1
Under the state code, any essential facility (in this case an acute
care hospital) requires the importance factor “I” to be 1.5 when
designing a new building. Similarly, when evaluating or
retrofitting an existing building, a higher performance criteria
is utilized. The higher seismic criteria result in more extensive
retrofits compared to similar buildings under the same hazard.
California has always been in the forefront of seismic
protection by demanding stricter regulations to protect lives
and property. Essential facilities, such as hospitals, came under
regulation after passage of the Alfred E. Alquist Hospital
Seismic Safety Act post 1971’s Sylmar earthquake. Senate Bill
(SB) 1953 and subsequent regulations have provided timelines Figure 1b: Timeline of Hospital Upgrades in California
and performance objectives that hospitals should meet to contd.
comply with California State’s overall goal of ensuring the
196
2017 SEAOC CONVENTION PROCEEDINGS
Note: Figure re-printed from webinar by California Hospital category provides an alternate path to compliance beyond
Commission on May 2015 2030.
Table 2.5.3 of the California Administrative Code (CAC) American Society of Civil Engineers (ASCE) 41-13 defines
defines the Structural Performance Categories (SPC) in more the different performance levels and CBC 2016 outlines the
detail (Figure 1c). It is worth noting that an existing building objectives for each performance level. As part of this case
could only be upgraded from an SPC-1 to an SPC-2 or SPC-5. study these objectives and criteria were performed for three
However, in recent years OSHPD has defined an intermediate different performance categories: SPC-2, SPC-4D, and SPC-5.
category SPC-4D that can be used to retrofit an existing
building. This new category is expected to yield a similar • SPC-2: Life Safety structural performance level in
seismic performance level as SPC-4. accordance with § 2.3.1.3 of ASCE 41-13 at BSE-1E
hazard. BSE-1E hazard corresponds to a return period
The retrofit example is a six story steel moment frame of 225 year.
building, which was erected in 1972. OSHPD designated the
building as an SPC-1 due to significant structural deficiencies. • SPC-4D: Damage Control structural performance
The project’s general contractor provided pricing to upgrade level in accordance with § 2.3.1.2.1 of ASCE 41-13
the building to structural performance categories: SPC-2, SPC- at BSE-1E hazard and Collapse Prevention structural
4D and SPC-5. See Table 1 for reference. What follows is an performance level in accordance with § 2.3.1.5 of
analysis of project’s potential seismic upgrades and their ASCE 41-13 at BSE-2E hazard. BSE-2E hazard
associated costs. This type of analysis is recommended for corresponds to a return period of 975 years
assisting building owners, as they make critical safety and
financial decision to make seismic upgrades. • SPC-5: Immediate Occupancy structural
performance level in accordance with § 2.3.1.1 of
Table 1: Snapshot from CAC Table 2.5.3 for SPC ASCE 41-13 at BSE-1N hazard and Life Safety
description performance level in accordance with ASCE 41-13 §
2.3.1.3 at BSE-2N hazard. BSE -1N corresponds to a
return period of 475 years, and BSE-2N corresponds
to a return period of 2,475 years.
197
2017 SEAOC CONVENTION PROCEEDINGS
198
2017 SEAOC CONVENTION PROCEEDINGS
returning Architectural-Mechanical-Electrical-Plumbing
(AMEP) fixtures back after necessary removals (if any) to
conduct the retrofit. Finally, ADA projects are upgrades that
are triggered by code for seismic upgrade projects.
STRUCTURAL COST
$30 $234 /sf
$222 /sf
199
2017 SEAOC CONVENTION PROCEEDINGS
$17.2
$17.0
$16.8
$137 /sf TOTAL COST
$16.6 $800 /sf
$16.4 $100
$90
$16.2
$80
$16.0
$70
Millions
200
2017 SEAOC CONVENTION PROCEEDINGS
References
201
CASE STUDY: 2
202
Factors enhancing seismic performance requirement is not met for the Type D columns shown in
the plans. This code requirement is intended to prevent
The structure under consideration has several key design buckling of longitudinal reinforcement at locations of high
features that enhance its earthquake resistance, including the seismic loading.
following:
Joint eccentricity. Eccentricity in the line of action
between beams and columns will amplify loading on the
Structural configuration. The building is regular in plan,
members.
with no re-entrant corners or vertical off-sets. Regular
buildings have performed well in past earthquakes. Seismic performance of existing building
Close stirrup spacing at the beam-to-column joints. The
Overview
plans show stirrup spacing of 4-in. on center for beams
and tie spacing of 3.25-in. on center at the joints. The
ASCE 41-13 (ASCE 2014) provides comprehensive
reinforcement is shown with 135-degree hooks. Such
requirements for seismic evaluation and upgrade of existing
close spacing of transverse reinforcement would prevent
buildings and was used for this structure. Computer program
the buckling of reinforcement at the location of highest
ETABS (CSI 2016) was used to prepare a three-dimensional
seismic stress.
mathematical model of the building; see Figure 2. This model
was used to assess the performance of the existing building
Factors decreasing seismic performance moment frames. Nominal material properties, spans and
member sizes specified in the original construction documents
The structure under consideration has several key design were used in analysis. Dimensions were based on centerline
features that reduce its earthquake resistance, including the dimensions provided in the drawings. Gravity loading on the
following: building is composed of member self-weights, design live load
and additional dead load to account for non-structural
Soft-story response. The first story of the building is elements such as flooring, ceiling, and duct work, which is
approximately 50% taller than the stories above. distributed uniformly on floor slabs. The concrete floor
Buildings with such configuration can be vulnerable to diaphragms are modeled as rigid, meshed shell elements. The
earthquake damage because the deformation and damage seismic loading was based on values obtained from the USGS
is concentrated at the first floor, while good design web site for the design earthquake (475-year event).
typically results in uniform distribution of lateral
deformation among all floors.
Transverse reinforcement. The beams have stirrup spacing
of 18-in. and 13-in. on center near midspan at the second
level and above, respectively. The mid-height column tie
spacing is 12-in. on center. These values exceed the
current code limits and can lead to premature failure in
some members.
Shear capacity of beams. Beams are constructed of
lightweight concrete and use No. 3 or 4 transverse bars
spaced 18 in. or 13 in. on center at middle third of the
members, thus having limited shear capacity. Modern
codes attempt to mitigate shear failure by requiring ductile
flexural damage prior to shear failure.
Splices and development length. The tension lap splices
for the beams do not meet the current code requirements.
The column #18 to #14 longitudinal bar splices use cold-
welded couplers. Inadequate splice and development
length can lead to bar pullout and prevent reinforcement
from reaching its capacity.
Column ties. The code requires that every other Figure 2. Mathematical model of the building
longitudinal reinforcement have a tie around it. This
203
Building codes allow for both linear and nonlinear analysis. measures should be considered for the first floor or two. For
When linear analysis is used, there are certain conservatisms multistory non-ductile reinforced concrete buildings, drifts
built into the results to account for the modeling and analysis need to be kept to 1.5% or lower.
assumptions. By contrast, nonlinear analysis attempts to
model the behavior of the building and its components in Pushover analysis
greater detail, resulting in greater accuracy of the results,
thusly requiring less conservatism. For this structure, Preliminary nonlinear analysis of the structure was conducted.
nonlinear analysis was utilized to compute capacities and the For this analysis, it was assumed that all reinforcement as
principal of equal displacement was applied to demands. In shown in the plans will be fully developed and that bending
other word, displacement-based (or performance-based), nonlinearity would only occur near the joints. Additionally,
rather than force-based, methodology was employed. given the low capacity of concrete beams in shear, the model
incorporated nonlinear elements at midspan of the beams. Key
Story drift ratios (SDRs) findings are summarized in Table 1.
Figure 3 presents the computed drift ratios at the design Key pushover analysis results
earthquakes. Drift ratios are one of the most telling parameters
in evaluating the response of a building, as they correlate Displacement, in SDR %
directly to the demand on structural members and drift-
sensitive structural components, such as partitions. The Step Level X- Y- X- Y-
building codes place limits on drifts at the design-level Existing Roof 17.0 20.0
1.9 2.2
earthquake. building L1 3.9 4.5
Onset of Roof 14.0 13.0
200
1.6 1.4
180
damage First 3.2 2.9
160 X‐
Y‐ The deformed shapes of the perimeter frame for the building
140
in its existing condition during design earthquake is shown in
120 Figure 4.
Elevation, ft
100
80
60
40
20
0
0.0% 0.5% 1.0% 1.5% 2.0% 2.5%
Drift ratio, %
Drift ratio in the Y- (transverse) direction are larger than Examination of Table 1 and Figure 4 indicates the following:
in the X- (longitudinal) direction. This is because there are The building in its existing condition (without upgrade)
fewer moment frame bays in the Y-direction. will experience damage when subjected to the design
Drift ratios at the first floor are the largest because of the earthquake
soft story present at this level. First floor drift in the Y- The major damage will be primarily limited to the first
direction exceeds 2%. floor. Since damage is concentrated at one level only, this
For multistory non- or low-ductile reinforced concrete can lead to instability and collapse.
moment frame buildings, the target drift ratio is typically set If the first floor displacement is reduced below
at approximately 1% to 1.5%. At 1% or below, the structure approximately 2.9 in. (1.4% drift), then damage is
is unlikely to experience any damage. The 1.5% value is essentially eliminated.
referred to as nearly elastic—implying that there will be some
small level of nonlinearity but the damage is likely to be
localized and minor. A review of Figure 3 shows that upgrade
204
Seismic upgrade with fluid viscous dampers
Fluid viscous dampers, were used as the upgrade solution.
Dampers possess the following characteristics:
80
Overview 60
40
The analytical model of the building was revised by adding 8
dampers per floor for the bottom story; see Figure 5 and Figure 20
205
200 400
180
300
160 Existing
Retrofitted 200
140
100
120
Elevation, ft
Force, kips
100 0
80
‐100
60
‐200
40
‐300
20
0 ‐400
0.0% 0.5% 1.0% 1.5% 2.0% 2.5% ‐3 ‐2 ‐1 0 1 2 3
Drift ratio, % Displacement, in.
Figure 8. Computed drift ratios (Y direction) Figure 10. First floor damper force-displacement
response
The effectiveness of the damper upgrade solution can further
be seen in Figure 9, where the significant reduction in first Risk (PML) analysis
floor displacement and nonlinear structural damage can be
seen. Probabilistic risk analysis was conducted to compute the
5 probable maximum loss (90% confidence PML) and the
4
Existing scenario expected loss (50% confidence SEL) of the structure
Retrofitted
Limit before and after upgrading. A similar analysis was conducted
3
previously by URS Corporation. The results are presented in
2 Table 2 for both studies.
Displacement, in.
0 PML SEL
‐1 Existing 31 14
‐2
Upgraded 19 9
‐3
Scenario-based risk analysis (design
‐4
earthquake)
‐5
0 5 10 15 20
Time, sec
The following is noted:
Figure 9. Displacement of existing and upgraded
models, First floor, Y-direction
The reduction in PML and SEL for the upgraded building
is more pronounced due to the differences in upgrade
As shown in Figure 10, viscous dampers dissipate a significant
approaches proposed. The URS proposed upgrade
amount of the earthquake input energy. In the absence of
consisted of wrapping the mid-sections of all frame beams
dampers, such energy must be absorbed by the existing
and columns. While this approach is effective in providing
reinforced concrete members through nonlinear action and
confinement and increasing shear capacity of the concrete
structural damage.
members, it does not reduce the seismic demand or soft-
story behavior. With the proposed upgrade using dampers,
the soft-story behavior is mitigated and demand on the
existing members is reduced to near-elastic levels. Thus
concerns regarding the member ductility are no longer
applicable.
206
Seismic Risk Analysis Procedure viscous dampers. The key input parameters include story drift
ratio, peak floor acceleration, and residual drift; see Figure 13
The FEMA P-58 (FEMA 2012 and SP3 2016) methodology is through Figure 14.
a probabilistic approach that combines the site-specific hazard,
building properties, and exposure to estimate key response
parameters, including the 90th-percentile repair cost in the
event of the design (475-year return period) earthquake. The
simulation for this project included 10,000 Monte Carlo
analyses.
Site Hazard
The input data for building properties were based on the results
from the structural analysis of the building retrofitted with
207
Median and 90% repair cost
Sa (3.6s) Mean Median 90th percentile
(g) repair cost repair cost repair cost
8% 12% 6% 12%
Project status
208
Conclusions
References
209
CASE STUDY: 3
Abstract Introduction
This paper presents the nonlinear seismic analysis, This paper presents the performance-based evaluation
development, and implementation of an innovative and retrofit design of the Hotel Stockton. The 145,000-sf
seismic retrofit strategy for a six-story nonductile (13,470 m2) reinforced concrete building, built in 1910
reinforced concrete 145,000-sf (13,470 m2) historic in Stockton, California, is a torsionally irregular
building. Dynamic and nonlinear static analytical results structure comprised of a six-story portion connected to a
verified that the building had a weak soft-story with two-story portion. There was significant concern that
inadequate post-yield capacity, and large torsional the building will not be able to withstand the level of
response. The analysis indicated that the existing earthquake shaking expected at the site for two reasons:
building is not seismically adequate to withstand a weak and soft lateral force resisting system at the first
anticipated lateral forces generated by earthquake floor level, and the inadequate confinement of
excitations at the site. A “collapse prevention” reinforcement in the first story columns. To assess the
performance upgrade for a 475-year return event was performance of the structure, a detailed mathematical
desired. Nonlinear fluid viscous dampers were placed at model of the building was prepared based on FEMA 273
the first story level to reduce the seismic demand and guidelines. Dynamic and nonlinear static analytical
obtain a more uniform response. Visco-elastic fluid results verified the presence of the soft-story response,
viscous dampers were strategically placed at one side of inadequate post-yield capacity, and large torsional
the building to reduce the torsional irregularity of the response. The analyses indicated that the existing
building. The proposed cost effective, state-of-the-art building is not seismically adequate to withstand
retrofit will improve the seismic performance of the anticipated lateral forces generated by earthquake
building. excitations at the site. The existing structure will suffer
substantial damage and possible collapse in the event of
a major earthquake.
210
To address the above-mentioned inadequacies, the E-W direction and 100 ft (30.5 m) in the N-S direction.
