TECHNOLOGY

AND LIVELIHOOD
EDUCATION
8
Electronic Products Assembly & Servicing
TLE (EPAS) – Grade 8
Quarter 2 – Module 14: Preparing and Interpreting Technical Drawings (PITD)
First Edition, 2020

Republic Act 8293, Section 176 states that no copyright shall subsist in any
work of the Government of the Philippines. However, prior approval of the
government agency or office wherein the work is created shall be necessary for
exploitation of such work for profit. Such agency or office may, among other things,
impose as a condition the payment of royalties.

Borrowed materials (i.e., songs, stories, poems, pictures, photos, brand

names, trademarks, etc.) included in this module are owned by their respective
copyright holders. Every effort has been exerted to locate and seek permission to use
these materials from their respective copyright owners. The publisher and authors
do not represent nor claim ownership over them.

Published by the Department of Education - Schools Division of Pasig City

Development Team of the Self-Learning Module

Writer: Catherine F. Labrador
Content Reviewer: Vicente B. Lao
Technical Reviewer:
Illustrator:
Layout Artist: Catherine F. Labrador
Management Team: Ma. Evalou Concepcion A. Agustin
OIC-Schools Division Superintendent
Aurelio G. Alfonso EdD
OIC-Assistant Schools Division Superintendent
Victor M. Javeña EdD
Chief, School Governance and Operations Division and
OIC-Chief, Curriculum Implementation Division

Education Program Supervisors

Librada L. Agon EdD (EPP/TLE/TVL/TVE)

Liza A. Alvarez (Science/STEM/SSP)
Bernard R. Balitao (AP/HUMSS)
Joselito E. Calios (English/SPFL/GAS)
Norlyn D. Conde EdD (MAPEH/SPA/SPS/HOPE/A&D/Sports)
Wilma Q. Del Rosario (LRMS/ADM)
Ma. Teresita E. Herrera EdD (Filipino/GAS/Piling Larang)
Perlita M. Ignacio PhD (EsP)
Dulce O. Santos PhD (Kindergarten/MTB-MLE)
Teresita P. Tagulao EdD (Mathematics/ABM)

Printed in the Philippines by Department of Education – Schools Division of

Pasig City
 TLE 8
Quarter 2
Module14
Preparing and Interpreting
Technical Drawings (PITD)

LO2. Electronic Components and Symbols

2.1 Recognize components, assemblies, or objects
2.2 Correctly identify the dimensions of the key features of the
objects depicted in the drawing
2.3 Interpret symbols used in the drawing
2.4 Validate the drawing against job requirements or equipment
Introductory Message

For the facilitator:

Welcome to the TLE Grade 8 Module on Electronic Products Assembly and

Servicing (EPAS)!

This Self- Learning Module was collaboratively designed, developed and

reviewed by educators from the Schools Division Office of Pasig City headed by its
Officer-In-Charge Schools Division Superintendent, Ma. Evalou Concepcion A.
Agustin in partnership with the Local Government of Pasig through its mayor,
Honorable Victor Ma. Regis N. Sotto. The writers utilized the standards set by the K
to 12 Curriculum using the Most Essential Learning Competencies (MELC) in
developing this instructional resource.

This learning material hopes to engage the learners into guided and
independent learning activities at their own pace and time. Further, this also aims
to help learners acquire the needed 21st century skills especially the 5 Cs namely:
Communication, Collaboration, Creativity, Critical Thinking and Character while
taking into consideration their needs and circumstances.

In addition to the material in the main text, you will also see this box in the
body of the module:

Notes to the Teacher

This contains helpful tips or strategies that
will help you in guiding the learners.

As a facilitator you are expected to orient the learners on how to use this
module. You also need to keep track of the learners' progress while allowing them to
manage their own learning. Moreover, you are expected to encourage and assist the
learners as they do the tasks included in the module.
 For the learner:

Welcome to the TLE Grade 8 Module on Electronic Products Assembly &

Servicing (EPAS)!

This module was designed to provide you with fun and meaningful
opportunities for guided and independent learning at your own pace and time. You
will be enabled to process the contents of the learning material while being an active
learner.

This module has the following parts and corresponding icons:

Expectation - These are what you will be able to know after

completing the lessons in the module

Pre-test - This will measure your prior knowledge and the

concepts to be mastered throughout the lesson.

Recap - This section will measure what learnings and skills

that you understand from the previous lesson.

Lesson- This section will discuss the topic for this module.

Activities - This is a set of activities you will perform.

Wrap Up- This section summarizes the concepts and

applications of the lessons.
Valuing-this part will check the integration of values in the
learning competency.

Post-test - This will measure how much you have learned from
the entire module.
 EXPECTATIONS

In this lesson, the students shall be able to perform the following:

1. Identify the schematic symbols of commonly used electronic components.
2. Recognize and label the symbols in a schematic diagram.
3. Understand how the symbols are connected in a circuit.
4. Interpret a schematic diagram.

PRETEST

Direction: Name each schematic symbol on the space provided in each item.

1. 6.

2. 7.

3. 8.

4. 9.

5. 10.

RECAP

Direction: Read each item carefully. Write “TRUE” if the statement is correct. Write
the term to be replaced on the underlined word if the statement is incorrect.

________________1. Various types of electrical diagrams are used to represent a

certain circuit.

________________2. Technical drawings helps in understanding connections between

components.
________________3. Block diagram is used to show the actual image of the
components.
________________4. Block diagram uses boxes and arrows to show the flow of the
circuit.
________________5. The boxes in a block diagram are important point of interest in
the system from input to storage.

