BUS DUCT INSTALLATION CHECKLIST

Project: Job Number:


Tag No.: Client:
Description: Data Sheet:
Sub System: Location:
Sub System Drawing:
Description: Date:
Manufacturer: Model No:
PO Number: Serial or Mark No:
No. Items to be Checked Attribute Status
Required
1 Check equipment and nameplate details with datasheet.
2 Verify protection of live parts is correct.
3 Check for mechanical damage.
Confirm equipment is mounted/anchored according to
4
drawings and Manufacturer’s instructions.
5 Confirm bus duct is properly supported.
Confirm bus bars and connecting links are tightened to
6
specified torque.( IS-1367-20/1996)
7 Verify phase identification is correct.
Verify unit is internally and externally clean, and covers are
8
securely fastened with all screws in place.
Confirm equipment is grounded according to drawings and
9
Manufacturer’s instructions.
Check insulation resistance between ground and phases.
Test Voltage: 2500VDC (690V). 1000VDC (415V)
MΩ Temp. °
a L1 – Earth MΩ
10 b L2 – Earth MΩ
c L3 – Earth MΩ
d L1 – L2 MΩ
e L1 – L3 MΩ
f L2 – L3 MΩ

Page 1 of 3
BUS DUCT INSTALLATION CHECKLIST

Project: Job Number:


Tag No.: Client:
Description: Data Sheet:
Sub System: Location:
Sub System Drawing:
Description: Date:
Manufacturer: Model No:
PO Number: Serial or Mark No:
No. Items to be Checked Attribute Status
Required
11 Perform Ductor test across all bolted connections.
12 Verify low point drains/traps are installed.
13 Verify heaters are correctly installed.

15 Verify all testing complete and documented

Make (Test Equipment) Model Serial No. Calibration Expiration Date

16

Remarks:

Description BVIL VL CONTRACTOR


Signature
Print Name
Date

Page 2 of 3
BUS DUCT INSTALLATION CHECKLIST

Page 3 of 3