Owner decided to undertake a voluntary seismic upgrade In elevation, it is comprised of a six-story portion on the
of this building. The focus of the seismic rehabilitation east side and a two-story portion on the west side, and
was to address the major deficiencies of the structure, has a full basement. The first story is 18 ft (5.5 m) high
namely the soft-story and torsional response of the and the remaining floors have a story height of 10’-3”
building. The main objective was to provide a “collapse (3.1 m). Figure 1 below shows a south elevation of the
prevention” performance goal during a 475-year return eastern portion of the building.
event. Nonlinear fluid viscous dampers were placed at
the first story level to reduce the seismic demand and In the E-W direction, the building consists of 15 bays at
obtain a more uniform response. Visco-elastic fluid approximately 20-ft (6.1-m) spacing. In the N-S
viscous dampers were strategically placed at one side of direction, there are five bays at approximately 20 ft (6.1
the building to reduce the torsional irregularity of the m) per bay, see Figure 2. The structure is a cast-in-place
building. Finally, the first story interior columns reinforced concrete building. Reinforced concrete
supporting the six-story portion of the building were columns, beams, and shear walls comprise the gravity
wrapped with a fiber-reinforced polymer composite and lateral load resisting system. The basement columns
(FRP). A new mathematical model was prepared are 18- and 20-in. (457 and 508 mm) square for the two-
incorporating the seismic upgrades, and was subjected to story and six-story segments of the building,
nonlinear time history analyses using three sets of two- respectively. At the ground floor and above, column
component, independent acceleration histories derived sizes vary from 18-in. (457 mm) square at the first story
from a site-specific acceleration spectrum. Evaluation of to 14-in. (356 mm) square at the fifth story. There is a
the analytical results of this model showed that the story full 9-in. (229 mm) thick concrete perimeter wall
drift for the first floor was significantly reduced, the between the basement and the first floor, and there are
torsional response was nearly eliminated, and all numerous 6-in. (152 mm) thick concrete walls between
structural members remained elastic. the floors above the second floor. However, there are no
structural walls between the ground and the second floor
Description of Structure levels. Typical floors consist of 4-in. (102 mm) concrete
slabs with a 2-in. (51 mm) topping slab supported by E-
The Hotel Stockton, built in 1910 as a 252-guest room W concrete beams, and N-S concrete girders.
hotel, is a historic landmark building in Stockton,
California. The building, also referred to as The Although the as-built plans of the structure are not
Stockton, measures approximately 300 ft (91.4 m) in the available, field investigations have shown that the
211
columns typically have four and eight longitudinal MPa), per FEMA 273. A yield value of 36 ksi (250
reinforcing bars around the perimeter of columns at the MPa) was used for the column ties.
two-story and six-story segments, respectively. Typical
• Frame elements. All columns were modeled as
minimum concrete cover for the reinforcement is
square sections with longitudinal bars in a circular
approximately 2 ½ to 3 in. (64 to 76 mm). The ground-
pattern. Girders and beams were modeled as
to-first story columns have eight 1-in (25 mm) square
rectangular sections with the section depth measured
bars. Typical transverse ties consist of 1/8-in (3.2 mm)
from the top of the topping slab. T-beam action from
thick by 1-in (25 mm) wide bars at 8 in. (203 mm)
the floor slab was neglected. All dimensions were
spacing.
specified as centerline-to-centerline – (i.e. no rigid
end offsets were specified). The perimeter basement
walls and wall segments between the floors were
212
318-99 were used to determine the axial force- columns should remain elastic.
biaxial moment yield surface. For the nonlinear
• Gravity loading. Gravity loads used in the model
analysis, the column plastic hinge properties are a
consisted of the self-weight of the structure, 0.02 ksf
function of column slenderness, transverse
(0.96 kPa) for partitions, 0.025 ksf (1.20 kPa) for
reinforcement (size, spacing, and anchorage), and
weight of the 2-in. (50-cm) topping slab, and 0.005
axial and shear demand. For the columns under
ksf (2.40 ksf) for miscellaneous (e.g., fans, vents,
consideration, the axial force ranges between 10-15
plaster). Live loads consisted of typical code
percent of the nominal compressive strength, and
prescribed floor loads.
flexure is the controlling response. The shear force is
less than three times the nominal shear strength, and • Inertial mass. The mass of the structure consisted of
the columns have poor confinement (transverse all structure dead loads and one half of the partition
reinforcement). Since the lap splices for the loads. The code-mandated 5-percent eccentricity
longitudinal reinforcement are not fully developed, was achieved by offsetting the floor mass. The total
sudden strength degradation may occur after the inertial weight (mass) of the structure is
onset of the nonlinear behavior. Therefore, hinge approximately 14,000 kips (64,050 kN).
formation (yielding) should be avoided, and subject
213
Earthquake Histories from the horizontal components of each of the three
recorded earthquake records to the target spectra, and
Site investigations were used to determine the site- then base-line correcting in the time domain. The
specific acceleration spectra. The Design Basis records were derived from the 1989 Loma Prieta
Earthquake (DBE) spectra (10% probability of earthquake (0- and 90-degree components recorded at
0.8
0.6
Spectral Acceleration (g)
0.4
0.2
0.0
0.0 1.0 2.0 3.0 4.0
Period (sec)
0
-0 . 1
-0 . 2
0 5 10 15 20 25 30
t im e , s e c
0 .8
0 .6
sa, g
0 .4
0 .2
0
0 0 .5 1 1 .5 2 2 .5 3 3 .5 4
p e rio d , s e c
214
Analytical results of the existing building
building torsional component to this mode. In particular, the
largest deformation occurs at the far right (east) side of
Dynamic analysis. A modal analysis of the building was the building. This torsional response will place
conducted to determine the fundamental period and additional demand on the columns at this side of the
mode shapes of the structure. Table 1 summarizes the structure.
results for the first three modes obtained. The first two
mode shapes of the building are shown in Figure 6a and Nonlinear pushover analysis. To assess the performance
6b. It is noted that the response is that of a soft-story of the building to seismic loading, a nonlinear static
structure with nearly all the deformation concentrated in analysis was conducted. The structure was initially
the first story columns. loaded to a gravity loading equal to 110% of the dead
load and 27.5% of the unreduced live load. Next, step-
Table 1 by-step lateral loading in the x- and y- directions were
Mode Period (sec) Principal direction applied to the structure. Two separate and independent
1 1.2 Transverse (N-S) lateral load patterns were considered: (1) a force pattern
2 1.0 Longitudinal (E-W) matching the mode shapes with 100% and 30% loading
3 0.9 Torsion in each direction and (2) uniform force pattern with
100% and 30% loading in each direction. For the
Ground Level
215
Two particular events of interest were studied: (1) when
does the first plastic hinge form in each direction, and The displaced structure at a story displacement of 1.5 in.
(2) what is the ultimate configuration of the plastic (38 mm) for loading along the longitudinal-axis (Figure
hinge? (The plastic hinges are identified by circles on 9a), and 2.5 in. (64 mm) for loading along the
the columns.) The displaced shape of the structure at the Transverse-axis are shown (Figure 9b). Note that many
formation of the first column plastic hinge is shown in of the first story columns have formed plastic hinges at
Figure 8. The frame elevation on the left corresponds to the top and bottom. The soft-story behavior of the
the formation of the first plastic hinge when the structure building is made clear in the figures; all the floors above
is pushed along the longitudal-direction. This yielding the second floor have a nearly rigid behavior, while the
response occurs at a displacement of 0.84 in. (21 mm), first story columns experience substantial deformation.
measured at the second floor level. The frame elevation
on the right corresponds to the formation of the first Figure 10 shows the second floor plan view of the
plastic hinge when the structure is pushed along the structure at the deformation level of 2.5 in. (64 mm) as
transverse-direction. This yielding response occurs at a the structure is pushed in the transverse-direction. It is
displacement of 1.44 in. (37 mm), measured at the right noted that all the nonlinear behavior is concentrated at or
(east) side of the second floor level. In summary, as close to the right (east) side of the building. As
long as the second floor displacements are limited to the previously noted, the building is torsionally irregular in
values specified above, it is expected that the column the transverse direction.
response for the critical first story columns will remain
in the elastic range.
216
Figure 10: Progressive Hinge Formation (Plan)
Linear time history analyses. To investigate the Performance Goal. Since this is a voluntary seismic
performance of the building during a 475-year return upgrade, the focus of the seismic rehabilitation is to
event (DBE), the structure was subjected to acceleration address the major deficiencies of the structure, namely,
time histories. Study of the three motions revealed that the soft-story and torsional response of the building.
the San Marino record produced the most severe test for The retrofit will limit the response of the structure to
the structure (i.e., the largest values of column stress and linear elastic behavior; that is, limiting the maximum x-
story drift). As such, this record will be used for the and y-components of the second floor displacement to
remainder of this paper for comparison purposes. 0.85 in. (22 mm) and 1.44 in. (37 mm), respectively.
This will give an adequate level of confidence against
The three dimensional linear model was subjected to this collapse of the structure. The main performance goal is
accelerogram. Figure 11 shows the second floor to provide a cost-effective “collapse prevention”
displacements as measured at the lower-right (S.E.) performance upgrade during a 475-year return event
corner of the building. Using equal displacement (DBE).
assumption, a comparison of the time history response of
the existing building with that of the nonlinear pushover Retrofit method
analysis indicates that the story drifts will cause
significant plastic rotation in the hinge regions of the To meet the selected performance goals for the upgrade
columns, and cause probable collapse of the building.
5.0
2.5
Displ, in.
0.0
-2.5
-5.0
0 10 20
Time, sec
217
of this structure, a retrofit approach combining several were considered for the upgrade, however, this approach
state-of-the-art strategies was utilized. necessitated using relatively large devices to meet the
performance criteria. In addition, this did not address
1. Reduce the soft-weak story effects by increasing the
the torsional irregularity of the building. To mitigate
effective damping of the structure. This objective
these problems, two types of devices were utilized:
was achieved by employing Fluid Viscous Dampers
nonlinear fluid viscous dampers were used in 16 braced
(FVD) at the first floor.
bays, and a combination of nonlinear fluid viscous
2. Reduce the torsional response of the building dampers in parallel with elastic elements (herein referred
without increasing acceleration demand of the super to as fluid visco-elastic dampers, or FVEDs) was utilized
structure. This was achieved by adding fluid visco- in four braced bays. The table below summarizes the
elastic dampers at the east side of the structure. pertinent properties of the devices.
3. Provide a more redundant story shear capacity in the
Table 2: Damper Properties
upper floor transverse direction. In the transverse
Device No. DBE c, k-sec/in α K, k/in
direction, the building has structural walls at the
Capacity, (kN- (kN/mm)
exterior walls only. Therefore, wood shear walls
kip (kN) sec/mm)
were added for the upper six story portion of the
FVD 16 210 (934) 100 (35) 0.5 None
building. These walls will act in a fashion
FVED 4 300 (1334) 125 (44) 0.5 144 (50)
analogous to cross-walls in an unreinforced masonry
(URM) bearing wall building. Additional columns at either end of the diagonal devices
will prevent the transfer of the damper forces to the
4. Provide redundancy for the gravity load-carrying existing building columns. Figure 12 shows a typical
capacity of the columns along the right (east) side of damper frame elevation.
the structure. Addition of steel columns for the FVD
braces adjacent to all the columns along this gridline
met this goal.
5. Increase ductility of all the interior first story
columns for the 6-story segment of the building. To
meet this criterion, fiber-reinforced polymer
composite (FRP) was wrapped around the hinge
regions (top and bottom) of the columns.
Structural upgrade
218
1. Urethane Elastomers provides consistent mechanical incorporating the dampers were performed. The
properties through a temperature range of 0ºF to mathematical model of the existing building was
225ºF (-18ºC to 107ºC). modified by adding the sixteen FVDs and the four
FVEDs. Two time history cases were considered. In
2. Urethane exhibits compressive capacity of 80 ksi
one case, the mathematical model was preloaded by a
(552 MPa) without molecular damage and elasticity.
static load equal to 90% of the total dead load prior to
3. Aging under static stress has no effect on mechanical being subjected to the lateral accelerations. In the
properties if protected from ultraviolet light. second case, the preload equaled 110% of the dead load
4. Flame resistance is sufficient to meet Federal and 27.5% of the unreduced live load. The envelope of
Aerospace Regulation 25.853B. response quantities was then obtained by selecting the
maximum values from the two load cases.
See Figure 13 for FVED and FVD construction.
Response evaluation. To evaluate the seismic response
Prototype testing per FEMA 273 will be conducted to
of the upgraded structure, the displacement response of
verify response and durability.
the second floor was examined and a stress check of all
FVED FVD
Figure 13: FVED & FVD Devices
Response of the retrofitted structure first story columns was performed. Figure 14 shows the
second floor displacement responses for the lower-right
To assess the effectiveness of the proposed building (S.E.) corner. It is noted that the maximum computed
upgrade, nonlinear time history analyses of the structure displacements are approximately 0.56 in. (14 mm) and
Displacement History
1.0
0.8
0.6
0.56
0.4
Displacement, in.
0.2
0.0
-0.2
-0.4
x-Direction y-Direction
-0.6
-0.8
-0.85
-1.0
0 5 10 15 20
Time, sec
219
0.85 in. (22 mm) in the longitudal transverse directions, structure was upgraded with a combination of sixteen
respectively, which is well below their target values. nonlinear fluid viscous dampers, four nonlinear fluid
This corresponds to story drift ratios of approximately visco-elastic dampers, and fiber reinforced polymer wrap
0.003 and 0.004, respectively. A comparison of the at selected columns. The analytical studies predict that
displacement response for the original structure and this the retrofitted structure will have a significantly
figure shows that the maximum response was reduced by improved performance when compared to the existing
more than a factor of five by the addition of FVD and structure. In particular, the upgrade will limit the
FVED elements. response of the existing members to the linear range by
limiting the expected seismic demand on the structure.
Finally, the computed axial force in the columns was This upgrade will reduce the risk of building collapse.
examined. No net axial tension was found in the Total seismic upgrade cost was $1.3 million ($9/ft2,
existing columns. The maximum force in the FVD was $96/m2), which was about 5% of total construction
less than 200 kips (890 kN). As such, the 200-kip (890 budget ($24 million, $165/ft2, $1780/m2).
kN) dampers used are adequate for these 16 damper
200
100 Elastomer 86
Response
Force, kip
-100 Combined
Viscous
-200 Response
-2 4 9
-300
-0.5 -0.4 -0.3 -0.2 -0.1 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7
Displacement, in.
Figure 15: Typical FVED response
bays. Figure 15 depicts the response of a typical FVED. References
It is noted that the maximum damper and spring forces
are approximately 250 kips ( 1112 kN) and 90 kips (400 Computer and Structures, Inc., 2002, “ETABS 7.2.2,
kN), respectively. Spectra acceleration of this structure Linear and nonlinear static and dynamic analysis and
was 0.17g. design of building systems,” Berkeley, CA
Conclusion FEMA 273, October 1997, “NEHRP Guidelines for the
Seismic Rehabilitation of Buildings,” Building Seismic
Analytical studies of the Hotel Stockton revealed that the Safety Council, Washington, D.C.
structure would not be able to withstand the seismic
loading resulting from the anticipated site-specific Miyamoto, H.K. and Scholl, 2002, “Seismic Rehabilitation
earthquakes. To mitigate this seismic deficiency, the of an Historic Non-Ductile Soft-Story Concrete Structure
220
using Fluid Viscous Dampers,” Proceedings of the 11th
World Conference on Earthquake Engineering
221
CASE STUDY: 4
The Pacific Earthquake Engineering Research (PEER) Center In traditional design where seismic energy is mainly
has expanded its Tall Building Initiative (TBI) program to dissipated by irrecoverable inelastic deformation of structural
include the seismic performance of existing tall buildings. A elements, the building safety is maintained at the compromise
35-story steel moment resisting frame, designed in 1968, and of components’ damage, leading to direct and indirect
had representative details of buildings between 1960 to 1990 economic losses. This has been highlighted in recent
was selected for detailed seismic evaluation in the framework earthquakes in Chile, Japan, China and New Zealand. As
of Performance Based Earthquake Engineering (PBEE). It such, the development of seismic protection systems has been
was identified that the case study building failed to meet the spurred, which includes base isolation, active control and
performance objectives suggested by ASCE 41-13, and had a passive energy dissipation systems by large (Soong and
number of seismic vulnerabilities that endangered its Spencer, 2002). Of these, passive energy dissipation systems
structural integrity at two basic safety earthquake hazard do not require external power source, and are relatively easy
levels (BSE): BSE-1E and BSE-2E. Therefore, exploration to install, and thus considered as a better choice to upgrade
of retrofit strategies and their cost-effectiveness are fostered. existing structures. Three kinds of devices are investigated in
In this paper, three kinds of supplemental energy dissipation this paper: fluid viscous dampers (FVDs), viscous wall
devices are investigated to upgrade the seismic performance dampers (VWDs) and buckling restrained braces (BRBs), and
of the case study building, including fluid viscous dampers they are used in combination with preliminary retrofit
(FVDs), viscous wall dampers (VWDs) and buckling methods to upgrade an existing 35-story Pre-Northridge steel
restrained braces (BRBs). The retrofit design started by moment resisting frame. The investigations focus on
selecting locations to install supplemental devices. Then the comparing the cost-effectiveness of each retrofit method, and
total effective damping ratios needed to achieve the target also raise critical design considerations that appear for each
roof displacements in two directions were estimated based on strategy. Fig. 1 illustrates the applications of these three
a damping scale factor (DSF). One retrofit strategy by using devices.
