GENERAL PHYSICS 2
QUARTER 3 – MODULE 5
OHM’S LAW
General Physics 2
Republic Act 8293, section 176 states that: No copyright shall subsist in any work
of the Government of the Philippines. However, prior approval of the government agency or
office wherein the work is created shall be necessary for exploitation of such work for profit.
Such agency or office may, among other things, impose as a condition the payment of
royalties.
Borrowed materials (i.e., songs, stories, poems, pictures, photos, brand names,
trademarks, etc.) included in this module are owned by their respective copyright holders.
Every effort has been exerted to locate and seek permission to use these materials from
their respective copyright owners. The publisher and authors do not represent nor claim
ownership over them.
Illustrator:
Layout Artist:
Management Team:
General Physics 2
Quarter 3
Module 5 – Week
5
OHM’S LAW
3
Introductory Message
For the facilitator:
This learning resource hopes to engage the learners into guided and
independent learning activities at their own pace and time. Furthermore,
this also aims to help learners acquire the needed 21st century skills
while taking into consideration their needs and circumstances.
In addition to the material in the main text, you will also see this box in
the body of the module:
As a facilitator you are expected to orient the learners on how to use this
module. You also need to keep track of the learners' progress while
allowing them to manage their own learning. Furthermore, you are
expected to encourage and assist the learners as they do the tasks
included in the module.
The hand is one of the most symbolized part of the human body. It is
often used to depict skill, action and purpose. Through our hands we may
learn, create and accomplish. Hence, the hand in this learning resource
signifies that you as a learner is capable and empowered to successfully
achieve the relevant competencies and skills at your own pace and time.
Your academic success lies in your own hands!
This module was designed to provide you with fun and meaningful
opportunities for guided and independent learning at your own pace and
4
time. You will be enabled to process the contents of the learning resource
while being an active learner.
What I Need to Know This will give you an idea of the skills
or competencies you are expected to
learn in the module.
5
knowledge or skill
6
At the end
Assessment This is a task which aims to evaluate
of this
your level of mastery in achieving the
learning competency.
1. Use the module with care. Do not put unnecessary mark/s on any
part of the module. Use a separate sheet of paper in answering the
exercises.
6. Return this module to your teacher/facilitator once you are through with
it.
This module was designed and written with you in mind. It is here to help
you master the nature of Physics. The scope of this module permits it to
be used in many different learning situations. The language used
recognizes the diverse vocabulary level of students. The lessons are
arranged to follow the standard sequence of the course. But the order in
which you read them can be changed to correspond with the textbook
you are now using.
MELC:
Solve problems involving current, resistance and Ohm’s law in contexts such as, but not limited to
batteries and bulbs, household wiring and selection fuses
code
Specific Objectives:
Directions: Choose the letter of the correct answer. Write your answer on the space provided before
each number.
_____1. The amount of charge flowing through a cross-sectional area of a wire per unit of time is called
A. Current B. Power C. Resistance D. Work
_____2. According to Ohm's Law, current equals the voltage divided by the
_____3. What does the letter 'R' stand for in Ohm's Law?
_____6. What does the letter 'E' stand for in Ohm's Law?
A. 2 B. 5 C. 8 D. 10
_____8. If there are 5 Amps running through a 4 Ohm resistor, what will the voltage be across the resistor?
A. 9 B. 10 C. 15 D. 20
_____9. If the voltage across a resistor_____, the current flowing through will increase.
A. π B. Ω C. θ D. λ
Ohm’s Law
Real-life applications of Ohm’s law ranges from simple appliances like conventional electric
fans, electric heaters, electric kettles and irons to the high tension wires and massive projects like
rockets.
What’s In
The aim of the lesson is to help you understand the relationships of voltage, current and
resistance. At this moment, you should be skillful enough in manipulating formulas to solve for an
unknown variable. Also, you should be aware on the different units of measurement for each variable in
Ohm’s Law.
