Slickline Tool String

Configuration
 Slickline
Tool String
Rope Socket
Components

Weight Bar

Jars

Knuckle
Joint
 What Size of Toolstring?

1-1/4” Toolstring Fishing Neck = 1-3/16”

1-1/2”Pulling Tool OD = 1.430

Tubing
ID

1-1/2” Toolstring Fishing Neck = 1-3/8”

2”Pulling Tool OD = 1.770

1-7/8” Toolstring Fishing Neck = 1-3/4”

2-1/2”Pulling Tool OD = 2.180
 Other Considerations

Nipple Sizes
No-Go Nipples
Cutter Bars
Go-Devils

• Make sure you can pass through

the tubing and landing nipples and
still be retrieve
• Size your tools so that Cutters or
Go-Devils can not go along side.
 Stem/Weight Bar

How Much is
Needed?

D2 x .7854 = Area
Wire Size Area
.092 .0066
.108 .0092
.125 .0123
3/16 .0276

Forc
e
Area x Pressure =
FORCE

D2 x 8 ÷ 3 = Wt/Ft
Stem Size Wt/Ft (lbs.)
1-1/4 4.17
1-1/2 6
1-7/8 9.375
2-1/8 12
Wire Weight/1000 Ft.
.092 = 22.5 lbs 2-3/8 15
.108 = 31.0 lbs
.125 = 41.5 lbs
3/16 = 93.8 lbs
 Jars and Stem
Jars should be the
same OD as the Stem.
Tools attached to the lower
end of the Jars must always
be larger than the Stem and
the Jars
Purpose of Knuckle Joint

Flexibility

Centralizing
the Tool
below the
Jars
Tubular Jars

When there is wire or

debris present that could
foul a set of spang jars.
Hydraulic Jars

Used to create
high impact
upward jar
action.
Installed in the
toolstring
between the
Stem and
Mechanical Jars
 Accelerator

Used with Hydraulic or Spring

Jars to increase the jarring
effect by imitating line stretch.
Used mainly near the surface
where there is minimum line
stretch, but can be used
effectively downhole to increase
jarring impact at the tools.
Installed in the toolstring
between the Rope Socket and
the Stem.
Spring Jars

Used for the same purposes as

Hydraulic Jars.

Spring Jars won’t gas-up.

Some designs might be longer

than Hydraulic Jars