FVDs was investigated as a first trail, and the mechanical
characteristics of each damper device were calculated based
on the overall effective damping ratio and the story wise
distributions of dampers. Next, other two retrofit strategies
by using VWDs or BRBs were investigated. Sizing of
different devices at one location was performed following the
principle of equal energy dissipation. The effectiveness of
each strategy to meet the retrofit intent of ensuring structural
stability at BSE-2E were compared. Moreover, probabilistic
damage and loss analysis were conducted using Performance
Assessment Calculation Tool (PACT) to relate the structural (a). FVDs
responses to economic losses. After a detailed examination, Figure 1. Supplemental energy dissipation devices
it was found that upgrading the case study tall building using
FVDs was the most effective retrofit strategy to control
structural responses, and reduce damage and economic losses
after BSE-2E events.
222
A systematic structural evaluation of the case study building
indicated that the building failed to meet the performance
objectives suggested by ASCE/SEI 41-13, Seismic
Evaluation and Retrofit of Existing Buildings (ASCE 41,
2013). Similar outcomes were found using FEMA 351,
Recommended Seismic Evaluation and Upgrade Criteria for
Existing Welded Steel Moment-Frame Buildings (FEMA
2000), and FEMA P-58, Seismic Performance Assessment of
Buildings (FEMA 2012a-c), showing that the building had a
(b). VWDs variety of seismic vulnerabilities, and suffered great damage
and economic losses after basic safety earthquake hazard
level (BSE) events. Consequently, feasible upgrade
strategies are necessary to enhance the seismic performance
of the building. The intent of the retrofit is to reduce the
overall drifts of the structure to a level where brittle fracture
of the beam-to-column connections would not seriously
jeopardize the overall stability of the structure at a basic
safety earthquake, level 2 (BSE-2E) hazard (with a
probability of exceedance of 5% in 50 years). To achieve this,
a “two-stage” retrofit plan was proposed. In “Stage-1”, the
(c). BRBs prevalent brittle column splices were fixed everywhere, and
Figure 1 (continued). Supplemental energy dissipation heavy concrete claddings were removed. The retrofit resulted
devices in a change of elastic model periods, that were 4.33 sec. (X-
direction translation), 4.18 sec. (Y-direction translation), and
02. Evaluation of the Case Study Building 3.59 sec. (rotation). Nevertheless, these strategies were
demonstrated insufficient to achieve the target performance
A 35-story steel moment resisting frame that had goal, and thus additional strategies are necessary. In “Stage-
representative design details from the period of 1960 to 1990 2”, three different kinds of supplemental energy dissipation
was selected for systematic seismic evaluations. The case devices were used in conjunction with strategies used in
study building is about 490 ft. tall, with a typical floor height “Stage-1” for further improvement, including FVDs, VWDs
of 13 ft. It spans about 185 ft. by 135 ft. in plan, and has a and BRBs. This paper focuses on the “Stage-2” retrofits, and
typical beam span of 30 ft. The building completed compares the cost-effectiveness of upgrading the case study
construction in San Francisco in 1971, consisting of complete tall building using selected devices.
three-dimensional moment-resisting space frames in both
longitudinal direction (X) and transverse direction (Y). Fig. 2
shows a frame elevation and a floor plan of the building
model.
223
efficiency. Effective damping ratios were estimated based on
the target roof displacement in each direction at BSE-2E
events. The mechanical properties of dampers were selected
using an equation related to the effective damping ratio, and
story wise distributions of dampers. Several design
considerations and viable alternatives to address these
considerations were raised at the end of this section.
224
during dynamic vibration is neglected (Constantinou and
Symans 1992; Reinhorn and Constantnou 1995):
Fd = Cvα·sign(v) (1)
where C is the damping constant, α is the damping exponent,
and sign (v) is the sign function of relative velocity of the
piston end with respect to the damper housing. In earthquake
engineering, α is generally in the range of 0.3 to 1.0 (Lee and
Taylor 2001). Eq. (1) could predict behaviors of a FVD well
for low rate excitations, but the frequency-dependent contents
need to be accounted as the operating frequency increases.
Estimating the overall effective damping (including the 4.4 Design considerations
intrinsic damping and supplemental damping) needed to
reduce the overall drifts is a prerequisite to estimate For a high-rise building, fairly large dampers are usually
additional damping demand. A non-iterative approach was required to achieve the target performance goal, and this
used based on researches of Rezaeian et al. (2012). In this poses great challenges to existing buildings. Issues such as
approach, a Damping Scale Factor (DSF) was developed to delivering heavy devices to multiple stories and clearing
adjust the 5% damped spectral ordinates to damping ratio structural/non-structural components would increase
ranging between 0.5% and 30%, which is defined as the ratio construction difficulty and retrofit costs, and need careful
between the target overall displacement to the current considerations. Alternatives such as using two dampers per
displacement demand. The target roof displacement at each driver, more damped bays at selected stories, and utilizing
direction was selected based on the static pushover curves toggle-brace mechanisms to magnify the effective force of a
when the original building abruptly lost more than 70% force damping device (Taylor and Constantinou 1998) might be
resistance capacity. Meanwhile the current displacement considered. On the other perspective, reduced performance
demands were estimated from the displacement spectrum at objectives might be used.
BSE-2E event. The DSF was then related to a regression
relation derived based on the entire NGA-W2 earthquake Another critical design consideration is the vulnerable
record set (Rezaeian et al. 2012). Variations of magnitude, columns. After implementing “Stage-1” retrofits, the
source-to-site distance and local site conditions have been columns are anticipated to have adequate tension capacities,
considered in the regression relation. With a calculated DSF but they might still be overloaded in compression. Using
of each direction, the required damping ratios at a BSE-2E FVDs could bring down the drift ratios and reduce the axial
event were estimated, which were 8% for X-direction and 13% forces and bending moments in columns. Nevertheless, an
for Y-direction. excessive accumulation of damper forces on adjoining
columns would cause problems if the structure enters into
4.3 Mathematical modeling inelastic range, and the damper forces are large. Other
factors such as the flexibility of connecting elements (e.g.,
General fractional derivative Maxwell model was described driving braces, girders, connections and columns) would
by Makris and Constantinou (1990) to capture the behavior of drive the dampers to act more in-phase with peak
FVDs, whereas a simplified mathematical model (Eq. (1)) displacement and add up to the total forces in columns.
could be used if the operating frequency is under the cut-off Additional retrofit methods such as filling the columns with
frequency of a FVD, that is, the stiffening effect of a FVD concrete, constructing mega columns at the corners might be
investigated.
225
05. Retrofit with VWDs
226
failure might produce a spike of force and deformation on the
VWD, and bring about the rupture of viscous material and the
failure of the wall damper.
(b). Case 2: deformed shape with pin-end connection BRBs are cheaper than FVDs or VWDs, and they are
Figure 8. Deformed shape of a frame with different boundary considered as ordinary braces in the U.S. design code, which
conditions make their design and analysis procedures less complicated
than other supplemental energy dissipation devices. As with
Secondly, the storage stiffness of a VWD would affect the previous two retrofit methods, the distributions of BRBs in
beam deformations. If the storage stiffness of a VWD under the existing building followed the pattern with FVDs and
a dynamic loading is large, it would prevent the two steel VWDs. In this section, the mathematic modeling of a BRB
plates moving freely (see Fig. 9), and resulted in reduced in OpenSees and the major design considerations would be
energy dissipation capacity of a VWD. Note that the storage discussed.
stiffness of a VWD is not an exclusive contribution from the
steel plates; the frequency-dependent part of the viscous 6.1 Mathematical modeling
material would also influence the storage stiffness (Fu and
Kasai, 1998). More research is needed to understand the BRB is a kind of displacement-dependent devices, and it
relation between the VWD storage stiffness, beam stiffness, dissipates energy through the yielding of the brace. The basic
and their effect on the behavior of the VWD. force-displacing relation of a BRB is expressed as:
Fd = Ku (3)
where K is the effective stiffness of the brace, and u is the
relative displacement between two ends of a brace. When a
brace is in its elastic range, K represents the elastic stiffness.
After it yields, a post-yield stiffness in the order of 0.001 of
the elastic stiffness is used to represent its force resistant
capacity. This strain hardening value of 0.001 is
recommended in the OpenSees manual (Mazzoni et al. 2006),
227
which could control the transition from elastic to plastic direction follow a similar trend. It should be noted that
branches and accounts for isotropic hardening. during the simulation (entire ground motion duration plus 15-
second free vibrations), most numerical simulations were
To simulate the behavior of a BRB, a co-rotational truss successful; however, in the case with VWDs, several VWDs
element was used in OpenSees. The material model used a were broken under one ground motion excitation after the
Giuffre-Menegotto-Pinto model (Steel02), and was assigned connected beams failed, and the structure had a peak drift
in the axial direction of the element. The effective stiffness ratio in excess of 10%. In this case, the numerical analysis
K0 in the elastic range was estimated using the principle of was arbitrarily terminated since the building was most likely
equal energy dissipation. This was calibrated by assuming to collapse.
that that the peak force F0 of a FVD and a BRB would be the
same when they reached a same peak displacement U0 ; see 7.1 Global responses
Fig. 10. The proposed simple model was adequate to capture
the primary characteristics of BRBs, e.g., the Bauchinger The peak displacement distributions shown in Fig. 11
effect and strain hardening effect, and thus selected for this indicate that all cases incorporating different devices could
study. The stiffening effect of BRBs changed the help reduce the structural deformations by a large amount,
fundamental period of the building from 4.33 sec. to 4.05 sec. ranging from 20% to 40%. With a same effective damping
ratio, they help bring down the peak roof displacement to a
similar value, and the value is close to the selected target roof
displacement, i.e., 38 inches in the X-direction. This
demonstrates that the DSF method discussed in Section 4.2 to
estimate the effective damping ratio is adequate for
preliminary design of FVDs.
228
Figure 14. Time history of roof accelerations
Figure 12. Distributions of peak drift ratio in X-dir.
7.2 Damper responses
The maximum peak floor accelerations are examined in Fig.
In addition to the structural global responses, the peak force
13. The “as-built” case has a peak floor acceleration of 0.85g
demands of each retrofit scheme are examined. The
at roof level. FVDs are able to reduce the peak floor
hysteresis loops of one device, located in Y-direction at the
accelerations by about 30% throughout the stories, and bring
3rd floor, subjected to one ground motion are plotted for
down the peak value at roof to 0.69g. The reductions benefit
different schemes; see Fig. 15. Under a same excitation,
from the additional damping effect provided by FVDs, and
three devices have different behaviors. The FVD exhibits
the additional stiffening effect is not significant. On the other
pure viscous properties, as shown by the elliptical shape of
hand, the case installing VWDs provides limited control over
hysteresis loop. The VWD has steel tanks at the exteriors of
the peak floor accelerations: the reduction is less than 10%
the viscous material, thus having an increased load-resistant
over all the story levels, and is essential zero at roof level.
capacity. However, a BRB has a totally different energy
The third case that uses BRBs is demonstrated to have the
dissipation mechanism compared to a FVD or a VWD. A
worst control effect, where the floor accelerations are
BRB dissipates energy through the yielding of braces, and a
increased at a majority of floor levels, and the peak roof
typical hysteresis loop is represented by a bilinear curve. For
acceleration is increased to 0.96g. This counter productivity
the damper selected for investigation, the FVD dissipates
of BRBs to control floor accelerations is mainly attributed to
most input energy despite that all three devices are designed
their displacement-dependent characteristics, which would
to have a similar energy dissipation capacity. All different
increase the force demands and accelerations at each floor.
devices show a similar deformation level.
Similarly, the roof acceleration time history during free
Meanwhile, the maximum damper force demands are shown
vibration phase in Fig. 14 shows that only FVDs could
for all schemes in Fig. 16. Fairly large force demands are
contribute to a more rapid decay of vibrations among three
observed for all cases, ranging from 1200 kips to 2300 kips.
cases under investigation.
It should be noted that FVD scheme, the most effective to
suppress the peak deformations and peak floor accelerations,
turns to have the smallest peak force demands among the
three.
229
(a). FVD
230
compression demands due to gravity force, which consumes 08. Damage and Loss Analysis
about 30% of the column compression capacities. For the
“as-built” case, the peak D/C exceeds 1.0 at floor 6-7, and The damage and loss analysis was conducted using the
there are more than half of stories having peak D/C ratios software developed by FEMA: Performance Assessment
larger than 0.5. At these levels, ASCE 41 indicates that the Calculation Tool (PACT). The PACT performs the
members should be treated to be force controlled and remain probabilistic loss calculations in the framework of
elastic. The high D/C ratios at most floor indicate a Performance Based Earthquake Engineering (PBEE). The
significant reduction of column bending capacities, which repair cost and repair time of each realization were estimated
would likely contribute to the weak column, strong beam from fragility curves of structural and non-structural
behavior observed in the results. On the other hand, tension components, and consequence functions of damaged
rupture/failure is typically not a concern with all the brittle components. Four engineering demand parameters were used
splices fixed. to predict the damage states of different components,
including the peak story drift ratios, peak floor accelerations,
For the case with FVDs, the peak D/C rations are reduced peak floor velocities and maximum residual drift ratios.
slightly at several floors on tension, though there are no Among these, the first three parameters were results from
significant reductions of compression forces. Nevertheless, nonlinear response history analyses, while the residual drift
neither VWDs nor BRBs are able to alleviate the high column ratios were estimated based on an empirical relation
axial forces. The axial D/C ratios at most floors are increased suggested by FEMA P-58 (FEMA 2012a).
instead, and widespread column failures are more likely in
both cases. Other strategies to upgrade the column capacities, The probability of the building having irreparable residual
such as filling concrete in the built-up section columns, or drifts and the probability of unsafe tagging at BSE-2E event
adding corner columns could be explored. for the “as-built” building and three fully retrofitted buildings
are summarized in Table 1. The “as-built” one is expected to
have very large residual drift ratios at BSE-2E events, making
repair work unsafe and unrealistic. This could be seen from
the high chances of irreparability and high probability of
unsafe tagging of the “as-built” case. It is most likely that a
complete tearing down and reconstruction are necessary. As
a comparison, the building inserting FVDs successfully
brings down the residual drifts, and it has only 0.6% chance
of being irreparable. A 26.9% of unsafe tagging is estimated,
which is mainly resulted from failure of Pre-Northridge
beam-to-column connections and prefabricated steel stairs.
Consistent with what have been observed from structural
analysis results, the other two retrofit methods by using either
VWDs or BRBs still exhibit large residual drifts, and are less
Figure 17. Column group designations effective to reduce the chance of tearing down the building,
nor the chance of unsafe tagging at BSE-2E.
10
231
level (90 percentile) is assessed. On the contrary, the retrofit
scheme using FVDs avoids large economic losses, and
reduces the median repair loss ratios to 0.047, and 90
percentile value to 0.071.