LESSON

SCHEMATIC SYMBOLS

To understand the functionality of a circuit, a technician should be

knowledgeable of reading schematic diagrams. As with out previous lesson, a
schematic diagram is a detailed illustration of how each electronic component is
connected in a circuit. It can be used for troubleshooting any device.

Thus, the knowledge of each symbols assigned to an electronic component is

a very important skill in troubleshooting. A technician may refer to a diagram on
how the components should be attached looking on its terminal connections. The
following are some of the few electronic components used in common circuits:

or or

Resistor Variable Resistor Battery

Transformer

Standard Capacitor Polarized Capacitor Ground

Inductor Polarized Inductor Switch

Standard Diode Light Emitting Diode Zener Diode IC

Memorizing the schematic symbols is necessary to fully understand a

diagram. Awareness of the polarities (positive and negative terminals) of electronic
components when draw as symbols helps in connecting appropriate terminals.
Damage on the device might happen if components are improperly connected
because polarities are not observed. Look at the diagram below:

Circuits Tune, “12v Regulated Power Supply Diagram,” Accessed August 17, 2020. http://www.circuitstune.com/2011/12/12v-power-supply-circuit-diagram.html

This is a schematic diagram of a 12V regulated power supply unit. Let us try
to identify the components starting from the left part of the diagram.

A. Transformer - a symbol of two inductors facing each other separated by two or

three lines. The coil on the left side is considered as the primary coil and on the
right is secondary conductor. Primary coil receives voltage from an outlet. In
between the coils the voltage is being lowered down. Then, the secondary coil
forwards the voltage to the next component. The positive terminal on top and the
ground at the bottom.

Primary Coil (230V) Secondary Coil (12V)

B. Diodes - when 4 diodes are used it is considered as “Bridge Rectifier.” It has a

very strict positioning of its polarities. Notice that they are arranged in pair. Two
diodes with their negative terminals are on the positive line of the circuit and the
other pair with their positive terminals on the ground. The bridge rectifiers
converts the 12 ACV from the transformer into 12DCV passing it to the next
component.
C. Capacitor - a polarized capacitor is on the diagram where the positive terminal
goes to the transistor and it’s negative terminal on the ground.

D. Transistor - it sometimes drawn in this manner where the base is the labeled as
common which is connected to the ground. In as the emitter, and out is the
connector.

E. Capacitor - a polarized capacitor again. Positive terminal above and negative

terminal below.

ACTIVITIES

Part I: Label the schematic diagram of a blinker by writing the letters assigned for
each symbol. If component is repeated, place a number after the letter (Ex. C1, C2,
C3 - symbols drawn from left to right)

Battery LED Resistor Capacitor Transistor

9V L1 - L2 R1 - R4 C1 - C2 Q1 - Q2

Part II: Practice labeling the parts again here in this speech amplifier circuit.
 WRAP-UP

Knowledge of schematic symbols is a great help for every technician.

1. What are schematic symbols?
2. What is the purpose of understanding a schematic diagram?

3. What is polarity? Why is it necessary to be observed in a diagram?

VALUING

Now that you know the symbols of commonly used basic electronic components,
answer the following questions:
1. Why is it necessary to know the symbols of each electronic component?
____________________________________________________________________________________

2. How will it help a technician in repairing devices?

____________________________________________________________________________________

3. Will a student like you be able to create a circuit following a schematic

diagram? Why do you think so?
____________________________________________________________________________________

POSTTEST

Directions: Choose the letter of the best correct answer. Write it on your notebook.
1. Which of the following components has NO polarity?
A. capacitor C. LED
B. diode D. resistor

2. What is the component that has primary and secondary coil?

A. capacitor C. transformer
B. resistor D. transistor

3. Which of the following components receives voltage from an outlet?

A. capacitor C. transformer
B. resistor D. transistor
4. What does 4 diodes become when put in a circuit with each other?
A. bridge recitifier diode C. regular diode
B. light emitting diode D. zener diode

5. What is the polarity of the arrow in a diode?

A. negative
B. positive

6. What is the polarity of the curve line in a capacitor?

A. negative
B. positive

7. Which of the following components has an input, output, and common

terminal?
A. capacitor C. transformer
B. resistor D. transistor

8. How many terminals a transistor has?

A. 2 C. 4
B. 3 D. 5

9. How many terminals a capacitor has?

A. 2 C. 4
B. 3 D. 5

10. What is the letter used in labeling transistors?

A. L C. R
B. Q D. T

KEY TO CORRECTION

10 B 5B 5 Output 10 switch 5 resistor

9A 4A 4 TRUE 9 NPN transistor 4 PNP transistor

8B 3C 3 Pictorial Diagram 8 polarized capacitor 3 LED

7D 2C 2 TRUE 7 inductor 2 capacitor

6A 1D 1 TRUE 6 variable resistor 1 battery

POSTTEST RECAP PRETEST

 ACTIVITIES - Part II

ACTIVITIES - Part I

References

Build Electronic Circuits, “Electronic Schematic Symbols,” Accessed August 17, 2020.8.17
https://www.build-electronic-circuits.com/schematic-symbols/

Circuits Tune, “12v Regulated Power Supply Diagram,” Accessed August 17, 2020.
http://www.circuitstune.com/2011/12/12v-power-supply-circuit-diagram.html

IndiaMART, “Single Phase Step Down Transformer,” Accessed August 17, 2020.
https://www.indiamart.com/proddetail/step-down-transformer-19977931173.html

Seymour, Arthur. Basic Electronic Components 1994. Elenco® Electronics, Inc. © 2016