What’s New
In order to understand Ohm’s law, we should be able to describe current, voltage and resistance
and their standard units of measurement.
The relationship between Voltage, Current and Resistance in any DC electrical circuit was firstly
discovered by the German physicist Georg Simon Ohm. Ohm found that, at a constant temperature, the
electrical current flowing through a fixed linear resistance is directly proportional to the voltage applied
across it, and also inversely proportional to the resistance.
__
V Voltage
I=
R Resistance
Current
This law is the most fundamental relation in the analysis of electrical circuit. It connects the
relationship of the quantities of voltage, electric current and resistance in one easy-to-use equation
above.
Rearrange the terms in order to solve the equation for a specific unit of measurement.
I=V/R
V=IR
R=V/I
V = IR
V I = V/R
R = V/I
I R
Sample Problem 1
You have a circuit with a source voltage of 12 V and a resistance of 15 Ω. What is the current in
the circuit?
Solution:
I = V/R
I = 12 V/15 Ω
I = 0.8 A
Sample Problem 2
I = 3A
Formula : V = IR
Solution : V= (3 A) (9 Ω)
V = 27 V
Sample Problem 3
A circuit has a 24 V voltage supply and a current of 11 A runs through it. What is the
resistance?
Given: V = 24 V Unknown: R = ?
I = 11 A
Formula : R = V/I
R = 24 V/11A
R = 2.18 Ω
What’s More
3. What is the resistance of a circuit with three 1.5V batteries and running at a
current of 5A?
4. How much current is flowing through a circuit that has 120 V and presents 5 Ω resistance?
____________________________________________________________________________
____________________________________________________________________________
____________________________________________________________________________
____________________________________________________________________________
Electric Heaters
____________________________________________________________________________
____________________________________________________________________________
Mobile or Laptop Charger
____________________________________________________________________________
____________________________________________________________________________
____________________________________________________________________________
____________________________________________________________________________
____________________________________________________________________________
Assessment
Directions: Choose the letter of the correct answer. Write your answer on the space provided before each
number.
_____1. A 10 ohms resistor is powered by a 5-V battery. The current flowing through the source is
A. 0.5 B. 10 C. 15 D. 50
_____2. What is the unit of measurement to measure the movement of charge (electron) through a wire?
A. Volt B. Ohm C. Current D. Ampere
_____3. Which of the following condition for the validity of ohm’s law?
A. Voltage should be equal to current
B. Temperature should remain constant
C. Current should be proportional to voltage
D. Current should be inversely proportional to voltage
_____4. Resistance of carbon filament lamp _________ as the applied voltage increases.
A. Increases B. Decreases C. Remains the same D. doubled
_____5. If you increase the voltage across a resistor, what will happen to the current?
A. The current will increase
B. The current will decrease
C. The current will be doubled
D. The current will stay the same
_____6. What is the unit of measurement to measure the opposition to current flow in an electrical
circuit?
A. Volt B. Ohm C. Current D. Ampere
_____7. The circuit with higher resistance will allow less charge to flow.
A. True B. False C. Sometimes D. Not enough information
_____8. Least current will flow through which of the following resistor?
A. 10 ohm resistor B. 18 ohm resistor C. 20 ohm resistor D. 25 ohm resistor
_____9. Current-voltage relationship has _________ graph.
A. hyperbola B. linear C. non –linear D. parabolic
_____10. What will be the potential difference across a 50Ω resistor if a current of 0.5A is flowing
through it?
A. 0.25 V B. 0.5 V C. 25 V D. 50 V
References
Admin. (2020, November 10). Ohm's Law - Statement, Formula, Solved Examples, Verification, FAQs.
Retrieved November 30, 2020, from https://byjus.com/physics/ohms-law/
StudiousGuy. (2019, March 25). 6 Examples Of Ohm's Law In Everyday Life. Retrieved November 30,
2020, from https://studiousguy.com/examples-of-ohms-law-in-everyday-life/