11
232
09. Conclusions beams fail. The displacement-dependent BRBs are acting in-
phase with structural displacements, and increase the force
A representative Pre-Northridge high-rise steel moment demands to existing members. Besides, both VWDs and
resisting frame was selected for seismic performance BRBs provided additional stiffness, reducing the building’s
assessment. The evaluations were based on ASCE 41-13 fundamental period and increasing the seismic force demands.
procedures FEMA 351 and FEMA P-58, and identified
several major structural vulnerabilities of the case study In addition, the behaviors of dampers or BRBs are checked.
building. As such, possible retrofit methods as well as their The results indicate that fairly large devices are required in all
cost-effectiveness were explored. A “two-stage” retrofit plan schemes, while the sizes of FVDs needed are anticipated to
was proposed for the case study building. In “Stage-1”, the be the smallest despite of their best control effects among the
brittle column splices were fixed everywhere, and the exterior three schemes. To relate the structural performance to the
heavy claddings were removed. However, analysis results economic losses, a damage and loss analysis is conducted
indicated that “Stage-1” method alone was not enough to following procedures outlined in FEMA P-58. The results
meet the retrofit goal of maintaining structural stability at a are consistent with the structural analyses, indicating that
BSE-2E event. Therefore, in “Stage-2”, several supplemental FVDs are the most effective to reduce the probability of
energy dissipation devices were used in combination with having irreparable residual drifts, probability of unsafe
“Stage-1” methods to further enhance the building’s seismic tagging, and led to much reduced economic losses after a
performance. The control effect, in particularly the cost- BSE-2E event from the “as-built” case. BRBs help improve
effectiveness of each retrofit method is investigated and the structural behavior a little, but are insufficient to provide
compared in this paper. a high confidence level of 90% to reduce repair cost. On the
other hand, VWDs provide little, if any, contributions to
Three devices are investigated in this paper: FVDs, VWDs reducing the economic consequences after a BSE-2E event
and BRBs. The design started by designing FVDs. Four due to a great number of beam failure and diminished damper
perimeter frames were selected to install these devices so that effect.
the interaction of occupants and interior components could be
minimized. The total effective damping ratios were Several design considerations exist for each scheme. One
estimated to achieve the target roof displacements at each common issue among three cases is the widespread
horizontal direction. A refined damper design was proposed vulnerable columns in the building. Even after the brittle
where dampers were installed only in locations with better splices were fixed, the columns are overloaded in
control effectiveness. These locations were the same for all compression and sensitive to yielding under combined axial
retrofitted schemes using different energy dissipation devices. force and bending. This poses great threat to the seismic
In addition, the mechanical properties of three devices were integrity of the building, and additional methods to upgrade
selected based on the assumption of equal energy dissipation. columns should be explored.
The structural global responses, devices behaviors and In summary, among three energy dissipation devices
column axial force status are presented. The results presented investigated, FVDs have the least interaction with structural
are the maximum values from three nonlinear response members, and are able to introduce additional damping
history analyses at BSE-2E. The global responses show that without significantly increasing the structural demands on the
the FVDs are the most effective to bring down the drift vulnerable columns and beams. Therefore, they are viewed
concentrations at floor level 2 to 10, and result in a more as the most promising solution to improve the structural
uniform distribution of the peak deformations. The peak drift behavior and reduce the economic losses of a Pre-Northridge
ratio after installation of FVDs is less than 1.5%, which could high-rise steel moment resisting frame.
essentially eliminate the beam-to-column connections failure
at BSE-2E events. FVDs are also shown to be the most Acknowledgement
efficient to suppress the peak floor accelerations and
contribute to a more rapid decay of the structural vibrations. This paper is supported by Pacific Earthquake Engineering
For other two retrofitted cases using VWDs or BRBs, unique Research center (PEER) as part of its Tall Building Initiative
problems are found and neither of them is able to provide and Next-Generation Attenuation Relationship programs.
effective structural control to the building under seismic Special thanks to Dr. Jiun-Wei Lai and Dr. Matthew
excitations, and thus unable to meet the retrofit goal. Schoettler who dedicated to set up the OpenSees model, as
Specifically, the introduction of a VWD in the middle of a well as the assistance from Dr. Frank McKenna, Dr. Andreas
beam having Pre-Northridge connection details would cause Schellenberg and Prof. Dimitrois Lignos to refine the
an earlier fracture of beams, and the control effect of VWDs numerical model. The authors would also like to express
would be significantly diminished once a large number of great gratitude to Prof. Kazuhiko Kasai of Tokyo Institute of
12
233
Technology, Dr. Kit Miyamoto and Dr. Amir Gilani of No. 2015/14, Pacific Earthquake Engineering Research
Miyamoto International, Dr. Amarnath Kasalanati of Center, University of California, Berkeley, CA.
Dynamic Isolation Systems, Jim Malley of Degenkolb
Engineers and Rob Smith of Arup for sharing their valuable Lee D. and Taylor D. P. (2001). Viscous damper
expertise and advice. development and future trends, J. Struct. Des. Tall Buil., 10,
311-320.
Reference
Lobo, R.F., Bracci, J.M., Shen, K.L. et al., Reinhorn, A.M.,
AISC (2010). Specification for Structural Steel Buildings, and Soong, T.T. (1993). Inelastic response of reinforced
American Institute of Steel Construction, Chicago, IL. concrete structures with viscoelastic braces, Report No.
NCEER-93-0006, National Center for Earthquake
ASCE (2013) Seismic Evaluation and Retrofit of Existing Engineering Research, Buffalo, State University of New
Buildings, American Society of Civil Engineers, ASCE/SEI York at Buffalo, Buffalo, N.Y.
41-13, Reston, VA.
Makris N., and Constantinou M.C. (1990). Viscous dampers:
Constantinou M. C., Symans M. D. (1992). Experimental and testing, modeling and application in vibration and seismic
analytical investigation of seismic response of structures with isolation, Report No. NCEER-90-0028, National Center for
supplemental fluid viscous dampers, NCEER-92-0032, Earthquake Engineering Research, State University of New
National Center for Earthquake Engineering Research, York at Buffalo, Buffalo, NY.
Buffalo, NY.
Mazzoni, S., Mckenna, F., Scott, M.H., and Fenves, G.L.
FEMA (2000). Recommended Seismic Evaluation and (2009). Open system for earthquake engineering simulation:
Upgrade Criteria for Existing Welded Steel Moment-Frame User command-language manual, Pacific Earthquake
Buildings, Federal Emergency Management Agency, FEMA Engineering Research Center, University of California,
351 report, Washington, D.C. Berkeley, OpenSees version 2.0 users’ manual, retrieved
from
FEMA. (2012a): Seismic Performance Assessment of http://opensees.berkeley.edu/OpenSees/manuals/usermanual/,
Buildings, Volume 1 – Methodology. Federal Emergency August, 2016.
Management Agency, FEMA P-58-1 report, Washington,
D.C. McKenna, F., Scott, M., and Fenves, G. (2010). Nonlinear
finite-element analysis software architecture using object
FEMA (2012b). Seismic Performance Assessment of composition, J. Comput. Civil Eng., 24(1): 95-107.
Buildings, Volume 2 – Implementation Guide, Federal
Emergency Management Agency, FEMA P-58-2 report, Newell J., Love J., Sinclair M., Chen Y-N., and Kasalanati A.
Washington, D.C. (2011). Seismic design of a 15-story hospital using viscous
wall dampers, Proceedings of Structural Congress, Las
FEMA (2012c). Seismic Performance Assessment of Vegas, Nevada, U.S.
Buildings, Volume 3 – Supporting Electronic Materials and
Background Documentation, Federal Emergency Reinhorn A. M., Li C., Constantinou M. C. (1995):
Management Agency, FEMA P-58-3 report, Washington, Experimental and analytical investigation of seismic retrofit
D.C. of structures with supplemental damping, part I: fluid viscous
damping devices. NCEER-95-0001, National Center for
Fu Y., Kasai K. (1998). Comparative study of frames using Earthquake Engineering Research, State University of New
viscoelastic and viscous dampers, Structural Engineering, York at Buffalo, Buffalo, NY.
124:513-552.
Rezaeian S., Bozorgnia Y., Idriss I.M., Campbell K.W.,
Kidder Mathews (2015). San Francisco office real estate Abrahamson N.A., Silva W.J. (2012). Spectral damping scale
market review 3 rd quarter 2015, retrieved March 2016, from factors for shallow crustal earthquakes in active tectonic
http://www.kiddermathews.com/downloads/research/office- regions, PEER Report No. 2012/01, Pacific Earthquake
market-research-san-francisco-2015-3q.pdf. Engineering Research Center, University of California,
Berkeley, CA.
Lai, J.-W., Wang, S. Schoettler, M. and Mahin S. (2015). Soong T. T., Spencer B. F. (2002). Supplemental energy
Seismic performance assessment of a tall building having dissipation: state-of-the-art and state-of-the-practice. Eng.
Pre-Northridge moment-resisting connections, PEER Report Struct., 24, 243-259.
13
234
Takewaki I. and Yoshitomi S. (1998). Effects of support
stiffness on optimal damper placement for a planar building
frame, J. Struct. Des. Tall Buil., 7: 323-336.
14
235
CASE STUDY: 5
Gregory Nielsen PE, Simon Rees SE, Branden Dong PE, Kermin Chok SE,
Eaman Fatemi, Atila Zekioglu SE
Arup
Los Angeles, CA
236
2017 SEAOC CONVENTION PROCEEDINGS
minimum vertical seismic component (0.2SDS) as shown in base BRBF solution was rejected due to incompatibility
Figure 2. Arup’s approach to mitigating this severe vertical between the required number of brace lines and the functional
seismic component through the use of an innovative vertical program of the hospital.
isolation system (VIS) will be detailed in a future paper. A
suite of 11 tri-directional ground motions was used to be The final selected structural design uses a base isolation
consistent with the provisions of ASCE 7-16 and forms the system comprised of 126 triple friction pendulum bearings
basis for the nonlinear response history analysis (NLRHA) with +/-42” displacement capacity manufactured by
procedure used for the structural design. These were originally Earthquake Protection Systems and 104 fluid viscous dampers
developed at the MCE level and scaled by two-thirds for the with 800 kip MCE capacity manufactured by Taylor Devices.
DE level. Ultimately 110 individual ground motions were The pendulum isolators have an effective period of 4.5 seconds
required for each design iteration: 11 ground motions, 2 and the dampers have a velocity exponent of 0.7. The total
orthogonal directions, upper bound (UB) and lower bound equivalent system damping coefficient is 50% of critical
(LB) properties, DE and MCE, and an additional 45 degree damping. High damping using supplemental dampers was
oriented UB and LB analysis at MCE. selected to control the overall building displacements and
reduce reliance on the friction pendulum system for system
damping, which is affected by the changing vertical load due
to the high site-specific vertical ground motion component.
Controlling the isolator displacements to 42” instead of 84”
without supplemental damping resulted in an optimal cost
solution by controlling the isolator and damper component
costs, the costs associated with stability framing above and
below the isolators, and the costs associated with expansion
joint covers and flexible service connections.
237
2017 SEAOC CONVENTION PROCEEDINGS
moment connections are bolted connections to control welding substantially less nonlinearity in the model and hence
distortion in the field during steel erection. A SidePlate special substantially less analysis time and data generation. For
moment frame system is used in the East-West (tower long LLUMC the seismic demands were much higher and
axis) direction and a BRBF system is used in the North-South optimization of the NLRHA performance was required to
(tower short axis) direction. The frames are designed to widen reduce the overall structural tonnage. NLRHA optimization
at the base in order to reduce the overall uplift demands on the could not be practically done without first creating an
base isolation system to manageable levels. A representative automated workflow which could generate, analyze, and post-
braced frame elevation is shown in Figure 3. The design uses process all of the required analyses into a reduced form
ASTM A913 Grade 65 steel sections for columns and selected suitable for design while also minimizing the feedback time to
BRBF beams in order to achieve the required IO performance fit within the aggressive project schedule. A single design
at MCE for these “overstrength” category elements. A full list iteration of 110 ground motions resulted in over 6 TB of data
of the performance requirements of various elements of the generated and over 10 design iterations were conducted
structure are listed in Table 1. While the average result was through the course of the project from Design Development to
required to meet the criteria of Table 1, no ground motion was final Permit. From the outset, the goal was to turn the time
allowed to result in elements exceeding the Collapse intensive NLRHA into a practical tool in the designer’s
Prevention (CP) limit. toolbox, similar to response spectrum analysis, so that from a
designer’s view NLRHA was not used as a final performance
Table 1: Performance requirements for NLRHA verification but rather an integral design process.
Element Performance at Performance at
DE MCE The team chose to use LS-DYNA as the analysis engine for the
FPT LRFD Design Expected Strength project. This choice was for the following reasons:
Isolator Design
FV Damper LRFD Design Expected Strength • Excellent model stability under 3d ground motions
Design with 1.5 FOS
Mat LRFD Design, Expected Strength • Reduced analysis time using explicit time domain
Foundation Settlement < 1.5” Design, Settlement < solver versus other software
6”
Level A IO, 1 șy IO, 1 șy • Staff familiarity
Isolator
Framing • Ability to use with cloud computing services
SidePlate IO, 0.25 șy IO, 0.25 șy
Columns There was a considerable learning curve in introducing LS-
SidePlate IO, 0.02 radians LS, 0.03 radians DYNA to OSHPD plan review staff. The design utilized the
Beams Collaborative Plan Review (CPR) process which allowed for
BRBF IO, 0.25 șy IO, 0.25 șy monthly meetings between the design team and the review
Columns team during the 18 month review duration which was essential
BRBF IO, 0.25 șy IO, 0.25 șy in helping OSHPD become confident in the nonstandard
Beams analysis tools. A bounding analysis study was performed in
BRBF IO, 3 ǻy LS, 10 ǻy order to select the most demanding set of bounding parameters
Braces for the soil behavior, isolator behavior, damping behavior, and
Drag LRFD Design Expected Strength BRB strengths. Figure 4 shows the result of the bounding
Connections Design analysis on a 2-dimensional frame which indicated that the
Diaphragms LRFD Design Expected Strength least favorable sets of bounding values corresponded to Lower
Design Bound of all parameters and the Upper Bound of all
parameters. The Lower Bound analysis controlled the isolator
NLRHA Workflow displacements and damper velocities while the Upper Bound
analysis controlled the superstructure drifts, frame demands,
The major analytical challenge facing the design team was and floor accelerations. Selecting a single Lower Bound and a
creating an analysis framework that could handle the large sets single Upper Bound analysis reduced the possible
of data generated by the NLRHA models which were larger permutations considerably and was essential in keeping the
than any Arup had previously had to deal with. Arup’s prior analysis set to a manageable 110 ground motions.
work on the base isolated San Francisco General Hospital
utilized an essentially elastic design on top of isolation with
238
2017 SEAOC CONVENTION PROCEEDINGS
239
2017 SEAOC CONVENTION PROCEEDINGS
and vertical force resisting elements are imported, including nodes was limited to those processes which primarily served
the floor slabs. Rigid end offsets, element discretization, to reduce the data sets, for instance reducing a set of
element offsets, and particular material assignments are added displacement histories into drift histories or converting damper
using a set of Grasshopper components ensuring the generated relative displacements from the three axes of global
analysis geometry model is fully connected and aligns with all displacement to a single rotating along-damper axis. The
of the essential parameters validated in the LS-DYNA essential data was then transferred to AWS Redshift, a cloud
validation package signed off by OSHPD. As part of this database warehousing service, where it could be stored,
process the floor slabs are generated as cracked elastic 2d shell queried, and processed at a cheaper cost per core. Due to IT
elements with the required seismic mass and all gravity beam infrastructure limits in Arup’s LA office, the transfer from
members are included as elastic beam elements. While the POD to AWS was much faster than transferring the data from
baseline output is that all elements and nodal displacements are POD to Arup for internal processing. The AWS platform also
written by LS-DYNA at 20 Hz sampling rate, selected nodes allows for scalability and automatic backups for the large data
and elements, such as drift nodes, building separation nodes, sets. At the time that the LLUMC project was in analysis
and floor acceleration nodes, must be selected prior to analysis production, two other projects of similar scale and data
to output at a higher 200 Hz sampling rate. A 200 Hz sampling generation were being run out of the same office. Having a
rate is not used on all elements as this would generate more central off-site repository allowed the teams to focus on
data than is physically necessary to capture the relevant EDPs delivering the projects using a common set of tools rather than
and slow the entire process. Once all of these assignments are spending valuable time maintaining internal IT infrastructure.
complete, the Grasshopper components write the necessary
keyword cards for the complete LS-DYNA analysis models in Finally, the data was post-processed on AWS Redshift using
all 110 variants (ground motion, bounding properties, standard SQL queries to turn the 110 individual records into
directionality, and severity). This model preparation process is sets of EDP’s representing the average of the maximum
fully automated. An image of the LS-DYNA model is shown response from each ground motion over the ground motion
in Figure 6. suites. This final database of EDP’s was visualized in Rhino
on the same geometry wireframe model used to generate the
analysis models at the start. These final visualizations, along
with a hard drive with all of the post-processed data tables,
analysis run files, and keyword files, were submitted to
OSHPD for review. Intermediate iterations were used to
optimize the performance of the structure primarily using
conservation of energy approaches for resizing deformation-
controlled elements with target inelastic deformation limits.
