Experiment (5): Flow Through A Venturi Meter:

Objective: Determination Of The Pressure Distribution Along The Meter & Comparing It With
Ideal Pressure Distribution.

Equipment: Venturi Meter, Power Supply,


Piezometer Tubes, Hydraulic Bench & Stop
Watch.

Theory: Bernoulli’s Equation & Continuity


Equation.

From applying Bernoulli’s Equation &


Continuity Equation we get:

hn−h1 a2 2 a2 2
=( ) −( )
U 22 a1 an
2g

Readings:
Piezometer dn (mm) d2/dn (a2/an)2 (a2/a1)2 - (a2/an)2
Tube
A (Inlet) 26.00 0.615 0.144 0.000
B 23.20 0.690 0.226 -0.082
C 18.40 0.869 0.575 -0.431
D (Throat) 16.00 1.000 1.000 -0.856
E 16.80 0.953 0.830 -0.686
F 18.47 0.867 0.565 -0.421
G 20.16 0.787 0.400 -0.256
H 21.84 0.730 0.289 -0.145
J 23.53 0.680 0.215 -0.071
K 25.24 0.633 0.168 -0.024
L (Outlet) 26.00 0.615 0.144 0.000
Sample Of Calculation:
V = 15 litre Time = 43.7 seconds.

Q= V/T= 15x10-3/43.7= 3.43x10-4 m3/s.

U2= Q/A= 3.43x10-4 / (π/4)x(26x10-3)2 = 1.7 m/s.

U22/2g = 1.72/2x9.8 = 0.149

Piezometer dn (mm) hn (mm) hn-h1 (mm) ((hn-h1)x10-


3
Tube )/0.149
A (Inlet) 26.00 167 0 0
B 23.20 153 -14 -0.094
C 18.40 99 -68 -0.456
D (Throat) 16.00 19 -148 -0.993
E 16.80 83 -84 -0.563
F 18.47 106 -61 -0.409
G 20.16 120 -47 -0.315
H 21.84 128 -39 -0.262
J 23.53 136 -31 -0.208
K 25.24 141 -26 -0.174
L (Outlet) 26.00 158 -9 -0.06

Curves:

0
0 2 4 6 8 10 12

-0.2

-0.4

Experimental
-0.6
Theoritical

-0.8

-1

-1.2

Piezometer % error
1 0
2 14.6
3 5.8
4 16
5 -17
6 -2.8
7 23
8 80.7
9 192.9
10 625
11 100

Comments:
The error is very acceptable & might be because:

1) Impurity of water.
2) Natural human error.
3) The imperfection of the instrument used.