The EDPs tracked are tabulated in Table 3. A sample of the
figures generated from the process is shown in Figure 7.
240
2017 SEAOC CONVENTION PROCEEDINGS
Interstory Drift Relative drifts at key points in Vertical Load Factor for NLRHA of Friction
building Pendulum Isolated buildings
Floor Accelerations Accelerations at key points in
building A unique feature of friction pendulum isolated buildings is that
Lateral Frames Story force time histories from the shear force in the bearings is directly proportional to the
cross-sections axial load applied to the bearing. This can lead to, and did on
Diaphragms Moment and shear envelopes the LLUMC project, a difference in interpretation regarding
derived from concurrent story the appropriate load combination to be applied to the overall
force time histories building when performing NLRHA. This issue has previously
been avoided in the designs for elastic structures on top of
isolation in which case the NLRHA was performed using an
unfactored 1.0 D combination roughly equivalent to the
seismic mass and then factoring the additional dead loads on
the superstructure elements using linear superposition.
However this is not possible for a combined NLRHA model
with nonlinearity in both the isolation system and the
superstructure lateral frame. A number of interpretations could
be considered ranging from 1.0 D + 0.25 L (ASCE 7-10
Section 16.2.3) to as much as 1.2 D + (0.2SMS W) + 0.5L or as
little as 0.9 D – (0.2SMS W) (ASCE 7-10 Section 17.8.2.5). On
LLUMC this maximum case could require the building to be
analyzed as though it was under 0.48g or 1.62g, meaning that
the same seismic force could act on the building but with 50%
or 160% of the lateral resistance in the isolators. A series of
analyses were performed to illustrate that the effect of the time
varying vertical ground motion on the lateral shear of the
isolation system was on the order of 5% variation in shear and
2% for isolator displacement. This result is primarily due to the
large amount of damping present in the isolation system
despite the very high vertical ground motions. The final load
combinations for the NLRHA lateral analysis were selected as
a compromise between the two extremes:
241
2017 SEAOC CONVENTION PROCEEDINGS
of Section D3 specifies that “flexible shear connections that delay onset of the flexural hinge. It should be noted that the
allow member end rotations per Section J1.2 of the magnitude of the forces in the BRBF beams was too great to
Specification should be considered to meet these make a true pin connection viable. This appears to be an
requirements.” The commentary further illustrates that only unintended consequence of the code since it does not appear
differential drift between floors leads to additional column logical to design a BRBF based on the performance of the
moment demands. Since this is not written into the body of the moment connected frame rather than rely on the energy
Seismic Provisions additional analysis was required to dissipating capacity of the BRB itself. It is unlikely that prior
illustrate that the columns did not have inelastic rotation projects utilizing deeper beam section and allowed to drift
demands when the drift histories of the building were applied. beyond 1.5% perform as required by this strict interpretation
To prove this a typical gravity column stack was modeled in of the code provisions.
LS-DYNA with ASCE 41-06 plastic hinge properties modeled
and FEMA 355 gravity shear tab inelastic hinges where the Floor Accelerations – Expected versus Actual
columns connected to gravity beams. The full suite of DE and
MCE ground motions were then applied in two orthogonal Seismic isolation is often used to reduce in-floor accelerations
directions and the plastic rotation was monitored. Only 1 for sensitive equipment. However, as Table 4 shows, the floor
ground motion at MCE resulted in hinging in the column. The acceleration results from LLUMC were in some cases higher
sizing design for the columns considered a 0.3% differential than the code prescriptive floor accelerations for nonstructural
story drift as an added moment in the LRFD column design component design in a fixed base building at the same site. The
and appears to be a reasonable design factor for this building relatively tall and flexible structure on top of the isolation
which was designed to 1.5% drift at DE. While the project plane likely leads to higher accelerations than may be
required that this be proven through rigorous methods it is a originally expected. Further, the design team found that LS-
logical result considering that the NLRHA did not indicate DYNA tends to predict higher accelerations (by up to 50%)
hinging in force controlled columns which are part of the than SAP2000. This will be investigated in the future and
lateral system and, in the case of the moment frames, are much compared to actual experimental shake table tests. It may also
stiffer than the gravity columns and hence will yield at a lower be the case that the prescriptive code floor accelerations for
rotation than the gravity columns. The use of Grade 65 steel nonstructural components in fixed base buildings may be
for the column sections also delays the onset of plastic hinging lower than they should be to ensure reliable performance. This
and is recommended. should also be investigated further and compared to actual
instrumented buildings and experimental tests.
BRBF Beam Plastic Rotation Limits Incompatible
with BRB Strain Limits Force-Controlled Frame Columns
An unintended consequence was discovered by virtue of A final lesson learned relates to force-controlled columns and
having modeled all of the lateral frame elements with plastic their treatment in the NLRHA model. Per the requirements of
hinges. ASCE 41-06 requires that beams of buckling restrained ASCE 41-06 these force-controlled columns should be
braced frames be treated similarly to the columns of the same modeled as elastic elements and the average of the maximum
frames and in some cases are force controlled. However, these forces developed in these elements from the suite of ground
low plastic rotation thresholds appear to be incompatible with motions should be compared to the capacity of the column.
the BRB strain limits of 3ǻy and 10ǻy for IO and LS However this could underestimate the response of the building
performance, respectively. The imposed deformation pattern if these elements were to exceed their capacity in any one
of the frame in the NLRHA that is required to yield the braces, ground motion. Due to this fact OSHPD requested that force
particularly for the W18 or W21 beam sections which are used controlled elements be modeled with axial load dependent
in typical designs, often results in inelastic behavior of the inelastic hinges. This then created the problem of
beams which cannot be controlled except by increasing the interpretation of results from the average of the suite of
stiffness and strength of the braces. This in turn increase the analyses. If any one of the motions resulted in plastic hinging,
column and brace forces required for capacity design. Due to no matter how slight, the average of the suite would indicate a
these reasons, the typical BRBF beam on the LLUMC project nonzero plastic rotation. This would then no longer meet the
is a stocky W14 column section since its shallow depth results requirement that there should be no yielding in force-
in delayed onset of a flexural hinge. Further the majority of the controlled elements. The only way to satisfy the requirement
BRBF beams were proportioned to have less than 0.5 P/Pcl so would be to design the column such that it did not hinge in any
as to keep them in the deformation controlled category of of the ground motions, which clearly represents overdesign
ASCE 41-06. Nonetheless this still required a plastic rotation relative to the averaging methodology used throughout ASCE
of 0.25 șy in accordance with ASCE 41-06. In a few select 41-06. This issue was finally concluded by allowing a plastic
instances the beams were even increased to Grade 65 to further rotation of up to 0.05șy in force-controlled elements. This also
242
2017 SEAOC CONVENTION PROCEEDINGS
Conclusion
243
CASE STUDY: 6
244
245
246
247
248
249
250
251
252
253
CASE STUDY: 7
Integrated Design and Construction at the 250 West 55th Street Tower
ABSTRACT
The recently completed 40 story office tower at 250 west 55th street in Manhattan
demonstrates the best in innovative structural design, and use of 3-D coordination
tools for design and construction. This paper describes the integrated process that was
followed and some of the challenges that were met along the way, and will be of
interest to design professionals and others interested in integrated construction
processes.
The integrated 3-D process started with the use of Revit from the Schematic design
stage, and was followed through the design, procurement, and construction phases,
with all major sub contractors producing 3-D or 4-D models. These models were
carefully integrated by the general contractor, and enabled savings in schedule,
reduction of field conflicts, and reduced project risks.
INTRODUCTION
250 West 55th st, is a steel framed, 600ft tall, 40 story office tower, located in
midtown Manhattan. The tower, developed by Boston Properties, and designed by
Architect Skidmore Owings and Merrill, contains approximately one million sq. ft,
and is slated for occupancy in early 2014.
The design of the project commenced in 2007, and it was decided from the beginning
of the schematic design phase, that BIM, and specifically Revit, would be used
throughout the design of the tower by the Architect, Structural, and MEP Engineers.
Although this is more common now, at the time this was very unusual, and this was
pursued with the goal of not only delivering a better integrated project, but also
developing a 3-D working process that could serve as a model for future projects.
254
Figure 1. Completed Tower © Kevin Chu/KCJP Figure 2. Structural Revit model
One aspect of particular focus for the coordination was the core. As is typical for a
New York City project, the core was a steel braced frame, and as such coordination of
gusset plates, with the ducts, pipes and conduits that must pass in and out of the core
is critical. This began for the typical office floors at the schematic design stage,
before the framing of the core was finalized, and included consideration of not only
the current needs of the building, but allowance for the addition of extra conduits in
the future.
Although clash detection tools exist within the software to facilitate this, this work
still requires an understanding of the critical coordination locations due to the
numerous other hits that an automated tool would produce on a model at this level of
detail. In addition it is necessary to bring forward the modeling of many items in
255
these critical areas, beyond the level of detail that would typical be required at this
stage.
The use of the Revit model continued throughout the design into the procurement
phase with the model being shared with bidders, providing greater understanding of
the level of design and coordination. This is particularly important for fast-track
projects where early trades are bid before the design is completed, and this process
helped realize very consistent bids for the early steel package.
During the steel bid, the contract documents also required the steel detailer to provide
models and attend meetings early during the detailing phase, with the goal that the
design team would review the model, and thus expedite review of the shop
submittals, with minimal re-submittals required.
The Steel Contractor, Owen Steel, and their detailer, 4D Global Group, embraced
these ideas, and participated in several in person and on-line meetings as the model
was built and reviewed. This not only helped speed reviews, but the improved
interaction with the detailer, together with the BIM design process that was followed
enabled a substantial reduction in the number of RFI’s that were raised in the process.
In the 5 years that have passed since this phase was completed, the software available
has improved to the point where conventional shop drawings could be eliminated
entirely.
Due to the fast-track nature of the project, the detailing model, produced in Tekla,
was available to the design team, before the completion of Construction Documents
by the architect, and hence this fully detailed model was able to be overlaid with the
Architecture and MEP models and further clash checks carried out.
256
STRUCTURAL DESIGN CHALLENGES
A significant structural challenge arose when the wind tunnel testing was completed,
after the end of the schematic design stage. The testing revealed that the loading on
the building from the wind was less than that required by the code, and that which
had been assumed in the preliminary design. Although the loading was lower, the
accelerations that occupants would experience at the top of the tower were predicted
to be higher than desirable according to most guidelines.
Desirable
Options to reduce the accelerations to an acceptable level were studied, and this
included adding more steel to the lateral system in order to add stiffness, as well as
various options for adding damping to the structure. Because the loads were less than
originally designed for, this allowed for some steel weight to be removed, however
this would potentially increase accelerations further. If however a damping system
with sufficient damping was added, then the benefit of these reduced loads could be
taken, and overall steel tonnage reduced. The result of this was that damping was
demonstrated to be a much more cost effective solution than adding stiffness, as is
commonly the case for tall buildings.
Damping systems considered included tuned mass dampers, tuned liquid column
dampers, and a viscous damping system integrated into the structure of the building.
As the building included a mechanical room at the top of the tower, the intention was
to integrate the damping into this space. Both the tuned mass dampers and tuned
liquid column damping system would have required significant rearrangement of the
257
mechanical equipment to accommodate the damper, however a novel arrangement of
viscous dampers was developed that incorporated the dampers into a series of
outriggers connecting the core to the perimeter of the building.
By arranging the dampers into an outrigger configuration, and thus damping the
dominant flexural deformation rather than shear deformation, sufficient damping was
obtained with the use of just 7 dampers.
There are many challenges to designing a viscous damping system, in particular the
damping system must be analyzed as a part of the overall structure, rather than as a
separate bolt on system as can be done with a tuned mass damper.
The specification of the dampers for control of wind movements is quite different to
those used for seismic applications, where viscous dampers are more commonly used
in buildings. The dampers must operate at very small amplitudes to avoid building
movements being able to build up, and must also cycle constantly whenever the
winds reach a sufficient level. To meet these challenges, and allow for a long
maintenance free life, a damper with no conventional seals provided by Taylor
Devices, was selected.
Despite the high specification of the dampers, the overall cost of the system was less
than half the cost of a conventional tuned mass damper that would have achieved a
similar level of damping.
A more detailed description of the damping system and the challenges of integrating
this into the design is contained in the paper ‘Increasing Efficiency in tall buildings by
Damping’ (Jackson and Scott 2010).
258
DELAYED CONSTRUCTION
One of the most significant challenges encountered during the project was caused by
the economic crisis in 2008. Because of the changed market conditions the developer
chose to postpone construction until the market was more favorable. The team
quickly moved to put in place a plan to allow for an orderly demobilization and
efficient restart when the time was right. The foundation construction and steel
fabrication was already under way at this time, and so the team decided to complete
the structure up to the grade level to both stabilize the perimeter walls and allow the
site to be more easily waterproofed and protected. The fabrication continued for the
remainder of the steel, and this was stored in a yard in South Carolina, close to
fabricator Owen Steel. The team developed a plan to ensure that the site would be
safe and agreed a monitoring program with the department of buildings to make
certain the site would continue to be secure.
When time came to restart construction, the team was concerned about the corrosion
that had developed on the surfaces that had been prepared for slip-critical
connections; in particular, those that had been blast cleaned to achieve a Class B
surface. The RCSC bolting specification suggests that some corrosion for up to a year
should be acceptable, but no further data was available to specify exactly what level
of corrosion over what period of time would still perform in a satisfactory way.
We decided to test a sample of representative connections from the stored pieces and
verify the coefficient of friction directly. The resulting tests showed that the stored
259
steel exceeded the required 0.5 coefficient of friction, and all of the samples showed
higher levels of friction than some freshly blast cleaned control samples, some of
which did not quite reach the required friction level.
CONSTRUCTION RESTART
Once the developer made the choice to restart construction, several unusual
opportunities and challenges arose. The availability of the already fabricated steel
meant that steel erection could start almost immediately, and the previously
completed and waterproofed cellar levels meant that some of the critical MEP spaces
were already available for installation, however none of the MEP subcontractors had
yet to start their work. This meant that engineering, coordination and fabrication for
MEP trades, was now on the critical path for construction, and any reduction in this
time would directly improve the schedule.
One of these installation areas, where construction could begin, was the switchgear
room, which was on the critical path of the construction schedule. Another challenge
during the cellar level coordination was the fact that because no electrical contractor
coordination was carried out in the first phase of construction, no conduit had been
embedded into the slab; this resulted in substantial amount of electrical conduits to be
accounted for in coordination.
Navisworks was used for 3D coordination; and every trade used their own choice of
software specialized in their field. Within 20 sessions, coordination of the cellar
levels was completed. Thanks to BIM, subcontractors were able to go into fabrication
from the coordination model almost immediately. Typically, on similar projects,
subcontractors would submit shop drawings before and after coordination for
engineer’s review and approval. In this project, the MEP design engineer, Cosentini,
participated in the 3D coordination, and the final model was submitted for their
review and approval. As there was no need to wait for shop drawing review and
approval, fabrication started almost immediately after coordination.
260
RFIs that would have been submitted if the team did not utilize BIM and engage the
engineer during this process. Most of the RFIs were being addressed on the fly and in
person by the engineer. Virtual meetings were used when the engineer was not
available to attend all day meetings.
With the help of strategies outlined above, MEP installation started in cellar levels
earlier than scheduled. One of the key areas, as mentioned before, was the switchgear
room. Early start of this area eventually resulted in early delivery of permanent
power, which was one of the major construction milestones scheduled for December
of 2012. Instead, this milestone was delivered in May of 2012. Needless to say,
getting permanent power earlier than scheduled benefited the overall construction
schedule.
261
BIM it was possible to identify these penetrations early on and with great accuracy
allowing steel subcontractor to apply penetrations without any field measurements.
One of the most challenging areas of 250 West 55th Street project was the
construction of 39th floor mechanical room. The construction team has coordinated
the installation sequence of this area in great level of detail with the help of BIM.
Specifically, 4D-scheduling was used to identify underutilized and overcrowded
areas, leading to an efficient staging and sequence of installation. The team also
heavily relied on the 3D-model to identify necessary structural steel leave-outs.
Two particular examples of obtaining tangible results from using BIM were boilers
and the generator. These were the largest and heaviest pieces of equipment on this
floor, originally intended to be set during steel erection on temporary posts and
dropped to their permanent positions after floor was poured. With the staging
262
coordination efforts outlined above, the construction team was able to continue to
pour concrete and set both of these equipment without the use of temporary posts.
This way, the 39th floor was delivered to MEP trades earlier and substantial schedule
savings were realized. Another important benefit of this strategy was the reduced risk
due to not double-handling this sensitive equipment.
Another example as a result of structural steel coordination on the 39th floor was the
issue with cooling tower dunnage steel. This steel was fabricated prior to the approval
of cooling towers due to the fabrication schedule and stalled nature of this project.
Early enough in the project the discrepancy between cooling towers and dunnage
steel was identified, allowing the team to make adjustments on cooling towers and
giving the structural engineer enough time to analyze and make sure that the offset
nature of the new layout was structurally acceptable.
Once the tower cranes were erected, and steel erection restarted, the steel progressed
very quickly with topping out achieved in approximately 9 months. With the MEP
trades able to follow closely behind through the expedited coordination and
accelerated schedules.
263
CONCLUSIONS
The design and construction of the 250 West 55th St tower utilized a tightly integrated
approach in order to maximize the benefit to the client, and minimize construction
issues and cost. This included extensive use of BIM during design and construction,
as well as a closely integrated team approach to dealing with project challenges.
Overall, the full building TCO was received in May of 2013, compared to the initial
scheduled date of September of 2013 when the project was restarted. From cost
perspective no construction contingency was used throughout the project. Although
there are many other factors in these great achievements, the carefully integrated
approach to design and construction using the best available BIM tools, was a key
factor.
REFERENCES
264
265
CASE STUDY: 8
71st Annual Structural Engineers Association of California (SEAOC) Convention Santa Barbara, California, September 2002
266
the longitudinal direction. For the transverse direction, plan. A 24-inch (61.0cm) deep pad foundation is
one-bay SMRF is provided at each column line. The provided at WF columns.
location and quantity of SMRF is the same for the roof
Indicates Indicates
Composite Moment
WF Beam Frames
267
to be active, is closest to the site at a distance of 0.2 km. Great Valley Fault. The 1889 Antioch (M 6.3)
The next closest faults are segments 4 and 5 of the earthquake is attributed to the Greenville fault (Singh,
Great Valley Seismic Source Zone located at distance 2002). The 1997 Uniform Building Code (ICBO, 1997)
of 6.6 and 9.8 km, respectively. These faults are ignores the near fault effects from blind thrust faults
considered to be blind thrust faults. The closest fault such as the Great Valley Source, therefore, the site
considered capable of surface rupture is the Green specific response spectra were created for this project
Valley-Concord fault located at 18 km from the site. (Singh, 2002). See figure 3 for a 475-year return and
The significant nearby earthquake was the 1892 figure 4 for a 2,500-year return response spectra.
Vacaville/Winters (M 6.5), which was attributed to the
Average
Fault Normal
1.400 Fault Parallel
Acceleration (g)
1.200
1.000
0.800
0.600
0.400
0.200
0.000
0.000 0.500 1.000 1.500 2.000 2.500 3.000 3.500 4.000
Period (sec)
2.000
1.500
1.000
0.500
0.000
0.000 0.500 1.000 1.500 2.000 2.500 3.000 3.500 4.000
(Period) (sec)
268
2000 NEHRP was used to design SMRF. The following discussion, only the longitudinal frame is considered.
are design parameters for the Equivalent Lateral Force Tributary weight of the roof is 380kip (1,690KN) and of
Procedure. the floor is 924kip (4,110KN). Table 1 shows the results
Seismic Use Group III I = 1.5 of the modal analysis.
SMS = 1.95g at 0.3sec. (site specific)
SML = 1.05g at 1.0sec. (site specific) Period (sec) Mass Participation %
SDS = 2/3 x 1.95g = 1.3g Mode 1 0.69 84
SDL = 2/3 x 1.05g = 0.7g Mode 2 0.27 16
Seismic Design Category D Table 1: Results of Modal Analysis
SMRF: R = 8, Cd = 5.5 (Conventional Design)
Cs = SRDS I = 0.24g
Nonlinear static pushover was conducted to gauge an
Cs = SDL I = 0.32g earthquake performance of this frame. Figure 6 shows
RTa
capacity/demand spectra with a site-specific 475-year
Ta = 0.4 return event. Please note that figure 6 is for a single
0.24g should be used for seismic shear. degree of freedom system.
The above value is compared with 1997 UBC. The following are results of the pushover for a 475-year
Ca = 0.44xNa = 0.44 return event. The results are converted to the multi
Cv = 0.64xNv = 0.64 degree of freedom system.
Near field factors are 1.0, since blind thrust faults are Maximum roof displacement = 5.6 inch
ignored by 1997 UBC. (14.2cm)
R = 8.5, I = 1.25 Base shear = 0.80g
2.5 CaI Effective period = 0.71sec.
V= R = 0.16g Effective damping = 8.4%
Cv I Max drift ratio = 0.016
V = RT = 0.24g Some yielding events were observed at the bottom of
0.16g should be used for seismic shear. This value is the first floor columns and second floor beams. The
lower than 2000 NEHRP value. It is affected by the drift ratio is reasonable, but the base shear of 0.8g may
magnitude of R, I, and near field factors. The 2000 cause nonstructural damage to the second floor
NEHRP allows 75% of seismic shear to be used for the equipment and roof HVAC units. This is the limitation
damped frame if the total effective damping is 14% or of the conventional design. This fairly strong SMRF
greater. Therefore, 0.75x0.24g = 0.18g. SMRF is provides near elastic response. However this system
designed for both strength and drift criteria using 0.18g also produces high roof and floor accelerations. For this
base shear. The 0.18g value is larger than the 0.16g ground motion, the high frequency system such as shear
value required by the 1997 UBC; therefore it will be walls and steel brace systems would produce an even
used to design this frame to compare with the damped higher acceleration and increase seismic demands on
frame described later. The drift criteria is the controlling nonstructural components. The base isolation may be an
criteria of the design rather than the strength criteria. ideal solution for this case, yet, the cost increase was
Allowable story drift ratio is 0.015 and computed not allowed by the project requirement.
maximum drift is multiplied by Cd .
I
Figure 5 shows the longitude frame elevation. For the
transverse direction, SMRFs and dampers are provided
to approximate equivalent stiffness and strength as the
longitudinal direction. Therefore, for the following
269
30'-0" (TYP) W21X50 @ ROOF
(TYP)
(9.14 m)
(4.88 m)
16'-0"
W24X68 @ FLOOR
(TYP)
(4.27 m)
14'-0"
W14X159 COLUMN PAD FOOTING 3'-0"x3'-0" (0.92 m x 0.92 m)
(TYP) (TYP) GRADE BEAM (TYP)
1.4
5% Damped Spectra
1.2 Demand Spectra
Capacity Spectra
Spectra Acceleration (g)
0.8
0.6
0.4
0.2
0
0 1 2 3 4 5 6 7 8
Hi-tech Systems Design elevation. The difference from figure 5 is the “pinned”
foundation condition and roof beam sizes. See table 2
The structure was then redesigned using SMRF with for FVD properties.
FVDs per 2000 NEHRP. The base shear of 0.18g as Damping Constant ‘C’ Per a FVD
described above was used to resize the frame members. Unit
The 2000 NEHRP describes that the frame members are 1st Floor FVDs 60kip-sec2/in (105kN-sec2/cm)
sized with strength requirements of the code level 2nd Floor FVDs 30kip-sec 2/in (52.5kN-sec2/cm)
(0.18g), and FVDs are provided to control displacement Table 2: FVD Property
of the structure. See figure 7 for the new frame
270
The damping force is defined as
F = CV α
V = Velocity
α = 0.6 Nonlinear time history analysis showed that all SMRF
These damping properties were selected based on an elements remained elastic. The maximum roof
optimal displacement reduction and FVD force output. displacement is reduced by 55% from the conventional
Table 3 shows the results of the modal analysis. The design; the base shear is reduced by 65%; and the
results show that the predominant period shifted from maximum story drift ratio is reduced by 38%. The
0.69sec of the conventional SMRF to 1.2sec. This maximum FVD force per unit is 206kip (916kN) at the
frequency shift effectively brings the dynamic response first level. These results show that the structural damage
to a lower acceleration range in the site-specific is eliminated and nonstructural damage is significantly
response spectra. reduced by adding FVD. Figure 8 shows FVD force vs.
FVD displacement for one of the first floor FVD units.
Period (sec) Mass Participation (%) It shows the effect of the damping exponent 0.6. The
Mode 1 1.20 96.5 shape of the hysteresis loop is between the oval
Mode 2 0.08 03.5 (α = 1.0) and the rectangular (α < 0.1). Figure 9 shows
Table 3: Results of Modal Analysis FVD force vs. 2nd floor velocity for one of the first floor
units. It shows nonlinear response of FVD unit. Figure
The nonlinear computer model with discrete damping 10 shows FVD force at one of the first floor FVD units
elements were created using ETABS 7. Three sets of and first floor column bending moment of the first 20
time history ground motions compatible to a 475-year seconds of this 40-second record. It shows maximum
return event were synthesized by Singh (2002). FVD force is out-of-phase from maximum bending
Nonlinear time history analyses using step-by-step moment. Figure 11 shows the base shear of SMRF with
linear acceleration procedure were conducted. Table 4 FVD and the conventional SMRF for the first 20
compares the results of this analysis with the results of seconds. It shows a substantial reduction of the base
the push over analysis of conventional SMRF. shear. A linear time history analysis was conducted on
the elastic frame of the conventional SMRF. The elastic
frame was used since the push over results show near
Conventional
SMRF w/ FVD elastic response of the conventional frame. Results of
SMRF
linear time history and pushover analyses are slightly
Max. roof
2.5in (6.4cm) 5.6in (14.2cm) varied. Figure 12 shows the roof displacement of SMRF
displacement
with FVD and the conventional SMRF for the first 20
Max. base shear 0.29g 0.8g seconds. It shows a substantial reduction of the
Max. story drift displacement. Figure 13 shows energy balance. FVD
0.010 0.016
ratio energy dissipates the majority of the input energy.
Table 4: Performance Comparison for 475-year
Record
271
30'-0" (TYP) W18X40 @ ROOF W24X68 @ FLOOR
(9.14 m) (TYP) (TYP)
(4.88 m)
16'-0"
(4.27 m)
14'-0"
W14X159 COLUMN PAD FOOTING INDICATES FVD
(TYP) (TYP) (TYP)
250
200
150
100
50
Forces (k)
-50
-100
-150
-200
-250
-1.5 -1 -0.5 0 0.5 1 1.5
Displacement (in)
272
250
200
150
100
50
Force (k)
-50
-100
-150
-200
-250
-15 -10 -5 0 5 10 15
Velocity (in/sec)
Figure 9: FVD Force vs. 2nd Floor Velocity for 475-year Record
600
500
400
FVD Force
Moment (k-in) or Force (k)
200
100
-100
-200
-300
-400
-500
0 2 4 6 8 10 12 14 16 18 20
Time (sec)
Figure 10: FVD Force vs. Column Moment for 475-year Record
273
1500
Conventional SMRF
1000
SMRF with FVD
Base Shear (k)
500
-500
-1000
-1500
0 2 4 6 8 10 12 14 16 18 20
Time (sec)
Figure 11: Base Shear of SMRF with FVD vs. Conventional SMRF for 475-year Record
Conventional SMRF
6
-2
-4
-6
0 2 4 6 8 10 12 14 16 18 20
Time (sec)
Figure 12: Conventional SMRF for a 475-year Record vs. Roof Displacement of SMRF with FVD
274
5000
4500
4000
3500
3000
2500
Input Kinetic
Potential Inherent Damp
FVD
2000
1500
1000
500
0
0 2 4 6 8 10 12 14 16 18 20
The results of this case study show that the 2000 Gimmel, Lindorfar, and Miyamoto, “Design of a New
NEHRP procedure is a very effective way to design a Moment Frame Building Incorporating Viscous
damped structure. The elastic frequency of the structure Dampers Following the Guidelines of the 1999 SEAOC
is shifted to a low frequency that generates lower floor Blue Book,” Proceedings of ATC17-2, May 2002,
and roof accelerations while the story displacements are Redwood City, California.
controlled by dampers. The maximum story drift was
limited to less than 1.0%, while all members remained NEHRP, 2000, “Recommended Guidelines for the
elastic. The maximum base shear is 0.29g for a 475- Seismic Design of Buildings and Other Structures,”
year return event. The final study will include results of FEMA 368, Washington, DC
a 2,500-year return. These parameters indicate that
structural and non-structural damages are significantly ICBO, 1997, Uniform Building Code, International
reduced when compared to conventional lateral system. Council of Building Officials, Whittier, California.
The cost of FVDs are effectively offset by the reduction
in costs of the foundation system and the structural J.P. Singh and Associates, 2002, “Geotechnical and
steel of the roof beams. Seismological Findings and Recommendations,”
Richmond, California.
275
CASE STUDY: 9
Abstract Background
Richard Neutra’s iconic Tower of Hope on the Christ Built in 1968, the Tower of Hope was the final piece of the
Cathedral (formerly “Crystal Cathedral”) campus in Garden four-building campus that formed the original home to
Grove, California has been an important Orange County Reverend Robert H. Schuller’s growing Reformed Church of
landmark since it was built in 1968. The thirteen-story tower America congregation in Garden Grove, California. Designed
– the tallest building in Orange County when it was built – has by famed international architect Richard Neutra, the Tower of
been called an “overlooked masterwork in Neutra’s oeuvre” by Hope joined Neutra’s Arboretum worship hall and the Large
architectural historians. and Small Galleries to create an enclosed garden courtyard at
the heart of the campus. The Tower was originally planned to
Like many concrete buildings built prior to the 1971 Sylmar be a low-lying companion to the other low-profile buildings on
Earthquake in California, the Tower of Hope’s concrete frames the site but was ultimately reconceived as a slender vertical
lack the ductility needed to safely dissipate seismic energy. tower with 28,000 square feet of offices and classrooms in
After acquiring the Crystal Cathedral campus in 2012 the thirteen stories. The Tower of Hope along with the other three
Roman Catholic Diocese of Orange undertook a Neutra-designed buildings on the Christ Cathedral campus are
comprehensive renovation and seismic retrofit project to recognized by architectural historians as important examples
provide 21st century seismic resilience to the historic tower. of mid-century modernism as well as works in Neutra’s
This challenging seismic retrofit and renovation project was celebrated portfolio.
completed in 2015. The retrofit work included the installation
of fluid viscous dampers on the second through fifth floors of Reverend Schuller’s ministry grew dramatically during the
the tower in combination with fiber-reinforced polymer 1970s and 1980s as his televised “Hour of Power” became
strengthening of targeted concrete columns and walls. synonymous with televangelism and his campus grew to
include Philip Johnson’s landmark glass-and-steel clad Crystal
This paper focuses on two challenges unique to the Tower of Cathedral directly to the north of the Tower of Hope.
Hope. First, it was imperative that the retrofit design respect
the historically significant mid-century modernist architecture, In 2012, the Roman Catholic Diocese of Orange purchased the
preserving those features that were emblematic of that period former Crystal Cathedral campus including the Tower of Hope
of significance. Seismic retrofit construction was limited to from Reverend Schuller to serve as its long-planned diocesan
areas that didn’t affect Neutra’s open floor plate design cathedral. The Diocese immediately begin a program of
aesthetic or lessen the inside-outside connectivity of each of modernization and renovation of all of the buildings on the
the spaces. This openness was particularly challenging to newly re-named Christ Cathedral campus. From the beginning
preserve in the glass-walled first floor lobby where seismic the fate of the Tower of Hope was in doubt. During the
forces are at their most intense. The second unique challenge Diocese’s acquisition due diligence process in the Fall of 2011,
was the large damper connection forces that had to be a seismic assessment suggested that the Tower of Hope was
developed into the existing cast-in-place concrete frames the most vulnerable building on the Cathedral campus. While
without damaging the existing steel rebar. The strategies the Diocese recognized the Tower’s architectural and cultural
described by the authors are generally applicable to other significance, it decided that the safety of its large parish
historic buildings from the mid-century modernist movement population must ultimately take precedence. It was at that time
and to the use of fluid viscous dampers to retrofit concrete that contingency plans were made to demolish the Tower of
frames. Hope and replace it with a modern office building in case a
viable seismic retrofit solution could not be devised.
276
Building Description
Figure 1 – The Tower of Hope’s 13th floor Chapel in Figure 2 – Tower of Hope South Elevation.
the Sky offers 360o views of Orange County.
277
Figure 4 – Typical floor plan showing locations of
concrete moment frames (in blue) and concrete
shear walls (in red).
278
Seismic Vulnerabilities
The initial seismic assessment of the Tower of Hope was based
When the Diocese of Orange purchased the Christ Cathedral on a “Tier 1 Screening” as described in ASCE Standard 31-03
campus in 2012 the due diligence phase of the real estate “Seismic Evaluation of Existing Buildings.” This process
transaction identified the Tower of Hope as a building of consists of a series of quick checks to identify potential
elevated seismic risk due to its age and concrete moment frame vulnerabilities that warrant more detailed study. The
construction. The seismic vulnerabilities associated with non- prescriptive checklist of potential vulnerabilities was
ductile concrete frames and the risk they pose to buildings of supplemented by a detailed review of the construction
this age and construction type are well-known. As part of a documents by experienced structural engineers to identify
campus wide modernization and renovation program the potentially brittle concrete details and other system-wide
Diocese solicited the services of several structural engineers, vulnerabilities.
including Irvine-based integrated design firm LPA, Inc., to
perform a detailed evaluation of the Tower of Hope. This Several serious deficiencies were identified during the
initial assessment comprised three basic steps: data collection, screening phase, most of them related to non-ductile detailing
seismic screening, and identification of potential deficiencies. of the concrete frames:
A common challenge with assessment and retrofit of buildings Inadequate confinement of column reinforcing. The
of this age is that original construction documents are not often central core of each columns is confined with a tight
available. This potential challenge is amplified in a concrete spiral of #4 bars at a 2” on center. However, the
building because direct observation of the steel reinforcing is remainder of the vertical bars, including those at the
impossible and non-destructive testing methods are time- perimeter of the column that are potentially most
consuming and not always accurate. This challenge was effective in resisting flexural forces is confined with
largely bypassed on the Tower of Hope retrofit project, #3 ties spaced at 12” on center.
however, because the building is an important piece of
architectural history and the design team had incredible access Short splices in column vertical bars. Typical column
to original sources of information on the design and splices are 30 bar diameters.
construction of the building.
Vertical column bars are not fully developed into the
For the Tower of Hope project these issues were avoided foundation.
entirely due to the careful preservation of Richard Neutra’s
records by architectural historians at the “Richard and Dion Frame beam longitudinal bars not fully developed
Neutra papers, 1925-1970” archive at the Charles E. Young into frame columns. In multiple locations not all of
Research Library on the campus of UCLA. This archive holds the longitudinal bars are fully developed into the
nearly comprehensive documentation on the design and columns due to 90-degree hooks that don’t extend far
construction of the Tower of Hope. Complete construction enough into the columns or bottom bars that don’t
drawings by Richard and Dion Neutra, Architects and have hooks at all.
Associates and J. Kinoshita & Associates Consulting
Structural Engineers dated May 15, 1966 proved to be Torsional irregularity. The stair tower at the
instrumental in understanding the construction of the Tower. northeast corner is enclosed with 12” thick concrete
In addition to original construction documents, the design team walls while the much larger main tower is a moment-
was able to review meeting minutes, correspondences, resisting space frame. The difference in lateral
construction RFIs, submittals, and crucially, inspection and stiffness of these two systems leads to a torsional
testing reports. The availability of original concrete testing response and induces amplified seismic forces in the
reports was important for two reasons. First, it gave the design outer frames and the relatively narrow portion of floor
team confidence in the as-built compressive strength of the slab that ties the stair tower to the rest of the structure.
concrete. This confidence is directly applied analytically in
the form of a knowledge factor, , that is a part of the seismic Taken in total these deficiencies – particularly those related to
retrofit provisions of ASCE Standard 41-06. The most non-ductile concrete detailing – represent a serious risk to the
important discovery during the design team’s review of building despite a seismic-force resisting system that is
Neutra’s project records was the fact that during construction otherwise relatively well-proportioned and redundant for a
the contractor decided to use 4,000 psi concrete in lieu of the building of this size.
3,000 psi concrete called for in the structural. This change is
not insignificant in relation to the seismic performance of the
building as is discussed further below.
279
Figure 5 – Typical column reinforcing detail.
280
Seismic Retrofit Constraints
281
Seismic Retrofit Design shear, flexure, and axial behavior and rebar slip deformations
per the requirements of ASCE 41-06.
Based on the aesthetic, historic, economic, and practical
constraints the seismic retrofit strategy for the Tower of Hope The seismic analysis of the building was performed using
was designed to meet the following objectives: ETABs Version 9.7 structural analysis and design software
published by Computers and Structures, Inc. The finite
Respect the period of architectural significance and element model was subjected to seven pairs of site-specific
historical context of the Tower by not adding response spectra-scaled time histories for each of the two
structural elements to the first floor, twelfth floor earthquake hazard levels. The time histories were constructed
offices of Reverend Schuller or thirteenth floor by Leighton Consulting, Inc. geotechnical engineers based on
Chapel-in-the-Sky earthquake records having magnitudes between 6.0 and 7.0 at
Limit new seismic-force resisting elements to the distances ranging from 10 to 20 kilometers and geologic and
perimeter column lines to maximize usable interior seismic/tectonic environments compatible to the site of the
space and allow for future flexibility. Tower of Hope. Leighton Consulting, Inc. built these site
Avoid the need for adding new foundation elements specific acceleration time histories to meet the requirements of
in order to minimize construction costs. Section 1.6.2.2 of ASCE 41-06. Because seven sets of time
histories were considered in the analysis the average value of
LPA, Inc. structural engineers worked closely with the Diocese each of the maximum response parameters from each time
of Orange to establish the structural performance objectives for history was used for assessing the acceptability of each
the seismic retrofit. In accordance with the voluntary seismic structural element. Multi-directional seismic effects were
retrofit provisions of the 2013 California Building Code and taken into account by using 100% of the response parameter
American Society of Civil Engineers Standard 41-06, “Seismic with a given time history applied in the X-direction combined
Rehabilitation of Existing Buildings” (ASCE 41-06) the with 30% of the response parameter with the time history
following structural performance objectives were selected: applied in the Y-direction. This resulted in fourteen time
history analyses for each of the two earthquake hazard levels.
Life Safety performance during an earthquake having
a 10% probability of exceedance in 50 years (BSE-1) The results of the time history analysis were exported to
Collapse Prevention performance during an Microsoft Excel and post-processed using proprietary LPA,
earthquake having a 2% probability of exceedance in Inc. spreadsheets and Visual Basic macros. Each existing
50 years (BSE-2). concrete beam, column and shear wall that resists seismic
forces was checked against the ASCE 41-06, Supplement No.1
In order to satisfy both the practical and analytical project acceptability criteria for both Life Safety and Collapse
objectives two specialized structural components were used in Prevention performance. These acceptance criteria are based
tandem. First, supplemental damping was added to the on multiple force-controlled or deformation controlled actions
building in the form of diagonally-oriented fluid viscous for each element and explicitly include consideration of stress
dampers. This served to reduce the seismic demand on the level, rebar splice length, confining reinforcement, and
existing concrete frames without adding significant foundation development of rebar into beam-column joints. Because of the
forces. Second, fiber-reinforced polymer (FRP) was added to lack of ductile rebar detailing at the Tower of the Hope the
select concrete columns and walls for increased strength. acceptance criteria of many of the concrete beams and columns
necessitates nearly elastic behavior.
The structural design for the seismic retrofit followed the
linear dynamic procedure of ASCE 41-06 using site specific
time histories. The linear time history procedure was chosen
for two reasons. First, the fluid viscous dampers are velocity-
dependent so a time-history analysis was needed to model the
effect of this supplemental damping. Because of the limited
ductility of the existing concrete beams and columns these
elements had very little post-elastic capacity so any effective
retrofit design would necessarily result in nearly linear behaver
of these elements. Because of this practical reality and for
computational efficiency a linear time history analysis was
performed. The concrete elements were modelled with
reduced effective stiffness parameters between 30% and 70%
of EcIg for flexure and 40% of EcAg for shear to account for
282
resulted in dampers with a maximum of 260 kips of axial force
and 4” of stroke during the suite of BSE-2 time histories. A
factor of safety of 2.0 against yielding and 2.5 against ultimate
failure was used in the design of the damper components.
Taylor Devices of North Tonawanda, NY designed and
fabricated the 32 dampers for the Tower of Hope.
The final retrofit design for the Tower of Hope balanced the
addition of fluid viscous dampers and FRP-strengthening of
columns and walls with the goal of minimizing total
construction cost. To that end, the retrofit design process was
iterative with supplemental damping increased until the
addition of more damping had only incremental effect on the
acceptability of the existing concrete frames and shear walls.
The final result was a design that included dampers added in a Figure 11 – Fluid viscous dampers on the north side
two-story X configuration on each of the perimeter column of the Tower of Hope.
lines on stories two through five. After analytically
experimenting with several different combinations of damper
properties it was determined that dampers with a damping
constant, C, of 120 kip-sec/in and a velocity exponent, , of
0.5 was most effective for this building. These properties
283
Figure 12 – West elevation of the Tower of Hope, fluid
viscous dampers visible at second through fifth
floors.
284
Seismic Retrofit Detailing and Construction
10
285
Figure 16 – Damper connection to existing concrete
beam-column joint detail.
At the west side of the building the concrete frame beams are
narrower than on the other three sides because of the proximity
of the building’s elevator shaft. This condition reduced the Figure 17 – Damper connection to beam and column
effectiveness of expansion anchors installed on the top surface at southern column line.
of the beam due to reduced concrete edge distance. Because of
this Grade 105 through-bolts were added through the two Maintaining and preserving the mid-century modernist
columns on the west side of the building. The through-bolts at aesthetic and the specific elements of Richard Neutra’s design
both column and beam were designed to resist the combined was as important as the structural engineering requirements of
effects of tension and shear. Because the column ties were the project. While much of the FRP wrap occurred within the
spaced too closely to avoid damaging them when installing the curtain-wall envelope of the Tower there were locations where
through-bolts the retrofit design included the addition of FRP was needed on the exterior of the building as well. In
confinement FRP between the connection plates and the order to hide the FRP yet maintain an aesthetic true to the
concrete columns on this side of the tower. The sequencing original period of architectural significance the design team
and coordination between the GPR testing company, structural worked closely with the team’s architectural historian to
engineer, FRP sub-contractor and steel sub-contractor had to develop fluted 10-gage metal cladding that was differentiated
be carefully orchestrated to ensure that the dampers and FRP from but consistent with the original Neutra design.
could be installed without damaging the longitudinal column
and beam reinforcing.
11
286
The addition of supplemental damping to an existing
structure is an effective way to significantly reduce
seismic demands on the building. Fluid viscous
dampers are most effective near the base of the
building but need not extend through the first floor to
the foundation to improve overall seismic
performance of a structure.
Figure 18 – Architectural metal paneling to hide FRP Locating and avoiding existing steel reinforcing in a
at column adjacent to building entrance. Reference large concrete frame is very challenging. While the
Figure 14. quantity of bars may be understood by reviewing
record drawings and other as-built information the
Conclusions exact location in the field may vary by several inches
in any direction. Careful detailing to allow for
This paper presented a case study in performance-based flexibility during construction and thoughtful
seismic retrofit for a historically significant non-ductile coordination and planning between the structural
concrete frame building using a combination of fluid viscous engineer, contractor, testing company and project
dampers and fiber reinforced polymer (FRP). Several of the inspector is essential when new steel elements are
lessons learned by the project team on this project may be being added to an existing concrete building.
broadly applicable to other projects with similar project goals
and features. These general conclusions include the following: Acknowledgements
12
287
The authors would also like to acknowledge the contributions
of the LPA, Inc. integrated architecture and interior design
team led by Jim Wirick, AIA, and Maria Louie.
References
13
288
CASE STUDY: 10
Strong
Renovation and Retrofit
Medicine
By Douglas R. Wilson, P.E.,
Russell D. Kent, P.E.,
Stephen Stanek, P.E., and
David B. Swanson, P.E., S.E.
N
aval Hospital Bremerton, in This effort provided the US Navy and the
Bremerton, WA, serves 60,000 design team with a “big picture”
A much-needed military families in the Puget overview of the building stock and seis-
seismic retrofit is just Sound area. Located near
Seattle, it is only one of two
mic hazards, as well as an initial relative
ranking of seismic risk among the facili-
what the doctor major hospitals on Washington’s Kitsap ties. It was an exceptional tool to priori-
Peninsula. In the aftermath of a serious tize further work for investigating in
ordered for this aging natural disaster, like a large-scale earth- more detail those facilities with the high-
quake, the hospital could be called on to est risk.
naval hospital immediately serve more than 250,000 One of the high-risk buildings was the
people. late 1960s-era main hospital building—a
serving thousands nine story, 250,000 sq ft. structure with a
on Washington’s First Step structural steel moment frame, compos-
The hospital complex includes more ite concrete on metal deck floors, precast
Puget Sound. than 20 buildings, some of which were concrete cladding, and concrete stair
constructed as early as the 1930s. The US towers. The main hospital building did
Navy wanted to know the seismic risk of not have the worst hazard score. How-
the Bremerton medical facility, and how ever, the structure is significantly larger
best to go about mitigating that risk. than any of the other medical buildings
Starting in 1999, structural engineers from in the complex and is home to the most
Reid Middleton embarked on a series of essential medical functions.
seismic screenings and evaluations of the
various naval hospital facilities to system- Recommendation
atically determine seismic deficiencies. A detailed seismic evaluation of the
The first step was to understand the hospital using performance-based engi-
extent and type of seismic structural haz- neering standards (FEMA 310 – Hand-
ards and evaluate the risk based on book for the Seismic Evaluation of Buildings–
building type, use, and occupancy. A Prestandard and FEMA 356 – Pre-
FEMA 154 – Rapid Visual Screening of standard and Commentary for the Seismic
Buildings for Potential Seismic Hazards: A Rehabilitation of Buildings) was performed
Handbook techniques were employed to to gain a better understanding of the
screen and document initial findings. potential seismic deficiencies.
289
The building’s lateral force resisting
Nisqually Earthquake Scaled to 10% in 50 Years
system (LFRS) is comprised of a highly
redundant steel moment frames system ∆ = 12.1”
at all beam-to-column connections. With (0.74% Drift)
Roof
more than 1,200 moment connections, the Floor 7
LFRS has a large amount of redundancy.
Floor 6
However, it is too flexible, resulting in
∆ = 3.8” Floor 5
excessive drift, large torsional response (0.47% Drift)
of the narrow tower, high expected rota- Mechanical
connections. Floor 2
Additionally, there was incompatibil-
ity between the flexible LFRS and the Floor 1
∆ = 2.4” Floor 5
Mother Nature Steps In (0.30% Drift)
Mechanical
In February 2001, the magnitude 6.8
Floor 4
Nisqually Earthquake shook the Puget
Sound area. Shaking at the hospital was Floor 3
290
ity to minimize the impact of construc-
tion on essential hospital operations. The
project will breathe life back into the
building for a cost in line with other
upgrades to the facility. ★
291
CASE STUDY: 11
ABSTRACT
An impediment to the use of seismic protection devices has been the difficulty for
practicing engineers to design buildings with isolation system or damping devices.
ASCE/SEI task committees charged with the development of a new generation of codes
for seismic design and retrofit of buildings have updated the relevant code sections with
one goal being to encourage the use of such devices. An effort was undertaken to
develop a step-by-step design guideline for such design. Following the preparation of
guideline, incremental analysis of four steel SMF building models was undertaken. The
benchmark model was designed using the strength and drift requirements of ASCE 7-
16. The other models were based on provisions of Chapter 18 of ASCE 7-16. For one
model the lower base shear value was used, and for a third model, the drift ratios were
further limited to obtain enhanced performance. Lower- and upper-bound analyses as
required by ASCE 7-16 were conducted to size the dampers. The models were then
subjected to incremental nonlinear analysis and key response parameters were
evaluated. In all cases, the use of dampers resulted in reduction in the hinging of SMF
members. It was noted that the best performing model was the model designed for 100%
of nominal base shear and above minimum effective damping had superior performance,
remaining elastic at design earthquake, and having almost no residual displacement at
very large earthquakes.
INTRODUCTION
Overview. Fluid viscous dampers (FVDs) were originally developed as shock absorbers
for the defense and aerospace industries. FVDs consist of a cylinder and a stainless-steel
piston. The cylinder is filled with compressible silicone fluid. The damper is activated
by the flow of silicone fluid between chambers at opposite ends of the unit, through
small orifices. Figure 1 shows the damper cross-section. In recent years, they have been
used extensively for seismic application for both new and retrofit construction. During
292
seismic events, the devices become active and the seismic input energy is used to heat
the fluid and is thusly dissipated. After installation, the dampers require minimal
maintenance. They have been shown to possess stable and dependable properties for
design earthquakes. Figure 2 shows the diagonal dampers placed in a reinforced concrete
moment frame building.
Figure 1. FVD cross section (Taylor 2017) Figure 2. Diagonal FVD in a building
ASCE 7-16 design procedure. The general approach is to design the SMF members for
the strength requirements of the building code only. Such building would then meet all
the relevant requirements of ASCE (2016) except the limitations for the SDRs. FVDs
are then added to design to reduce the SDRs and provide compliance with all the code
requirements. Since the force in FVDs is primarily out-of-phase with the inertial forces,
the demand on the existing members of the foundation is not significantly increased.
However, a second design check for the model with the dampers in necessary to assure
that the design is still satisfactory.
The provisions in ASCE 7 (2016) provide information on the bounding analysis.
For viscous dampers it is anticipated that the property modification factors factors)
to be in the range of +/-15%. The upper bound analysis would govern the requirement
for the damper force, whereas the lower bound analysis will determine the damper
constant necessary to meet the SDR requirements.
293
When a building is designed according to Chapter 18 of ASCE 7-16, it is
permissible to reduce the base shear demand to as low as 75% of the computed demand
to account for the beneficial effect of supplementary damping. The effect of this
reduction in strength on the response of the structure to large earthquakes is not well
known.
Additionally, currently there are no provisions on the minimum effective
damping to be added as part of the design process. Research (Miyamoto and Gilani
2015) has shown that enhanced performance with a reduced SDR can be archived for
the design by using larger dampers. While the larger (or more) dampers will add slightly
to the initial cost, both the seismic performance and the life-cycle cost are significantly
improved.
In this paper, analytical investigation of an example steel SMF with dampers is
presented. The models were designed per ASCE 7-16 for the design earthquake (DE)
and then subjected to larger earthquake and key responses and level of expected damage
(assumed correlated to the plastic hinging and plastic hinge rotations) was investigated.
Table 1 summarizes the key parameters considered as part of this investigation.
Building Model. The five-story building is square in plan measuring 150 ft on a side
consisting of five 30-ft long bays. Typical stories are 13 ft tall. The gravity system
consists of a 4-in thick concrete slab supported by steel gravity beams and columns. The
lateral force resisting system (LFRS) comprises three bays of steel SMF placed on the
perimeter. The building seismic mass is approximately 10,000 kips. A typical frame on
the perimeter was selected for analysis. The dead load and inertial mass tributary to this
frame were included in the model. Figure 3 presents elevation an elevation view of the
model.
Seismic demand. The seismic demand was based on a typical location in Los Angeles,
California, with mapped short-period (SS) and 1-second (S1) spectral accelerations of
1.5g and 0.6g, respectively. The structure was classified as Risk Category II (I = 1.0)
and located on Site Class D. Thus, the design earthquake (DE) short- and 1-second
spectral accelerations were equal to 1.0g and 0.6g, respectively. This value placed the
structures in Seismic Design Category (SDC) D, according to the ASCE/SEI 7
definition, for both short- and 1-second spectral intensities. The spectral acceleration
(Sa) as a function of period (T) can be obtained for all period ranges of interest. The
design spectrum is shown in Figure 4.
294
Following the design of moment frames according to ASCE/SEI 7 requirements
for strength, dampers were sized to limit story drift ratios for models B1 through B3.
For new structures that use energy dissipation devices, the engineers can use either the
nonlinear response history analysis (NLRHA) procedure or other methods such as
equivalent lateral force or response spectrum analysis. The use of methods other than
NLRHA are subject to certain limitations. The NLRHA requires that the dampers be
modeled as nonlinear elements to capture their force-velocity response. However, the
structural members in most cases can be modeled as linear. This approach was used to
size the dampers.
To perform NLRHA, seven pairs of independent pairs of strong motion data
were selected from the PEER NGA West database (PEER 2017). Either scaling or
spectrum-matching of records is permitted. In this example, the matching procedure is
used. The recorded accelerations were spectrally matched to the target spectrum of
Figure 4; and presented in the same figure. In this investigation, one of the components
for each record was used in analysis.
Building design. The equivalent lateral force (ELF) procedure of ASCE 7-16 was used
to design the members of the LRFS for the models. The first model was designed for
both strength and drift, whereas, the last three models were checked for strength
provisions only. The design of the models was based on the current seismic provisions
and thus all AISC seismic requirements (2016a and 2016b) were met. The requirement
for the strong column-weak beam governed the size of several columns; especially for
B0. As it is common in practice, the same beam or column sizes were used for a given
story. In addition, the members were grouped to reduce the number of member sizes for
a more efficient design. Table 2 summarizes the size of LFRS members.
295
L4-Roof W24x176 W24x131 W24x131 W24x94
L1-L3 W24x94 W24x76 W24x76 W24x55
Beams
L4-Roof W24x76 W24x62 W24x62 W24x55
Table 3 presents the SDRs computed for each model. The listed values are the so-called
inelastic SDR as defined in ASCE 7-16. For models B1 through B3, FVDs are added to
lower the SDR to the 2% threshold value. The fundamental period for each model is also
shown in the figure.
Damper property selection. The initial selection of damper size was based on the
approximate reductions in the response listed in ASCE 7-16. The damper constant (C)
was then optimized to provide an SDR of approximately 2% (1% for B2) for the level
with the highest SDR for the lower bound NLRHA; see Table 4. Since there are only
five levels in the building, one size damper was used for all elevations. For all dampers,
nonlinear models with a velocity exponent () of 0.5 were used.
Table 5 summarizes the nominal damper properties from analysis. The damper
force and displacement correspond to the average value from the seven NLRHA for the
damper with the largest response.
296
Table 6 presents the computed damper force and displacements from the upper bound
and lower bound analyses. Note that the increase in the damper force from upper bound
analysis is somewhat mitigated because nonlinear dampers are used.
ASCE 7-16 requires that the dampers be sized to resist forces, displacements, and
velocities from MCER ground motions. Table 7 presents the expected displacement and
force capacity of dampers based on the ASCE 7-16 requirements.
ANALYSIS PROGRAM
Overview. In this section, the response of the four models to large earthquakes is
investigated. For analyses, the following assumptions were made: a) for incremental
analysis, epsilon effect is usually used to account for the variation on the spectral shape
of ground motion for larger intensities (Vamvatsikos and Cornell, 2004). This factor was
not included in the analysis; b) since the model is representative of new construction, it
was assumed that ductile beam-to-column connections were used. As such hinge
properties for compact sections from Table 9.6 of ASCE 41-17 (2018) were used for the
beams and columns (see Figure 5); c) the panel zone was not explicitly modeled,
however, the centerline dimensions without rigid end offsets were used; d) research
(Miyamoto and Gilani 2015) has shown that reaching the damper force and stroke
capacities can have significant effect on the response of structures with dampers. This
effect was not explicitly modeled; however, the damper forces were monitored, and a
limit state was considered when the force in the dampers reached its capacity; e) Damper
manufacturers (Taylor 2017) typically use a larger factor of safety for the damper force
than required by ASCE 7-16; however, since the objective of the analysis was to strictly
comply with the ASCE 7-16 requirements, such increase in capacity was not accounted
for in the analysis; and f) to expedite the analysis and data processing, incremental
analysis was performed using only one of the seven records. The selection of the record
was based on how close an individual record represented the average response. Figure
6 presents the individual response from seven records normalized to the average
297
response at each level. The record with the least deviation is identified with a solid line
and used hereafter.
5
Story
3
1
0.7 0.9 1.1 1.3
SDR, ratio to average of seven
Figure 5. Nonlinear analysis model Figure 6. Response normalized to average
ANALYSIS RESULTS
Deformed shapes. Figure 7 depicts the displaced shape of the model at maximum
deflection (not concurrent for all models) at four selected levels of incremental ground
motion. In the figures, the models correspond to B0 through B4 from top to bottom
respectively. The following is noted:
At 67%DE intensity, all models remained elastic and thus comply with the
assumptions used in the allowable stress design methodology
At 100%DE, B2 the model with enhanced design, remained elastic and thus
damage free. For the other three models, plastic hinges formed. The hinges for all
the models met the life safety requirement, which is the implied performance level
for the new buildings. The models with minimum supplemental damping (B1 and
B3) underwent less nonlinearity and met a higher performance
At 100%MCE, all models met the collapse prevention criteria or better whereas;
B2 met the higher immediate occupancy performance.
At 200%MCE, except for B2, large plastic hinge rotations beyond collapse
prevention are noted.
298
100%DE 100%MCE
150%MCE 200%MCE
Figure 7. Displaced shape of the models at given intensities
299
Displacement response. Figure 8 presents the displacement response of the top floor of
the models at the selected responses.
15
B0 B1
10 B2 B3
Roof displacement, in
‐5
‐10
‐15
5 10 15 20 25 30 35
Time, sec
100%DE
20
B0 B1
15 B2 B3
Roof displacement, in
10
‐5
‐10
‐15
‐20
5 10 15 20 25 30 35
Time, sec
100%MCE
40
B0 B1
30
B2 B3
Roof displacement, in
20
10
‐10
‐20
‐30
‐40
5 10 15 20 25 30 35
Time, sec
200%MCE
Figure 8. Key response parameters as a function of incremental intensities
300
Response evaluation. Key response parameters from analyses are summarized in Table
8. The maximum responses from analysis are shown. The values correspond to the
values at the top floor of the building. The results for B3 are not shown, as they were
similar to B1. These response parameters are the key in assessing the seismic risk for
the buildings, are indicative of downtime, and repair costs. The structures with dampers
experience lower accelerations and thus reduce demand on acceleration-sensitive
components. For the enhanced model B2, the residual displacement is essentially
eliminated. This parameter is critical whether a building needs replacement in the
aftermath of an earthquake.
Damper responses. Table 9 summarizes the damper forces from the analysis. As seen,
the damper forces at large earthquakes exceed the current ASCE 7-16 requirements. It
is recommended that a factor of approximately 2.0 beyond MCE be used for sizing
dampers—consistent with the current manufacturer practice (Taylor 2017).
CONCLUSIONS
New steel buildings were designed using provisions of ASCE 7-16. A baseline case was
designed using the code strength and drift requirements. The other three cases used
dampers to control the drift ratios. Different targets of base shear and SDR were used.
The analysis showed that:
When subjected to large earthquakes, models with dampers would experience
smaller plastic hinge rotations, SDR, floor accelerations, and residual
displacement
The enhanced model based on 100% of nominal base shear and larger effective
damping (smaller SDR) has superior performance. This model remained damage
free at MCE.
To utilize the beneficial effect of dampers, it is critical to size the units to have
sufficient strength. This is the current manufacturer practice and provides an
additional margin of safety for very large earthquakes.
301
REFERENCES
302
303
Edition History
Edition Summary of Changes Revision Date
304
90 Taylor Drive
North Tonawanda, NY 14120-0748
Phone: (716) 694-0800 | Fax: (716) 695-6015
www.taylordevices.com
12.20 Edition
